TOYOTA CAMRY 1997 Owners Manual

100
Dolby [ B V C NR*
If you are listening to a tape that was re-
cored with Dolby
[ B or C Noise Reduc-
tion, push the button marked with the
double-D symbol until the appropriate
symbol appears on the display. To turn off
Dolby
[ NR, push the button until the sym-
bol disappears from the display.
The Dolby B NR mode reduces tape noise
by about 10 dB. The Dolby C NR mode re-
duces tape noise by another 10 dB, or
about 20 dB total. For best sound repro-
duction, select the same NR mode that
was used to record the tape.
*: Dolby noise reduction manufactured under license from Dolby Lab-
oratories Licensing Corporation. DOLBYº and the double D symbol
are trademarks of Dolby Laboratories Licensing Corporation.
Five EQ settingsEQ (Equalizer)
Your audio system can store five different
EQ settings in its memory so that you will
not need to readjust it every time you lis-
ten to a different program.
Five common settings are stored in the
system's memory whenit is manufactured
(see illustration).
To use a preset EQ setting: Push EQº.
The levers for the first setting and EQ-1º
will appear on the display. Push EQº until
you reach the setting you want. The audio
system will adjust the program you are
hearing to the selected setting.
To change a preset EQ setting: Push EQº
until the setting you want to change ap-
pears on the display. Adjust the bass,
mid-range, and treble leves using the
BASSº, MID/BALº, and TREB/FADE.º
To save an EQ setting: After you have
changed a setting, push EQº until you
hear a beep. This will replace the original
factory setting with your new one.
To cancel one of the EQ settings you
saved: With the setting on the display,
push in and hold EQº until you have
heard both the first saveº beep and a sec-
ond beep that means the setting has been
canceled. The original factory setting will
appear on the display.
ProCarManuals.com

101
To cancel all of the changed EQ setting:
Push and hold inºEQº until you hear a third
beep.
FADE
This knob lets you adjust the balance be-
tween the front and rear speakers.
Push TREB/FADEº so that it pops out of
its retracted position. Pull out the knob.
Turn the knob to adjust the front/rear bal-
ance. Push the knob back into its re-
tracted position.
MID (Mid-range)
This knob lets you adjust the mid-range
level.
Push MID/BALº knob so that it pops out
of its retracted position. Turn the knob to
adjust the mid-range level. Push the knob
back into its retracted position.
MTL (Metal) display
If a metal or chrome equivalent cassette
tape is put in the cassette player, the play-
er will automatically adapt to it and MTLº
will appear on the display.PROG (Program)
Push PROGº to select the other side of
a cassette tape. The display indicates
which side is currently selected (~º indi-
cates top side, vº indicates bottom side).
Auto-reverse feature: After the cassette
player reaches the end of a tape side, it
automatically reverses and begins to play
the other side. This is true whether the
cassette was playing or fast forwarding.
PWR/VOL (Power/Volume)
Push PWR/VOLº to turn the audio sys-
tem on and off. Turn the PWR/VOLº knob
to adjust the volume.
RAND (Random)
The random feature allows you to listen to
the tracks on a compact disc in random or-
der.
When you push RANDº, RANDº will ap-
pear on the display and the player will play
the tracks in random order. Push the but-
ton again to turn off the random feature.RM (Radio Monitor)
The radio monitor feature allows you to
listen to the radio while a cassette is being
rewound or fast forwarded.
Push RMº. RMº will appear on the dis-
play. Any time you are rewinding or fast
forwarding a cassette tape, the radio will
play the station that was set most recent-
ly. (You can not change the radio station
unless you switch out of the cassette play-
er function.)
Push RMº again to turn off the RM fea-
ture.
RPT (Repeat)
The repeat feature automatically replays
the current cassette or compact disc
track.
Push RPTº while the track is playing.
RPTº will appear on the display. When
the track ends, it will automatically be re-
wound and replayed. This process will be
continued until you push the button again
to turn off the repeat feature.
CassettesÐThere must be at least 3
seconds of blank space between tracks in
order for the repeat feature to work
correctly.
ProCarManuals.com

102
Scan
Radio
You can either scan all the frequencies on
a band or scan only the preset stations for
that band.
To scan the preset stations: Quickly push
and release SCAN.º If you hear a beep,
you held the button too long, and the radio
will scan all the frequencies. The radio will
tune in the next preset station up the
band, stay there for a few seconds, and
then move to the next preset station. To
select a station, push SCANº a second
time.
To scan all the frequencies: Push SCANº
until you hear a beep. The radio will find
the next station up the station band, stay
there for a few seconds, and then scan
again. To select a station, push SCANº a
second time.
Cassette Player
The cassette player scan feature is similar
to the radio scan feature and uses the
same button.Push SCANº. SCANº will appear on the
display. The player will fast forward to the
next cassette track, play it for 12 seconds,
and then scan again. To select a track,
push SCANº a second time. If the player
reaches the end of one side of a cassette
tape, it will continue scanning on the other
side.
Compact disc player
The compact disc player scan feature is
similar to the radio scan feature.
Push SCANº. SCANº will appear on the
display. The compact disc player will play
the next track for 10 seconds, then scan
again. To select a track, push SCANº a
second time. If the player reaches the end
of the disc, it will continue scanning at
track 1.
SKIP
The skip feature allows you to fast forward
past long stretches of blank tape. This is
especially useful at the end of cassettes.Push SKIPº. SKIPº will appear on the
display. The cassette player will keep
track of how much blank space it plays.
Any time it has played about 10 seconds
of blank tape, it will automatically fast for-
ward to the next track and begin to play.
Push the button a second time to turn off
the skip feature.
ST (Stereo reception) display
Your radio automatically changes to ste-
reo reception when a stereo broadcast is
received. STº appears on the display. If
the signal becomes weak, the radio re-
duces the amount of channel separation
to prevent the weak signal from creating
noise. If the signal becomes extremely
weak, the radio switches from stereo to
mono reception.
TAPE
Push TAPEº to switch from radio or com-
pact disc operation to cassette operation.
If the audio system is off, you can turn on
the cassette player by pushing TAPEº. In
both cases, a cassette must already be
loaded in the player.
ProCarManuals.com

103
TREB (Treble)
This knob lets you adjust the treble level.
Push BASS/TREBº so that it pops out of
its retracted position. Pull out the knob.
Turn the knob to adjust the treble. Push
the knob back into its retracted position.
TUNE
Tuning
Your Toyota has an electronic tuning radio
(ETR). Push and release the ~º (up) or vº
(down) side of TUNEº to step up or down
the station band. (If you hear a beep, you
held the button too long and the radio will
go into the seek mode.)
Seeking
In the seek mode, the radio finds and
plays the next station up or down the sta-
tion band.
To seek a station, push and hold the ~º or
vº side of TUNEº until you hear a beep.
Do this again to find another station.The anti-theft system prevents the audio
system from working after it has been dis-
connected. To activate the system, you
must set a three-digit security code. After
the system is set, SECº will appear in the
display each time the ignition is turned
form LOCKº or ACCº or ONº. Also, the
anti-theft light flashes every few seconds
while the ignition key is in the LOCKº
position.
You will need to know your security code
to reactivate your radio after electrical ser-
vice is performed on your vehicle.
Choose a security code that is easy to re-
member and keep a copy of it (not in your
Toyota).
NOTICE
If you pushed any wrong buttons on
the anti-theft system, the following
messages will appear on the display.
ErrºÐYou have pushed wrong
buttons.
1-9ºÐIndicates the number of er-
rors you have made. You may make
up to nine errors, but no more!
HELPºÐThe number of error you
can make was exceeded. The audio
sytem is completely inoperable.
Contact you Toyota dealer.
ÐAnti-theft system
(Type 2-2 and 3 only)
ProCarManuals.com

104
Setting a security code for the first
time.
1. Turn off the audio system.
Simultaneously push and hold in 1º, 6º,
and PWR/VOLº until SECº appears on
the display.2. While you are holding in the ~º side of
TUNEº, push 1º.
The display will read к.
On some modes, º and º will also
turn on.3. Input the three digit code.
You have 10 seconds to enter each digit.
For example, 209º:
To set the first digit: Push 1º until the digit
you want appears on the display.
To set the second digit: Push 2º until the
digit you want appears on the display.
To set the third digin: Push 3º until the dig-
it you want appears on the display.
ProCarManuals.com

105
4. The three-digit code should be on the
display.
Push and hold in SCANº until the display
goes dark. (At first, SECº will appear on
the display.)If you pushed any wrong buttons,
Errº and the number of errors you
have made will appear ont eh display
before SECº does. Go back to step 2
and try again. If the display returns to
Ð while you are entering the code,
go back to step 3.
To make sure the security code has been
accepted, turn the ignition to LOCKº and
then back to ACC.º SECº should appear
on the display.
Choose a security code that is easy to re-
member and keep a copy of it (not in your
Toyota).Changing the security code
1. Turn off the audio system.
Turn the ignition key to ACCº.
Simultaneously push and hold in 1º, 6º,
and PWR/VOLº until SECº appears in
the display.
ProCarManuals.com

106
2. While you are holding in the ~º side of
TUNEº push 1º.
The display will read к.
On some models,  º and º will also
turn on.3. Input the existing three-digit code.
You have 10 seconds to enter each digit.
For example, 209º:
To set the first digit: Push 1º until the digit
you want appears on the display.
To set the second digit: Push 2º until the
digit you want appears on the display.
To set the third digit: Push 3º until the digit
you want appears on the display.4. The three-digit code should be on the
display.
Push SCANº.
5. Repeat steps 2 and 3, this time enter-
ing your new code. You can use digits
0º through 9º.
ProCarManuals.com

107
6. The new three-digit code should be on
the display.
Push and hold in SCANº until the display
goes dark. (At first, SECº will appear on
the display.)If you pushed any wrong buttons,
Errº and the number of errors you
have made will appear on the display
before SECº does. Go back to step 2
and try again. If the display returns to
Ð while you are entering the code,
go back to step 3.
To make sure the security code has been
accepted, turn the ignition to LOCKº and
then back to ACCº. SECº should appear
on the display.NOTICE
A tenth error will activate the
anti-theft system and HELPº will
appear on the display. The audio
system will be completely inoper-
able. At this time, the anti-theft light
also comes on. If this occurs,
contact your Toyota dealer.Cleaning the security code.
1. Turn off the audio system.
Turn the ignition key to ACCº.
Simultaneously push and hold in 1º, 6º,
and PWR/VOLº until SECº appears on
the display.
ProCarManuals.com

108
2. While you are holding in the ~º side of
TUNEº, push 1º.
The display will read Ð.
On some models, º and º will also
turn on.3. Input the existing three-digit code.
You have 10 seconds to enter eahc digit.
For example, 209º:
To set the first digit: Push 1º until the digit
you want appears on the display.
To set the second digit: Push 2º until the
digint you want appears on the display.
To set the third digit: Push 3º until the di-
gint you want appears on the display.4. The three-digit code should be on the
display.
Push SCANº.
The display will read Ð.
5. Wait for 10 seconds until the security
system is deactivated and the display
goes dark.
ProCarManuals.com

109
If you pushed any wrong buttons,
Errº and the number of errors you
have made will appear on the display
before SECº does. Go back to step 2
and try again. If the display returns to
Ð while you are entering the code,
go back to step 3.
NOTICE
A tenth error will activate the
anti-theft system and HELPº will
appear on the display. The audio
system will be completely inoper-
able. At this time, the anti-theft light
also comes on. If this occurs,
contact your Toyota dealer.
Reactivating a disabled audio system
1. Turn the ignition switch to ACCº.
2. While you are holding in the ~º side of
TUNEº, push 1º.
The dispay will read ---º.
On some models, º and º will also
turn on.3. Input the existing three-digit code.
You have 10 seconds to enter each digit.
For example, 209º:
To set the first digit: Push 1º until the digit
you want appears on the display.
To set the second digit: Push 2º until the
digint you want appears on the display.
To set the third digit: Push 3º until the di-
gint you want appears on the display.
ProCarManuals.com
