BEFORE DRIVING
Keys ...................................................................................................................................... 4-1
Door Locks.......................................................................................................................... 4-2
Keyless Entry System Transmitter (if equipped)......................................................... 4-4
Mirrors................................................................................................................................ 4-13
Heated Rear Window Switch (if equipped).................................................................4-14
Front Seats........................................................................................................................ 4-14
Rear Seats......................................................................................................................... 4-16
Seat Belts and Child Restraint Systems.....................................................................4-18
Supplemental Restraint System (air bags) (if equipped).........................................4-24
Instrument Cluster (For Petrol & Diesel)....................................................................4-28
Warning and Indicator Lights........................................................................................4-29
Speedometer/Odometer/Trip meter/Meter Illumination Control................................4-34
Tachometer (if equipped)................................................................................................4-35
Fuel Gauge........................................................................................................................ 4-35
Lighting Control Lever....................................................................................................4-38
Front Fog Light Switch (if equipped)..........................................................................4-39
Rear Fog Light Switch (if equipped)............................................................................4-39
Headlight Leveling Switch.............................................................................................. 4-39
Turn Signal Control Lever.............................................................................................. 4-40
Hazard Warning Switch...................................................................................................4-40
Windshield Wiper and Washer Lever...........................................................................4-40
Rear Window Wiper/Washer Switch (if equipped).....................................................4-41
Tilt Steering Lock Lever (if equipped) ......................................................................... 4-42
Horn ..................................................................................................................................... 4-42
BEFORE DRIVING

Downloaded from www.Manualslib.com manuals search engine 1483K
Door LocksSide Door Locks
To lock a door from inside the vehicle, turn
the lock knob forward. Turn the lock knob
backward to unlock the door.
NOTE:
Be sure to hold the door handle up when
you close a locked front door, as the door
will not remain locked.
EXAMPLE BEFORE DRIVING
4-2
83K-02-003
To lock a front door from outside the vehi-
cle:
Insert the key and turn the top of the
key anti clockwise or
Turn the lock knob forward and hold the
door handle as you close the door.
To unlock a front door from outside the
vehicle, insert the key and turn the top of
the key clockwise.
To lock a door from outside the vehicle, turn
the lock knob forward and close the door.
83K-02-004
Central Door Locking SystemDriver’s door (if equipped)
You can lock and unlock all doors (includ-
ing the tailgate) simultaneously by using the
key in the driver’s door lock.
To lock all doors simultaneously, insert the
key in the driver’s door lock and turn the
top of the key anti-clockwiseTo unlock all doors simultaneously, insert
the key in a driver’s door lock and turn the
top of the key toward the front of the vehi-
cle twice.
To unlock the driver’s door only, insert the
key in that door lock and turn the top of
the key toward the front of the vehicle once.
You can also lock or unlock (4 or 5) all
doors by depressing the front or rear of the
switch (1), respectively.
NOTE:
If your vehicle is equipped with keyless
entry system, you can also lock or unlock
all doors by operating the transmitter. Refer
to “Keyless Entry System Transmitter”.
83K-02-006
EXAMPLE

Downloaded from www.Manualslib.com manuals search engine 1683K
You can lock and unlock the tailgate by
using the key in the driver’s door lock.
To open the tailgate, pull up and hold the
tailgate unlatch handle (1) and lift the tailgate.
w ww w
w WARNING
Always make sure that the tailgate is
closed and latched securely. Com-
pletely closing the tailgate helps pre-
vent occupants from being thrown
from the vehicle in the event of an
accident. Completely closing it also
helps keep away exhaust gases from
entering the car.BEFORE DRIVING
4-4
83K-02-011
2) Push open the tailgate from inside by
pushing up on the emergency lever (2)
using a flat blade screw driver or the
jack handle. The tailgate will be latched
again by closing the tailgate simply.
If the tailgate can not be unlatched by pull-
ing up the tailgate unlatch switch (1), have
the vehicle inspected by your MARUTI
SUZUKI authorized dealer. If you can not unlatch the tailgate by pulling
up the unlatch handle (1) due to a malfunc-
tion, follow the procedures below to unlatch
the tailgate from inside the vehicle.
1) Fold the rear seat forward for easier
access. Refer to “Folding Rear Seats”
section for details on how to fold the
rear seat forward.
w ww w
w WARNING
To avoid injury, do not use your fin-
ger to push the emergency lever.
Make sure there is no one near the
tailgate when pushing open the tail-
gate from inside the vehicle.
Keyless Entry System Trans-
mitter (if equipped)
83K-02-012
(1) “LOCK” button
(2) “UNLOCK” button
There are two ways to lock or unlock all
doors (including the tailgate) simultaneously
by operating the transmitter near the vehicle.
Central door locking system
To lock all doors, push the “LOCK” but-
ton (1) once.
To unlock all other doors, push the
“UNLOCK” button (2) once.
The turn signal lights will flash once when
the doors are locked.
When the doors are unlocked:
The turn signal lights will flash twice.
If the interior light switch is in the middle
position, the interior light will turn on for
about 15 seconds and then fade out. If
you insert the key into the ignition switch
during this time, the light will start to
fade out immediately.

Downloaded from www.Manualslib.com manuals search engine 1783K
BEFORE DRIVING
4-5
Be sure the doors are locked after you
operate the “LOCK” button. If no door is
opened within about 30 seconds after the
“UNLOCK” button is operated, the doors will
automatically lock again.NOTE:
The maximum operating distance of the
keyless entry system transmitter is about
5 m (16 ft.), but this can vary depending
on the surroundings, especially near
other transmitting devices such as radio
towers or CB (citizen’s band).
The door locks can not be operated with
the transmitter if the ignition switch is in
a position other than “LOCK”, or the igni-
tion key is inserted in the ignition switch.
When any door is open, the door locks
can be operated only unlock with the
transmitter, and the turn signal light will
not flash.
If you lose one of the transmitters, con-
tact your MARUTI SUZUKI authorized
dealer as soon as possible for a replace-
ment. Be sure to have your dealer pro-
gram the new transmitter code in your
vehicle’s memory so that the old code
is erased.
CAUTION
The transmitter is a sensitive elec-
tronic instrument. To avoid damaging
the transmitter:
Do not expose it to impacts, mois-
ture or high temperature such as by
leaving it on the dashboard under
direct sunlight.
Keep the transmitter away from
magnetic objects such as a televi-
sion.
Replacement of the Battery
If the transmitter gets discharged, replace
the battery with a new one.
To replace the battery of the transmitter:
83K-02-013
1) Remove the screw (1), and open the
transmitter cover.2) Remove the transmitter (2).
3) Put the edge of a flat blade screw driver
in the slot of the transmitter (2) and pry
it open.
4) Replace the battery (3) (Lithium disc-type
CR1620 or equivalent) so its + terminal
faces the “+” mark of the transmitter.
5) Close the transmitter and install it into
the transmitter holder.
6) Close the transmitter cover, install and
tighten the screw (1).
7) Make sure the door locks can be oper-
ated with the transmitter.
8) Dispose of the used battery properly
according to applicable rules or regula-
tions. Do not dispose of lithium batter-
ies with ordinary household trash.
CAUTIONw ww w
w WARNING
Swallowing a lithium battery may
cause serious internal injury. Do not
allow anyone to swallow a lithium
battery. Keep lithium batteries away
from children and pets. If swallowed,
contact a physician immediately.
The transmitter is a sensitive elec-
tronic instrument. To avoid damaging
it, do not expose it to dust or mois-
ture or tamper with internal parts.

Downloaded from www.Manualslib.com manuals search engine 1883K
BEFORE DRIVING
4-6Keyless Entry Cum Alarm
System (if equipped)System
83K-02-015
The Keyless Entry Cum Alarm System has
two basic modes of operation.
VALET MODE
When the vehicle is to be given for servic-
ing or Valet parking, turn the system into
Valet mode. In Valet mode all the Security
features of system will be OFF. The Sys-
tem will work as a Keyless Entry/Exit in this
mode.
83K-02-016
designed to protect your vehicle from
unauthorized entry. The system can be
operated in three stages. The First is “Arm
Stage” , Second is “ Trigger Stage” & Third
is “Disarm Stage”.
ALARM MODE
Alarm mode system is in three stages: Arm,
Disarm & Trigger stage. The system is
83K-02-017
83K-02-018
ARM STAGE
In Arm Stage, your vehicle is safe from any
unauthorized entry.
1) Press and release the Key Lock button.
2) One Siren chirp and one indicator light
flash will confirm Arm and Lock.
3) Doors will get locked and vehicle will get
armed.
4) Visible theft warning LED on security
switch will flash slowly.NOTE: System will not Arm in following
condition:
1. If any of door is open (except Bonnet).
2. If System is in Valet Mode.
3. If Key is in key cylinder.
TRIGGER STAGE
If anybody tries to tamper with the vehicle,
the alarm triggers and indicators flashes
DISARM STAGE
System should be brought in Disarm Mode
83K-02-019
