dimensions TOYOTA C-HR 2021 Owners Manual (in English)

4768-1. Specifications
C-HR_OM_USA_OM10684U
Maintenance data (fuel, oil level, etc.)
*1: Unladen vehicles
*2: Vehicles with 215/60R17 tires
*3: Vehicles with 225/50R18 tires
■
Vehicle identification number
The vehicle identification number (VIN) is the legal identifier for
your vehicle. This is the primary identification number for you r
Toyota. It is used in registeri ng the ownership of your vehicle .
This number is also stamped on
the top left of the instrument
panel.
Dimensions and weights
Overall length 172.6 in. (4385 mm)
Overall width 70.7 in. (1795 mm)
Overall height*161.2 in. (1555 mm)
Wheelbase103.9 in. (2640 mm)
Tread
Front61.0 in. (1550 mm)*2
60.6 in. (1540 mm)*3
Rear61.4 in. (1560 mm)*2
61.0 in. (1550 mm)*3
Vehicle capacity weight
(occupants + luggage)
825 lb. (375 kg)
Seating capacity
Seating capacity
5 (Front 2, Rear 3)
Vehicle identification

4908-1. Specifications
C-HR_OM_USA_OM10684U■
Typical tire size information
The illustration i
ndicates typical
tire size.
Tire use (P = Passenger car,
T = Temporary use)
Section widt h (millimeters)
Aspect ratio
(tire height to section width)
Tire construction code
(R = Radial, D = Diagonal)
Wheel diameter (inches)
Load index
(2 digits or 3 digits)
Speed symbol
(alphabet with one letter)
■Tire dimensions
Section width
Tire height
Wheel diameter
Tire size

535Alphabetical index
C-HR_OM_USA_OM10684U
Daytime running light system .................................... 206
Deck board ............................... 331
Defogger Outside rear view mirrors...... 315
Rear window ......................... 315
Windshield ............................ 315
Dimensions .............................. 476
Dinghy towing .......................... 179
Display Multi-information display ......... 99
Warning message ................ 444
Do-it-yourself maintenance .... 355
Door lock Back door.............................. 127
Key........................................ 121
Side doors............................. 120
Smart key system ......... 120, 127
Wireless remote control ........ 120 Doors
Back door ............................. 127
Door lock ....................... 120,127
Door windows ....................... 157
Open door warning
buzzer ........................ 125, 128
Outside rear view mirrors ..... 154
Rear door child-protector ...... 124
Side doors ............................ 120
Drive information..................... 100
Driving ...................................... 164 Break-in tips.......................... 167
Correct posture ....................... 26
Procedures ........................... 164
Winter drive tips .................... 306
D
