TOYOTA CAMRY 1999 Service Repair Manual

H02118H02272H03251
Airbag
Sensor
Assembly Squib (RH)
(+)SFR+
(±)
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±689
924 Author: Date:
DTC B0112/41 Short in Side Squib (RH) Circuit
(to Ground) (TMMK Made)
CIRCUIT DESCRIPTION
The side squib circuit consists of the airbag sensor assembly and side airbag assembly (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0112/41 is recorded when ground short is detected in the side squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0112/41

Short circuit in side squib (RH) wire harness (to ground)

Side squib (RH) malfunction

Airbag sensor assembly malfunction
Side airbag assembly (RH)

Airbag sensor assembly

Wire harness

Sub wire harness
WIRING DIAGRAM
See page DI±674.
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (RH) circuit.
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (RH) and the airbag sensor assembly,
measure the resistance between SFR+ and body ground.
OK:
Resistance: 1 MW or Higher
NG Go to step 5.
OK
DI4L4±01

W03860AB0118AB0119R13006H01067
H02273
H03252
Squib (RH)Airbag
Sensor
Assembly
SFR+
E1 SFR±
TcACC
or
DTC B0112/41 DLC1
ON " u
DI±690
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
925 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect SFR+ and SFR± of the con-
nector (on the side airbag assembly side) between the
side airbag assembly (RH) and the airbag sensor assem-
bly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See step 5 on page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0112/41 is not output.
HINT:
Codes other than code B0112/41 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

AB0118AB0119R13006H01067
H02274
H03253
"u
E1TcACC ON
or Airbag
Sensor
Assembly Squib (RH)
DTC B0112/41 DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±691
926 Author: Date:
4 Check side squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See step 5 on page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0112/41 is not output.
HINT:
Codes other than code B0112/41 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.

H02118H02275H03254
Airbag
Sensor
Assembly
Squib (RH)
(+)SFR+
(±)Sub Wire Harness
u "
H02276H02118H08251
Airbag
Sensor
Assembly
SFR+Sub Wire Harness
(±)(+) Squib (RH)
DI±692
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
927 Author: Date:
5 Check sub wire harness.
PREPARATION:
Disconnect the sub wire harness connector on the airbag sen-
sor assembly side.
CHECK:
For the connector (on the sub wire harness side) between the
side airbag assembly and the sub wire harness, measure the
resistance between SFR+ and body ground.
OK:
Resistance: 1MW or Higher
NG Repair or replace sub wire harness.
OK
6 Check harness between airbag sensor assembly and sub wire harness.
CHECK:
For the connector (on the sub wire harness side) between the
sub wire harness and the airbag sensor assembly, measure the
resistance between SFR+ and body ground.
OK:
Resistance: 1MW or Higher
NG Repair or replace harness or connector be-
tween airbag sensor assembly and sub wire
harness.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.

H01019H02119
AB0119
H08263
Squib (RH)Airbag
Sensor
Assembly
(±)
(+)SFR+
ON
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±693
928 Author: Date:
DTC B0113/42 Short in Side Squib (RH) Circuit (to B+)
(TMC Made)
CIRCUIT DESCRIPTION
The side squib circuit consists of the airbag sensor assembly and side airbag assembly (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0113/42 is recorded when a B+ short is detected in the side squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0113/42

Short circuit in side squib (RH) wire harness (to B+)

Side squib (RH) malfunction

Airbag sensor assembly malfunction
Side airbag assembly (RH)

Airbag sensor assembly

Wire harness
WIRING DIAGRAM
See page DI±670.
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±626)
2 Check side squib (RH) circuit.
CHECK:
(a) Turn ignition switch to ON.
(b) For the connector (on the airbag sensor assembly side)
between the side airbag assembly (RH) and the airbag
sensor assembly, measure the voltage between SFR+
and body ground.
OK:
Voltage: 0 V
NG Repair or replace harness or connector be-
tween side airbag assembly (RH) and airbag
sensor assembly.
OK
DI1BC±03

AB0118
R13006AB0119
H01020
H01068
H01175
Squib (RH)Airbag
Sensor
Assembly
SFR+
E1
SFR±
TcACC
or
DTC B0113/42
DLC1
ON "u
DI±694
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
929 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect SFR+ and SFR± of the con-
nector (on the side airbag assembly side) between the
side airbag assembly (RH) and the airbag sensor assem-
bly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See step 5 on page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0113/42 is not output.
HINT:
Codes other than code B0113/42 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

AB0118
R13006AB0119H01021
H01068H01176
"u
E1
Tc ACC ON
orAirbag
Sensor
Assembly Squib (RH)
DTC B0113/42 DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±695
930 Author: Date:
4 Check side squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See step 5 on page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0113/42 is not output.
HINT:
Codes other than code B0113/42 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.

H02119H02272AB0119
H08264
Squib (RH)Airbag
Sensor
Assembly
(±) (+)SFR+
ON
DI±696
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
931 Author: Date:
DTC B0113/42 Short in Side Squib (RH) Circuit (to B+)
(TMMK Made)
CIRCUIT DESCRIPTION
The side squib circuit consists of the airbag sensor assembly and side airbag assembly (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0113/42 is recorded when a B+ short is detected in the side squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0113/42

Short circuit in side squib (RH) wire harness (to B+)

Side squib (RH) malfunction

Airbag sensor assembly malfunction
Side airbag assembly (RH)

Airbag sensor assembly

Wire harness

Sub wire harness
WIRING DIAGRAM
See page DI±674.
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (RH) circuit.
CHECK:
(a) Turn ignition switch to ON.
(b) For the connector (on the airbag sensor assembly side)
between the side airbag assembly (RH) and the airbag
sensor assembly, measure the voltage between the
SFR+ and body ground.
OK:
Voltage: 0 V
NG Go to step 5.
OK
DI4L5±01

AB0118
R13006AB0119H01068
H02273
H03256
Squib (RH)Airbag
Sensor
Assembly
SFR+
E1
SFR±
TcACC
or
DTC B0113/42
DLC1
ON "u
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±697
932 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect SFR+ and SFR± of the con-
nector (on the side airbag assembly side) between the
side airbag assembly (RH) and the airbag sensor assem-
bly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See step 5 on page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0113/42 is not output.
HINT:
Codes other than code B0113/42 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

AB0118
R13006AB0119H01068
H02274
H03257
"u
E1
Tc ACC ON
orAirbag
Sensor
Assembly Squib (RH)
DTC B0113/42 DLC1
DI±698
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
933 Author: Date:
4 Check side squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See step 5 on page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0113/42 is not output.
HINT:
Codes other than code B0113/42 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
