Toyota Supports ASE CertificationPage 1 of 2
AX005±00Title:
RS3000 TVIP AUTOMATIC DOOR LOCK
FEATURE PROGRAMMING
Models:
All Models
Technical Service
BULLETIN
April 14, 2000

As a convenience feature, the RS3000 TVIP system is programmed to automatically lock
all of the vehicle's doors (for vehicles equipped with power door locks) when the ignition
key is turned to ªONº or ªSTARTº, and unlock them when the key is turned back to ªACCº
or ªLOCKº. The initial factory setting of this programmable feature is ªONº. For some
customers however, this feature is not desirable due to instances of passenger lockout
when the driver enters the vehicle first and starts the ignition.
For vehicles equipped with RS3000 TVIP, this bulletin advises the dealers to
communicate the following information to the customers at vehicle delivery:
1. Inform the customers of the RS3000 system's automatic (ignition controlled) door
lock/unlock feature.
2. Inquire about the customers' preference for it to be set ªONº or ªOFFº.
3. Reprogram the feature's setting according to the customer's preference.
To change the feature's operation mode, follow the programming procedures on page 2.
Verification of the Dealer±Installed Option (DIO) or Port±Installed Option (PIO) RS3000
TVIP System can easily be performed by identifying the status monitor and remote
transmitter.
The remote transmitter has two
buttons, Top and Bottom.The status monitor has a Toyota label,
LED, and microphone.
Remote Control
LED
Status Monitor
Microphone
All models equipped with DIO or PIO RS3000 TVIP.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ACCESSORIES
Introduction
Applicable
Vehicles
Warranty
Information

RS30000 TVIP AUTOMATIC DOOR LOCK FEATURE PROGRAMMING ± AX005±00 April 14, 2000
Page 2 of 2
AUTOMATIC (IGNITION±CONTROLLED) DOOR LOCKING/UNLOCKING FUNCTION
The factory setting for the Automatic Door Locking/Unlocking Function is ªONº.
To change this feature's operation, follow the steps below:
1. Sit in the driver's seat with driver's door open.
2. Insert the key into the ignition switch, and turn it to ªONº position (not ªACCº)
5 times (ON > LOCK > ON > LOCK > ON > LOCK > ON > LOCK > ON) within a
10 second period.
System Response: The STATUS MONITOR's LED turns on, and the PIEZO
BUZZER sounds once.
NOTE:
You must perform the next steps within 30 seconds.
3. Select the customer's preferred operating mode.
ModeProgramming StepProgramming Completion
AUTOMATIC DOOR
LOCKING/UNLOCKING ªONºClose the driver's door.
Turn the ignition switch to the
ªLOCKº position.
System Response:
The PIEZO BUZZER sounds
once, and the exterior lights
flash once.
AUTOMATIC DOOR
LOCKING/UNLOCKING ªOFFºClose the driver's door,
then open and close it
one more time.
Turn the ignition switch to the
ªLOCKº position.
System Response:
The PIEZO BUZZER sounds
twice, and the exterior lights
flash twice.
Programming
Procedure

Toyota Supports ASE CertificationPage 1 of 2
AX006±99Title:
RS3000 TVIP PROGRAMMING CHANGES
FOR GBS
Models:
All Models
Technical Service
BULLETIN
April 23, 1999

Starting with 1999 MY, the programming in the RS3000 ECU for the Glass Breakage
Sensor (GBS) to trigger the alarm has been changed to improve the Toyota Vehicle
Intrusion Protection (TVIP) system's theft warning feature when glass breakage or impact
to the glass is detected.
Previous operation of GBS (for 1998 MY and prior):
Upon (first) detection of breakage of the vehicle's glass, the GBS will sound the
security system for 5 seconds (3 horn honks).
If there is a second detection of glass breakage, within 5 seconds of the first
detection, the security system will sound for the full duration of 59 seconds.
Improved operation of GBS (from 1999 MY):
Upon (first) detection of breakage of the vehicle's glass, the GBS will sound the
security system for 20 seconds.
If there is a second detection of glass breakage, the security system will sound for the
full duration of 59 seconds, regardless of time between the first and second
detections.
After the first detection, any subsequent detection will trigger the alarm for the full
duration of 59 seconds as long as the security system is armed. The GBS trigger
cycle will reset once the security system is disarmed and then rearmed.
This improvement is intended to enhance the previous trigger cycle of the security
system and ward off an intruder.
The color of the previous (1998 MY and prior) RS3000 ECU was black. The new
RS3000 ECU color is gray.
All Models
PREVIOUS PART NUMBERCURRENT PART NUMBERPART NAME
08585±00921SAMERS3000 Base Kit
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot applicable to warranty ±±±±
ACCESSORIES
Introduction
Affected
Vehicles
Parts
Information
Warranty
Information

RS3000 TVIP PROGRAMMING CHANGES FOR GBS ± AX006±99 April 23, 1999
Page 2 of 2
When performing the RS3000 System Test, check the Glass Breakage Sensor sensitivity
as follows:
1. Press and release the Remote Control's top button to arm the system.
2. Wait two seconds.
3. With the tip of the ignition key (or striker tool), softly tap the center of the driver's door
window glass.
If the system is triggered (horn sounds for 20 seconds), the sensitivity must be
adjusted. Turn the Glass Breakage Sensor ECU's adjustment screw clockwise
one notch, and repeat this step again.
4. If the system is not triggered, repeat the glass tapping with moderate force.
The system should trigger when the glass is tapped with moderate force. If it is
not triggered, turn the Glass Breakage Sensor ECU's adjustment screw clockwise
one notch, and repeat this step again.
CAUTION:
Use caution when performing the step above. Do not tap the window glass with too
much force, or the glass may crack or break. Use extra caution when the temperature
is extremely cold.
NOTE:
The Owner's Guide included in the RS3000 Base Kit is changed to reflect the
(GBS logic) improvement. There is no change to the GBS ECU itself. Repair
Procedure

Toyota Supports ASE CertificationPage 1 of 1
AX007±00Title:
INTERCHANGEABILITY OF ACCESSORY
ALLOY WHEELS
Models:
'99 ± '01 Avalon, Camry, Solara & Sienna
Technical Service
BULLETIN
September 22, 2000

This bulletin introduces a new accessory alloy wheel for 1999 through 2001 model year
Avalon, Camry, Solara and Sienna vehicles. This new wheel is similar in appearance to
an existing alloy wheel. This bulletin points out that the two wheels are not
interchangeable.
1999 ± 2001 model year Avalon, Camry, Solara & Sienna.
WHEELWHEEL PART NUMBERREMARK
Style 1, Split 5 SpokePT351±00990Conical (Tapered) Seat Lug Nut
Style 2, Split 5 SpokePT351±00991Flat Seat Lug Nut
Flat Seat Lug Nut Conical (Tapered)
Seat Lug Nut
Every applicable vehicle must be installed with all four wheels of the same part number.
In cases where replacement of one wheel is necessitated, it must be replaced by a wheel
of the same part number. Replacement of one part number with the other is permitted
only as a set of four wheels.
The service part numbers for the lug nuts are not interchangeable.
WHEEL PART NUMBERLUG NUT PART NUMBERLUG NUT DESCRIPTION
PT351±00990PT351±00990±LNConical (Tapered) Seat
PT351±00991PT351±12009±01Flat Seat
The service part numbers for the center caps are not interchangeable.
WHEEL PART NUMBERCENTER CAP PART NUMBER
PT351±00990PT351±00991±WC
PT351±00991PT351±00991±CC
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
ACCESSORIES
Introduction
Applicable
Vehicles
Parts
Information
Warranty
Information

Toyota Supports ASE CertificationPage 1 of 7
BO002±00
Title:
SEAT BELT EXTENDER
Models:
'98 ± '00 Model Year
Technical Service
BULLETIN
January 21, 2000

Toyota customers who find it necessary to
increase the length of their seat belts may
obtain Seat Belt Extenders at no cost
through their local Toyota dealer.
The extender is available in 6 inch, 9 inch,
12 inch, 15 inch and 18 inch lengths.
The extender is available only in black.
Owners are informed of the seat belt
extender availability through the Toyota
Owner 's Manual included in each vehicle.
The customer
(individual requiring the extender) must visit a Toyota dealership to have
the required measurements made and to complete the seat belt extender worksheet.
The worksheet will allow the proper fitting and selection of a seat belt extender for the
customer. The dealership personnel should then determine the applicable part number
and place a
Critical Order through the TDN Parts Network.
The dealership service department should complete the affixed Seat Belt Extender Label
and review the ªowner instruction sheetº with the customer. The dealership should give a
copy of the completed worksheet to the customer and keep the original in the customer's
file.
To assure utmost owner satisfaction, it is recommended that a dealership designate one
person to coordinate all activities related to the seat belt extender issue.
From past sales history, it is recommended that dealerships do not
stock Seat belt
extenders due to low demand and the need for customer fitting.
This bulletin contains the following information:
Procedure and Sample Label.................Page 2
Application Charts .................................Page 3±4
Part Number Information........................Page 5
Owner Instructions..................................Page 6
Seat Belt Extender Worksheet............... Page 7
All Toyota models, 1998 through 2000 model years.
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
BODY
Introduction
Extender Seat Belt
Applicable
Vehicles
Warranty
Information

SEAT BELT EXTENDER: '98 ± '00 ± BO002±00 January 21, 2000
Page 2 of 7
1. Owner requests a seat belt extender from dealer.
2. Dealer verifies the need for a seat belt extender and obtains a current copy of this
TSB and copies the worksheet.
3. Dealer measures the customer and completes the worksheet. Dealer determines the
correct part number and places a Critical Order for the part through the TDN Parts
Network.
4. Dealer receives seat belt extender and calls the customer in to check fit of the part.
5. If the seat belt extender fit is good, dealership personnel completes the customer
information label on the part, explains usage of the part, and gives the customer a
copy of the completed worksheet.
6. Dealer places a copy of the completed worksheet in the customer's records.
DEALER
MEASURE
CUSTOMER
&
COMPLETE
WORKSHEET
PLACE
CRITICAL
ORDER
THROUGH
TDNSHIP SEAT
BELT
EXTENDER
TO
DEALERTEST FIT
CUSTOMER
WITH PARTCOMPLETE
LABEL AND
ADVISE
OWNERRECEIVE
COPY OF
WORKSHEET
& USE
EXTENDER
FILE
WORKSHEET
IN
CUSTOMER
RECORDS
PARTS
SUPPLYDEALEROWNER
CAUTION
Procedure
Sample Seat
Belt Extender
Customer
Information
Label

SEAT BELT EXTENDER: '98 ± '00 ± BO002±00 January 21, 2000
Page 3 of 7
FRONT SEAT ± EXTENDER APPLICATION
MODELTYPE'00'99'98
RAV4ÐR±5R±5R±5
RAV4 EVÐR±5R±5R±5
TERCELRHÐR±5R±5TERCELLHÐR±5R±5
COUPE (RH)ÐR±5R±5PASEOCOUPE (LH)ÐR±5R±5
CONVERTIBLEÐN±6N±6
ECHOÐK±5ÐÐ
COROLLATMMC PRODUCTIONQ±4Q±4Q±4COROLLANUMMI PRODUCTIONQ±4Q±4Q±4
MR2ÐN±6ÐÐ
CELICALIFTBACK & COUPEN±6N±6N±6CELICACONVERTIBLEÐN±6N±6
CAMRYTMC PRODUCTIONQ±4Q±4Q±4CAMRYTMMK PRODUCTIONQ±4Q±4Q±4
CAMRYCOUPEQ±4Q±4ÐCAMRY
SOLARACOVERTIBLEQ±4ÐÐ
SUPRAÐÐÐR±3
AVALON *1ÐT±1Q±2Q±2
SIENNAÐQ±4Q±4Q±4
TACOMA *1ÐS±1S±1S±1
4RUNNERÐK±5K±5K±5
LAND CRUISERÐK±5K±5K±5
T100 *1ÐÐÐR±5
TUNDRA *1ÐQ±4ÐÐ
*1 The extender must not be used for the center seat belt of Avalon, Tacoma, T100 and Tundra which have
bench seats.
Front Seat Belt
Extender
Applications

SEAT BELT EXTENDER: '98 ± '00 ± BO002±00 January 21, 2000
Page 4 of 7
REAR SEAT ± EXTENDER APPLICATION
MODELTYPE'01'00'99
RAV4W/TOKAI RIKAR±5*1R±5*1R±5*1
RAV4W/QSSQ±4*2Q±4*2Q±4*2
RAV4 EVÐQ±4Q±4Q±4
TERCELW/TOKAI RIKAÐR±5*1R±5*1
TERCELW/QSSÐQ±4*2Q±4*2
COUPEÐR±5R±5
PASEOCONVERTIBLE (RH)ÐN±3N±1*3,
N±3*4
CONVERTIBLE (LH)ÐN±6N±5*3,
N±6*4
ECHOÐR±5ÐÐ
COROLLATMMC PRODUCTIONQ±4Q±4Q±4COROLLANUMMI PRODUCTIONT±1T±1T±1
LIFTBACK & COUPEN±6N±6N±6
CELICACONVERTIBLE (RH)ÐN±1N±1
CONVERTIBLE (LH)ÐN±5N±5
CAMRYTMC PRODUCTIONQ±4Q±4Q±4CAMRYTMMK PRODUCTIONQ±4Q±4Q±4
CAMRYCOUPEQ±4Q±4ÐCAMRY
SOLARACONVERTIBLEQ±4ÐÐ
SUPRAÐÐÐR±3
AVALONÐT±1Q±2Q±2
SIENNAÐQ±4Q±4Q±4
TACOMAXTRACABA±2A±2A±2
4RUNNERÐR±5R±5R±5
LAND CRUISERÐK±5K±5K±5
T100XTRACABÐÐK±4
TUNDRAACCESS CABQ±4ÐÐ
*1 This seat belt was supplied by TOKAI RIKA.
Make sure that the I/D mark on the back side of
the seat belt buckle is the same as shown.
*2 This seat belt was supplied by QSS. Make sure
that the I/D mark on the back side of the seat belt
buckle is the same as shown.
*3 N±1 and N±5 are applied to PASEO convertible from September 1997 to November 1997 production.
*4 N±3 and N±6 are applied to PASEO convertible from December 1997 production.
Rear Seat Belt
Extender
Applications

SEAT BELT EXTENDER: '98 ± '00 ± BO002±00 January 21, 2000
Page 5 of 7
PART NUMBER PREFIX: 73399±
SERIESLENGTHSERIES6 INCH9 INCH12 INCH15 INCH18 INCH
R±1±12010±12020±12030±12040±12050
R±2±12160±12170±12180±12190±12200
R±3±50010±50020±50030±50040±50050
R±4±16010±16020±16030±16040±16050
R±5±16060±16070±16080±16090±16100
N±1±12060±12070±12080±12090±12100
N±3±20011±20021±20031±20041±20051
N±4±20060±20070±20080±20090±20100
N±5±20110±20120±20130±20140±20150
N±6±20160±20170±20180±20190±20200
K±1±12110±12120±12130±12140±12150
K±2±22010±22020±22030±22040±22050
K±3±22060±22070±22080±22090±22100
K±4±33010±33020±33030±33040±33050
K±5±35010±35020±35030±35040±35050
A±1±02010±02020±02030±02040±020050
A±2±01060*1±01070±01080±01090±01100
Q±1±02060±02070±02080±02090±02100
Q±2±06010±06020±06030±06040±06050
Q±3±06060±06070±06080±06090±06100
Q±4±0W010±0W020±0W030±0W040±0W050
S±1±04010±04020±04030±04040±04050
T±1±01110±01120±01130±01140±01150
*1 Length: 7 1/4º
Parts
Information
