TOYOTA AVALON 2001 Service Repair Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: AVALON, Model: TOYOTA AVALON 2001Pages: 1897, PDF Size: 26.61 MB
Page 301 of 1897
BE1DM-01
N18026
2
1
21
3
4 Free Pushed in
Free Pushed in w/o Cruise Control:
w/ Cruise Control:
I13416
BE-36
- BODY ELECTRICALSTOP LIGHT SYSTEM
1640 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. w/o Cruise Control:
INSPECT STOP LIGHT SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
Switch pin free1 - 2Continuity
Switch pin pushed in1 - 2No continuity
If continuity is not as specified, replace the switch.
2. w/ Cruise Control:
INSPECT STOP LIGHT SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
Switch pin free1 - 2Continuity
Switch pin pushed in1 - 2No continuity
Switch pin free3 - 4No continuity
Switch pin pushed in3 - 4Continuity
If continuity is not as specified, replace the switch.
3. INSPECT HI- MOUNTED STOP LIGHT ASSEMBLY
CONTINUITY
Using the ohmmeter,check that continuity exists between termi-
nal 1 and terminal 2.
If continuity is not as specified,replace the light assembly or
bulb.
Page 302 of 1897
BE0I6-05
I12529
Stop Light Switch
Driver Side Junction Block
STOP Fuse
Light Failure Sensor
Stop Light
HI-Mounted Stop Light
- BODY ELECTRICALSTOP LIGHT SYSTEM
BE-35
1639 Author: Date:
2001 AVALON (RM808U)
STOP LIGHT SYSTEM
LOCATION
Page 303 of 1897
BE1E2-01
I04045
Wire Harness Side:
- BODY ELECTRICALSLIDING ROOF SYSTEM
BE-103
1707 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT SLIDING ROOF CONTROL SWITCH CONTI-
NUITY
Switch positionTester connectionSpecified condition
Slide Open2 - 3Continuity
Tilt Up1 - 2Continuity
If continuity is not as specified, replace the switch.
2. INSPECT SLIDING ROOF CONTROL ASSEMBLY CIR-
CUIT
Disconnect the connector from the assembly and inspect the
connector on the wire harness side, as shown in the chart.
Tester connectionConditionSpecified condition
3 - Ground
Driver's door courtesy switch ºONº
(Door opened)Continuity3 Ground
(DCTY)Driver's door courtesy switch ºOFFº
(Door closed)No continuity
4 - Ground
Passenger's door courtesy switch ºONº
(Door opened)Continuity4 Ground
(PCTY)Passenger's door courtesy switch ºOFFº
(Door closed)No continuity
5 - Ground
(+B)ConstantBattery positive voltage
7 - Ground
(E)ConstantContinuity
8 - GroundIgnition switch LOCK or ACCNo voltage8 Ground
(IG)Ignition switch ONBattery positive voltage
9 - Ground
(DOWN)Sliding roof control switch OPEN / DOWNContinuity
9 - Ground
(DOWN)Sliding roof control switch CLOSE / UPNo continuity
10 - GroundSliding roof control switch CLOSE / UPContinuity10 Ground
(UP)Sliding roof control switch OPEN / DOWNNo continuity
*: Exceptions: During 60 second period after ignition switch ON
" OFF (ACC) or until driver of passenger door in opened after
ignition switch ON " OFF (ACC).
If circuit is as specified, replace the assembly.
Page 304 of 1897
BE0IP-06
I12542
Instrument Panel Junction Block
Sun Roof Fuse
GAUGE No,1 FuseIgnition Switch Sliding Roof Assembly
Sliding Roof Switch
Sliding Roof Control ECU
Door Courtesy Switch
BE-102
- BODY ELECTRICALSLIDING ROOF SYSTEM
1706 Author: Date:
2001 AVALON (RM808U)
LOCATION
Page 305 of 1897
BE0O9-02
Sliding Roof reverses during close (down) operation.
Start
Mechanical check
Replace sliding roof motor with ECU. Perform forced operation.*
*: Holding the CLOSE/UP (OPEN/DOWN) switch pressed inhibits the jam protection function at approx.
10 sec. after starting the reverse operation.
If the switch remains pressed any longer, the sliding door starts close operation and it stops when
detecting the fully closed position.
CLOSE/UP
(OPEN/DOWN)
SWITCHON
OFF
Close
(Down)
Roof OperationStop Forced Operation Reverse
Stop
Close (Down)
Close Position Approx. 10 sec.
HINT:
At approx. 10 sec. after starting the reverse operation, it is switched to the forced close (down) operation.
- BODY ELECTRICALSLIDING ROOF SYSTEM
BE-101
1705 Author: Date:
2001 AVALON (RM808U)
SLIDING ROOF SYSTEM
TROUBLESHOOTING
Page 306 of 1897
BE04Q-06
BE-2
- BODY ELECTRICALTROUBLESHOOTING
1606 Author: Date:
2001 AVALON (RM808U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
POWER OUTLET
SymptomSuspect AreaSee page
Electric power source cannot be taken out of the power outlet11. PWR OUTLET No. 1, 2 Fuse
12.Wire Harness-
-
IGNITION SWITCH AND KEY UNLOCK WARNING SWITCH:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
HEADLIGHT AND TAILLIGHT SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
FOG LIGHT SYSTEM:
SymptomSuspect AreaSee page
Fog light does not light with light control SW HEAD.
(Headlight is normal)
1. FOG Fuse
2. Fog Light Relay
3. Fog Light Switch
4. Wire Harness-
BE-26
BE-26
-
Fog light does not light with light control SW HEAD.
(Headlight does not light)1. Other Parts*1
2. Wire Harness
-
-
Only one light does not light.1. Bulb
2. Wire Harness-
-
*1: Inspect Headlight System.
TURN SIGNAL AND HAZARD WARNING SYSTEM:
SymptomSuspect AreaSee page
ºHazardº and ºTurnº do not light up.
1. Hazard Warning Switch
2. Turn Signal Flasher
3. Wire HarnessBE-29
BE-29
-
The flashing frequency is abnormal.
1. Bulb
2. Turn Signal Switch
3. Wire Harness-
BE-29
-
Hazard warning light does not light up.
(Turn is normal.)1. HAZ Fuse
2. Wire Harness-
-
Hazard warning light does not light up in one direction.1. Hazard Warning Switch
2. Wire HarnessBE-29
-
*1Turn signal does not light up.
1. Ignition Switch
2. TURN Fuse
3. Turn Signal Switch
4. Wire HarnessBE-16
-
BE-29
-
*2Turn signal does not light up.
1. TURN Fuse
2. Turn Signal Switch
3. Wire Harness-
BE-29
-
Turn signal does not light up in one direction.1. Turn Signal Switch
2. Wire HarnessBE-29
-
Only one bulb does not light up.1. Bulb
2. Wire Harness-
-
*1: Combination Meter, Wiper and Washer do not operate.
*
2: Combination Meter, Wiper and Washer are normal.
Page 307 of 1897
- BODY ELECTRICALTROUBLESHOOTING
BE-3
1607 Author: Date:
2001 AVALON (RM808U)
INTERIOR LIGHT SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
BACK-UP LIGHT SYSTEM:
SymptomSuspect AreaSee page
Back-Up Light does not light up.
1. GAUGE Fuse
2. Ignition Switch
3. Park/Neutral Position Switch
4. Back-up Light Relay (Column Shift)
5. Bulb
6. Wire Harness-
BE-16
DI-199
BE-34
-
-
Back-Up Light remains always ON.
1. Park/Neutral Position Switch
2. Back-up Light Relay (Column Shift)
3. Wire HarnessDI-199
BE-34
-
Only one light does not light up.1. Bulb
2. Wire Harness-
-
STOP LIGHT SYSTEM:
SymptomSuspect AreaSee page
Stop light does not light up.
1. STOP Fuse
2. GAUGE Fuse
3. Stop Light Switch
4. Light Failure Sensor
5. Wire Harness-
-
BE-36
BE-53
-
Only one light always lights up.1. Wire Harness-
Only one light does not light.1. Bulb
2. Wire Harness-
-
WIPER AND WASHER SYSTEM:
SymptomSuspect AreaSee page
Wiper and washers do not operate.
1. IG 1 Relay
2. WIPER Fuse
3. Wiper Switch
4. Wiper Motor
5. Wire Harness-
-
BE-38
BE-38
-
Wipers do not operate in LO or HI.
1. Wiper Switch
2. Wiper Motor
3. Wire HarnessBE-38
BE-38
-
Wipers do not operate in INT.
1. Wiper Fuse
2. Wiper Switch
3. Wiper Motor
4. Wire Harness-
BE-38
BE-38
-
Washer motor does not operate.
1. Washer Switch
2. Washer Motor
3. Wire HarnessBE-38
BE-38
-
Wipers do not operate when washer switch in ON.1. Washer Motor
2. Wire HarnessBE-38
-
Washer fluid does not operate.1. Washer Hose and Nozzle-
In wiper switch HI position, the wiper blade is in contact with
the body.
When the wiper switch is OFF, the wiper blade does not
retract or the retract position is wrong.1. *1Wiper Switch
2. Wire HarnessBE-38
-
*1: Inspect wiper arm and blade set position
Page 308 of 1897
BE-4
- BODY ELECTRICALTROUBLESHOOTING
1608 Author: Date:
2001 AVALON (RM808U)
COMBINATION METER (Meter, Gauges and Illumination):
SymptomSuspect AreaSee page
Tachometer, Fuel Gauge and Engine Coolant Temperature Gauge
do not operate.
1. ECU-B Fuse
2. ECU-IG No. 2 Fuse
3. Meter Circuit Plate
4. Wire Harness
5. Multi Display-
-
BE-43
-
-
Speedometer does not operate.
1. Vehicle Speed Sensor (ABS - ECU)
2. Meter Circuit Plate
3. Wire Harness
4. Multi DisplayBE-53
BE-43
-
-
Tachometer does not operate.
1. EFI - ECU
2. Meter Circuit Plate
3. Wire Harness
4. Multi Display-
BE-43
-
-
Fuel Gauge does not operate or abnormal operation.
1. Fuel Receiver Gauge
2. Fuel Sender Gauge
3. Meter Circuit Plate
4. Wire HarnessBE-53
BE-53
BE-43
-
Engine Coolant Temperature Gauge does not operate or abnormal
operation.
1. Engine Coolant Temperature Receiver Gauge
2. Engine Coolant Temperature Sender Gauge
3. Meter Circuit Plate
4. Wire HarnessBE-53
BE-53
BE-43
-
All illumination lights do not light up.
1. Bulb
2. PANEL Fuse
3. Light Control Rheostat
4. Wire Harness-
-
BE-53
-
Brightness does not change even when rheostat turned.
1. Bulb
2. Rheostat
3. Wire Harness-
-
-
Only one illumination light does not light up.1. Bulb
2. Wire Harness-
-
COMBINATION METER (Warning Lights):
SymptomSuspect AreaSee page
Warning lights do not light up. (Except Discharge, Open Door and
SRS)
1. Bulb
2. GAUGE No. 1 Fuse
3. Meter Circuit Plate
4. Wire Harness-
-
BE-53
-
Low Oil Pressure warning light does not light up.
1. Multi Display
2. Bulb
3. Low Oil Pressure Warning Switch
4. Meter Circuit Plate
5. Wire Harness-
-
BE-53
BE-43
-
Fuel Level warning light does not light up.
1. Multi Display
2. Bulb
3. Fuel Sender Gause
4. Meter Circuit Plate
5. Wire Harness-
-
BE-53
BE-43
-
ABS warning light does not light up.
1. Bulb
2. ABS ECU
3. Wire Harness-
DI-210
-
Page 309 of 1897
- BODY ELECTRICALTROUBLESHOOTING
BE-5
1609 Author: Date:
2001 AVALON (RM808U) Seat Belt warning light does not light up.
1. Bulb
2. Body Control System
3. Meter Circuit Plate
4. Wire Harness-
DI-615
BE-53
-
Discharge warning light does not light up.
1. AM2 - Fuse
2. Bulb
3. Meter Circuit Plate
4. Wire Harness
5. Generator-
-
BE-53
-
CH-9
Light Failure warning light does not light up.
1. Bulb
2. Light Failure Sensor
3. Bulb Check Relay
4. Wire Harness
5. Taillight System-
BE-53
BE-53
-
BE-2
Brake warning light does not light up.
1. Bulb
2. Parking Brake Switch
3. Brake Fluid Level Warning Switch
4. Bulb Check Relay
5. Meter Circuit Plate
6. Wire Harness-
BE-53
BE-53
BE-53
BE-43
-
SRS Warning light does not light up.
1. AM2 - Fuse
2. Bulb
3. Airbag Sensor Assembly
4. Meter Circuit Plate
5. Wire Harness-
-
RS-62
RS-67
BE-43
Open Door warning light does not light up.
1. DOME Fuse
2. Bulb
3. Door Courtesy Switch
4. Body Control System
5. Meter Circuit Plate
6. Wire Harness-
-
BE-31
DI-615
BE-43
-
Washer Level warning light does not light up.
1. Bulb
2. Washer Fluid Level Warning Switch
3. Meter Circuit Plate
4. Wire Harness-
BE-53
BE-43
-
COMBINATION METER (Indicator Lights):
SymptomSuspect AreaSee page
O/D OFF indicator light does not light up.
1. Bulb
2. O/D OFF Switch
3. ECM
4. Meter Circuit Plate
5. Wire Harness-
DI-203
DI-1
BE-43
-
Cruise Control indicator light does not light up.
1. Bulb
2. Cruise Control ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-549
BE-43
-
High beam indicator light does not light up.
1. Bulb and Taillight
2. Headlight System
3. Meter Circuit Plate
4. Wire Harness-
BE-2
BE-43
-
Turn indicator light does not light up.
1. Bulb
2. Turn Signal and Hazard Warning System
3. Meter Circuit Plate
4. Wire Harness-
BE-2
BE-43
-
Page 310 of 1897
BE-6
- BODY ELECTRICALTROUBLESHOOTING
1610 Author: Date:
2001 AVALON (RM808U) Shift indicator lights do not light up.
1. Bulb
2. Park/Neutral Position Switch
3. Meter Circuit Plate
4. Wire Harness-
DI-199
BE-43
-
Only one shift indicator does not light up.1. Bulb
2. Meter Circuit Plate-
BE-43
Malfunction indicator light does not light up.
1. Bulb
2. ECM
3. Meter Circuit Plate
4. Wire Harness-
DI-1
BE-43
-
SLIP indicator light does not light up.
1. Bulb
2. ABS & TRAC ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-250
BE-43
-
TRAC OFF indicator light does not light up.
1. Bulb
2. ABS & TRAC ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-250
BE-43
-
Security indicator light does not light up.
1. LED
2. Theft Deterrent ECU
3. Meter Circuit Plate
4. Wire Harness-
DI-517
BE-43
-
Indicator lights do not light up. (Except Turn, Hi-beam and
security)1. GAUGE Fuse
2. Wire Harness-
-
DEFOGGER SYSTEM:
SymptomSuspect AreaSee page
All defogger systems do not operate.
1. SEAT HEATER Fuse
2. DEF Fuse
3. Defogger Relay
4. Defogger Switch
5. Wire Harness-
-
BE-67
DI-1
-
Rear window defogger does not operate.
1. Defogger Wire
2. Choke Coil
3. Wire HarnessBE-67
-
-
Mirror defogger does not operate.
1. MIR/HTR Fuse
2. Mirror Defogger
3. Wire Harness-
BE-67
-
POWER WINDOW CONTROL SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
POWER DOOR LOCK CONTROL SYSTEM:
This system uses the multiplex communication system, so check diagnosis system of the multiplex commu-
nication system before checking the body control system.
