Page 41 of 238

TOYOTA CAMRY 1998 Service Manual 41
The SRS (Supplemental Restraint Sys-
tem) airbags are designed to provide
further protection for the driver and
front passenger when added to the pri-
mary protection provided by the seat
belts.
In

Page 42 of 238

TOYOTA CAMRY 1998 Service Manual 42
The SRS airbag system is designed to
activate in response to a severe frontal
impact within the shaded area between
the arrows in the illustration.
There may be the case that the SRS air-
bag will

Page 43 of 238

TOYOTA CAMRY 1998 Service Manual 43
The SRS airbag system mainly  consists of
the following components and their loca-
tions are shown in the illustration.
1. SRS airbag warning light
2. Airbag module for driver (airbag and
inflator)

Page 44 of 238

TOYOTA CAMRY 1998 Service Manual 44
Improperly seated and/or restrained
infants and children can be killed
or seriously injured by a deploying
airbag. An infant or child who is
too small  to use a seat belt should
be properly secure

Page 45 of 238

TOYOTA CAMRY 1998 Service Manual 45
For instructions concerning the
installation of a child restraint sys-
tem, see “Child restraint” in this
chapter.
Do not sit on the edge of the seat
or lean over the dashboard when
the vehi

Page 46 of 238

TOYOTA CAMRY 1998 Service Manual 46
Do not put objects or your pets on
or in front of the dashboard or
steering wheel pad that houses the
airbag system. They might restrict
inflation or cause death or serious
injury as they are proj

Page 47 of 238

TOYOTA CAMRY 1998 Service Manual 47
This SRS airbag system has a service
reminder indicator to inform the driver of
operating problems. If either of the
following conditions occurs, this indicates
a malfunction of the airbags. Contac

Page 48 of 238

TOYOTA CAMRY 1998 Service Manual 48
SRS side airbags
The SRS (Supplemental Restraint Sys-
tem) side airbags are designed to pro-
vide further protection for the driver
and front passenger when added to the
primary protection provided

Page 49 of 238

TOYOTA CAMRY 1998 Service Manual 49
The SRS side airbag system may not
inflate if  the vehicle  is subjected  to a
collision from the side at an angle, or
a collision to the side of the vehicle
body other than the passenger compart-

Page 50 of 238

TOYOTA CAMRY 1998 Service Manual 50
The SRS side airbag system mainly con-
sists of the following components and
their locations are shown in the illustra-
tion.
1. SRS airbag warning light
2. Side airbag module (airbag and inflator)
