warning TOYOTA AVALON 2021 (in English) Owner's Guide

701-1. For safe use
Exhaust gas precautions
Harmful substance to the human body is included in exhaust
gases if inhaled.
WARNING
Exhaust gases include harmful carbon monoxide (CO), which is colorless and
odorless. Observe the following precautions.
Failure to do so may cause exhaust gases enter the vehicle and may lead to
an accident caused by light-headedness, or may lead to death or a serious
health hazard.
■Important points while driving
●Keep the trunk lid closed.
●If you smell exhaust gases in the vehicle even when the trunk lid is closed,
open the windows and have the vehicle inspected at your Toyota dealer as
soon as possible.
■When parking
●If the vehicle is in a poorly ventilated area or a closed area, such as a
garage, stop the engine.
●Do not leave the vehicle with the engine on for a long time.
If such a situation cannot be avoided, park the vehicle in an open space
and ensure that exhaust fumes do not enter the vehicle interior.
●Do not leave the engine running in an area with snow build-up, or where it
is snowing. If snowbanks build up around the vehicle while the engine is
running, exhaust gases may collect and enter the vehicle.
■Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or
crack caused by corrosion, damage to a joint or abnormal exhaust noise, be
sure to have the vehicle inspected and repaired by your Toyota dealer.

791-3. Theft deterrent system
1
For safety and security
WARNING
■Certifications for the engine immobilizer system
Changes or modifications not expressly approved by the party responsible
<00490052005500030046005200500053004f004c00440051004600480003004600520058004f0047000300590052004c004700030057004b00480003005800560048005500b600560003004400580057004b00520055004c0057005c000300570052000300
5200530048005500440057004800030057004b004800030048[quipment.
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

83
Instrument cluster2
2. Instrument cluster
Warning lights and
indicators .......................... 84
Gauges and meters ............ 90
Multi-information display ..... 93
Head-up display ................ 109
Fuel consumption
information ...................... 116

842. Instrument cluster
The units used on the meters and some indicators may differ depending on
the target region.
Warning lights and indicators
The warning lights and indicators on the instrument cluster, cen-
ter panel and outside rear view mirrors inform the driver of the
status of the vehicle’s various systems.
For the purpose of explanation, the following illustrations dis-
play all warning lights and indicators illuminated.

852. Instrument cluster
2
Instrument cluster
Warning lights inform the driver of malfunctions in the indicated vehi-
cle’s systems.
Warning lights
*1
(U.S.A.)
Brake system warning
light (P. 434)*1
(U.S.A.)
ABS warning light
(P. 435)
*1
(Canada)
(Red)
Brake system warning
light (P. 434)
*1
(Canada)
ABS warning light
(P. 435)
*1
(Yellow)
Brake system warning
light (P. 434)*2Brake Override System/
Drive-Start Control/Intel-
ligent Clearance Sonar
(if equipped) warning
light (P. 435)
*2High coolant tempera-
ture warning light
(P. 434)
(U.S.A.)
Parking brake indicator
(P. 436)
*2Charging system
warning light (P. 434)
(Canada)
Parking brake indicator
(P. 436)
*2Low engine oil pressure
warning light (P. 434)*1, 3Brake hold operated
indicator (P. 436)
*1
(U.S.A.)
Malfunction indicator
lamp (P. 435)*1
(Red/yellow)
Electric power steering
system warning light
(P. 436)
*1
(Canada)
Malfunction indicator
lamp (P. 435)*1, 4PCS warning light
(P. 437)
*1SRS warning light
(P. 435)*1, 3
(if equipped)
ICS OFF indicator
(P. 437)

862. Instrument cluster
*1: These lights turn on when the engine switch is turned to IGNITION ON
mode to indicate that a system check is being performed. They will turn off
after the engine is started, or after a few seconds. There may be a mal-
function in a system if a light does not come on, or turn off. Have the vehi-
cle inspected by your Toyota dealer.
*2: This light illuminates on the multi-information display.
*3: This light flashes to indicate a malfunction.
*4: This light flashes or illuminates to indicate a malfunction.
*5: This light illuminates on the center panel.
*2
(Amber)
LDA indicator (P. 436)
*5Rear passengers’ seat
belt reminder lights
(P. 438)
*1
Slip indicator (P. 437)*1Master warning light
(P. 438)
Low fuel level warning
light (P. 437)*1Tire pressure warning
light (P. 438)
Driver’s and front
passenger’s seat belt
reminder light (P. 438)

872. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
Turn signal indicator
(P. 195)*1Brake hold standby
indicator (P. 200)
(U.S.A.)
Headlight indicator
(P. 202)*2Cruise control indicator
(P. 247)
(Canada)
Tail light indicator
(P. 202) *2Dynamic radar cruise
control indicator
(P. 247)
Headlight high beam
indicator (P. 203)
*2Cruise control “SET”
indicator (P. 247)
*2Automatic High Beam
indicator (P. 206)*1, 4PCS warning light
(P. 230)
*1, 2, 3
Eco driving indicator
(P. 107)*1, 4
(if equipped)
ICS OFF indicator
(P. 287)
(U.S.A.)
Parking brake indicator
(P. 196)*2
(White)
LDA indicator (P. 237)
(Canada)
Parking brake indicator
(P. 196)*2
(Green)
LDA indicator (P. 237)
*1
Brake hold operated
indicator (P. 200)*2, 5
(Amber)
LDA indicator (P. 237)

892. Instrument cluster
2
Instrument cluster
*1: These lights turn on when the engine switch is turned to IGNITION ON
mode to indicate that a system check is being performed. They will turn off
after the engine is started, or after a few seconds. There may be a mal-
function in a system if a light does not come on, or turn off. Have the vehi-
cle inspected by your Toyota dealer.
*2: This light illuminates on the multi-information display.
*3: This light does not turn on when the system is disabled.
*4: This light turns on when the system is off.
*5: This light flashes to indicate that the system is operating.
*6: These indicators will illuminate in the following situations to indicate that
the system initial check is being performed:
• When the BSM function or RCTA function is enabled and the engine
switch is turned to IGNITION ON mode.
• When the engine switch is in IGNITION ON mode and the BSM function
is enabled.
• When the engine switch is in IGNITION ON mode and the RCTA func-
tion is enabled. (At this time, a buzzer will also sound.)
The indicators will turn off after a few seconds. If the indicators do not
illuminate or turn off, or if a buzzer does not sound when the RCTA func-
tion is enabled, the system may be malfunctioning. Have the vehicle
inspected by your Toyota dealer.
*7: This light illuminates on the outside rear view mirrors.
*8: This light illuminates on the center panel.
*9: When the outside temperature is approximately 37°F (3°C) or lower, this
indicator will flash for approximately 10 seconds, then stay on.
WARNING
■If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning lights not
come on when you start the engine, this could mean that these systems are
not available to help protect you in an accident, which could result in death
or serious injury. Have the vehicle inspected by your Toyota dealer immedi-
ately if this occurs.

902. Instrument cluster
The units used on the meters may differ depending on the target region.
Tachometer
Displays the engine speed in revolutions per minute
Shift position (P. 1 8 9 )
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to
122°F (50°C). Low outside temperature indicator comes on when the
ambient temperature is 37°F (3°C) or lower.
Multi-information display
<0033005500480056004800510057005600030057004b0048000300470055004c0059004800550003005a004c0057004b000300440003005900440055004c00480057005c000300520049000300590048004b004c0046004f00480003004700440057004400
03000b[P. 93)
Displays warning messages in case of a malfunction (P. 444)
Speedometer
Fuel gauge
Odometer and trip meter P. 1 0 6 )
Engine coolant temperature gauge
Displays the engine coolant temperature
Gauges and meters
1
2
3
4
5
6
7
8

942. Instrument cluster
Content display area
A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.
• Menu icon content (P. 96)
• Suggestion function (P. 106)
• Warning message (P. 444)
Odometer/trip meter (P. 106)
Shift position (P. 1 8 9 )
Outside temperature (P. 9 0 )
Menu icons (P. 96)
“ODO/TRIP” switch (P. 9 5 )
Meter control switches (P. 94)
◆Using the content display area
The content display area is operated using the meter control
switches.
Scroll screens
*, change the
displayed content
* and move
the cursor
Press: Enter/Set
Press and hold: Reset/Dis-
play the next screen
Return to the previous
screen
Pressing and holding the switch will display the first screen of the
selected menu icon.
Call sending/receiving display
Linked with the hands-free system, sending or receiving call is dis-
played. For details regarding the hands-free system, refer to the “NAVI-
GATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
*: When the screen can be scrolled or different content can be displayed,
a mark, such as an arrow, will be displayed to suggest which switch to
operate.
Using the multi-information display
6
7
8
9
10
11
12
1
2
3
4
