Page 11 of 532
11
B
Window lock switch P. 81
Outside rear view mirror switches P. 79
Door lock switch P. 52
Power window switches P. 81
Inside lock button P. 53
: If equipped
*1: For vehicles with a navigation system, refer to “Navigation System Owner’s Manual”.
*2: For vehicles with a Display Audio system, refer to “Display Audio System Owner’s Manual”.
Page 12 of 532
12
C
Automatic transmission shift lever P. 159
Cup holders P. 294
Pictorial indexInterior
Auxiliary box P. 296
Shift lock overridebutton
P. 449
Power outlet P. 304
Page 13 of 532
13
Gauges and meters P. 169
Tilt and telescopic steering rock release lever
P. 76
Pictorial indexInstrument panel
Audio system
Navigation system
, *3
Display Audio system , *4
P. 242
Windshield wiper and washer switch P. 194
Clock P. 300
Tire pressure warning
reset switch
P. 368
Parking brake pedal P. 167Hood lock release
lever
P. 350: If equipped
*3: Refer to “Navigation System Owner’s Manual”.
*4: Refer to “Display Audio System Owner’s Manual”.
Horn
P. 168
Engine (ignition) switch (vehicles
with a smart key system)
P. 148
Headlight switch
Turn signal lever
Fog light switch
P. 185
P. 166
P. 192
Fuel filler door opener
P. 88
Trunk opener P. 58
Floor mat P. 311
Page 14 of 532
14Rear window and outside rear view mirror defogger switch
P. 240
A
Air conditioning system P. 233
Rear window defogger switch
Outside rear view mirror defogger switch
P. 240
P. 240
Air conditioning system P. 226
Pictorial indexInstrument panel
Automatic air conditioning system Manual air conditioning system
Emergency flasher switch P. 414
Emergency flasher switch P. 414
Security indicator P. 92, 95
Security indicator P. 92, 95
Page 15 of 532
15
B
Telephone switches , *1, *2
Type A
Audio remote control switches , *1, *2
Talk switch , *1, *2
Cruise control switch P. 199
Engine (ignition) switch
(vehicles without a smart
key system)
P. 145
: If equipped
*1: For vehicles with a navigation system, refer to “Navigation System Owner’s Manual”.
*2: For vehicles with a Display Audio system, refer to “Display Audio System Owner’s Manual”.
Page 16 of 532
16
B
Engine (ignition) switch
(vehicles without a smart
key system)
P. 145
Telephone switches *4
Pictorial indexInstrument panel
Type B
Paddle shift switches P. 162
Audio remote control
switches *4
Cruise control switch P. 199
Talk switch , *4
Page 17 of 532
17
C
Power outlet P. 304
AUX port/USB port P. 264, 272, 283
Seat heater switches
P. 307
: If equipped
*4: Refer to “Display Audio System Owner’s Manual”.
Page 18 of 532
18
D
VSC OFF switch P. 204
BSM main switch P. 208
Pictorial indexInstrument panel
Coin holder P. 292
: If equipped
Headlight leveling dial
P. 188
Page 19 of 532
19
For your information
Main Owner’s Manual
Please note that this manual covers all models and all equipment, including
options. Therefore, you may find some explanations for equipment not
installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota
vehicles are currently available on the market. You should know that Toyota
does not warrant these products and is not responsible for their
performance, repair, or replacement, or for any damage they may cause to,
or adverse effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products.
Modification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In
addition, damage or performance problems resulting from the modification
may not be covered under warranty.
Page 20 of 532
20
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multiport fuel injection system /sequential multiport fuel injection system
● Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.
