display TOYOTA 4RUNNER 2006 N210 / 4.G Navigation Manual

53
2. Touch the number button to display
the desired destination.
The distance, the estimated travel time and
the estimated arrival time from the current
position to the selected destination are dis-
played.Estimated travel time is displayed.
Estimated arrival time is dis-
played.
To switch to estimated arrival
time.
To switch to estimated travel time.
Displayed while driving off the
guidance route. The destination
direction is indicated by an arrow.
INFORMATION
When the vehicle is on the guidance
route, the distance measured along the
route is displayed. T ravel time and arriv-
al time is calculated based on the set ve-
hicle speed information. (See page 81.)
However, when the vehicle is not on the
guidance route, the distance is the linear
distance between the current position
and the destination.
Setting and deleting
destination —
— Adding destinations
Adding destinations and searching again for
the routes can be done.
1. Touch “Route”.
2. Touch “Add”.

54
3. Input an additional destination in the
same
way as the destination search. (See
“Destination search” on page 24.)
4. Touch the desired “Add” to determine
the arrival order of the additional destina-
tion.
— Reordering destinations
When more than one destination is set, you
can change the arrival order of the destina-
tions.
1. Touch “Route”.
2. Touch “Reorder”.
3. Select the destination in the order of
arrival by touching the destination button.
Reordered number of arrival is displayed on
the right side of the screen.
Touching “Undo” will cancel each selected
order number front the previously input num-
ber.
4. After selecting the destinations, touch
“OK”.
The system searches for the guidance route
again, and displays the entire route. Even if
“OK” is not touched, the entire route is dis-
played automatically within a few seconds
when the order is fixed.

55
— Deleting destinations
A set destination can be deleted.
1. Touch “Route”.
2. Touch “Delete”.
When more than one destination is set, a list
will be displayed on the screen.
3. Touch the destination for deletion.
“Delete All”: To delete all destinations on the
list.
A message appears to confirm the request to
delete.
4. To delete the destination(s), touch
“Yes”.
If “Yes” is touching, the data cannot be recov-
ered.
If “No” is touching, the previous screen will
return.
5. If more than one destination is set,
touch “OK” after deleting the destination-
s.
The system searches for the guidance route
again, and displays the entire route.
Setting route —
— Search condition
You can designate the route conditions of the
route to the destination.
1. Touch “Route”.
2. Touch “Search Condition”.

56
3. Touch “Quick”, “Quick1”, “Quick2” or
“Short” and touch “OK”.
The entire route from the starting point to the
destination is displayed.
“Guide”: To start guidance.
“Route”: To change a route. (See pages 53
and 55.)
— Detour setting
While the route guidance is operating, you
can change the route to detour around a sec-
tion of the route where a delay is caused by
road repairs, or an accident, etc.
1. Touch “Route”.
2. Touch “Detour”.
3. Select the touchscreen button below
to select the desired detour distance.
“1 mile (km)”, “3 miles (km)” or “5 miles
(km)”: Touch one of these touch −screen but-
tons to start the detour p rocess. After detour-
ing, the system returns to the original guid-
ance route.
“Whole Route”: By touching this touch −
screen button, the system will calculate an
entire new route to the destination.

58
— Starting route from
adjacent road
You can start the route guidance from the ad-
jacent road.
(ex. When route guidance is set on the free-
way, but the vehicle is driven parallel along
the freeway.)
1. Touch “Route”.
2. Touch “Start from Adjacent Road”.
When there is no adjacent road, this button
will not be displayed.
Map view —
— Display POI icons
Points of Interest such as gas stations and
restaurants can be displayed on the map
screen. You can also set their location as a
destination and use them for route guidance.
1. Touch “Map View”.

59
2. Touch “Display POI Icon” to display a
particular type of Point of Interest on the
screen.
A screen with a limited choice of Points of In-
terest will be displayed. (To change the dis-
played POI, see page 84.)
Selecting POIs to be displayed
Up to 5 categories of icons can be displayed
on the screen.
Touch the desired Point of Interest catego-
ry to display POI location symbols on the
map screen.
By selecting the desired POI category and
then touching “OK”, the selected POI icons
are displayed on the map screen.
To turn off the Points of Interest icon on the
map screen, touch “Delete”.
“Other POI’s”: If the desired Point of Interest
can not be found on the limited choice screen,
touch this button. The screen then displays
the complete POI listing screen.
“Local POI List”: When searching for the
nearest Point of Interest, touch this touch −
screen button. The system will list the points
within 20 miles (32 km). (See page 60.) Touch “Other POI’s” on the “Display POI
Icons” screen.
When a Point of Interest
category is selected
from either the limited list or the complete list,
the screen will display symbols at those loca-
tions on the map screen.
Select the desired POI categories.
The selected category icon appears on the
top left of the screen.
By selecting the desired POI category and
then touching “OK”, the selected POI icons
are displayed on the map screen.
If the desired POI category is not on the
screen, touch “List All Categories” to list all
POI categories.

60
Select the desired POI categories from the
list.
The selected category icon appears on the
top left of the screen.
By selecting the desired POI category and
then touching “OK”, the selected POI icons
are displayed on the map screen.
To return to the POI category selection
screen, touch “More”.
To display the local POI list
Points of Interest that are within 20 miles (32
km) of the current position will be listed from
among the selected categories.
1. Touch “Local POI List” on the “Display
POI icons” screen.
2. Touch the touchscreen button of the
desired Point of Interest.
The selected Points of Interest are displayed
on the map screen.
“On Route”: When the indicator is illumi-
nated by touching this touch −screen button,
the list of the items searched along the route
is displayed

61
To set a POI as a destination
You can select one of the Points of Interest
icons on the map screen as a destination and
use it for route guidance.
1. Directly touch the Point of Interest icon
that you want to set as a destination.
The map will shift so that the icon is centered
on the screen and overlaps with the cursor
. At this time, the distance from the current
position is displayed on the screen. The dis-
tance shown is measured as a straight line
from the current vehicle position to the POI.
2. When the desired Point of Interest
overlaps with the cursor, touch “Enter
”.
The screen changes and displays the map
location of the selected destination and route
preference. (See
“Starting route guidance”
on page 43.)
— Route overview
1. Touch “Map View”.
2. Touch “Route Overview”.
The entire route from the current position to
the destination is displayed.
“Guide”: To start guidance.
“Route”: To change the route. (See pages
53 and 55.)
“Turn List”: The following screen displays
the list of the roads up to the destination.

62
You can scroll through the list of roads by
touching
or . However, not all road
names in the route may appear on the list. If
a road changes its name without requiring a
turn (such as on a street that runs through two
or more cities), the name change will not ap-
pear on the list. The street name closest to
the starting point will be displayed with the
mileage to the next turn.
These marks indicate the
direction in which you should turn
at an intersection.
Touch “Map” on the “Turn List” screen.
The point which you choose is displayed on
the map screen.— Route preview
1. Touch “Map View”.
2. Touch “Route Preview”.

63
:To indicate the next destination.
:To preview the route to the next des-
tination.
: To preview the route to the next des-
tination in fast −forward mode.
: To stop the preview.
:To review the route to the previous
destination or starting point.
: To review the route to the previous
destination or starting point in fast −
forward mode.
: To indicate the previous destination
or starting point.
— Route trace
It is possible to store the traveled route up to
124 miles (200 km) and retrace the route on
the display.
INFORMATION
This feature is available on the map with
more detailed map scale than 30 mile (50
km).
Touch “Map View”.
“Record”: To start recording the route trace.
“Stop”: To stop recording the route trace.
If you touch “Stop” to display the following
screen.
Touching “Yes” stops recording and the
route trace remains displayed on the screen.
Touching “No” stops recording and the route
trace is erased.
