Page 17 of 307
17
1. NORMALLY
OPENOpens and
closes circuits,
thereby
stopping (1) or
allowing (2)
current flow.
RESISTOR
An electrical component with a
fixed resistance, placed in a circuit
to reduce voltage to a specific
value.
RESISTOR, TAPPED
A resistor which supplies two or
more different non adjustable
resistance values.
SENSOR (Thermistor)
A resistor which varies its
resistance with temperature.
SHORT PIN
Used to provide an unbroken
connection within a junction block.
SOLENOID
An electromagnetic coil which
forms a magnetic field when
current flows, to move a plunger,
etc.SWITCH, DOUBLE THROW
A switch which continuously
passes current through one set
of contacts or the other.
SWITCH,
IGNITION
A key operated switch with
several positions which allows
various circuits, particularly the
primary ignition circuit, to
become operational.
Wires are always
drawn as straight lines
on wiring diagrams.
Crossed wires (1)
without a black dot at
the junction are not
joined; crossed wires
(2) with a black dot or
octagonal (
) mark at
the junction are spliced
(joined) connections. RELAY, DOUBLE THROW
A relay which passes current
through one set of contacts or the
other.
SENSOR, ANALOG SPEED
Uses magnetic impulses to open
and close a switch to create a
signal for activation of other
components.TRANSISTOR
A solidstate device typically used
as an electronic relay; stops or
passes current depending on the
voltage applied at ªbase.º SWITCH, WIPER PARK
Automatically returns wipers to
the stop position when the wiper
switch is turned off. SWITCH, MANUAL SPEAKER
An electromechanical device
which creates sound waves from
current flow.
2. NORMALLY
CLOSED
RESISTOR, VARIABLE or
RHEOSTAT
A controllable resistor with a
variable rate of resistance.
Also called a potentiometer or
rheostat. 2. NORMALLY
OPEN RELAY
1. NORMALLY
CLOSEDBasically, an electrically
operated switch which may
be normally closed (1) or
open (2).
Current flow through a
small coil creates a
magnetic field which either
opens or closes an
attached switch.
(2) SPLICED WIRES
(1) NOT
CONNECTED
Page 28 of 307
![TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 28
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[1MZ±FE]
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure F 1 Front Airbag Sensor LH
SW) F 2 Front Airbag Sensor RH
A 3 A/](/img/14/6859/w960_6859-27.png "TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 28
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[1MZ±FE]
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure F 1 Front Airbag Sensor LH
SW) F 2 Front Airbag Sensor RH
A 3 A/")
28
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[1MZ±FE]
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure F 1 Front Airbag Sensor LH
SW) F 2 Front Airbag Sensor RH
A 3 A/C Magnetic Clutch and Lock Sensor F 3 Front Clearance Light LH
A 4 ABS Actuator F 4 Front Clearance Light RH
A 5 ABS Actuator F 5 Front Side Marker LH
A 6 ABS Relay F 6 Front Side Marker RH
A 7 ABS Relay F 7 Front Turn Signal Light LH
A 8 ABS Speed Sensor Front LH F 8 Front Turn Signal Light RH
A 9 ABS Speed Sensor Front RH F 9 Front Wiper Motor
F 10 Fuse Box
B 2 Brake Fluid Level SW F 16 Fuse Box
F 18 Fuse Box
C 2 Cruise Control Actuator
C 17 Camshaft Position Sensor G 1 Generator (Alternator)
C 18 Crankshaft Position Sensor G 2 Generator (Alternator)
D 1 Data Link Connector 1 (Check Connector) H 1 Headlight Hi LH
D 2 Distributor H 2 Headlight Hi RH
H 3 Headlight Lo LH
E 1 EGR Gas Temp. Sensor H 4 Headlight Lo RH
E 2 Electronic Controlled Transmission Solenoid H 5 Horn LH
E 4 Engine Coolant Temp. Sensor (EFI Water Temp. H 6 Horn RH
Sensor) H 11 Heated Oxygen Sensor (Bank 1 Sensor 1)
E 5 Engine Coolant Temp. Sensor (Water Temp. Sensor) H 12 Heated Oxygen Sensor (Bank 2 Sensor 1)
(for Cooling Fan)
Page 29 of 307
![TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 29
Position of Parts in Engine Compartment
[1MZ±FE]
I 1 Idle Air Control Valve (ISC Valve) N 1 Noise Filter (for Ignition System)
I 2 Igniter
I 4 Injector No. 1 O 1 Oil Pressure SW
I 5 Injector No. 2](/img/14/6859/w960_6859-28.png "TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 29
Position of Parts in Engine Compartment
[1MZ±FE]
I 1 Idle Air Control Valve (ISC Valve) N 1 Noise Filter (for Ignition System)
I 2 Igniter
I 4 Injector No. 1 O 1 Oil Pressure SW
I 5 Injector No. 2")
29
Position of Parts in Engine Compartment
[1MZ±FE]
I 1 Idle Air Control Valve (ISC Valve) N 1 Noise Filter (for Ignition System)
I 2 Igniter
I 4 Injector No. 1 O 1 Oil Pressure SW
I 5 Injector No. 2 O 6 O/D Direct Clutch Speed Sensor
I 6 Injector No. 3
I 7 Injector No. 4 P 1 Park/Neutral Position SW (Neutral Start SW) (A/T)
I 8 Injector No. 5
I 9 Injector No. 6 S 1 Solenoid Valve (for Hydrauric Motor)
I 15 Igniter S 3 Starter
I 16 Ignition Coil No. 1 S 4Starter
I 17 Ignition Coil No. 2
I 18 Ignition Coil No. 3 T 1 Throttle Position Sensor
I 19 Ignition Coil No. 4
I 20 Ignition Coil No. 5 V 1 VSV (for A/C Idle±Up)
I 21 Ignition Coil No. 6 V 2 VSV (for EGR System)
V 3 VSV (for Fuel Pressure Up)
J 6 Junction Connector V 4 VSV (for Intake Air Control)
V 5 Vehicle Speed Sensor (Speed Sensor)
K 1 Knock Sensor 1
K 2 Knock Sensor 2 W 1 Washer Motor
W 2 Water Temp. Sender
M 6 Mass Air Flow (Air Flow Meter)
Page 30 of 307
![TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 30
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[5S±FE]
A 1 A/C Condenser Fan Motor E 1 EGR Gas Temp. Sensor
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure E 2 Electron](/img/14/6859/w960_6859-29.png "TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 30
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[5S±FE]
A 1 A/C Condenser Fan Motor E 1 EGR Gas Temp. Sensor
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure E 2 Electron")
30
ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
[5S±FE]
A 1 A/C Condenser Fan Motor E 1 EGR Gas Temp. Sensor
A 2 A/C Triple Pressure SW (A/C Dual and Single Pressure E 2 Electronic Controlled Transmission Solenoid
SW) E 3 Electronic Controlled Transmission Solenoid
A 3 A/C Magnetic Clutch and Lock Sensor E 4 Engine Coolant Temp. Sensor (EFI Water Temp.
A 4 ABS Actuator Sensor)
A 5 ABS Actuator E 5 Water Temp. SW (for Cooling Fan)
A 6 ABS Relay
A 7 ABS Relay F 1 Front Airbag Sensor LH
A 8 ABS Speed Sensor Front LH F 2 Front Airbag Sensor RH
A 9 ABS Speed Sensor Front RH F 3 Front Clearance Light LH
F 4 Front Clearance Light RH
B 1 Back±Up Light SW (M/T) F 5 Front Side Marker LH
B 2 Brake Fluid Level SW F 6 Front Side Marker RH
F 7 Front Turn Signal Light LH
C 2 Cruise Control Actuator F 8 Front Turn Signal Light RH
F 9 Front Wiper Motor
D 1 Data Link Connector 1 (Check Connector) F 10 Fuse Box
D 2 Distributor F 16 Fuse Box
F 17 Fuse Box
F 18 Fuse Box
G 1 Generator (Alternator)
G 2 Generator (Alternator)
Page 31 of 307
![TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 31
Position of Parts in Engine Compartment
[5S±FE]
H 1 Headlight Hi LH O 1 Oil Pressure SW
H 2 Headlight Hi RH O 2 Oxygen Sensor (Sub)
H 3 Headlight Lo LH O 3 Oxygen Sensor (Main)
H 4 Headlight Lo RH](/img/14/6859/w960_6859-30.png "TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 31
Position of Parts in Engine Compartment
[5S±FE]
H 1 Headlight Hi LH O 1 Oil Pressure SW
H 2 Headlight Hi RH O 2 Oxygen Sensor (Sub)
H 3 Headlight Lo LH O 3 Oxygen Sensor (Main)
H 4 Headlight Lo RH")
31
Position of Parts in Engine Compartment
[5S±FE]
H 1 Headlight Hi LH O 1 Oil Pressure SW
H 2 Headlight Hi RH O 2 Oxygen Sensor (Sub)
H 3 Headlight Lo LH O 3 Oxygen Sensor (Main)
H 4 Headlight Lo RH
H 5 Horn LH P 1 Park/Neutral Position SW (Neutral Start SW) (A/T)
H 6 Horn RH
R 1 Radiator Fan Motor
I 1 Idle Air Control Valve (ISC Valve)
I 2 Igniter S 3 Starter
I 3 Ignition Coil S 4Starter
I 4 Injector No. 1
I 5 Injector No. 2 T 1 Throttle Position Sensor
I 6 Injector No. 3
I 7 Injector No. 4 V 1 VSV (for A/C Idle±Up)
I 10 Intake Air Temp. Sensor (In±Air Temp. Sensor) V 2 VSV (for EGR System)
V 3 VSV (for Fuel Pressure Up)
K 1 Knock Sensor V 5 Vehicle Speed Sensor (Speed Sensor)
M 1 Manifold Absolute Pressure Sensor (Vacuum Sensor) W 1 Washer Motor
W 2 Water Temp. Sender
N 1 Noise Filter (for Ignition System)
Page 32 of 307
32
ELECTRICAL WIRING ROUTING
Position of Parts in Instrument Panel
A 10 A/C Amplifier C 12 Combination SW
A 11 A/C Evaporator Temp. Sensor C 13 Combination SW
A 12 A/C SW C 14 Cooling Fan ECU
A 13 ABS ECU C 15 Cruise Control Clutch SW (M/T)
A 14 ABS ECU C 16 Cruise Control ECU
A 15 Airbag Squib (Steering Wheel Pad)
A 16 Air Inlet Control Servo Motor D 3 Data Lik Connector 2 (TDCL (Toyota Diagnostic
A 17 Air Vent Mode Control Servo Motor Communication Link))
A 18 Ashtray Illumination D 4 Daytime Running Light Relay (Main)
A 22 Airbag Squib (Front Passenger Airbag Assembly) D 5 Diode (for Cruise Control)
D 6 Diode (for Idle±Up)
B 3 Back Door Lock Control SW D 7 Diode (for Courtesy)
B 4 Blower Motor D 8 Door Lock Control Relay)
B 5 Blower Resistor D 24 Date Link Connector 3
B 6 Blower SW D 25 Diode (for Tension Reducer)
B 7 Buckle SW LH (w/ Power Seat)
B 8 Buckle SW LH (w/o Power Seat) E 6 Electronic Controlled Transmission Pattern Select SW
B 10 Buckle SW RH E 7 Engine Control Module (Engine and Electronic
Controlled Transmission ECU) (A/T)
C 3 Center Airbag Sensor Assembly E 8 Engine Control Module (Engine and Electronic
C 4 Cigarette Lighter Controlled Transmission ECU) (A/T)
C 5 Cigarette Lighter Illumination E 9 Engine Control Module (Engine and Electronic
C 6 ClockControlled Transmission ECU) (A/T)
C 7 Clutch Start SW (M/T) E 10 Engine Control Module (Engine and Electronic
C 8 Combination Meter Controlled Transmission ECU) (A/T)
C 9 Combination Meter E 11 Engine Control Module (Engine ECU) (M/T)
C 10 Combination Meter E 12 Engine Control Module (Engine ECU) (M/T)
C 11 Combination Meter E 14 Engine Control Module (Engine ECU) (M/T)
Page 33 of 307
33
Position of Parts in Instrument Panel
G 3 Glove Box Light O 5 O/D Main SW and A/T Indicator Light (Shift Lever)
G 4 Glove Box Light SW
P 2 Parking Brake SW (for 1MZ±FE)
H 7 Hazard SW P 3 Parking Brake SW (for 5S±FE)
H 8 Heater Control SW (for Push Control SW Type) or Air P 4 Power Seat Control SW
Vent Mode Control SW (for Lever Control SW Type) P 5 Power Seat Motor (for Front Vertical Control)
H 9 Heated Oxygen Sensor (Bank 1 Sensor 2) P 6 Power Seat Motor (for Rear Vertical Control)
P 7 Power Seat Motor (for Reclining Control)
I 11 Ignition Key Cylinder Light P 8 Power Seat Motor (for Slide Control)
I 12 Ignition SW and Unlock Warning SW
I 13 Integration Relay R 2 Radio and Player (w/ CD Player)
R 3 Radio and Player (w/o CD Player)
J 1 Junction Connector R 4 Radio and Player (w/o CD Player)
J 2 Junction Connector R 5 Rear Window Defogger SW
J 3 Junction Connector R 6 Remote Control Mirror SW
J 4 Junction Connector (for SRS System) R 7 Rheostat
J 7 Junction Connector
S 5 Shift Lock ECU
K 3 Key Interlock Solenoid S 8 Stereo Component Amplifier
S 9 Stereo Component Amplifier
N 2 Noise Filter (for Stop Light) S 10 Stop Light SW
N 3 Noise Filter (for Stop Light)
Page 34 of 307
![TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 34
ELECTRICAL WIRING ROUTING
Position of Parts in Body
[Sedan]
A 19 ABS Speed Sensor Rear LH L 3 Luggage Compartment Light
A 20 ABS Speed Sensor Rear RH L 4 Luggage Compartment Light SW
A 21 Auto Ante](/img/14/6859/w960_6859-33.png "TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 34
ELECTRICAL WIRING ROUTING
Position of Parts in Body
[Sedan]
A 19 ABS Speed Sensor Rear LH L 3 Luggage Compartment Light
A 20 ABS Speed Sensor Rear RH L 4 Luggage Compartment Light SW
A 21 Auto Ante")
34
ELECTRICAL WIRING ROUTING
Position of Parts in Body
[Sedan]
A 19 ABS Speed Sensor Rear LH L 3 Luggage Compartment Light
A 20 ABS Speed Sensor Rear RH L 4 Luggage Compartment Light SW
A 21 Auto Antenna Motor and Relay
M 2 Moon Roof Control Relay
D 10 Door Courtesy Light Front LH M 3 Moon Roof Control SW and Personal Light (w/ Moon
D 11 Door Courtesy Light Front RH Roof)
D 12 Door Courtesy SW Front LH M 4 Moon Roof Limit SW
D 13 Door Courtesy SW Front RH M 5 Moon Roof Motor
D 14 Door Courtesy SW Rear LH
D 15 Door Courtesy SW Rear RH P 9 Power Window Control SW Front RH
D 16 Door Key Cylinder Light and SW P 10 Power Window Control SW Rear LH
D 17 Door Key Lock and Unlock SW LH P 11 Power Window Control SW Rear RH
D 18 Door Key Lock and Unlock SW RH P 12 Power Window Master SW and Door Lock Control SW
D 19 Door Lock Control SW RH LH
D 20 Door Lock Motor and Door Unlock Detection SW Front P 13 Power Window Motor Front LH
LHP 14 Power Window Motor Front RH
D 21 Door Lock Motor and Door Unlock Detection SW Front P 15 Power Window Motor Rear LH
RHP 16 Power Window Motor Rear RH
D 22 Door Lock Motor Rear LH
D 23 Door Lock Motor Rear RH R 8 Rear Combination Light LH
R 9 Rear Combination Light LH
F 11 Front Door Speaker LH R 10 Rear Combination Light RH
F 12 Front Door Speaker RH R 11 Rear Combination Light RH
F 13 Front Tweeter (Speaker) LH R 12 Rear Speaker LH
F 14 Front Tweeter (Speaker) RH R 13 Rear Speaker RH
F 15 Fuel Pump and Sender R 16 Rear Window Defogger (+)
R 17 Rear Window Defogger (±)
H 10 High Mount Stop Light R 20 Remote Control Mirror LH
R 21 Remote Control Mirror RH
I 14 Interior Light
V 8 Vanity Light LH
L 1 License Plate Light V 9 Vanity Light RH
L 2 Light Failure Sensor
Page 35 of 307
![TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 35
Position of Parts in Body
[Coupe]
A 19 ABS Speed Sensor Rear LH M 2 Moon Roof Control Relay
A 20 ABS Speed Sensor Rear RH M 3 Moon Roof Control SW and Personal Light
A 21 Auto Antenna Motor and Rel](/img/14/6859/w960_6859-34.png "TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 35
Position of Parts in Body
[Coupe]
A 19 ABS Speed Sensor Rear LH M 2 Moon Roof Control Relay
A 20 ABS Speed Sensor Rear RH M 3 Moon Roof Control SW and Personal Light
A 21 Auto Antenna Motor and Rel")
35
Position of Parts in Body
[Coupe]
A 19 ABS Speed Sensor Rear LH M 2 Moon Roof Control Relay
A 20 ABS Speed Sensor Rear RH M 3 Moon Roof Control SW and Personal Light
A 21 Auto Antenna Motor and Relay (w/ Moon Roof)
M 4 Moon Roof Limit SW
D 10 Door Courtesy Light Front LH M 5 Moon Roof Motor
D 11 Door Courtesy Light Front RH
D 12 Door Courtesy SW Front LH P 9 Power Window Control SW Front RH
D 13 Door Courtesy SW Front RH P 12 Power Window Master SW and Door Lock Control
D 16 Door Key Cylinder Light and SW SW LH
D 19 Door Lock Control SW RH P 13 Power Window Motor Front LH
D 26 Door Lock Motor, Door Unlock Detection SW P 14 Power Window Motor Front RH
Door Key Lock and Unlock SW LH
D 27 Door Lock Motor, Door Unlock Detection SW R 8 Rear Combination Light LH
Door Key Lock and Unlock SW RH R 9 Rear Combination Light LH
D 28 Door Lock Control SW LH (w/o Power Window) R 10 Rear Combination Light RH
R 11 Rear Combination Light RH
F 11 Front Door Speaker LH R 12 Rear Speaker LH
F 12 Front Door Speaker RH R 13 Rear Speaker RH
F 13 Front Tweeter (Speaker) LH R 16 Rear Window Defogger (+)
F 14 Front Tweeter (Speaker) RH R 17 Rear Window Defogger (±)
F 15 Fuel Pump and Sender R 20 Remote Control Mirror LH
R 21 Remote Control Mirror RH
H 10 High Mount Stop Light
T 2 Tension Reducer Solenoid LH
I 14 Interior Light T 3 Tension Reducer Solenoid RH
L 1 License Plate Light V 8 Vanity Light LH
L 2 Light Failure Sensor V 9 Vanity Light RH
L 3 Luggage Compartment Light
L 4 Luggage Compartment Light SW
Page 36 of 307
![TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 36
ELECTRICAL WIRING DIAGRAM
Position of Parts in Body
[Wagon]
A 19 ABS Speed Sensor Rear LH F 13 Front Tweeter (Speaker) LH P 11 Power Window Control SW Rear
A 20 ABS Speed Sensor Rear RH F 14 Front](/img/14/6859/w960_6859-35.png "TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual 36
ELECTRICAL WIRING DIAGRAM
Position of Parts in Body
[Wagon]
A 19 ABS Speed Sensor Rear LH F 13 Front Tweeter (Speaker) LH P 11 Power Window Control SW Rear
A 20 ABS Speed Sensor Rear RH F 14 Front")
36
ELECTRICAL WIRING DIAGRAM
Position of Parts in Body
[Wagon]
A 19 ABS Speed Sensor Rear LH F 13 Front Tweeter (Speaker) LH P 11 Power Window Control SW Rear
A 20 ABS Speed Sensor Rear RH F 14 Front Tweeter (Speaker) RH RH
A 21 Auto Antenna Motor and Relay F 15 Fuel Pump and Sender P 12 Power Window Master SW and
Door Lock Control SW LH
D 10 Door Courtesy Light Front LH H 10 High Mount Stop Light P 13 Power Window Motor Front LH
D 11 Door Courtesy Light Front RH P 14 Power Window Motor Front RH
D 12 Door Courtesy SW Front LH I 14 Interior Light P 15 Power Window Motor Rear LH
D 13 Door Courtesy SW Front RH P 16 Power Window Motor Rear RH
D 14 Door Courtesy SW Rear LH L 1 License Plate Light
D 15 Door Courtesy SW Rear RH L 2 Light Failure Sensor R 8 Rear Combination Light LH
D 16 Door Key Cylinder Light and SW L 3 Luggage Compartment Light R 9 Rear Combination Light LH
D 17 Door Key Lock and Unlock SW LH L 4 Luggage Compartment Light SW R 10 Rear Combination Light RH
D 18 Door Key Lock and Unlock SW RH R 11 Rear Combination Light RH
D 19 Door Lock Control SW RH M 2 Moon Roof Control Relay R 12 Rear Speaker LH
D 20 Door Lock Motor and Door Unlock M 3 Moon Roof Control SW and R 13 Rear Speaker RH
Detection SW Front LH Personal Light (w/ Moon Roof) R 16 Rear Window Defogger (+)
D 21 Door Lock Motor and Door Unlock M 4 Moon Roof Limit SW R 17 Rear Window Defogger (±)
Detection SW Front RH M 5 Moon Roof Motor R 20 Remote Control Mirror LH
D 22 Door Lock Motor Rear LH R 21 Remote Control Mirror RH
D 23 Door Lock Motor Rear RH P 9 Power Window Control SW Front
RH V 8 Vanity Light LH
F 11 Front Door Speaker LH P 10 Power Window Control SW Rear V 9 Vanity Light RH
F 12 Front Door Speaker RH LH
