Page 461 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 4
Maintenance and care
461
4-3. Do-it-yourself maintenance
Partly remove the fender liner
and unplug the connector while
depressing the lock release.
Turn the bulb base counterclock-
wise.
Exchange th

Page 462 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 462 4-3. Do-it-yourself maintenance
Turn and secure the socket and
plug the connector.
After installing the socket, turn the
fog lights on once and visually
confirm that no light is leaking
through th

Page 463 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 4
Maintenance and care
463
4-3. Do-it-yourself maintenance
Remove the light bulb.
■ Front side marker lights
Remove the fender liner clip.
Partly remove the fender liner
and turn the bulb base count

Page 464 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 464 4-3. Do-it-yourself maintenance
Remove the light bulb.
■ Auxiliary lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.STEP3
STEP1
STEP2

Page 465 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 4
Maintenance and care
465
4-3. Do-it-yourself maintenance
■
Rear turn signal lights, stop lights and rear side marker lights
Open the trunk and remove the
cover as follows.
Turn the bulb bases coun

Page 466 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 466 4-3. Do-it-yourself maintenance
■Back-up lights
Open the trunk and remove the
trunk panel cover.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
STEP1
STEP2
STEP3

Page 467 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 4
Maintenance and care
467
4-3. Do-it-yourself maintenance
■
License plate light
Remove the cover.
To prevent damaging the vehicle,
wrap the flathead screwdriver
with a tape.
Remove the light bulb.

Page 468 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 468 4-3. Do-it-yourself maintenance
■Bulbs other than the above
If any of the bulbs listed below  has burnt out, have your Toyota
dealer replace it.
● Headlights (discharge bulb)
● Side turn sig

Page 469 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 4
Maintenance and care
469
4-3. Do-it-yourself maintenance
CAUTION
■
Replacing light bulbs
●Turn off the headlights. Do not attempt to replace the bulb immediately
after turning off the headlights

Page 470 of 580

TOYOTA AVALON 2012 XX40 / 4.G Owners Manual 470 4-3. Do-it-yourself maintenance
CAUTION
■High-intensity discharge (HID) headlights (if equipped)
●Contact your Toyota dealer before replacing high-intensity discharge
headlights (including lig
