TOYOTA AVALON 2014 XX40 / 4.G Owners Manual

2515-2. Using the audio system
5
Interior features
AVALON (U)_(OM41452U)
CAUTION
• This equipment complies with FCC/IC radiation exposure limits set forthfor an uncontrolled environment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of
the IC radio frequency (RF) Exposure rules. This equipment has very
low levels of RF energy that it deemed to comply without maximum per-
missive exposure evaluation (MPE). But it is desirable that it should be
installed and operated keeping the radiator at least 20 cm or more away
from person’s body (excluding extremities: hands, wrists, feet and
ankles).
• Cet équipement est conforme aux limites d’exposition aux rayonne- ments énoncées pour un environnement non contrôlé et respecte les
règles les radioélectriques (RF) de la FCC lignes directrices d’exposi-
tion dans le Supplément C à OET65 et d’exposition aux fréquences
radioélectriques (RF) CNR-102 de l’IC. Cet équipement émet une éner-
gie RF très faible qui est considérée conforme sans évaluation de
l’exposition maximale autorisée.
Cependant, cet équipement doit être installé et utilisé en gardant une
distance de 20 cm ou plus entre le dispositif rayonnant et le corps (à
l’exception des extrémités : mains, poignets, pieds et chevilles).
• Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain
approved for the transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type and its gain should
be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is
not more than that necessary for successful communication.
• Conformément à la réglementation d’Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d’un type et d’un
gain maximal (ou inférieur) approuvé pour l’émetteur par Industrie
Canada. Dans le but de réduire les risques de brouillage radioélectrique
à l’intention des autres utilisateurs, il faut choisir le type d’antenne et
son gain de sorte que la puissance isotrope rayonnée équivalente
(p.i.r.e.) ne dépasse pas l’intensité nécessaire à l’établissement d’une
communication satisfaisante.

2525-2. Using the audio system
AVALON (U)_(OM41452U)
CAUTION
●Laser products
• Do not take this unit apart or attempt to make any changes yourself.
This is an intricate unit that uses a laser pickup to retrieve information
from the surface of compact discs. The laser is carefully shielded so
that its rays remain inside the cabinet. Therefore, never try to disassem-
ble the player or alter any of its parts since you may be exposed to laser
rays and dangerous voltages.
• This product utilizes a laser. Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL
INCREASE EYE HAZARD.

2535-2. Using the audio system
5
Interior features
AVALON (U)_(OM41452U)
Push the tray forward until it
locks.
Open the cover and connect
the portable audio device.
■Operating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle's audio controls. All other
adjustments must be made on the portable audio device itself.
■ When using a portable audio devi ce connected to the power outlet
Noise may occur during playback. Use the power source of the portable
audio device.
Using the USB/AUX por t
This port can be used to connect a portable audio device and lis-
ten to it through the vehicle’s speakers.
1
2

254
AVALON (U)_(OM41452U)
5-3. Using the interior lights
Interior lights list
Outer foot lights (if equipped)
Rear personal/interior lights
( P. 255)
Front personal/interior lights
(  P. 255) Ambient lights (if equipped)
(
 P. 256)
Front door courtesy lights1
2
3
4
5

2555-3. Using the interior lights
5
Interior features
AVALON (U)_(OM41452U)
Turns the lights on/off
Turns the lights on/off linked to
door position
■Front
Turns the light on/off
■Rear
Turns the light on/off
If the lights are turned on by the
personal/interior light main
switch, the lights cannot turn off
by pressing the switch.
Personal/interior light main switch
1
2
Personal/interior lights

2565-3. Using the interior lights
AVALON (U)_(OM41452U)
Each time the “MOOD” switch is
pressed, the brightness level
changes.
■Illuminated entry system
The lights automatically turn on/off according to engine switch mode, the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are opened/closed.
■ To prevent battery discharge
If the personal/interior lights remain on when the engine switch is turned off,
the lights will go off automatically after 20 minutes.
■ Customization
Setting (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features: P. 453)
Ambient lights (if equipped)
NOTICE
■To prevent battery discharge
Do not leave the lights on longer than necessary when the engine is not
running.

257
5
Interior features
AVALON (U)_(OM41452U)
5-4. Using the storage features
List of storage features
Auxiliary boxes (P. 261)
Glove box ( P. 258) Cup holders (
P. 260)
Console box ( P. 259)
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
● Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
■ When driving or when the storag e compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4

2585-4. Using the storage features
AVALON (U)_(OM41452U)
Open (pull up the lever)
Lock with the mechanical key
Unlock with the mechanical key
■Removing the insert
The insert inside the glove box can be removed.
Glove box
1
2
3
CAUTION
■Caution while driving
Keep the glove box closed. In the event of sudden braking or sudden swerv-
ing, an accident may occur due to an occupant being struck by the open
glove box or the items stored inside.

2595-4. Using the storage features
5
Interior features
AVALON (U)_(OM41452U)
Lift the lid while pulling up the
lever to release the lock.
■When using the console box lid as an armrest
■ Tray in the console box
Console box
Slide the console box lid forward as
needed. Slide the lid forward while pulling
up the lever.
The lid can also be opened from the for-
wardmost position.
The tray slides forward/backward and can
be removed.

2605-4. Using the storage features
AVALON (U)_(OM41452U)
Front
Rear (type A)
Pull down the armrest.
Rear (type B)
Pull down the armrest and open
the lid.
CAUTION
■Caution while driving
Keep the console box closed. In the event of sudden braking, an accident
may occur due to an occupant being struck by the open console box or the
items stored inside.
Cup holders
