902. Instrument cluster
The units used on the meters may differ depending on the target region.
Tachometer
Displays the engine speed in revolutions per minute
Shift position (P. 1 8 9 )
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to
122°F (50°C). Low outside temperature indicator comes on when the
ambient temperature is 37°F (3°C) or lower.
Multi-information display
<0033005500480056004800510057005600030057004b0048000300470055004c0059004800550003005a004c0057004b000300440003005900440055004c00480057005c000300520049000300590048004b004c0046004f00480003004700440057004400
03000b[P. 93)
Displays warning messages in case of a malfunction (P. 444)
Speedometer
Fuel gauge
Odometer and trip meter P. 1 0 6 )
Engine coolant temperature gauge
Displays the engine coolant temperature
Gauges and meters
1
2
3
4
5
6
7
8

942. Instrument cluster
Content display area
A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.
• Menu icon content (P. 96)
• Suggestion function (P. 106)
• Warning message (P. 444)
Odometer/trip meter (P. 106)
Shift position (P. 1 8 9 )
Outside temperature (P. 9 0 )
Menu icons (P. 96)
“ODO/TRIP” switch (P. 9 5 )
Meter control switches (P. 94)
◆Using the content display area
The content display area is operated using the meter control
switches.
Scroll screens
*, change the
displayed content
* and move
the cursor
Press: Enter/Set
Press and hold: Reset/Dis-
play the next screen
Return to the previous
screen
Pressing and holding the switch will display the first screen of the
selected menu icon.
Call sending/receiving display
Linked with the hands-free system, sending or receiving call is dis-
played. For details regarding the hands-free system, refer to the “NAVI-
GATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
*: When the screen can be scrolled or different content can be displayed,
a mark, such as an arrow, will be displayed to suggest which switch to
operate.
Using the multi-information display
6
7
8
9
10
11
12
1
2
3
4

952. Instrument cluster
2
Instrument cluster
◆Using the odometer/trip meter
Items in this area are operated using the “ODO/TRIP” switch.
Press: Change displayed item
Each time the switch is pressed,
the displayed item will be
changed.
Press and hold: Reset
Display the desired trip meter
and press and hold the switch to
reset the trip meter.

1062. Instrument cluster
■Odometer
Displays the total distance the vehicle has been driven.
■Trip meter A/trip meter B
Displays the distance the vehicle has been driven since the meter
was last reset. Trip meters A and B can be used to record and dis-
play different distances independently.
To reset, display the desired trip meter and press and hold the “ODO/
TRIP” switch.
Displays suggestions to the driver in the following situations. To select
a response to a displayed suggestion, use the meter control switches.
The suggestion function can be turned on/off.
(Customizable features:P. 505)
■
Suggestion to turn off the headlights
If the headlights are left on for a certain amount of time after the
engine switch has been turned off, if the headlight switch is in the
“AUTO” position, a suggestion message will be displayed asking if
you wish to turn the headlights off. To turn the headlights off, select
“Yes”.
If a front door is opened after the engine switch is turned off, this sug-
gestion message will not be displayed.
Odometer/trip meter
Suggestion function

541Alphabetical index
Multi-information display .......... 93
Driving information .................. 97
Dynamic radar cruise control
with full-speed range .......... 247
Language .............................. 105
LDA (Lane Departure Alert
with steering control) .......... 242
Outside temperature ............... 90
PCS (Pre-Collision
System) .............................. 230
Settings ................................. 100
Suggestion function .............. 106
Warning messages ............... 444
Navigation system
*
Noise from under vehicle............ 8
Odometer.................................... 90
Oil
Engine oil .............................. 481
Opener
Fuel filler door ....................... 216
Hood ..................................... 381
Trunk..................................... 131
Outside rear view mirrors ....... 157
Adjusting and folding ............ 157
Blind spot monitor (BSM) ...... 260
Linked mirror function
when reversing ................... 158
Mirror position memory ......... 146
Outside rear view mirror
defoggers ........................... 324
Outside temperature
display ...................................... 90
Overheating.............................. 471Paddle shift switches .............. 191
Panic mode .............................. 123
Panoramic view monitor
*
Parking brake........................... 196
Parking brake engaged
warning buzzer/
message............................. 199
Warning light......................... 436
Parking lights........................... 202
Light switch ........................... 202
Replacing light bulbs ............ 421
PCS
(Pre-Collision System).......... 226
Warning light......................... 437
Personal lights......................... 333
Power outlet ............................. 343
Power steering
(Electric power steering
system) .................................. 310
Warning light......................... 436
Power windows ....................... 160
Door lock linked window
operation ............................ 162
Jam protection function ........ 160
Operation .............................. 160
Window lock switch .............. 160
Pre-Collision System
(PCS) ...................................... 226
Warning light......................... 437
Premium Audio
*
N
O
P
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.
