TOYOTA 4RUNNER 1998 Owners Manual

4RUNNER (1998)
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
3RZ- FE engineWith rear heater 11.0 (11.6, 9.7)
Without rear heater
10.0 (10.6, 8.8)
5VZ- FE engine With rear heater
9.0 (9.5, 7.9)
Without rear heater
8.0 (8.5, 7.0) Coolant type:
With ethylene- glycol antifreeze
(Do not use alcohol type.)
BATTERY
Open voltage *
at 20 C (68 F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8 Ð12.0 V Discharged
* : Voltage that is checked 20 minutes
after
the key is removed with all the lights
turned off
Charging rates:
5 A max.
CLUTCH
Pedal freeplay, mm (in.): 5Ð15 (0.2Ð0.6)
Fluid type: SAE J1703 or FMVSS No. 116 DOT
3 MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.):
3RZ- FE engine
Two- wheel drive models 2.6 (2.7, 2.3)
Four- wheel drive models
2.5 (2.6, 2.2)
5VZ- FE engine 2.2 (2.3, 1.9)
Oil type: Gear oil API GL- 4 or GL- 5
Recommended oil viscosity: SAE 75W- 90
AUTOMATIC TRANSMISSION
Fluid capacity (drain and ref ill),
L (qt., Imp. qt.): Two- wheel drive models Up to 1.6 (1.7, 1.4)
Four- wheel drive models Up to 2.0 (2.1, 1.8)

4RUNNER (1998)
Fluid type:
Automatic transmission fluid D- II or DEXRONIII (DEXRON II) TRANSFER
Oil capacity, L (qt., Imp. qt.):
1.0 (1.1, 0.9)
Oil type: Gear oil API GL- 4 or GL- 5
Recommended oil viscosity: SAE 75W- 90
DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.): Two- wheel drive models 2.75 (2.9, 2.4)
Four- wheel drive models FrontA.D.D.1.15 (1.2, 1.0)
Except A.D.D. 1.1 (1.2, 1.0)
Rear
With rear differential lock system2.75 (2.9, 2.4)
Without rear differential lock sys-
tem 2.45 (2.6, 2.2) Oil type:
Hypoid gear oil API GL- 5
Recommended oil viscosity:
FrontA.D.D.
SAE 75W- 90
Except A.D.D. Above -18 C (0 F)
SAE 90
Below -18 C (0 F)
SAE 80W or 80W- 90
Rear Above -18 C (0 F)
SAE 90
Below -18 C (0 F)
SAE 80W or 80W- 90
CHASSIS LUBRICATION
Propeller shafts: SpidersLithium base chassis grease,
NLGI No.2
Slide yoke and double cardan joint Molybdenum- disulfide lithium base
chassis grease, NLGI No.2

4RUNNER (1998)
BRAKES
Minimum pedal clearance when de-
pressed with the pressure of 490 N (50
kgf, 110 lbf) with the engine running,
mm (in.): 75 (2.9)
Pedal freeplay, mm (in.): 3Ð6 (0.12Ð0.24)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.): 1.0 (0.04)
Parking brake adjustment when pulled
with the force of 196 N (20 kgf, 44 lbf): 7Ð9 clicks
Fluid type: SAE J1703 or FMVSS No. 116 DOT
3
STEERING
Wheel freeplay: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II or III Tires
Tire size
Tire pressure
kPa (kgf/cm 2
or bar, psi)
Front Rear
P265/70R16
P225/75R15 220 (2.2, 32) 220 (2.2, 32)
200 (2.0, 29) 200 (2.0, 29) Wheel size
7J
16 *
1
7JJ16 *
2
7J
15 *
1
7JJ15 *
2
* 1
: Vehicles with steel wheels
* 2
: Vehicles with aluminum wheel
Wheel nut torque, N
Vm (kgf Vm, ft Vlbf):
110 (11.5, 83)

4RUNNER (1998)
Fuses
J80001
Engine compartment (U.S.A.)
Fuses (type A)
1. PWR OUTLET 15 A: Power outlet
2. DEFOG 15 A: Back window defog-
ger
3. STOP 10 A: Stop lights, high-
mounted stoplight
4. ALT- S 7.5 A: Charging system
5. OBD 7.5 A: On- board diagnosis
system
6. EFI 15 A: Multiport fuel injection
system/s equential multiport fuel in-
jection system

4RUNNER (1998)
J80002
Engine compartment (Canada)
7. HORN 15 A: Horns, emergency
flashers
8. DOME 15 A: Interior lights, person-
al lights, luggage compartment
light, clock, car audio system
9. TAIL 10 A: Tail lights, parking
lights, license plate lights
10. STA 7.5 A: Starting system
11. A.C 10 A: Air conditioning control
system
12. RR HTR 10 A: Rear air condition-
ing control system
13. HEAD(RH) 10 A: Right- hand head-
light

4RUNNER (1998)
J80003
Instrument panel
14. HEAD(LH) 10 A: Left- hand head-
light
15. DRL 7.5 A: Daytime running light
system
16. HEAD (LO RH) 10 A: Right- hand
headlight(low beam)
17. HEAD (LO LH) 10 A: Left- hand
headlight(low beam)
18. HEAD (HI RH) 10 A: Right- hand
headlight(high beam)
19. HEAD (HI LH) 10 A: Left- hand
headlight(high beam)
20. ACC 15 A: Car audio system, pow-
er antenna, clock, power rear view
mirror control 21. ECU- B 7.5 A:
SRS airbag warning
light
22. 4WD 20 A: A.D.D. control system,
four- wheel drive control system,
rear differential lock system
23. TURN 10 A: Turn signals lights,
emergency flashers
24. GAUGE 10 A: Gauges and meters,
back window defogger, daytime
running light system, air condition-
ing system, electric moon roof
25. ECU- IG 10 A: cruise control sys-
tem, anti- lock brake system, elec-
tronically controlled automatic
transmission system, power anten-na
26. WIPER 20 A: windshield wipers
and washer, back window wiper 27. IGN 7.5 A:
SRS airbag system,
multiport fuel injection system / se-
quential multiport fuel injection sys-
tem, discharge warning light

4RUNNER (1998)
Fuses (type B)
28. HEATER 50 A: air conditioning
system, ºA.Cº fuse
29. AM1 40 A: Starting system
30. AM2 30 A: Starting system, ºIGNº
fuse
31. POWER 30 A: Power window, pow-
er back window, electric moon roof
Fuses (type C)
32. ABS 60 A: Anti- lock brake system
33. ALT 100 A: Charging system

4RUNNER (1998)

4RUNNER (1998)
Part 9
REPORTING SAFE-TY
DEFECTS FOR U.S.
OWNERS AND
UNIFORM TIRE
QUALITY GRADING
Reporting safety defects for
U.S. owners
Uniform tire quality grading
If you believe that your vehicle
has a defect which could cause
a crash or could cause injury or
death, you should immediately
inform the National Highway
Traffic Safety Administration
(NHTSA) in addition to notifying
Toyota Motor Sales, U.S.A., Inc.
(Toll- free: 1- 800- 331- 4331).
If NHTSA receives similar com-
plaints, it may open an inves-
tigation, and if it finds that a
safety defect exists in a group of
vehicles, it may order a recall
and remedy campaign. Howev-
er, NHTSA cannot become in-
volved in individual problems
between you, your dealer, or
Toyota Motor Sales, U.S.A., Inc. To contact NHTSA, you may ei-
ther call the Auto Safety Hotline
toll- free at 1- 800- 424- 9393 (or
366- 0123 in Washington.D.C.
area) or write to: NHTSA.
U.S.Department of Transporta-
tion. Washington.D.C. 20590. You
can also obtain other information
about motor vehicle safety from
the Hotline.
Reporting safety defects
for U.S. owners

4RUNNER (1998)
Uniform tire quality grading
This information has been prepared in
accordance with regulations issued by
the National Highway Traffic Safety
Administration of the U.S. Department
of Transportation. It provides the pur-
chasers and/or prospective purchasers
of Toyota vehicles with information on
uniform tire quality grading.
Your Toyota dealer will help answer
any questions you may have as you
read this information.
DOT quality gradesÐAll passenger
vehicle tires must conform to Fed-
eral Safety Requirements in addition
to these grades. These quality
grades are molded on the sidewall.
Treadwear ÐThe treadwear grade is a
comparative rating based on the wear
rate of the tire when tested under
controlled conditions on a specified
government test course. For example,
a tire graded 150 would wear one and
a half (1- 1/2) times as well on the
government course as a tire graded
100. The relative performance of tires
depends upon the actual conditions of
their use, however, and may depart
significantly from the norm due to
variations in driving habits, service
practices and differences in road char-
acteristics and climate. Traction A, B, C
ÐThe traction
grades, from highest to lowest, are A,
B, and C, and they represent the
tire's ability to stop on wet pavement
as measured under controlled condi-
tions on specified government test
surfaces of asphalt and concrete. A
tire marked C may have poor traction
performance.
Warning: The traction grade assigned
to this tire is based on braking
(straight ahead) traction tests and
does not include cornering (turning)
traction.
Temperature A, B, C ÐThe tempera-
ture grades are A (the highest), B,
and C, representing the tire's resis-
tance to the generation of heat and its
ability to dissipate heat when tested
under controlled conditions on a speci-
fied indoor laboratory test wheel. Sus-
tained high temperature can cause the
material of the tire to degenerate and
reduce tire life, and excessive temper-
ature can lead to sudden tire failure.
The grade C corresponds to a level of
performance which all passenger car
tires must meet under the Federal Mo-
tor Vehicle Safety Standard No. 109.
Grades B and A represent higher lev-
els of performance on the laboratory
test wheel than the minimum required
by law. Warning: The temperature grades for
this tire are established for a tire that
is properly inflated and not over-
loaded. Excessive speed, underinfla-
tion, or excessive loading, either sepa-
rately or in combination, can cause
heat buildup and possible tire failure.
