Foreword
Thank you for your purchase of the Navigation System. Please read this manual ca refully to ensure proper use. Keep this
manual stored in your vehicle at all times.
The Toyota Navigation System is one of the most technologica lly advanced vehicle accessories ever developed. The system
receives satellite signals from the Global Po sitioning System (GPS) operated by the U.S. Department of Defense. Using these
signals and other vehicle sensors, the syst em can show you where you are and assist you in locating a desired destination.
The navigation system is designed to select efficient routes from your present starting location to your destination. The syste m is
designed to direct you to a destination that is unfamiliar to you in efficient manners. The routes are generated from a large
database that includes all roads contained in AAA state maps along with detailed street coverage for many major metropolitan
areas. The calculated routes ar e neither the shortest routes nor routes wit hout traffic congestion. Your own personal local
knowledge or “short cut” may at times be faster than the calculated routes.
The navigation system’s database includes more than 50 point of interest categories to allow you to easily select destinations
such as restaurants and banks. If a destination is not in the database, you can enter the street address or a major intersection
close to it and the system will route you there. The system will provide both a visual map and audio instructions. The audio
instructions will announce the dist ance and direction to go when you are approachi ng a fork or intersection. These voice instruc-
tions will help you keep your eyes on the road and are time d to provide enough time to allow you to maneuver, change lanes or
slow down.
Please be aware that all current vehicle navigation systems have certain li mitations that may affect their ability to
perform properly. The accuracy of the vehicle’s position depends on the satellite condition, road configuration, vehicle
condition or other circumstances. For more information on the limitations of the system, refer to pages 59 through 61.
 2001 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in
whole or in part, without the written pe rmission of Toyota Motor Corporation.

Camry_Navi_U (L/O 0108)
382002 MY CAMRY NAVI_U (OM33559U)
Voice guidance to the destination dur-
ing route guidance. Use voice guid-
ance just for your reference.
You can adjust the volume of the voice
or turn off voice guidance.
L00059
Touch the “MENU” tab on the
screen to display the “Menu” screen.
Then touch the
“Volume” switch on
the “Menu” screen.
L00075
Touch any number to select the
desired volume. Touching the
“Off”
switch turns the voice route guidance
off. If you turn the
“Adaptive
volume control”
on, the volume is
turned up automatically when the
vehicle speed exceeds 80 km/h (50
mph).
INFORMATION
During route guidance, the voice
guidance continues even if the navi-
gation screen is changed to the oth-
er screens, such as the audio
screen.
UN301
The voice guidance provides various
messages as you approach an intersec-
tion, or other point where you need to
maneuver the vehicle.
1“Proceed about 5 miles.”
2“In a quarter of a mile, right
turn.”
3“Right turn.”
4(Beep sound only)
Voice guidance Typical voice guidance
prompts

Camry_Navi_U (L/O 0108)
1222002 MY CAMRY NAVI_U (OM33559U)
Z00019
You can select a function that enables
automatic return to the previous
screen from the audio screen.1. Push the
“INFO” button to display the “Infor mation Menu” screen. Touch “Screen Transition”.
Screen transition

Camry_Navi_U (L/O 0108)
1232002 MY CAMRY NAVI_U (OM33559U)
Z00011
2. Select “ON” or “OFF” and then touch “OK”.
ON: The previous screen automatically
returns from the audio screen 20
seconds after the end of audio op-
eration.
OFF: The audio screen remains on.

Camry_Navi_U (L/O 0108)
1252002 MY CAMRY NAVI_U (OM33559U)
AUDIO SYSTEM
Quick reference for your audio system126
. . . . . . . . . . . . . . . . . . . . . . . .
Your audio system 127
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Using your audio system 128
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Car audio system operating hints 142
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION V

Camry_Navi_U (L/O 0108)
1262002 MY CAMRY NAVI_U (OM33559U)
Function switch display screen
Touch the switches displayed on
the screen to control the radio,
cassette tape player and compact
disc player. For details, see page
129.“TUNE” knob
Turn this knob to move up or
down the station band. For
details, see page 131.
“AM” button
Push this button to choose an AM
station. For details, see pages
128 and 131.
“FM” button
Push this button to choose a FM
station. For details, see pages
128 and 131.
“DISC” button
Push this button to turn the
compact disc player on. For
details, see pages 128 and 138.
“TAPE” button
Push this button to turn the
cassette tape player on. For
details, see pages 128 and 135.
“TRAF” button
Push this button to seek a station
that broadcasts traffic information
regularly. For details, see pages
128 and 134.
“OPEN” button
Push this button to open the
display to access the slots for the
cassette tape player and compact
disc player. For details, see pages
127, 135 and 139.
“PWR·VOL” knob
Push this knob to turn the
audio system on and off, and
turn it to adjust the volume.
For details, see page 128. “SEEK/TRACK” button
Push either side of this button
to seek up or down for a
station, or to access a desired
program or track. For details,
see pages 131, 138 and 140. “SCAN” button
Push this button to scan radio
stations or scan the tracks on
a compact disc. For details,
see pages 132 and 141. “AUDIO” button
Push this button to display the
audio control screen. For
details, see page 128.
“TILT” button
Push this button to tilt the
display. For details, see page
127.
Quick reference for your audio system

Camry_Navi_U (L/O 0108)
1272002 MY CAMRY NAVI_U (OM33559U)
L00004
You can adjust the angle of the dis-
play by pushing the “TILT” button.
Each push of the “TILT” button will tilt
the display to position 1, 2, 3 and then
back to 0 in that order.
If you turn the ignition switch off, the
display will automatically move back to
position 0. The display will automatically
resume the previous position you used when
the ignition switch is turned to the “ACC”
or “ON” position.
The slots for the cassette tape player
and compact disc player are behind
the display.
To lower the display, push the “OPEN”
button. After you inserting the cassette
tape or compact disc, push the button
again to close the display.
CAUTION
Do not place anything on the
opened display, as such items may
be thrown about in the compart-
ment and possibly injure people in
the vehicle during sudden braking
or in an accident.
To reduce the chance of injury in
case of an accident or sudden
stop while driving, keep the dis-
play closed.
Take care not to jam your fingers
while the display is moving. Other-
wise, you could be injured.
NOTICE
Do not obstruct th e display while it
is moving. It could damage your au-
dio system.
Your audio system

Camry_Navi_U (L/O 0108)
1282002 MY CAMRY NAVI_U (OM33559U)
This section describes some of the basic
features of the Toyota audio system.
Some information may not pertain to your
system.
Your audio system works when the igni-
tion switch is in the “ACC” or “ON” posi-
tion.
NOTICE
To prevent the battery from being
discharged, do not leave the car au-
dio on longer than necessary when
the engine is not running.
L00166
(a) Turning the system on and off
POWERVOL: Push this knob to turn the
audio system on and off. Turn this knob
to adjust the volume. The system turns
on in the last mode used.
AUDIO: Push this button to display
switches for audio s ystem (audio control
mode).
You can select the function that enables
automatic return to the previous screen
from the audio screen. See page 122 for
details.
L00167
Push “AM”, “FM”, “DISC”, “TAPE” or
“TRAF” button to turn on the desired
mode. The selected mode turns on im-
mediately.
Push these buttons if you want to switch
from one mode to another.
If the tape or disc is not set, the cassette
player or compact disc player does not
turn on.
You can turn off the cassette player or
compact disc player by ejecting the cas-
sette tape or compact disc. If the audio
system was previously off, then the entire
audio system will be turned off when you
eject the cassette tape. If another func-
tion was previously playing, it will come
on again.
Using your audio system—
—Some basics

Camry_Navi_U (L/O 0108)
1292002 MY CAMRY NAVI_U (OM33559U)
Z00001
Z00002
Z00003
Z00004
The switches for radio, cassette tape
and compact disc player operation are
displayed on the function switch dis-
play screen when the audio control
mode is selected. Touch them lightly
and directly on the screen.
The selected switch is highlighted in green.
INFORMATION
 If the system does not respond to
a touch of a switch, move your
finger away from the screen and
then touch it again.
 You cannot operate dimmed
switches.
 Wipe off fingerprints on the sur-
face of the disp lay using a glass
cleaning cloth.
(b) Tone and balance
How good an audio program sounds to you
is largely determined by the mix of the
treble, midrange, and bass levels. In fact,
different kinds of music and vocal programs
usually sound better with different mixes of
treble, midrange, and bass.
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to a
stereo recording or broadcast, changing the
right/left balance will increase the volume of
one group of sounds while decreasing the
volume of another.

Camry_Navi_U (L/O 0108)
1302002 MY CAMRY NAVI_U (OM33559U)
Z00009
Except JBL
Z00008
JBL
Touching the “SOUND” switch dis-
played on the screen at the audio con-
trol mode will display the sound con-
trol mode. Adjust the tone and balance
as follows.To adjust the tone, touch the “+” or
“” switches on the screen. To adjust
the balance between the front and rear
speakers, touch the “Front” or “Rear”
switch on the screen, and to adjust
the balance between the left and right,
touch the “L” or “R” switch on the
screen.
BASS:
Adjusts low− pitched tones.
MID: Adjusts mid −pitched tones (JBL
only).
TREB: Adjusts high− pitched tones.
As the orange display goes up, each tone is
more emphasized.
(c) Your radio antenna
Your vehicle has an antenna printed on
the inside of the rear window.
NOTICE
Attaching the film (especially con-
ductive or metallic type) on the rear
window will noticeably reduce the
sensitivity of the radio.
(d) Your cassette player
When you insert a cass ette, insert it with
the exposed tape side to the right.
NOTICE
Do not oil any part of the cassette
player, and do not insert anything
except a cassette tape into the slot.
(e) Your compact disc player
When you insert a compact disc, insert
it with the label side up. The compact
disc player will play from track 1 through
the end of the disc. Then it will play from
track 1 again.
NOTICE
Never try to disassemble or oil any
part of the compact disc player. Do
not insert anything except a compact
disc into the slot.
The player is intended for use with 12
cm (4.7 in.) discs only.
