TOYOTA CAMRY 2000 Service Repair Manual

TOYOTA ªDINGHYº TOWING GUIDE ± AX001±00 March 17, 2000
Page 2 of 2
All Models
YEARMODELDINGHY TOWABLESPEED/DISTANCEYEARMODELM/TA/T
SPEED/DISTANCELIMITS
1995 ± 2000AvalonNot Towable±
1992 ± 2000CamryYesNoNone
1999 ± 2000SolaraYesNoNone
1994 ± 1999CelicaYesNoNone
2000Celica GTYesNoNone
2000Celica GT±SYes±None2000Celica GT±S±Yes55 MPH / 200 Miles
1993 ± 2000CorollaYesNoNone
2000ECHOYesNoNone
1992 ± 2000Land CruiserNot Towable±
2000MR2 SpyderYesN/ANone
1996 ± 1998PaseoYesNoNone
1992 ± 1997Previa 2WDNot Towable±
1992 ± 1997Previa 4WDNot Towable±
1998 ± 2000SiennaNot Towable±
1994 ± 1999SupraNot Towable±
1996 ± 2000RAV4 2WDYesNoNone
1996 ± 2000RAV4 4WDYesNoNone
1995 ± 1998TercelYesNoNone
1996 ± 20004Runner 2WDNot Towable±
1996 ± 20004Runner 4WDNot Towable±
1995 ± 2000Tacoma 2WDNot Towable±
1995 ± 2000Tacoma 4WDNot Towable±
1993 ± 1999T100 2WDNot Towable±
1993 ± 1999T100 4WDNot Towable±
2000Tundra 2WDNot Towable±
2000Tundra 4WDNot Towable±
NOTE:
After ªDinghyº Towing, or at the recommended distance limits, let the Engine idle for
more than 3 minutes before operating the vehicle or resuming towing.
NOTE:
Vehicles that are Dinghy towable will not sustain internal damage to the transmission
or transfer components, as long as speed/distance limits are observed. The
transmission must
be placed in the ªneutralº position when Dinghy towing. Dinghy
towing these vehicles does not eliminate the possibility of damage to other vehicle
systems (Body, Chassis, Electrical Systems, etc.). Affected
Vehicles

Toyota Supports ASE CertificationPage 1 of 1
AX001-01Title:
RETRO-FIT INTERNAL TRUNK
RELEASE KITS
Models:
All Applicable '90 ± '00 Models
Technical Service
BULLETIN
March 9, 2001

In order to respond to requests of our valued customers, we are offering Retro±Fit
Internal Trunk Release Kits. These kits allow the trunk to be opened from the inside in
case of entrapment.
MODELMODEL CODEMODEL YEAR# CLAMPS
AvalonMCX101995 ± 19994AvalonMCX2020004
CamrySXV10, MCV10, VCV101992 ± 19964CamrySXV20, MCV201997 ± 20004
Celica (Coupe)AT200, ST2041994 ± 19994
Corolla (Sedan)AE10#1993 ± 19974Corolla (Sedan)ZZE1101998 ± 20005
ECHONCP1220004
MR2SW20, 211990 ± 19952
PaseoEL441992 ± 19954PaseoEL541996 ± 19994
SolaraSXV20, MCV201999 ± 20004
TercelEL421991 ± 19944TercelEL531995 ± 19994
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
±64640±33030Trunk Release
±64610±17040Trunk Release (MR2 Only)
±90464±00551Clamp
±MDC 00107±00316±TRInstallation Instructions
Order the appropriate trunk release, at least as many clamps as listed above, and a set
of installation instructions. Follow the installation procedure detailed in the installation
instructions. Installation time is 0.7 hours.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ACCESSORIES
Introduction
Applicable
Vehicles
Parts
Information
Installation
Procedure
Warranty
Information

Toyota Supports ASE CertificationPage 1 of 2
AX003±00Title:
PORT INSTALLED RS3000 TVIP TRUNK
COURTESY CONNECTION
Models:
'99 Camry
Technical Service
BULLETIN
March 31, 2000

The trunk courtesy connection for 1999 model year Camry vehicles equipped with a Port
Installed Option RS3000 (V3) has been relocated from the luggage compartment light
switch to below the dash (lower finish panel) on the driver's side in the Instrument Panel
J/B. (Refer to Illustrations A & B on page 2.)
The location was changed to improve the installation process.
A splicing connector is used for the new trunk courtesy wire installation (blue) to the
vehicle's wire harness at Instrument Panel J/B (red/yellow).
The previous location is the same as the dealer installed RS3000 trunk courtesy
connection to the luggage compartment light switch connection.
For service related purposes, this bulletin describes the procedures to locate the new
trunk courtesy connection at Instrument Panel J/B in vehicles equipped with PIO
RS3000.
The remote transmitter has two
buttons, Top and Bottom.The status monitor has a Toyota label,
LED, and microphone.
Remote Control
LED
Status Monitor
Microphone
1999 model year Camry vehicles equipped with PIO (V3) TVIP.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ACCESSORIES
Introduction
Applicable
Vehicles
Warranty
Information

PORT INSTALLED RS3000 TVIP TRUNK COURTESY CONNECTION ± AX003±00 March 31, 2000
Page 2 of 2
New Location:
These steps below are to be followed to
locate the new trunk courtesy connection
when servicing Camry vehicles equipped
with the PIO RS3000 TVIP.
1. Remove the negative battery cable.
2. Remove the driver's step cover.
3. Remove the driver's cowl cover (1
nut).
4. Locate the Connector Junction Block
in the driver's cowl area. You will
notice a RED/YELLOW wire routed to
the Blue 10P connector which
terminates at an adjacent splicing
connector. This is the TVIP Trunk
Courtesy Wire.
5. Disconnect the Blue 10P connector
from the Connector Junction Block.
With the tab of the Blue 10P
connector facing up, look at the back
(wire side) and locate the wire in the
bottom row, second space from the
right, which has the splicing connector
attached to it. This is the Vehicle's
Trunk Courtesy Signal Wire.
6. After completing the parts inspection
and repairs if applicable, reconnect
the Blue 10P connector and install all
previously removed parts.
Previous Location:
The White 1P connector for the Vehicle's
Trunk Courtesy Signal is located at the
trunk courtesy lamp switch near the trunk
latch in the vehicle's trunk.
Locating
Procedure
Connector
Junction Block
Illustration A
10P
Connector
(Blue)
TVIP Trunk
Courtesy Wire
(Yellow/Red)
Illustration B
Splicing
Connector
10P
Connector
(Blue)
Wire Side View

Toyota Supports ASE CertificationPage 1 of 1
AX004±99Title:
TOYOTA DINGHY" TOWING GUIDE
Models:
All Models
Technical Service
BULLETIN
March 19, 1999

The following chart indicates which Toyota vehicles can be Dinghy towed (towed with four
wheels on the ground) behind a Motorhome.
CAUTION:
Dinghy towing a vehicle behind a Motorhome requires special towing equipment and
accessories. Please see your Motorhome Manufacturer / Service Outlet for
recommended towing equipment.
All Models
YEARMODELDINGHY TOWABLESPEED/DISTANCEYEARMODELM/TA/TSPEED/DISTANCE
LIMITS
1995±1999AvalonNot Towable±
1992±1999CamryYesNoNone
1993±1999CorollaYesNoNone
1995±1998TercelYesNoNone
1996±1998PaseoYesNoNone
1994±1999CelicaYesNoNone
1994±1998SupraNot Towable±
1996±1999RAV4 2WDYesNoNone
1996±1999RAV4 4WDYesNoNone
1995±1999Tacoma 2WDNot Towable±
1995±1999Tacoma 4WDNot Towable±
1996±19994Runner 2WDNot Towable±
1996±19994Runner 4WDNot Towable±
1993±1998T100 2WDNot Towable±
1993±1998T100 4WDNot Towable±
1992±1999Land CruiserNot Towable±
1992±1999Previa 2WDNot Towable±
1992±1999Previa 4WDNot Towable±
1998±1999SiennaNot Towable±
NOTE:
Vehicles that are Dinghy towable will not sustain internal damage to the transmission
or transfer components. The transmission must
be placed in the ªneutralº position
when Dinghy towing. Dinghy towing these vehicles does not eliminate the possibility
of damage to other vehicle systems (Body, Chassis, Electrical Systems, etc.)
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ACCESSORIES
Introduction
Affected
Vehicles
Warranty
Information

TSB
Title:
1997 CAMRY REAR SPOILER INSTALLATION
Models:
`97 Camry
IntroductionUpon installation of the rear spoiler, as outlined in the Dealer Installation Instruction sheet
enclosed with the spoiler, please follow the outlined procedure for verification of the trunk
lid operation:
Affected1997 Model Year Camry.
Vehicles
Procedure1. Reinstall the carpet trim panel on the
inside of the trunk lid with the
appropriate fasteners.
2. The trunk lid must remain open and
hold its position, up to approximately
45 degrees from horizontal as shown.
3. If the trunk lid does not hold its open
position and the trunk lid closes:
a. Move the end of one of the torsion
rods to the next upper open slot.
b. Verify that the trunk lid functions
as outlined above.
c. If the condition is not corrected,
adjust the other torsion bar to
the next upper open slot position.
4. If the trunk lid does not hold its open
position and the trunk lid opens fully
forcibly:
a. Move the end of one of the torsion
rods to the next lower open slot
position.
b. Verify that the trunk lid functions
as outlined above.
c. If the condition is not corrected,
please adjust the other torsion
bar to the next lower open slot
position.
ACCESSORY
April 25, 1997
Page 1 of 1
AX005-97
NOTE:
Upon completion of the procedure
described in this bulletin, please refer
to the Dealer Installation Instructions
for final checks.
Upper Slot
Lower Slot

Toyota Supports ASE CertificationPage 1 of 4
AX005±99Title:
TOYOTA VIP RS3000 PROGRAMMING
Models:
All Models
Technical Service
BULLETIN
April 9, 1999

This bulletin describes the procedures that are used to program the two±button remote
control for vehicles that are equipped with the dealer or port installed option (PIO), not
the factory security system. For factory security system remote control programming,
refer to the appropriate vehicle repair manual.
Verification of the dealer or PIO Toyota VIP can easily be performed by identifying the
status monitor or remote transmitter.
The remote transmitter has two
buttons, Top and Bottom. The status monitor has a Toyota
label, LED, and microphone.
Remote Control Status MonitorLED
Microphone
Starting with 1998 MY, the remote controls for the RS3000 System were revised with new
coding logics. The color of the remote control cases was changed from Black to Gray to
help identify the new remote controls. The new (Gray) remote controls will not work with
the RS3000 ECU's produced prior to 1998 MY. The old (Black) remote controls are still
available for Service Parts.
NOTE:
The TVIP is programmed to operate with the two remote controls that come with the
vehicle. The ECU (computer) can be programmed to operate with up to four different
remote controls. For customer satisfaction, request that any existing remote be
furnished when programming a new or replacement unit.
All models with dealer or PIO equipped Toyota VIP (RS3000)
CODEDESCRIPTIONTIMEOPNT1T2
N/ANot applicable to warranty ±±±±
ACCESSORIES
Introduction
Affected
Vehicles
Warranty
Information

TOYOTA VIP RS3000 PROGRAMMING ± ALL MODELS ± AX005±99 April 9, 1999
Page 2 of 4
For location of the RS3000 ECU, refer to ECU Mounting Locations, Page 4.
I. To program (add) a REMOTE CONTROL to the system:
1. Insert the key into ignition switch,
and turn it to ªONº.
2. Press and hold the ECU's
PROGRAMMING SWITCH for 3
seconds.
The STATUS MONITOR LED
turns on for 5 seconds.
NOTE:
YOU MUST PERFORM THE NEXT
STEP WITHIN 5 SECONDS.
3. Press and release a REMOTE
CONTROL's top or bottom
button.*
The STATUS MONITOR LED
turns off.
The Piezo ªchirperº chirps once.
The exterior lights flash once.
4. Turn off the ignition. The ECU will
now operate with the REMOTE
CONTROL just programmed.
* Either button on your REMOTE CONTROL can be programmed to operate the system. The bottom
button can be programmed to operate a second vehicle with the Toyota VIP.
Programming
Procedure
Press and Hold
for 3 Seconds
Lights Up
Press Once

TOYOTA VIP RS3000 PROGRAMMING ± ALL MODELS ± AX005±99 April 9, 1999
Page 3 of 4
II. To erase all REMOTE CONTROL codes from the system:
1. Insert key into the ignition switch,
and turn it to ªONº.
2. Press and hold the ECU's
PROGRAMMING SWITCH for 3
seconds.
The STATUS MONITOR LED
turns on for 5 seconds.
NOTE:
YOU MUST PERFORM THE NEXT
STEP WITHIN 5 SECONDS.
3. Press and hold the ECU's
PROGRAMMING SWITCH for
over 2 seconds again.
The STATUS MONITOR LED
turns off, then flashes 3 times.
The Piezo ªchirperº chirps three
times and the exterior lights flash
3 times.
4. Turn off the ignition. The ECU has cleared all REMOTE CONTROL codes; until
another REMOTE CONTROL is programmed, the system will not work with any
REMOTE CONTROL.
Programming
Procedure
(Continued)
Press and Hold
for 3 Seconds
Lights Up
Press and Hold Again, for 2
Seconds

TOYOTA VIP RS3000 PROGRAMMING ± ALL MODELS ± AX005±99 April 9, 1999
Page 4 of 4
1. '98 Model and prior has ECU located beneath the driver's seat.
2. '97 Model and prior has ECU located beneath the driver's seat.
ECU MOUNTING LOCATIONS
