H02275AB0119
H02119H08260
Squib (RH)Airbag
Sensor
Assembly
(±)
(+)SFR+
Sub wire Harness
ON
H02276
H02119AB0119
H08252
Airbag
Sensor
Assembly
SFR+Sub Wire Harness
(±)(+) Squib (RH)
ON
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±699
934 Author: Date:
5 Check sub wire harness.
PREPARATION:
Disconnect the sub wire harness connector on the airbag sen-
sor assembly side.
CHECK:
(a) Turn ignition switch to ON.
(b) For the connector (on the sub wire harness side) between
the side airbag assembly and the sub wire harness, mea-
sure the voltage between SFR+ and body ground.
OK:
Voltage: 0 V
NG Repair or replace sub wire harness.
OK
6 Check harness between airbag sensor assembly and sub wire harness.
CHECK:
(a) Turn ignition switch to ON.
(b) For the connector (on the sub wire harness side) between
the sub wire harness and the airbag sensor assembly,
measure the voltage between SFR+ and body ground.
OK:
Voltage: 0 V
NG Repair or replace harness or connector be-
tween airbag sensor assembly and sub wire
harness.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.

H01454
Side Squib (LH)Airbag Sensor Assembly
SFL+
SFL± Y±R
Y±G 1
26 5
C17
C17 DI±700
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
935 Author: Date:
DTC B0115/47 Short in Side Squib (LH) Circuit
(TMC Made)
CIRCUIT DESCRIPTION
The side squib (LH) circuit consists of the airbag sensor assembly and side airbag assembly (LH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0115/47 is recorded when a short is detected in the side squib (LH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0115/47

Short circuit between SFL+ wire harness and SFL± wire
harness of squib

Side squib (LH) malfunction

Airbag sensor assembly malfunction
Side airbag assembly (LH)

Airbag sensor assembly

Wire harness
WIRING DIAGRAM
DI16K±08

H01019W03859H01191
Squib (LH)Airbag
Sensor
Assembly
SFL+
(±)
(+)
SFL±
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±701
936 Author: Date:
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (LH) circuit.
PREPARATION:
Release the airbag activation prevention mechanism of the
connector (on the airbag sensor assembly side) between the
airbag sensor assembly and the side airbag assembly (LH).
(See page DI±626)
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (LH) and the airbag sensor assembly,
measure the resistance between SFL+ and SFL±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween side airbag assembly (LH) and airbag
sensor assembly.
OK

AB0118
R13006AB0119H01017
H01073H07483
Squib (LH)Airbag
Sensor
Assembly
E1 TcACC
or
DTC B0115/47
ON " u
DLC1
DI±702
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
937 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0115/47 is not output.
HINT:
Codes other than code B0115/47 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

H01018AB0118AB0119R13006H01073H01190
"u
E1
Tc ACC ON
orAirbag
Sensor
Assembly Squib (LH)
DTC B0115/47 DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±703
938 Author: Date:
4 Check side squib (LH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (LH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to LOOK, and wait at least for 20 se-
cond.
(b) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(c) Clear DTC stored in memory.
(See page DI±626)
(d) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(e) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(f) Check DTC.
(See page DI±626)
OK:
DTC B0115/47 is not output.
HINT:
Codes other than code B0115/47 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.

H04507
Side Squib (LH)Airbag Sensor Assembly
SFL+
SFL± BV1
Y±G 1
26 5
C17
C17 Y±G Y±RY±R
BV1 DI±704
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
939 Author: Date:
DTC B0115/47 Short in Side Squib (LH) Circuit
(TMMK Made)
CIRCUIT DESCRIPTION
The side squib (LH) circuit consists of the airbag sensor assembly and side airbag assembly (LH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS±2.
DTC B0115/47 is recorded when a short is detected in the side squib (LH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0115/47

Short circuit between SFL+ wire harness and SFL± wire
harness of squib

Side squib (LH) malfunction

Airbag sensor assembly malfunction
Side airbag assembly (LH)

Airbag sensor assembly

Wire harness

Sub wire harness
WIRING DIAGRAM
DI1L6±02

W03859H02277H03259
Squib (LH)Airbag
Sensor
Assembly
SFL+
(±) (+)
SFL±
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±705
940 Author: Date:
INSPECTION PROCEDURE
1 Prepare for inspection. (See step 1 on page DI±787)
2 Check side squib (LH) circuit.
PREPARATION:
Release the airbag activation prevention mechanism of the
connector (on the airbag sensor assembly side) between the
airbag sensor assembly and the side airbag assembly (LH).
(See page DI±626)
CHECK:
For the connector (on the side airbag assembly side) between
the side airbag assembly (LH) and the airbag sensor assembly,
measure the resistance between SFL+ and SFL±.
OK:
Resistance: 1 MW or Higher
NG Go to step 5.
OK

AB0118
R13006AB0119H01073 W03860
H08254
H08253
Squib (LH)Airbag
Sensor
Assembly
E1 TcACC
or
DTC B0115/47
ON " u
DLC1
DI±706
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
941 Author: Date:
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory.
(See page DI±626)
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC.
(See page DI±626)
OK:
DTC B0115/47 is not output.
HINT:
Codes other than code B0115/47 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

AB0118AB0119R13006H01073
H02279
H03261
"u
E1
Tc ACC ON
orAirbag
Sensor
Assembly Squib (LH)
DTC B0115/47 DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±707
942 Author: Date:
4 Check side squib (LH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the side airbag assembly (LH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to LOOK, and wait at least for 20 se-
cond.
(b) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(c) Clear DTC stored in memory.
(See page DI±626)
(d) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(e) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(f) Check DTC.
(See page DI±626)
OK:
DTC B0115/47 is not output.
HINT:
Codes other than code B0115/47 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly (LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.

W03859H02280H03262
Squib (LH)
Airbag
Sensor
Assembly
SFL+
(±)
(+)
SFL±
Sub Wire Harnessu"
W03859H02281H03263
Squib (LH)
Airbag
Sensor
Assembly
SFL+
(±)(+)
SFL±
Sub Wire Harness
DI±708
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
943 Author: Date:
5 Check sub wire harness.
PREPARATION:
(a) Disconnect sub wire harness connector on the airbag
sensor assembly side.
(b) Release the airbag activation prevention mechanism of
the sub wire harness connector on the airbag sensor as-
sembly side. (See page DI±626)
CHECK:
For the connector (on the sub wire harness side) between the
side airbag assembly and the sub wire harness, measure the
resistance between SFL+ and SFL±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace sub wire harness.
OK
6 Check harness between airbag sensor assembly and sub wire harness.
PREPARATION:
Release the airbag activation prevention mechanism of the air-
bag sensor assembly connector. (See page DI±626)
CHECK:
For the connector (on the sub wire harness side) between the
airbag sensor assembly and sub wire harness, measure the re-
sistance between SFL+ and SFL±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween airbag sensor assembly and sub wire
harness.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
