TOYOTA CAMRY 2020 Owners Manual (in English)

131
3
Operation of
each component
CAMRY_U 3-1. Key information
Keys .................................. 132
3-2. Opening, closing and locking the doors
Doors ................................ 141
Trunk ................................. 149
Smart key system ............. 154
3-3. Adjusting the seats Front seats ........................ 163
Rear seats (folding type) ................... 165
Head restraints.................. 167
3-4. Adjusting the steering wheel and mirrors
Steering wheel .................. 169
Inside rear view mirror ...... 171
Outside rear view mirrors ............................. 173
3-5. Opening and closing the windows
Power windows ................. 175
Moon roof .......................... 179
Panoramic moon roof........ 183

132
CAMRY_U
3-1. Key information
The following keys are provided with the vehicle.
Vehicles without a smart key system
Keys
Operating the wireless remote con-
trol function (P. 133)
Key number plate
Vehicles with a smart key system
Electronic keys
• Operating the smart key system
(P. 154)
• Operating the wireless remote control function ( P. 133)
Mechanical keys
Key number plate
Keys
The keys
1
2
1
2
3

1333-1. Key information
3
Operation of each component
CAMRY_U
Vehicles without a smart key system
Locks all the doors (P. 1 4 2 )
Unlocks all the doors ( P. 1 4 2 )
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Opens the windows*2 and the
moon roof
*1, 2 (  P. 142)
Opens the trunk ( P. 1 5 0 )
Sounds the alarm ( P. 135)
*1: If equipped
*2: This setting must be customized at your Toyota dealer.
Vehicles with a smart key system
Locks all the doors ( P. 1 4 2 )
Unlocks all the doors ( P. 1 4 2 )
Pressing the button unlocks the
driver’s door. Pressing the button
again within 3 seconds unlocks the
other doors.
Opens the windows*2 and the
moon roof
*1, 2 or panoramic
moon roof
*1, 2 (  P. 142)
Opens the trunk ( P. 1 5 0 )
Sounds the alarm ( P. 135)
*1: If equipped
*2: This setting must be customized at your Toyota dealer.
Wireless remote control
1
2
3
4
5
1
2
3
4
5

1343-1. Key information
CAMRY_U
Releasing
To release the key, press the but-
ton.
Folding
To stow the key, press the button
then fold the key.
To take out the mechanical key,
slide the release lever and take
the key out.
The mechanical key can only be
inserted in one direction, as the
key only has grooves on one side.
If the key cannot be inserted in a
lock cylinder, turn it over and re-
attempt to insert it.
After using the mechanical key, store it in the electronic key. Carry the
mechanical key together with the electronic key. If the electro nic key bat-
tery is depleted or the entry function does not operate properl y, you will
need the mechanical key. ( P. 530)
Using the key (vehicles without a smart key system)
1
2
Using the mechanical key (vehic les with a smart key system)

1353-1. Key information
3
Operation of each component
CAMRY_U
■Panic mode
Vehicles without a smart key system
Vehicles with a smart key system
■ When required to leave the vehicle’s key with a parking attenda nt (vehi-
cles with a smart key system)
Lock the glove box as circumstances demand. (P. 387)
Remove the mechanical key for your own use and provide the attendant with
the electronic key only. When is pressed for longer than
about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.
When is pressed for longer than
about one second, an alarm will sound
intermittently and the vehicle lights will
flash to deter any person from trying to
break into or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

1363-1. Key information
CAMRY_U■
If you lose your keys
New genuine keys can be made by your Toyota dealer using the ot her key
(vehicles without a smart key system) or the other mechanical k ey (vehicles
with a smart key system) and the key number stamped on your key number
plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
■ When riding in an aircraft
When bringing a key with wireless remote control function onto an aircraft,
make sure you do not press any button on the key while inside t he aircraft
cabin. If you are carrying the key in your bag etc., ensure tha t the buttons are
not likely to be pressed accidentally. Pressing a button may cause the key to
emit radio waves that could interfere with the operation of the aircraft.
■ Conditions affecting operation
Vehicles without a smart key system
The wireless remote control function may not operate normally i n the follow-
ing situations:
● When the wireless key battery is depleted
● Near a TV tower, electric power plant, gas station, radio stati on, large dis-
play, airport or other facility that generates strong radio wav es or electrical
noise
● When carrying a portable radio, cellular phone or other wireles s communi-
cation devices
● When the wireless key is in contact with, or is covered by a me tallic object
● When other wireless key (that emit radio waves) is being used n earby
● If window tint with a metallic content or metallic objects are attached to the
rear window
Vehicles with a smart key system
P. 156

1373-1. Key information
3
Operation of each component
CAMRY_U■
Key battery depletion
Vehicles without a smart key system
● The standard battery life is 1 to 2 years.
● Even if the key is not used, the battery may become depleted an d the fol-
lowing symptoms may occur. Replace the battery with a new one when nec-
essary. (P. 468)
• The wireless remote control function does not operate.
• The area in which the wireless remote control function can be operated
becomes smaller.
Vehicles with a smart key system
● The standard battery life is 1 to 2 years.
● If the battery becomes low, an alarm will sound in the cabin wh en the engine
stops.
● As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate that the electronic key battery may be depleted. Replace the battery
when necessary. ( P. 468)
• The smart key system or the wireless remote control does not o perate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.
● To reduce key battery depletion when the electronic key is to not be used for
long periods of time, set the electronic key to the battery-sav ing mode.
( P. 156)
● To avoid serious deterioration, do not leave the electronic key within 3 ft. (1
m) of the following electrical appliances that produce a magnet ic field:
•TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Table lamps
• Induction cookers
■ Replacing the battery
P. 468
■ Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.
■ If a wrong key is used
The key cylinder rotates freely to isolate inside mechanism.

1383-1. Key information
CAMRY_U■
Certification for the wireless remote control (vehicles without a smart
key system)
For vehicles sold in the U.S.A.

1393-1. Key information
3
Operation of each component
CAMRY_U
For vehicles sold in Canada

1403-1. Key information
CAMRY_U■
Certification for wireless remo te control (vehicles with a smart key sys-
tem)
P. 160
NOTICE
■ To prevent key damage
● Do not drop the keys, subject them to strong shocks or bend them.
● Do not expose the keys to high temperatures for long periods of time.
● Do not get the keys wet or wash them in an ultrasonic washer et c.
● Do not attach metallic or magnetic materials to the keys or pla ce the keys
close to such materials.
● Do not disassemble the keys.
● Do not attach a sticker or anything else to the surface of the electronic key
and key (with a wireless remote control function).
● Vehicles with a smart key system: Do not place the keys near ob jects that
produce magnetic fields, such as TVs, audio systems and inducti on cook-
ers, or medical electrical equipment, such as low-frequency the rapy equip-
ment.
■ Carrying the electronic key on your person (vehicles with a sma rt key
system)
Carry the electronic key 3.9 in. (10 cm) or more away from elec tric appli-
ances that are turned on. Radio waves emitted from electric app liances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.
■ In case of a smart key system malfunction or other key-related prob-
lems (vehicles with a smart key system)
Take your vehicle with all the electronic keys provided with yo ur vehicle to
your Toyota dealer.
■ When an electronic key is lost (vehicles with a smart key system)
If the electronic key remains lost, the risk of vehicle theft i ncreases signifi-
cantly. Visit your Toyota dealer immediately with all remaining electronic
keys that were provided with your vehicle.
