TOYOTA 4RUNNER 2021 Owners Manual (in English)

571
9
For owners
4RUNNER (U)
WARNING
■Précautions avec le coussin gonflable SRS
● Ne placez rien sur le siège du passager avant, comme un coussin par
exemple. Cela a pour conséquence de répartir le poids du passag er sur
toute la surface du siège, ce qui empêche le capteur de détecter correcte-
ment le poids du passager. En conséquence, les coussins gonflab les fron-
taux SRS du passager avant risquent de ne pas se déployer en ca s de
collision.
■ Modification et mise au rebut des éléments du système de coussi ns
gonflables SRS
Consultez impérativement votre concessionnaire Toyota si vous a vez
besoin d’intervenir sur votre véhicule ou de procéder à l’une d es modifica-
tions suivantes. Les coussins gonflables SRS peuvent être défai llants ou se
déployer (se gonfler) accidentellement, provoquant la mort ou d e graves
blessures.
● Installation, dépose, démontage et réparation des coussins gonf lables
SRS
● Réparations, modifications, démontage ou remplacement du volant, du
tableau de bord, de la planche de bord, des sièges ou de leur g arniture,
des montants avant, latéraux et arrière ou des rails latéraux d e toit
● Réparations ou modifications des ailes avant, du pare-chocs ava nt ou des
flancs de l’habitacle
● Installation d’un protège-calandre (pare-buffle, pare-kangourou , etc.), de
chasse-neiges, de treuils ou d’une galerie de pavillon
● Modifications du système de suspension du véhicule
● Installation d’appareils électroniques, tels qu’une radio émett eur/récepteur
ou un lecteur CD
● Aménagements du véhicule visant à permettre sa conduite par une per-
sonne atteinte d’un handicap physique

572
4RUNNER (U)

573
Index
4RUNNER (U)What to do if...
(Troubleshooting) .................... 574
Alphabetical index ..................... 579
For details of equipment relat ed to the audio/navigation
system, refer to the “NAVIGATION AND MULTIMEDIA
SYSTEM OWNER’S MANUAL”.

574
4RUNNER (U)
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
●If you lose your keys or mechanical keys, new genuine mechanical keys
can be made by your Toyota dealer. ( P. 105)
●If you lose your keys or electronic keys, the risk of vehicle t heft increases
significantly. Contact your Toyota dealer immediately. ( P. 109)
●Is the key battery weak or depleted? (P. 443)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
When locking the doors, turn the engine switch off. ( P. 213)
●Vehicles with a smart key system:
Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
●The function may not operate properly due to the condition of t he radio
wave. ( P. 122)
●Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. ( P. 114)
If you have a problem, check the following before contacting
your Toyota dealer.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
The doors cannot be locked or unlocked
The rear door cannot be opened

575What to do if... (Troubleshooting)
4RUNNER (U)
●Is the shift lever in P? (P. 209)
●Is the steering wheel unlocked? ( P. 209)
●Is the battery discharged? (P. 510)
●Did you press the engine switch while firmly depressing the bra ke pedal?
( P. 212)
●Is the shift lever in P? ( P. 215)
●Is the electronic key anywhere detectable inside the vehicle? ( P. 119)
●Is the steering wheel unlocked? (P. 215)
●Is the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way. ( P. 508)
●Is the battery discharged? (P. 510)
●Vehicles without a smart key system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in the “ON” position. ( P. 221)
●Vehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake p edal with the
engine switch in IGNITION ON mode. ( P. 221)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)
The shift lever cannot be shifted from P even if you depress
the brake pedal

576What to do if... (Troubleshooting)
4RUNNER (U)
●Vehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 210)
●Vehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 2 1 5 )
●Is the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. ( P. 162)
●The auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a peri od of
time. ( P. 214)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches
The engine switch is tur ned off automatically
(vehicles with a smart key system)

577What to do if... (Troubleshooting)
4RUNNER (U)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts?
(P. 477)
●The brake system warning light is on
Is the parking brake released? ( P. 224)
●The open door warning indicator is on
Are all the doors closed? (P. 110, 131)
Depending on the situation, other types of warning buzzer may a lso sound.
( P. 474, 484)

●Did anyone inside the vehicle open a door during setting the al arm?
The sensor detects it and the alarm sounds. ( P. 79)
To stop the alarm, turn the engine switch to IGNITION ON mode ( vehicles
with a smart key system) or start the engine.
●Is the electronic key left inside the vehicle?
Check the message on the multi-information display.
●When a warning light turns on, refer to P. 474.
●When a warning light turns on or a warning message or indicator is dis-
played, refer to P. 474, 484.
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
A warning buzzer sounds w hen leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is displayed

578What to do if... (Troubleshooting)
4RUNNER (U)
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. ( P. 489)
●Try the procedure for when the vehicle becomes stuck in mud, di rt, or
snow. ( P. 517)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

579
4RUNNER (U)
Alphabetical index
Alphabetical index
A/C .................................... 340, 347Air conditioning filter ............. 441
ABS (Anti-lock Brake System)...... 320
Function ................................ 320
Warning light ......................... 475
Active head restraints ............. 137
Active traction control ............ 300
Air conditioning filter .............. 441
Air conditioning
system ............................ 340, 347 Air conditioning filter ............. 441
Airbags ....................................... 35
Airbag operating conditions .... 42
Airbag precautions for your child ......................... 37
Airbag warning light .............. 475
Correct driving posture ........... 28
Curtain shield airbag operating conditions ............. 42
Curtain shield airbag precautions ........................... 39
Front passenger occupant classification syst em............. 46
General airbag precautions .... 37
Locations of airbags................ 35
Modification and disposal of airbags.............................. 41
Side airbag operating
conditions ............................. 42
Side airbag precautions .......... 37
Side and curtain shield airbags operating conditions ............. 42
Side and curtain shield airbags precautions .............. 37
SRS airbags............................ 35 Alarm .......................................... 79
Alarm ...................................... 79
Warning buzzer .................... 474
Anchor brackets ........................ 57
Antennas (smart key system) ............... 118
Anti-lock Brake System (ABS) ...................................... 320
Function ................................ 320
Warning light......................... 475
Armrest..................................... 383
Assist grip ................................ 383
Audio system
*
AUTO LSD system................... 302
Automatic air conditioning
system.................................... 347
Automatic High Beam ............. 230
Automatic light control
system.................................... 225
Automatic running boards ..... 128
Automatic transmission ......... 218
If the shift lever cannot be shifted from P .... 221
S mode ................................. 219
AUX port
*
Auxiliary boxes ........................ 364
A
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

580Alphabetical index
4RUNNER (U)
Back doorBack door.............................. 131
Back window ......................... 166
Smart key system ................. 118
Wireless remote control ........ 110
Back window ............................ 166
Back-up lights Replacing light bulbs............. 457
Wattage ................................ 529
Battery ...................................... 417
Battery checking ................... 417
If the vehicle battery is discharged ...................... 510
Preparing and checking before winter....................... 329
Warning light ......................... 474
Bottle holders .......................... 366
Brake Fluid ...................................... 414
Parking brake........................ 224
Warning light ......................... 474
Brake assist ............................. 320
Brake override system ............ 177
Break-in tips ............................. 178
Brightness control Instrument panel light
control................................... 89 Care .................................. 392, 395
Exterior ................................. 392
Interior .................................. 395
Seat belts.............................. 396
Wheels and wheel ornaments .......................... 393
Cargo capacity......................... 191
Cargo hooks ............................ 367
Cargo net hooks ...................... 368
Center differential lock ........... 296
Chains ...................................... 331
Child restraint system............... 53 Booster seats, definition ......... 54
Booster seats, installation....... 65
Convertible seats, definition ... 54
Convertible seats,
installation ............................ 62
Front passenger occupant classification syst em ............ 46
Infant seats, definition............. 54
Infant seats, installation .......... 62
Installing CRS with LATCH anchors ............ 59
Installing CRS with seat belts...................................... 62
Installing CRS
with top tether strap.............. 66
BC
