- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
1688 Author: Date:
2001 AVALON (RM808U)
9. Rear LH Door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (-) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
10. Rear RH door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
4 and the negative (-) lead to terminal 5, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
11. Using an ammeter:
INSPECT DRIVER'S DOOR PTC THERMISTOR OP-
ERATION
(a) Connect the negative (-) lead from the battery to terminal
2.
(b) Connect the positive (+) lead from the ammeter to termi-
nal 1 and the negative (-) lead to battery positive (+) termi-
nal, and check that the current changes from approxi-
mately 3.2 A to less than 0.5 A within 20 to 70 seconds.
Page 262 of 1897
I12848
2
1
LOCK
UNLOCK
I12849
5 6
UNLOCK
I12854
5
6
LOCK
I07307
2
1 UNLOCK
I07308
21 LOCK
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
BE-85
1689 Author: Date:
2001 AVALON (RM808U)
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, connect the positive (+)
lead from the battery to terminal 2 and the negative (-)
lead to terminal 1, and check that the door lock moves to
the LOCK position.
If operation is not as specified, replace the door lock assembly.
12. Using an ammeter:
INSPECT PASSENGER'S DOOR PTC THERMISTOR
OPERATION
(a) Connect the negative (-) lead from the battery to terminal
6.
(b) Connect the negative (-) lead from the ammeter to termi-
nal 5 and the positive (+) lead to battery positive (+) termi-
nal, and check that the current changes from approxi-
mately 3.2 A to less than 0.5 A within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, connect the positive (+)
lead from the battery to terminal 6 and the negative (-)
lead to terminal 5, and check that the door lock moves to
the LOCK position.
If operation is not as specified, replace the door lock assembly.
13. Using an ammeter:
INSPECT REAR LH DOOR PTC THERMISTOR OP-
ERATION
(a) Connect the negative (-) lead from the battery to terminal
2.
(b) Connect the negative (-) lead from the ammeter to termi-
nal 1 and the positive (+) lead to battery positive (+) termi-
nal, and check that the current changes from approxi-
mately 3.2 A to less than 0.5 A within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, connect the positive (+)
lead from the battery to terminal 2 and the negative (-)
lead to terminal 1, and check that the door lock moves to
the LOCK position.
If operation is not as specified, replace the door lock assembly.
Page 263 of 1897
I07309
43 UNLOCK
I07310
43 LOCK
I12850
2 1
UNLOCK
I12851
21
LOCK
UNLOCK
I12852
5 6
UNLOCK
BE-86
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
1690 Author: Date:
2001 AVALON (RM808U)
14. Using an ammeter:
INSPECT REAR RH PTC THERMISTOR OPERATION
(a) Connect the negative (-) lead from the battery to terminal
4.
(b) Connect the negative (-) lead from the ammeter to termi-
nal 3 and the positive (+) lead to battery positive (+) termi-
nal, and check that the current changes from approxi-
mately 3.2 A to less than 0.5 A within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, connect the positive (+)
lead from the battery to terminal 4 and the negative (-)
lead to terminal 3, and check that the door lock moves to
the LOCK position.
If operation is not as specified, replace the door lock assembly.
15. Using an ammeter with a current-measuring probe:
INSPECT DRIVER'S DOOR PTC THERMISTOR OP-
ERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (-) lead to terminal 2.
(b) Attach a current-measuring probe to either the positive
(+) lead or the negative (-) lead, and check that the cur-
rent changes from approximately 3.2 A to less than 0.5 A
within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, reverse the polarity, and
check that the door lock moves to the LOCK position.
If operation is not as specified, replace the door lock assembly.
16. Using an ammeter with a current-measuring probe:
INSPECT PASSENGER'S DOOR PTC THERMISTOR
OPERATION
(a) Connect the positive (+) lead from the battery to terminal
5 and the negative (-) lead to terminal 6.
(b) Attach a current-measuring probe to either the positive
(+) lead or the negative (-) lead, and check that the cur-
rent changes from approximately 3.2 A to less than 0.5 A
within 20 to 70 seconds.
Page 264 of 1897
I12853
5 6
LOCK
I07317
21 UNLOCK
I07308
21 LOCK
I07319
4
3
UNLOCK
I07310
43 LOCK
- BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
BE-87
1691 Author: Date:
2001 AVALON (RM808U)
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, reverse the polarity, and
check that the door lock moves to the LOCK position.
If operation is not as specified, replace the door lock assembly.
17. Using an ammeter with a current-measuring probe:
INSPECT REAR LH DOOR PTC THERMISTOR OP-
ERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (-) lead to terminal 2.
(b) Attach a current-measuring probe to either the positive
(+) lead or the negative (-) lead, and check that the cur-
rent changes from approximately 3.2 A to less than 0.5 A
within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, reverse the polarity, and
check that the door lock moves to the LOCK position.
If operation is not as specified, replace the door lock assembly.
18. Using an ammeter with a current-measuring probe:
INSPECT REAR RH DOOR PTC THERMISTOR OP-
ERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (-) lead to terminal 4.
(b) Attach a current-measuring probe to either the positive
(+) lead or the negative (-) lead, and check that the cur-
rent changes from approximately 3.2 A to less than 0.5 A
within 20 to 70 seconds.
(c) Disconnect the leads from terminals.
(d) Approximately 60 seconds later, reverse the polarity, and
check that the door lock moves to the LOCK position.
If operation is not as specified, replace the door lock assembly.
Page 265 of 1897
