TOYOTA CAMRY 2000 Service Repair Manual

PP±80
± PREPARATIONSUSPENSION AND AXLE
132 Author: Date:
09555±55010Differential Drive Pinion
Bearing ReplacerFront drive shaft
09608±16042Front Hub Bearing Adjusting ToolFront drive shaft
(09608±02021)Bolt & Nut
(09608±02041)Retainer
09608±32010Steering Knuckle Oil Seal
ReplacerFront axle hub
Front suspension
09610±20012Pitman Arm PullerFront axle hub
09628±10011Ball Joint PullerFront axle hub
Rear axle hub
09628±62011Ball Joint PullerFront axle hub
Front suspension
09727±30021Coil Spring CompressorFront suspension
Rear suspension
09729±22031Front Spring Upper Seat HolderFront suspension
09950±00020Bearing RemoverFront axle hub
Front drive shaft
09950±60010Replacer SetFront axle hub
(09951±00400)Replacer 40

± PREPARATIONSUSPENSION AND AXLE
PP±81
133 Author: Date:
09950±70010Handle SetFront axle hub
(09951±07100)Handle 100

PP08W±01
PP±82
± PREPARATIONSUSPENSION AND AXLE
134 Author: Date:
RECOMMENDED TOOLS
09025±00010Torque Wrench (30 kgf±cm)
09042±00010Torx Socket T30 .
09905±00012Snap Ring No.1 Expander .
09905±00013Snap Ring Pliers .

PP08X±03
± PREPARATIONSUSPENSION AND AXLE
PP±83
135 Author: Date:
EQUIPMENT
Dial indicator
Drill
Torque wrench

PP08Y±01
PP±84
± PREPARATIONSUSPENSION AND AXLE
136 Author: Date:
LUBRICANT
ItemCapacityApplication
5S±FE:
Outboard joint greaseColor=Black
Inboard joint greaseColor=Yellow ocher
140 ± 160 g (5.5 ± 6.3 oz.)
185 ± 215 g (7.3 ± 8.5 oz.)
1MZ±FE:
Outboard joint greaseColor=Black
Inboard joint greaseColor=Gray
Joint side
Boot side
105 ± 125 g (3.7 ± 4.4 oz.)
142.5 ± 157.5 g (5.0 ± 5.6 oz.)
52.5 ± 57.5 g (2.1 ± 2.3 oz.)

PP0I7±01
± PREPARATIONBRAKE
PP±85
137 Author: Date:
BRAKE
SST (Special Service Tools)
09023±00100Union Nut Wrench 10 mm
09703±30010Brake Shoe Return Spring Tool
09709±29018LSPV Gauge Set
09718±00010Shoe Hold Down Spring Driver
09737±00010Brake Booster Push Rod Gauge
09751±36011Brake Line Union Nut 10 x 12 mm
Wrench
09843±18020Diagnosis Check Wire
09990±00150ABS Actuator Checker and
Sub±harnessDENSO type ABS,
ABS & TRAC type
09990±00163ABS Actuator Checker Sheet ºAºABS & TRAC type
09990±00250ABS Actuator Checker Sub±harness
ºGºDENSO type ABS,
ABS & TRAC type
09990±00300ABS Actuator Checker Sub±harness
ºIºDENSO type ABS
09990±00360ABS Actuator Checker Sub±harness
ºLºDENSO type ABS,
ABS & TRAC type

PP±86
± PREPARATIONBRAKE
138 Author: Date:
09990±00430ABS Actuator Checker Sheet ºPºDENSO type ABS
09990±00450ABS Actuator Checker Sub±harness
ºPºABS & TRAC type

PP0I8±01
± PREPARATIONBRAKE
PP±87
139 Author: Date:
RECOMMENDED TOOLS
09042±00030Torx Socket T20 .BOSCH type ABS
09082±00040TOYOTA Electrical Tester.
09905±00013Snap Ring Pliers .

PP0I9±03
PP±88
± PREPARATIONBRAKE
140 Author: Date:
EQUIPMENT
Torque wrench
MicrometerBrake disc
Dial indicatorBrake disc
Brake drum gaugeBrake drum and disc
Vernier calipersBrake drum

PP0IA±01
± PREPARATIONBRAKE
PP±89
141 Author: Date:
LUBRICANT
ItemCapacityClassification
Brake fluid±SAE J1703 or FMVSS No.116 DOT3
