turn signal TOYOTA BZ4X 2023 Owner's Manual

4446-4. Using the other interior features
Owners Manual_USA_M42C01_en
1Press and hold the desired
HomeLink
® button.
2 When the HomeLink
® indica-
tor starts flashing orange,
release the HomeLink
® but-
ton and perform “Program-
ming HomeLink
®” 1 (it takes
20 seconds for the Home-
Link
® indicator to start flash-
ing).
■Before programming
●Install a new battery in the trans-
mitter.
●The battery side of the transmitter
must be pointed away from the
HomeLink
® buttons.
Press the appropriate Home-
Link
® button. The HomeLink®
indicator light should turn on.
The status of the opening and
closing of a garage door is
shown by the garage door oper-
ation indicators.
Vehicles with auto anti-glare
inside rear view mirror Opening
Closing
Vehicles with Digital Rear-
view Mirror
Opening
Closing
This function is only available if the
garage door opener motor used is a
compatible device. (To check
device compatibility, refer to
www.homelink.com.)
The indicators can operate
within approximately 820 ft. (250
m) of the garage door. However,
if there are obstructions
between the garage door and
the vehicle, such as houses and
trees, feedback signals from the
garage door may not be
received.
Operating HomeLink®
ColorStatus
Orange (flash- ing)Currently open-
ing/closing
GreenOpening/closing
has completed
Red (flashing)
Feedback sig-
nals cannot be
received

4757-3. Do-it-yourself maintenance
Owners Manual_USA_M42C01_en
7
Maintenance and care
■How to change the unit
1 Park the vehicle in a safe
place and EV system off.
2 Start the EV system.
Changing the unit cannot be per-
formed while the vehicle is moving.
3Press or of the meter
control switch to select .
4 Press or of the meter
control switches and select
“Vehicle Settings” and then
press and hold “OK”.
5 Press or of the meter
control switches and select
“TPWS setting” and then
press “OK”.
6 Press or of the meter
control switches and select
“Setting Unit” and then press
“OK”.
7 Press or of the meter
control switches and select
the desired unit and then
press “OK”.
■Routine tire inflation pressure
checks
The tire pressure warning system
does not replace routine tire inflation
pressure checks . Make sure to
check tire inflation pressure as part
of your routine o f daily vehicle
checks.
■Tire inflation pressure
●It may take a few minutes to dis-
play the tire inflation pressure
after the power switch is turned to
ON. It may also take a few min-
utes to display the tire inflation
pressure after infl ation pressure
has been adjusted.
●Tire inflation pressure changes
with temperature.
The displayed values may also be
different from the values mea-
sured using a tire pressure gauge.
■Situations in which the tire
pressure warning system may
not operate properly
●In the following cases, the tire
pressure warning system may not
operate properly.
• If non-genuine Toyota wheels are used.
• A tire has been replaced with a
tire that is not an OE (Original
Equipment) tire.
• A tire has been replaced with a
tire that is not of the specified size.
• Tire chains etc. are equipped.
• If a window tint that affects the radio wave signals is installed.
• If there is a lot of snow or ice on the vehicle, particularly around the
wheels or wheel housings.
• If the tire inflation pressure is extremely higher than the speci-
fied level.
• If wheels without tire pressure warning valves and transmitters
are used.
• If the ID code on the tire pressure warning valves and transmitters is
not registered in the tire pressure
warning computer.

5048-1. Essential information
Owners Manual_USA_M42C01_en
8-1.Essential information
Press the switch.
All the turn signal lights will flash.
To turn them off, press the switch
once again.
■Emergency flashers
●If the emergency flashers are
used for a long time while the EV
system is not operating (while the
“READY” indicator is not illumi-
nated), the 12-volt battery may
discharge.
●If any of the SRS airbags deploy
(inflate) or in the event of a strong
rear impact, the emergency flash-
ers will turn on automatically.
The emergency flashers will turn
off automatically after operating
for approximately 20 minutes. To
manually turn t he emergency
flashers off, press the switch
twice. (The emergency flashers
may not turn on automatically
depending on the force of the
impact and conditions of the colli- sion.)
Emergency flashers
The emergency flashers are
used to warn other drivers
when the vehicle has to be
stopped in the road due to a
breakdown, etc.
Operating instructions

5729-2. Customization
Owners Manual_USA_M42C01_en
■Reverse warning buzzer
■Automatic light control system (P.248)
■PCS (Pre-Collision System) ( P.265)
■LDA (Lane Departure Alert) (P.281)
■Dynamic radar cruise control ( P.288)
FunctionDefault settingCustomized
setting
Signal (buzzer) when the
shift position is in RContinualMute––O
FunctionDefault settingCustomized setting
Light sensor sensitivityStandard–2 to 2O–O
Time elapsed before head-
lights automatically turn off
after doors are closed
30 seconds
Off
O–O60 seconds
90 seconds
Windshield wiper linked
headlight illuminationOnOff––O
FunctionCustomized setting
Pre-Collision SystemON/OFF–O–
Warning timingLater/Default/Earlier–O–
FunctionCustomized setting
Lane Departure Alert systemON/OFF–O–
Alert timingDefault/Earlier–O–
Alert optionsVibration/Beep–O–
FunctionCustomized setting
Extended Resume TimeON/OFF–O–
Acceleration settingHigh/Mid/Low–O–
Guide messageON/OFF–O–
Curve speed reductionOFF/High/Mid/Low–O–

602Alphabetical Index
Owners Manual_USA_M42C01_en
............................................. 74
Battery Electric Vehicle driving tips........................................ 81
Brake Override System ........ 220
Drive-start control ................. 224
Driving range .......................... 83
Electric Vehicle system precau- tions...................................... 76
Emergency shut off system .... 80
Features ................................. 72
How to start the EV system .. 231
How to use AC charging....... 105
How to use DC charging ...... 113
If the EV system will not start537
If your vehicle has to be stopped in an emergency................. 505
Ignition switch (power switch) ........................................... 231
Overheating.......................... 545
Power meter ......................... 152
Power switch ........................ 231
Regenerative braking ............. 73
Starting the EV system......... 231
Event data recorder (EDR)......... 9
F
Flat tire .................................... 527 Tire pressure warning system........................................... 474
Floor mats ................................. 26
Fluid Brake .................................... 554
Front eAxle ........................... 554
Rear eAxle ........................... 554
Washer ................................. 471
Fog light Replacing light bulbs ............ 502
Footwell lights ..... ................... 415
Front eAxle Fluid ..................................... 554
Front electric mo tor (traction
motor) Specification .........................551
Front fog light Replacing light bulbs ............502
Front interior lig hts ................416
Front passenger occupant clas- sification system ....................44
Front seat concentrated airflow mode (S-FLOW) ....................408
Front seats ..............................192 Adjustment ...........................192
Cleaning ...............................451
Correct driving posture ...........27
Head restraints .....................196
Seat heaters ......................... 411
Seat ventilators..................... 411
Front side marker lights.........248 Light switch...........................248
Front turn signal lights Replacing light bulbs ............502
Turn signal lever ...................242
Fuses .......................................499
G
Garage door opene r ...............439
Gauges ....................................152
Grip Control ............................385
H
Head restraints .......................196
Headlights ...............................248 Automatic High Beam (AHB) 250
Light switch...........................248
Replacing light bulbs ............502
Headlights aim ........................501 Headlight aim instructions for Canadian owners ...............590
Heated steering wheel............ 411
Heater system Capacity ...............................553

604Alphabetical Index
Owners Manual_USA_M42C01_en
L
Lane Departure A lert (LDA) ... 281
Operation ............................. 281
Warning lights....................... 516
Lane Tracing Assist (LTA)...... 276 Operation ............................. 276
Warning lights....................... 516
Language (multi-information dis- play) ............................... 158, 567
LATCH anchors ........................ 59
LDA (Lane Departure Alert) ... 281 Operation ............................. 281
Warning lights....................... 516
Lever Auxiliary catch lever ............. 462
Hood lock release lever........ 462
Turn signal lever ................... 242
Wiper lever ........................... 253
License plate lights Light switch .......................... 248
Replacing light bulbs ............ 502
Light bulbs Replacing ............................. 502
Lights Automatic High Beam (AHB) 250
Emergency flasher switch .... 504
Headlight switch ................... 248
Interior light list ..................... 415
Interior lights......................... 416
Luggage compartment light 174, 178
Personal lights...................... 417
Replacing light bulbs ............ 502
Turn signal lever ................... 242
Vanity lights .......................... 428
Load capacity ......................... 228
Locking and unlocking the AC charging c onnector................ 93
LTA (Lane Tracing Assist) ...... 276 Operation ............................. 276
Warning lights....................... 516 Luggage compartment light 174,
178
Luggage cover ........................423
M
Maintenance AC charging cable ..................92
Do-it-yourself maintenance ..460
General maintenance ...........456
Maintenance data .................550
Maintenance requirements ...455
Menu icons ..............................156
Meter Clock ....................................152
Indicators ..............................149
Instrument panel light control155
Meter control switches..........156
Meters ..................................152
Multi-information display.......155
Settings ........................158, 566
Units .....................................567
Warning lights .......................513
Warning message.................522
Mirrors Digital Rear-view Mirror ........201
Inside rear view mirror ..........200
Outside rear view mirror defog-gers ....................................404
Outside rear view mirrors .....210
Vanity mirrors........................428
Motor Compartment........................465
Multi-information display .......155
Audio system-linked display .157
Charging101, 121, 129, 131, 140
Clock ....................................154
Convenience Services (Sugges- tion function) .......................567
Cruise control .......................297
Driving information display ...157
Driving support system informa- tion display .........................157

606Alphabetical Index
Owners Manual_USA_M42C01_en
Power control unit coolant Checking .............................. 465
Preparing and c hecking before
winter.................................. 393
Radiator................................ 466
Power meter ............................ 152
Power outlets .......................... 428
Power sources .......................... 96
Power steering (Electric Power Steering system) .................. 387
Power steering (Electric power steering system)Warning light ........................ 515
Power switch .......................... 231 Auto power off function ........ 235
Changing the power switch modes ................................ 234
If your vehicle has to be stopped in an emergency................. 505
Starting the EV system......... 231
Power windows Catch protection function ..... 212
Door lock linked window opera-tion ..................................... 213
Jam protection function ........ 212
Operation ............................. 212
Window lock switch .............. 214
Pre-Collision System (PCS)... 265 Enabling/disabling the system........................................... 275
Function ............................... 265
Warning light ........................ 518
R
Radar cruise control .............. 296
Radar cruise control (dynamic radar cruise control) ............ 288
Radiant heaters ...................... 411
RCD (Rear Camera Detection) ............................................... 328Enabling/disabling the system ........................................... 329 RCTA (Rear Cross Traffic Alert)
...............................................322Enabling/disabling the system ...........................................323
Rear Camera Detection (RCD) ...............................................328Enabling/disabling the system ...........................................329
Rear Cross Traffic Alert (RCTA) ...............................................322Enabling/disabling the system ...........................................323
Rear eAxle Fluid......................................554
Rear electric motor (traction motor)Specification .........................552
Rear fog light Replacing light bulbs ............502
Rear interior lights..................416
Rear seat Folding down the rear seatbacks...........................................194
Rear seats ...............................193 Adjustment ...........................193
Head restraints .....................196
Seat heaters ......................... 411
Rear side marker lights Light switch...........................248
Rear turn signal lights Replacing light bulbs ............502
Turn signal lever ...................242
Rear view mirror Digital Rear-view Mirror ........201
Inside rear view mirror ..........200
Outside rear view mirrors .....210
Rear window defogger ...........404
Regeneration Boost Switch ...240
Regenerative braking ...............73 Warning lights .......................513
Remote Air Conditioning System ...............................................409

608Alphabetical Index
Owners Manual_USA_M42C01_en
RCTA (Rear Cross Traffic Alert) ........................................... 308
RCTA (Rear Crossing Traffic Alert)................................... 303
SEA (Safe Exit Assist) .. 303, 308
Toyota Teammate Advanced Park .................................... 311
Service plug .............................. 76
Shift lights ............................... 415
Side airbags .............................. 34
Side doors ............................... 167
Side marker lights Light switch .......................... 248
Side mirrors ............................ 210 Adjustment ........................... 210
BSM (Blind Spot Monitor)..... 302
Folding ................................. 210
Heaters................................. 404
Outside rear view mirror defog-gers .................................... 404
RCTA (Rear Cross Traffic Alert) ........................................... 322
SEA (Safe Exit Assist) .......... 307
Side turn signal lights Replacing light bulbs ............ 502
Turn signal lever ................... 242
Side windows ...... ................... 212
Smart key system ................... 187 Antenna location .................. 187
Entry functions ............. 167, 173
Starting the EV system......... 231
Snow mode ............................. 382
Snow tires ............................... 393
SOC (State of Charge) gauge 152
Software update .. ................... 257
“SOS” button ............................ 64
Specifications ......................... 550
Speedometer .......................... 152
SRS airbags .............................. 34
Steering wheel ........................ 199 Adjustment ........................... 199
Heated steering wheel ......... 411 Meter control switches..........156
Stop lights Replacing light bulbs ............502
Storage feature .. .....................418
Storage precaution s ...............418
Stuck If the vehicle becomes stuck 547
Suggestion functi on ...............159
Sun visors ...............................428
Sunshade ................................426
Switches Automatic High Beam switch 250
Brake hold switch .................246
Cruise control .......................297
Door lock switch ...................170
Dynamic radar cruise control 291
Eco mode .............................241
Electronic sunshade switch ..426
Emergency flashers switch...504
Garage door opener switches ...........................................439
Grip Control ..................382, 385
Heated steering wheel..........412
Ignition switch (power switch) ...........................................231
Light switch...........................248
LTA (Lane Tracing Assist) switch ...........................................279
Meter control switches..........156
Outside rear v iew mirror
switches..............................210
Parking brake switch ............243
Power back door s witch .......176
Power switch ........................231
Power window switch ...........212
Radiant heaters ....................413
Rear window and outside rear view mirror defoggers switch...........................................404
Regeneration Boost switch...240
Seat heater switches ............412
Snow mode switch ...............382

610Alphabetical Index
Owners Manual_USA_M42C01_en
Software update ................... 257
Toyota Teammate Advanced Park ....................................... 344Memory function................... 366
Parallel exiting function ........ 364
Parallel parking function ....... 360
Perpendicular exiting (forward/ reverse) function ................ 359
Perpendicular parking (forward/ reverse) function ................ 356
Remote control function ....... 371
TRAC (Traction Control) ........ 387
Traction battery ........................ 72 Charging....................... 105, 113
Location.................................. 72
Specification ......................... 552
Traction battery cooler............ 99
Traction battery heater ........... 99
Warning messages............... 140
Traction battery charge Warning light ........................ 515
Traction Control (TRAC) ........ 387
Trailer sway control ............... 387
Trailer towing .......................... 229
Transmission .......................... 236
Trip meters .............................. 154
Turn signal lights Replacing light bulbs ............ 502
Turn signal lever ................... 242
U
USB charging ports................ 429
Utility vehicle precautions ..... 396
V
Vanity lightsVanity lights .......................... 428
Vanity mirrors ......................... 428 Vanity lights .......................... 428
Vehicle data recordings ............. 8
Vehicle identifi cation number550 Vehicle information display ...158
Vehicle Stability Control (VSC)
...............................................387
Ventilators (seat ventilators) . 411
VSC (Vehicle Stability Control) ...............................................387
W
Warning buzzers Acceleration Suppression at Low Speed .................................268
Approach warning ................294
Brake hold ............................519
Brake Override System ........514
Brake system ........................513
Break suggestion function ....284
Cruise control .......................517
Drive-Start Control ................514
Dynamic radar cruise control 518
Electric power steering .........515
Hands off steering wheel warn- ing (LDA) ............................283
Hands off steering wheel warn- ing (LTA) .............................278
Intuitive parking assist ..319, 517
LDA (Lane Departure Alert) 281, 516
LTA (Lane Tracing Assist) ...276, 516
Open door ............................170
Open hood............................170
Open window........................213
PCS (Pre-Collisio n System) .518
Pre-collision warn ing ............266
Seat belt .......................515, 516
SRS airbag ...........................514
Tire pressure ...... ..................516
Warning lights .........................513 ABS ......................................514
Brake hold operated indicator...........................................519
Brake Override System ........514
