“START”—Starter motor on. The key
will return to the “ON” position when
released.
For starting tips, see page 196 in Section
3.
“ON”—Engine on and all accessories
on.
This is the normal driving position.
“ACC”—Accessories such as the radio
operate, but the engine is off.
If you leave the key in the “ACC” or
“LOCK” position and open the driver’s
door, a buzzer will remind you to remove
the key.“LOCK”—Engine is off and the steering
wheel is locked. The key can be re-
moved only at this position.
You must push in the key to turn the key
from “ACC” to the “LOCK” position. On
vehicles with an automatic transmission,
the selector lever must be put in the “P”
position before pushing the key.
Vehicles with engine immobiliser system—
Once you remove the key, the engine im-
mobiliser system is automatically set. (See
“Engine immobiliser system” on page 13
in Section 1−
2.)
When starting the engine, the key may
seem stuck at the “LOCK” position. To
free it, first be sure the key is pushed all
the way in, and then rock the steering
wheel slightly while turning the key gently.
If the automatic unlocking operation linked
with the ignition switch is set, all doors
are automatically unlocked when the igni-
tion switch is turned from the “ON” posi-
tion to the “ACC” or “LOCK” position. For
details, see “—Automatic door locking and
unlocking functions” on page 17 in Section
1 −2.
CAUTION
For manual transmission:
Never remove the key when the ve-
hicle is moving, as this will lock the
steering wheel and result in loss of
steering control.
NOTICE
Do not leave the key in the “ON”
position if the engine is not running.
The battery will discharge and the
ignition could be damaged.
Ignition switch with steering
lock

AP_Camry_U (L/O 0201)
1282002 MY CAMRY_U (OM33567U)
Error codes
“WAIT”: The compact disc player unit
may be too hot due to temperature. Allow
the player to cool down.
“Err 1”: The disc may be dirty, damaged
or inserted incorrectly (up− side down).
Clean disc and re −insert.
“Err 3”: There is trouble inside the sys-
tem. Eject the disc. Set the disc again.
“Err 4”: Overcurrent. Ask your Toyota
dealer to inspect.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
Dolby
B NR∗
If you are listening to a tape that was
recorded with Dolby  B Noise Reduction,
push “
”. “” will appear on the
display. Push the button again to turn off
Dolby  B NR.
The Dolby NR mode reduces tape noise
by about 10 dB. For best sound reproduc-
tion, play your tapes with this button on
or off according to the mode used for
recording the tape.
∗: Dolby noise reduction manufactured under license from
Dolby Laboratories Licensing Corporation. “DOLBY” and the
double D symbol
are trademarks of Dolby Laboratories
Licensing Corporation.
FM1·2
Push “FM1·2” to turn on the radio and
select the FM band. “FM1” or “FM2” will
appear on the display. This system allows
you to set twelve FM stations, two for
each button.
If the audio system is off, you can turn
on the radio by pushing “FM1·2”. Also,
push “FM1·2” to switch from cassette or
compact disc operation to radio operation.
MODE (manual tone and sound balance
adjustment function)
Each time you push the “MODE” knob, the
mode changes. To adjust the tone and
balance, turn the knob.
BASS: Adjusts low −pitched tones. The dis-
play ranges from −5 to 5.
MID (on some models): Adjusts mid−
pitched tones. The display ranges from −5
to 5.
TREBLE: Adjusts high− pitched tones. The
display ranges from −5 to 5.
BALANCE: Adjusts the sound balance be-
tween the right and left speakers. The
display ranges from L7 to R7.
FADER: Adjusts the sound balance be-
tween the front and rear speakers. The
display ranges from F7 to R7. PWR·VOL (Power and Volume)
Push “PWR·VOL” to turn the audio system
on and off. Turn “PWR·VOL” to adjust the
volume.
RAND (Random)
Push “RAND” to listen the tracks on the
disc in random order. “
” will ap-
pear on the display. The disc you are
listening to will play in random order. To
turn off the random feature, push this but-
ton again.
RPT (Repeat)
Cassette player
Push “RPT” while the track is playing.
“
” will appear on the display. When
the track ends, it will automatically be
rewound and replayed. This process will
be continued until you push the button
again to turn off the repeat feature.
There must be at least 3 seconds of blank
space between tracks in order for the re-
peat feature to work correctly.

AP_Camry_U (L/O 0201)
1332002 MY CAMRY_U (OM33567U)
If a tape rewinds completely, the cassette
player will stop and then play that same
side. If a tape fast−forwards completely,
the cassette will play the other side of the
tape using the auto −reverse feature.
Compact disc auto changer
If you want to fast −forward or reverse a
compact disc track, push and hold the
fast −forward or reverse button. When you
release the button, the compact disc auto
changer will resume playing.
AM
Push “AM” to turn on the radio and select
the AM band. “AM” will appear on the
display.
If the audio system is off, you can turn
on the radio by pushing “AM”. Also, push
“AM” to switch from cassette or compact
disc operation to AM.
MODE (manual tone and sound balance
adjustment function)
Each time you push the MODE knob, the
mode changes. To adjust the tone and
balance, turn the knob. BASS: Adjusts low
−pitched tones. The dis-
play ranges from −5 to 5.
MID: Adjusts mid −pitched tones. The dis-
play ranges from −5 to 5.
TREBLE: Adjusts high− pitched tones. The
display ranges from −5 to 5.
BALANCE: Adjusts the sound balance be-
tween the right and left speakers. The
display ranges from L7 to R7.
FADER: Adjusts the sound balance be-
tween the front and rear speakers. The
display ranges from F7 to R7.
CD (Compact disc)
Push “CD” to switch from radio or cas-
sette operation to compact disc auto
changer operation. If the audio system is
off, you can turn on the compact disc
auto changer by pushing “CD”. In both
cases, a disc must already be loaded in
the auto changer.
When the audio is set into compact disc
operation, the display shows the track or,
track and disc number currently being
played. If the auto changer or another unit
equipped with the player malfunctions,
your audio system will display one of the
six following error messages.
Error codes
“WAIT”:
The compact disc auto changer
unit may be too hot due to temperature.
Allow the auto changer to cool down.
“Err 1”: The disc may be dirty, damaged
or inserted incorrectly (up −side down).
Clean disc and re −insert.
“Err 2”: The compact disc auto changer
is empty. Insert a disc.
“Err 3”: There is trouble inside the sys-
tem. Eject the disc or magazine. Set the
disc or magazine again.
“Err 4”: Over−current. Ask your Toyota
dealer to inspect.
“OPEn”: The compact disc auto changer
lid of another unit is open. Close the com-
pact disc auto changer lid.
If the malfunction still exists, take your
vehicle to your Toyota dealer.
