7-12
INSPECTION AND MAINTENANCE
75RM4-01E
#3: Tires/Wheels (including tire rotation) for Mexico models :Inspect every 7500 km (4500 miles) or 6 months.
#4: Wheel bearings for Mexico models :Inspect every 7500 km (4500 miles) or 6 months.
#5: Drive axle boots for Mexico models :Inspect every 7500 km (45 00 miles) or 6 months.
#6: Suspension system for Mexico models :Inspect every 7500 km (4 500 miles) or 6 months.
#7: Steering system for Mexico m odels :Inspect every 7500 km (450 0 miles) or 6 months.
NOTE:
This table shows the service schedule up to 90000 km (54000 miles).
Beyond 90000 km (54000 miles), perform the same serv ices at the same intervals shown in the chart.
*1 Inspect more frequently if the v ehicle is used under dusty conditions.
*2 Check or replace as necessary if you usually drive with high speed or high engine revolutions.
*3 Clean more frequently if the air flow from the air conditioner decreases.Interval: This interval should be judged by odometer reading or months, whichever
comes first. km (x1000) 52.5 60 67.5 75 82.5 90
miles (x1000) 31.5 36 40.5 45 49.5 54 months 42 48 54 60 66 72BRAKE*5-1. Brake discs and pads (front) –I–I–I
Brake drums and shoes (rear)
–
I
–
–
–
I
*5-2. Brake hoses and pipes –I–––I
5-3.
Brake fluid
Check, *Replacement
–
R
–
–
–
R
5-4. Brake lever and cable
Check, *Adjustment (1st 15000 km only)
––––––
CHASSIS AND BODY *6-1. Clutch (Cable control type) –I–I–I6-2.
Tires/Wheels (#3)
–
I
–
I
–
I
*6-3. Wheel bearings (#4) –I–I–I
*6-4.
Drive axle boots (#5)
–
I
–
I
–
I
*6-5. Suspension system (#6) –I–––I
*6-6.
Steering system (#7)
–
I
–
–
–
I
*6-7.
Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W”
Inspect every 30000 km (18000 miles) or 24 months.Replace every 60000 km (36000 miles) or 48 months.
Other than “SUZUKI GEAR OIL 75W”
–R– – –R
6-8.
Continuously variable transaxle (CVT)
Fluid level
–
I
–
–
–
I
*Fluid deterioration check*
2
–I–––I
*Fluid change
Replace every 75000 km (45000 miles).
6-9. All latches, hinges and locks –I–––I
*6-10.
Air conditioner filter element (if equipped)*
3
–
I
–
I
–
R

7-13INSPECTION AND MAINTENANCE
75RM4-01E
Periodic maintenance schedule (for EU countries and Israel)“R” : Replace or Change
“I” : Inspect, clean, adjust, lub ricate or replace as necessary
NOTE:
This table shows the service schedule up to 240000 km (150000 miles). Beyond 240000 km (150000 miles), perform the same service s
at the same intervals shown in the chart.

7-14
INSPECTION AND MAINTENANCE
75RM4-01E
#1: For further details, see “Engine oil and filter” in this section.
#2: Perform the engine coolant l evel check under the daily inspection in the “OPERATING YOUR VEHICLE” section.
If you use the engine coolant other than “SUZUKI LLC: Super (Bl ue)” for replacement, follow the schedule of “SUZUKI LLC: Standard (Green)”.
Interval: This interval should be judged by
odometer reading or months, whichever comes
first. km (x1000) 20 40 60 80 100 120
miles (x1000) 12.5 25 37.5 50 62.5 75 months 12 24 36 48 60 72ENGINE*1-1. Engine accessory drive belt (with SHVS) Tension check, *Adjustment, *Replacement – I – R – I
(without SHVS) Tension check, *Adjustment, *Replacement
–
I
–
I
–
R
1-2. Engine oil and engine oil filter ACEA Standards or SUZUKI G ENUINE OIL (#1) RRRRRR
Refer to “Oil change request light” in the “BEFORE DRIVING” section.
Other than ACEA Standards or SUZUKI GENUINE OIL (#1) Replace eve ry 15000 km (9375 miles) or 12 months.
Refer to “Oil change request light” in the “BEFORE DRIVING” section.
1-3. Engine coolant SUZUKI LLC: Super (Blue) (#2) First time only : Replace at 160000 km (100000 miles) or 96 months.

Second time and after:
Replace every 80000 km (50000 miles) or 48 months.
SUZUKI LLC: Standard (Green) Replace every 40000 km (25000 mile s) or 36 months.
*1-4.
Exhaust system (except catalyst)
–
I
–
I
–
I
IGNITION
2-1.
Spark plugs When unleaded fuel is used
Iridium plug
Replace every 100000 km (62500 miles) or 84 months.
Spark plugs When leaded fuel is used, refer to “Severe driving condition” schedule.
FUEL
3-1. Air cleaner filter element Paved-road Inspect every 20000 k m (12500 miles) or 12 months.
Replace every 40000 km (25000 miles) or 36 months.
Dusty condition Refer to “Severe driving condition” schedule.
*3-2.
Fuel lines
–
I
–
I
–
I
*3-3. Fuel tank –I–I–I

7-15INSPECTION AND MAINTENANCE
75RM4-01E
#1: For further details, see “Engine oil and filter” in this section.
#2: Perform the engine coolant l evel check under the daily inspection in the “OPERATING YOUR VEHICLE” section.
If you use the engine coolant other than “SUZUKI LLC: Super (Bl ue)” for replacement, follow the schedule of “SUZUKI LLC: Standard (Green)”.
Interval: This interval should be judged by
odometer reading or months, whichever comes
first. km (x1000) 140 160 180 200 220 240
miles (x1000) 87.5 100 112.5 125 137.5 150 months 84 96 108 120 132 144ENGINE*1-1. Engine accessory drive belt (with SHVS) Tension check, *Adjustment, *Replacement – R – I – R
(without SHVS) Tension check, *Adjustment, *Replacement
–
I
–
I
–
R
1-2. Engine oil and engine oil filter ACEA Standards or SUZUKI G ENUINE OIL (#1) RRRRRR
Refer to “Oil change request light” in the “BEFORE DRIVING” section.
Other than ACEA Standards or SUZUKI GENUINE OIL (#1) Replace eve ry 15000 km (9375 miles) or 12 months.
Refer to “Oil change request light” in the “BEFORE DRIVING” section.
1-3. Engine coolant SUZUKI LLC: Super (Blue) (#2) First time only : Replace at 160000 km (100000 miles) or 96 months.

Second time and after:
Replace every 80000 km (50000 miles) or 48 months.
SUZUKI LLC: Standard (Green) Replace every 40000 km (25000 mile s) or 36 months.
*1-4.
Exhaust system (except catalyst)
–
I
–
I
–
I
IGNITION
2-1.
Spark plugs When unleaded fuel is used
Iridium plug
Replace every 100000 km (62500 miles) or 84 months.
Spark plugs When leaded fuel is used, refer to “Severe driving condition” schedule.
FUEL
3-1. Air cleaner filter element Paved-road Inspect every 20000 k m (12500 miles) or 12 months.
Replace every 40000 km (25000 miles) or 36 months.
Dusty condition Refer to “Severe driving condition” schedule.
*3-2.
Fuel lines
–
I
–
I
–
I
*3-3. Fuel tank –I–I–I

7-16
INSPECTION AND MAINTENANCE
75RM4-01E
Interval: This interval should be judged byodometer reading or months, whichever
comes first. km (x1000) 20 40 60 80 100 120
miles (x1000) 12.5 25 37.5 50 62.5 75 months 12 24 36 48 60 72EMISSION CONTROL SYSTEM*4-1. PCV valve ––– I ––*4-2.
Fuel evaporative emission control system
–
–
–
–
–
I
BRAKE
*5-1.
Brake discs and pads (front)
I
I
I
I
I
I
Brake drums and shoes (rear) –I–I–I
*5-2.
Brake hoses and pipes
–
I
–
I
–
I
5-3. Brake fluid Check, *Replacement – R – R – R
5-4.
Brake lever and cable
Check, *Adjustment (1st 20000 km only)
I
–
–
–
–
–
CHASSIS AND BODY
*6-1.
Clutch (Cable control type)
I
I
I
I
I
I
6-2. Tires/Wheels IIIIII
*6-3.
Wheel bearings
–
I
–
I
–
I
*6-4. Drive axle boots/Propeller shafts (4WD) –I–I–I
*6-5.
Suspension system
–
I
–
I
–
I
*6-6. Steering system –I–I–I
*6-7.
Manual transaxle oil
Genuine “SUZUKI GEAR OIL 75W”
Inspect every 40000 km (25000 miles) or 24 months.
Other than “SUZUKI GEAR OIL 75W”
–R–R–R
*6-8.
Auto Gear Shift oil
Genuine “SUZUKI GEAR OIL 75W”
Inspect every 40000 km (25000 miles) or 24 months.
Other than “SUZUKI GEAR OIL 75W”
–R–R–R
6-9.
Continuously variable transaxle (CVT)
Fluid level
–
I
–
I
–
I
*6-10. Transfer oil (4WD) Inspect every 40000 km (25000 miles) or 24 months.
Replace every 160000 km (100000 miles) or 96 months.
*6-11. Rear differential oil (4WD) Inspect every 40000 km (25000 miles) or 24 months.
Replace every 160000 km (100000 miles) or 96 months.
6-12. All latches, hinges and locks –I–I–I*6-13.
Air conditioner filter element (if equipped)
–
I
R
–
I
R
WA R N I N G
The shock absorbers are filled with high pressure gas. Never attempt to disassemble them or throw them into a fire. Avoid
storing them near a heater or heating device. When scrapping th e absorber, the gas must be released from the absorber
safely. Ask your deal er for assistance.

7-17INSPECTION AND MAINTENANCE
75RM4-01E
NOTE:
4WD: 4-wheel driveInterval: This interval should be judged byodometer reading or months, whichever
comes first. km (x1000) 140 160 180 200 220 240
miles (x1000) 87.5 100 112.5 125 137.5 150 months 84 96 108 120 132 144EMISSION CONTROL SYSTEM*4-1. PCV valve –I–––I*4-2.
Fuel evaporative emission control system
–
–
–
–
–
I
BRAKE
*5-1.
Brake discs and pads (front)
I
I
I
I
I
I
Brake drums and shoes (rear) –I–I–I
*5-2.
Brake hoses and pipes
–
I
–
I
–
I
5-3. Brake fluid Check, *Replacement – R – R – R
5-4.
Brake lever and cable
Check, *Adjustment (1st 20000 km only)
–
–
–
–
–
–
CHASSIS AND BODY
*6-1.
Clutch (Cable control type)
I
I
I
I
I
I
6-2. Tires/Wheels IIIIII
*6-3.
Wheel bearings
–
I
–
I
–
I
*6-4. Drive axle boots/Propeller shafts (4WD) –I–I–I
*6-5.
Suspension system
–
I
–
I
–
I
*6-6. Steering system –I–I–I
*6-7.
Manual transaxle oil
Genuine “SUZUKI GEAR OIL 75W”
Inspect every 40000 km (25000 miles) or 24 months.
Other than “SUZUKI GEAR OIL 75W”
–R–R–R
*6-8.
Auto Gear Shift oil
Genuine “SUZUKI GEAR OIL 75W”
Inspect every 40000 km (25000 miles) or 24 months.
Other than “SUZUKI GEAR OIL 75W”
–R–R–R
6-9.
Continuously variable transaxle (CVT)
Fluid level
–
I
–
I
–
I
*6-10. Transfer oil (4WD) Inspect every 40000 km (25000 miles) or 24 months.
Replace every 160000 km (100000 miles) or 96 months.
*6-11. Rear differential oil (4WD) Inspect every 40000 km (25000 miles) or 24 months.
Replace every 160000 km (100000 miles) or 96 months.
6-12. All latches, hinges and locks –I–I–I*6-13.
Air conditioner filter element (if equipped)
–
I
R
–
I
R

7-18
INSPECTION AND MAINTENANCE
75RM4-01E
Maintenance recommended under severe driving conditions (for EU countries and Israel)Follow this schedule if your vehicle is mainly operated under o ne or more of the following conditions:
• When most trips are le ss than 6 km (4 miles).
• When most trips are less than 16 km (10 miles) and outside temperature remains below freezing.
• Idling and/or low-speed operat ion in stop-and-go traffic.
• Operating in extremely cold we ather and/or on salted roads.
• Operating in rough and/or muddy areas.
• Operating in dusty areas.
• Repeated high speed drive or high engine revolutions.
• Towing a trailer, if admitted.
Schedule should also be followed if the vehicle is used for del ivery service, police, taxi or other commercial applications.

7-19INSPECTION AND MAINTENANCE
75RM4-01E
#1: For further details, see “Engine oil and filter” in this section.
#2: Perform the engine coolant l evel check under the daily inspection in the “OPERATING YOUR VEHICLE” section.
If you use the engine coolant other than “SUZUKI LLC: Super (Bl ue)” for replacement, follow the schedule of “SUZUKI LLC: Standard (Green)”.
Interval: This interval should be judged by
odometer reading or months, whichever comes
first. km (x1000) 10 20 30 40 50 60
miles (x1000) 6.25 12.5 18.75 25 31.25 37.5 months6 1218243036ENGINE*1-1. Engine accessory drive belt Tension check, *Adjustment, *Re placement – I – I – R 1-2.
Engine oil and engine oil filter
ACEA Standards or SUZUKI GENUINE OIL (#1)
R
R
R
R
R
R
Refer to “Oil change request light” in the “BEFORE DRIVING” section.
Other than ACEA Standards or SUZUKI GENUINE OIL (#1)
Replace every 7500 km (4687 miles) or 6 months.Refer to “Oil change request light” in the “BEFORE DRIVING” section.
1-3.
Engine coolant
SUZUKI LLC:
Super (Blue) (#2)
First time only:
Replace at 160000 km (100000 miles) or 96 months.
Second time and after: Replace every 80000 km (50000 miles) or 48 months.
SUZUKI LLC:
Standard (Green)
Replace every 40000 km (25000 miles) or 36 months.
*1-4. Exhaust system (except catalyst) ––– I ––
IGNITION
2-1. Spark plugs Iridium plug Replace every 30000 km (18750 miles) or 24 months.FUEL
3-1. Air cleaner filter element*
1
Inspect every 2500 km (1562 miles).Replace every 30000 km (18750 miles) or 24 months.
*3-2. Fuel lines ––– I ––
*3-3.
Fuel tank
–
–
–
I
–
–
EMISSION CONTROL SYSTEM
*4-1.
PCV valve
Inspect every 80000 km (5 0000 miles) or 48 months.
*4-2.
Fuel evaporative emi ssion control system
––––––

7-20
INSPECTION AND MAINTENANCE
75RM4-01E
#1: For further details, see “Engine oil and filter” in this section.
#2: Perform the engine coolant l evel check under the daily inspection in the “OPERATING YOUR VEHICLE” section.
If you use the engine coolant other than “SUZUKI LLC: Super (Bl ue)” for replacement, follow the schedule of “SUZUKI LLC: Standard (Green)”.
Interval: This interval should be judged by
odometer reading or months, whichever comes
first. km (x1000) 70 80 90 100 110 120
miles (x1000) 43.75 50 56.25 62.5 68.75 75 months 42 48 54 60 66 72ENGINE*1-1. Engine accessory drive belt Tension check, *Adjustment, *Re placement – I – I – R 1-2.
Engine oil and engine oil filter
ACEA Standards or SUZUKI GENUINE OIL (#1)
R
R
R
R
R
R
Refer to “Oil change request light” in the “BEFORE DRIVING” section.
Other than ACEA Standards or SUZUKI GENUINE OIL (#1)
Replace every 7500 km (4687 miles) or 6 months.Refer to “Oil change request light” in the “BEFORE DRIVING” section.
1-3.
Engine coolant
SUZUKI LLC:
Super (Blue) (#2)
First time only:
Replace at 160000 km (100000 miles) or 96 months.
Second time and after: Replace every 80000 km (50000 miles) or 48 months.
SUZUKI LLC:
Standard (Green)
Replace every 40000 km (25000 miles) or 36 months.
*1-4. Exhaust system (except catalyst) – I ––– I
IGNITION
2-1. Spark plugs Iridium plug Replace every 30000 km (18750 miles) or 24 months.FUEL
3-1. Air cleaner filter element*
1
Inspect every 2500 km (1562 miles).Replace every 30000 km (18750 miles) or 24 months.
*3-2. Fuel lines – I ––– I
*3-3.
Fuel tank
–
I
–
–
–
I
EMISSION CONTROL SYSTEM
*4-1.
PCV valve
Inspect every 80000 km (5 0000 miles) or 48 months.
*4-2.
Fuel evaporative emi ssion control system
––––– I

7-21INSPECTION AND MAINTENANCE
75RM4-01E
Interval: This interval should be judged byodometer reading or months, whichever
comes first. km (x1000) 10 20 30 40 50 60
miles (x1000) 6.25 12.5 18.75 25 31.25 37.5 months6 1218243036BRAKE*5-1. Brake discs and pads (front) –I–I–I
Brake drums and shoes (rear)
–
–
–
I
–
–
*5-2. Brake hoses and pipes ––– I ––
5-3.
Brake fluid
Check, *Replacement
–
–
–
R
–
–
5-4. Brake lever and cable
Check, *Adjustment (1st 20000 km only)
– I ––––
CHASSIS AND BODY *6-1. Clutch (Cable control type) –I–I–I6-2.
Tires/Wheels
–
I
–
I
–
I
*6-3. Wheel bearings –I–I–I
*6-4.
Drive axle boots/Propeller shafts (4WD)
–
–
–
I
–
–
*6-5. Suspension system ––– I ––
*6-6.
Steering system
–
–
–
I
–
–
*6-7.
Manual transaxle oil Genuine “SUZUKI GEAR OIL 75W”
Inspect every 20000 km (12500 miles) or 12 months.Replace every 80000 km (50000 miles) or 48 months.
Other than “SUZUKI GEAR OIL 75W”
–R–R–R
*6-8.
Auto Gear Shift oil
Genuine “SUZUKI GEAR OIL 75W”
Inspect every 20000 km (12500 miles) or 12 months.Replace every 80000 km (50000 miles) or 48 months.
Other than “SUZUKI GEAR OIL 75W”
–
R
–
R
–
R
6-9. Continuously variable transaxle (CVT) Fluid level – I – I – I
*Fluid deterioration check*
2
–
I
–
I
–
I
*Fluid change Replace every 70000 km (43750 miles).
*6-10.
Transfer oil (4WD)
Inspect every 20000 km (12500 miles) or 12 months.
Replace every 80000 km (50000 miles) or 48 months.
*6-11.
Rear differential oil (4WD)
Inspect every 20000 km (12500 miles) or 12 months.
Replace every 80000 km (50000 miles) or 48 months.
6-12.
All latches, hinges and locks
–
–
–
I
–
–
*6-13. Air conditioner filter element (if equipped)*
3
–I–I–R
WA R N I N G
The shock absorbers are filled with high pressure gas. Never at tempt to disassemble them or throw them into a fire. Avoid
storing them near a heater or heating device. When scrapping th e absorber, the gas must be released from the absorber
safely. Ask your deal er for assistance.
