display TOYOTA 4RUNNER 2006 N210 / 4.G Navigation Manual

39
— Destination search by
“Memory”
1. Touch “Memory” on the “Destination”
screen.
A list of registered memory points is dis-
played. (To register or edit memory points,
see “My places” on page 69.)
2. Touch the touchscreen button of your
desired memory point.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route guid-
ance” on page 43.)
— Destination search by
“Previous”
1. Touch “Previous” on the “Destination”
screen.
The previous starting point and up to 100 pre-
viously set destinations are displayed on the
screen.
2. Touch the touchscreen button of the
desired destination.
The screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route guid-
ance” on page 43.)
INFORMATION
The list of previous destinations can be
deleted while the vehicle is stopped, if
these destinations are no longer neces-
sary. (See “ — Deleting previous points”
on page 80.)

40
— Destination search by
“Map”
Touch “Map” on the “Destination” screen.
The screen changes and displays the map
location that was previously displayed just
before the destination input operation and the
route preference. (See “Starting route guid-
ance” on page 43.)
INFORMATION
Guidance starts if “Enter” is touched
even while driving. However, the cursor
cannot be moved.
— Destination search by
“Intersection”
1. Touch “Intersection” on the “Destina-
tion” screen.
2. Input the name of the two intersecting
streets which are located near the destina-
tion to be set.
3. Touch the touchscreen button of the
desired item.
After inputting the two intersecting streets,
the screen changes and displays the map
location of the selected destination and the
route preference. (See “Starting route guid-
ance” on page 43.)

42
4. Touch the touchscreen button of the
desired entrance or exit name.
The screen changes and displays the map
location of the selected destination and the
route preference. (See
“Starting route guid-
ance” on page 43.)
“Input Name”: An applicable list is displayed
by touching this touch− screen button and in-
putting the name.
— Destination search by
“Coordinates”
1. Touch “Coordinates” on the “Destina-
tion” screen.
2. Input the latitude and the longitude.
3. When the input is finished, touch
“OK”.
By touching touch −screen the button of the
desired point, the screen changes and dis-
plays the map location of the selected des-
tination and the route preference. (See
“Starting route guidance” on page 43.)
— Destination search by
“Phone #”
1. Touch “Phone #” on the “Destination”
screen.
2. Input a telephone number.
3. After inputting a telephone number,
touch “OK”.
The screen changes and displays the map
location of the selected destination and the
road preference. (See “Starting route guid-
ance” on page 43.)
If there is more than one site having the same
number, the following screen will be dis-
played.

43
INFORMATION
If there is no match for the telephone
number inputted, a list of identical
numbers with different area codes
will be displayed.
 To set a memory point as a destina-
tion using the phone number, the
number must be registered previous-
ly. (See page 75.)
Starting route guidance
After inputting the destination, the screen
changes and displays the map location of the
selected destination and the route prefer-
ence.
1. When an arrow facing the desired
point is touched, the map scrolls in that di-
rection.
Releasing the finger from the arrow will stop
the scrolling. 2. Touch “Enter”.
The system starts route search and displays
recommended routes.
If there is already a set destination,
“Add to
” and “Replace ” are displayed.
“Add to
”: To add a destination.
“Replace
”: To delete the existing destina-
tions and set a new one.
“Route Preference”: To change the route
preference. (See page 45.)
“Info.”: If this touch−screen button is dis-
played on the top of the screen, touch the
switch to view items such as name, address,
and phone number.

46
“Short”:
A route by which you can reach the
destination in the shortest distance.
This route is indicated by a green line.
“Info.”: To display the following information
about each of the 3 routes.
1Time necessary for the entire trip
2Distance of the entire trip
3Toll road
4Freeway
5Ferry

47
ROUTE GUIDANCE
Route guidance
Route guidance screen48
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Typical voice guidance prompts 50
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Distance and time to destination 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Setting and deleting destination 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Adding destinations 53
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Reordering destinations 54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . .
Deleting destination 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . .
Setting route 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . .
Search condition 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . .
Detour setting 56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . .
Route preference 57
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . .
Starting route from adjacent road 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map view 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . .
Display POI icons 58
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Route overview 61
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . .
Route preview 62
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . .
Route trace 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . .
SECTION III

48
Route guidance screen
During route guidance, various types of guid-
ance screens can be displayed depending on
conditions.
Screen layout
1Distance to the next turn and the ar-
row indicating turning direction
2Current street name
3Distance and travel/arrival time to the
destination
4Current position
5Guidance route
INFORMATION
 If the vehicle goes off the guidance
route, the route is searched again.
 For some areas, the roads have not
been completely digitized in our data-
base. For this reason, the route guid-
ance may select road that should not
be traveled on.
During freeway driving
During freeway driving, the freeway informa-
tion screen will be displayed.
This screen displays the distance to the next
junction and exit, or POIs in the vicinity of the
freeway exit.
1Current position
2Points of Interest that are close to a
freeway exit.
3Exit number and junction name
4Distance from the current position to
the exit or junction
5Current street name
: To display the selected map of the exit
vicinity.

49
:To scroll for farther junctions or exits.
:To scroll for closer junctions or exits.
:To scroll for the closest three junctions
or exits.
When approaching a freeway en-
trance, exit or junction
When the vehicle approaches an entrance,
exit, or junction, the guidance screen for the
freeway will be displayed.
1Road/area name
2Distance from the current position to
the entrance, exit, or junction
3Current position
“OFF”: The guidance screen on freeway dis-
appears and the map screen appears.
When touching
or pushing the “MAP/
VOICE” button, the guidance screen on free-
way reappears.
When approaching an intersection
When the vehicle approaches an intersec-
tion, the intersection guidance screen will be
displayed.
1Next street name
2Distance to the intersection
3Current position
“OFF”: The intersection guidance screen
disappears and the map screen appears.
When touching
or pushing the “MAP/
VOICE” button, the intersection guidance
screen reappears.

50
Other screens
TURN LIST SCREEN
On this screen, the list of turns on the guid-
ance route can be viewed.
Touching
during guidance displays the
turn list.
1Next street name or destination name
2Turn direction
3Distance to the next turn
4Current street name ARROW SCREEN
On this screen, information about next turns
on the guidance route can be viewed.
Touching
during guidance displays the
arrow screen.
1Exit number, street name containing
number or next street name
2Turn direction
3Distance to the next turn
4Current street name
Typical voice guidance
prompts
The voice guidance provides various mes-
sages as you approach an intersection, or
other point where you need to maneuver the
vehicle.
4.7 miles
0.25 miles
+ α
1“Proceed about 5 miles.”
2“In a quarter of a mile, right turn.”
3“Right turn.”
4(Beep sound only)

52
The system announces the approach to the fi-
nal destination.
1“Your destination is ahead.”
2“You have arrived at your destina-
tion. The route guidance is now
finished.”
INFORMATION
If the system cannot determine the
current vehicle position correctly (in
cases of poor GPS signal reception),
the voice guidance may be made ear-
ly or delayed.
 If you did not hear the voice guidance
command, push the “MAP/VOICE”
button to hear it again.
 To adjust the voice guidance volume,
see “Volume” on page 67.
Distance and time to
destination
When the vehicle is on the guidance route,
the distance and the estimated travel/arrival
time to the destination are displayed. When
the vehicle is not on the guidance route, the
distance and the direction of the destination
are displayed.
When driving on the guidance route and more
than one destination is set, the distance and
the estimated travel/arrival time from the cur-
rent position to each destination are dis-
played.
1. Touch this touchscreen but ton to dis-
play the following screen.
