stop start TOYOTA CAMRY 2023 Owner's Guide

5617-2. Steps to take in an emergency
CAMRY_U
7
When trouble arises
■Stopping the engine
Shift the shift lever to P and press the engine switch as you normally do when
stopping the engine.
■ Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery is depleted.
(P. 494)
■ Alarm (for Canada only)
Using the mechanical key to lock the doors will not set the ala rm system.
If a door is unlocked using the mechanical key when the alarm s ystem is set,
the alarm may be triggered.
■ Changing engine switch modes
Release the brake pedal and press the engine switch in step above.
The engine does not start and modes will be changed each time t he switch is
pressed. (P. 213)
■ When the electronic key does not work properly
●Make sure that the smart key system has not been deactivated in the cus-
tomization setting. If it is off, turn the function on.
(Customizable features: P. 606)
● Check if battery-saving mode is set. If it is set, cancel the f unction.
( P. 163)
WARNING
■ When using the mechanical key and operating the power windows or
the moon roof or panoramic moon roof
Operate the power window or the moon roof or panoramic moon roo f after
checking to make sure that there is no possibility of any passe nger having
any of their body parts caught in the window or the moon roof o r panoramic
moon roof. Also, do not allow children to operate the mechanical key. It is
possible for children and other passengers to get caught in the power win-
dow or the moon roof or panoramic moon roof.
3

5697-2. Steps to take in an emergency
CAMRY_U
7
When trouble arises
Start the engine and turn the air conditioning system on to check
that the radiator cooling fan operates and to check for coolant leaks
from the radiator or hoses.
The fan operates when the air conditioning system is turned on immedi-
ately after a cold start. Confirm that the fan is operating by checking the fan
sound and air flow. If it is difficult to check these, turn the air conditioning
system on and off repeatedly. (The fan may not operate in freezing tem-
peratures.)
If the fan is not operating:
Stop the engine immediately and contact your Toyota dealer.
If the fan is operating:
Have the vehicle inspected at the neare st Toyota dealer.
WARNING
■To prevent an accident or injury when inspecting under the hood of
your vehicle
Observe the following precautions.
Failure to do so may result in serious injury such as burns.
● If steam is seen coming from under the hood, do not open the ho od until
the steam has subsided. The engine compartment may be very hot.
● Keep hands and clothing (especially a tie, a scarf or a muffler) away from
the fan and belts. Failure to do so may cause the hands or clothing to be
caught, resulting in serious injury.
● Do not loosen the radiator cap and the coolant reservoir cap while the
engine and radiator are hot.
High temperature steam or coolant could spray out.
NOTICE
■When adding engine coolant
Wait until the engine has cooled down before adding engine cool ant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too
quickly can cause damage to the engine.
■ To prevent damage to the cooling system
Observe the following precautions:
● Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).
● Do not use any coolant additives.
6
7

5707-2. Steps to take in an emergency
CAMRY_U
Stop the engine. Set the parking brake and shift the shift lever to P.
Remove the mud, snow or sand from around the front wheels.
Place wood, stones or some other material under the front wheel s
to help provide traction.
Restart the engine.
Shift the shift lever to D or R and release the parking brake. Then,
while exercising caution, de press the accelerator pedal.
If the vehicle becomes stuck
Carry out the following procedures if the tires spin or the vehicle
becomes stuck in mud, dirt or snow:
1
2
3
4
5

633What to do if... (Troubleshooting)
CAMRY_U
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 82)
●Vehicles without a smart key system:
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system:
To stop the alarm, turn the engine switch to IGNITION ON mode o r start
the engine.
●Is the message displayed on the multi-information display?
Check the message on the multi-information display. ( P. 538)
●When a warning light turns on or a warning message is displayed , refer to
P. 528, 538.
●Stop the vehicle in a safe place and replace the flat tire with the spare
tire. ( P. 543)
●Try the procedure for when the vehicle becomes stuck in mud, di rt, or
snow. ( P. 570)
An alarm is activated and the horn sounds
A warning buzzer sounds w hen leaving the vehicle
(vehicles with a smart key system)
A warning light turns on or a warning message is displayed
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

638Alphabetical index
CAMRY_U
Dynamic radar cruise control with full-speed range ............ 290
Dynamic Torque Control AWD system .......................... 323
Eco drive mode ........................ 375
Eco Driving Indicator ...... 109, 126
Eco-friendly driving information ............................ 115
EDR (Event data recorder) ........ 11
Electric Power Steering
(EPS)....................................... 323 Warning light ......................... 530
Electronic key .......................... 140 Battery-saving function ......... 163
If the electronic key does not operate properly ................. 559
Replacing the battery ............ 494
Emergency flashers ................ 516
Emergency, in case of
If a warning buzzer sounds ................................ 528
If a warning light turns on...... 528
If a warning message is displayed ............................ 538
If the battery is discharged.... 562
If the electronic key does not
operate properly ................. 559
If the engine will not start ...... 557
If the vehicle is submerged
or water on the road is
rising ................................... 519
If you have a flat tire ............. 543
If you lose your keys ............. 144
If you think something is wrong.................................. 526
If your vehicle becomes stuck ................................... 570 If your vehicle has to be
stopped in an emergency ... 517
If your vehicle needs to be towed.................................. 520
If your vehicle overheats....... 567
Engine ACCESSORY mode ............. 213
Compartment ........................ 460
Engine switch ............... 209, 211
Hood ..................................... 457
How to start the engine ........................ 209, 211
Identification number ............ 577
If your vehicle has to be stopped in an
emergency ......................... 517
Ignition switch
(engine switch) ........... 209, 211
Overheating .......................... 567
Engine coolant
Capacity................................ 580
Checking............................... 466
Preparing and checking before winter ...................... 377
Engine coolant temperature gauge ....................................... 94
Engine immobilizer system ...... 80
Engine oil
Capacity................................ 578
Checking............................... 462
Preparing and checking before winter ...................... 377
Engine switch .................. 209, 211
Enhanced VSC ......................... 322
EPS (Electric Power Steering) ..... 323
Warning light......................... 530
Event data recorder (EDR)........ 11
E

640Alphabetical index
CAMRY_U
Hands-free system (for cellular phone)
*
Headlights ................................ 231
Automatic High Beam ........... 236
Light switch ........................... 231
Replacing light bulbs............. 512
Windshield wiper linked headlight illumination .......... 235
Head restraints ........................ 171
Head-up display ....................... 128
Heated steering wheel............. 402
Heaters Automatic air conditioning system .... 387, 394
Heated steering wheel .......... 402
Manual air conditioning system ......... ....................... 382
Outside rear view mirrors ................ 383, 389, 397
Seat heaters ......................... 402
Seat ventilators ..................... 402
High mounted stoplight Replacing .............................. 512
Hill-start assist control............ 323
Hood ......................................... 457
Hooks Coat hooks............................ 431
Grocery bag hooks ............... 415
Retaining hooks (floor mat)..... 26
Horn .......................................... 173
HUD (Head-up display)............ 128 Identification
Engine .................................. 577
Vehicle .................................. 576
Ignition switch (engine switch) .............. 209, 211
Illuminated entry system ........ 408
Immobilizer system ................... 80
I/M test ...................................... 454
Indicators ................................... 91
Initialization Items to initialize ................... 614
Inside rear view mirror ............ 175
Instrument panel light control ...................................... 95
Interior lights ........................... 406 Switch ................................... 406
Intuitive parking assist ........... 336
HI

646Alphabetical index
CAMRY_U
Side mirrors ............................. 177Adjusting and folding ............ 177
BSM (Blind Spot Monitor) ..... 330
Side turn signal lights Replacing light bulbs............. 512
Turn signal lever ................... 223
Smart key system .................... 161 Antenna location ................... 161
Entry functions .............. 147, 156
Starting the engine................ 211
Snow tires ................................ 379
Spare tire .................................. 543
Inflation pressure .................. 584
Storage location .................... 544
Spark plug ................................ 580
Specifications .......................... 574
Speedometer .............................. 94
Sport mode............................... 375
Steering lock Column lock release ............. 210
Steering wheel ......................... 173 Adjustment ............................ 173
Audio switches
*
Heated steering wheel .......... 402
Meter control switches .... 99, 113
Stoplights Replacing light bulbs............. 512
Storage feature ........................ 409
Stuck If the vehicle becomes
stuck ................................... 570
Sunshade Panoramic moon roof ........... 187
Roof ...................................... 184
Sun visors ................................ 416 Switches
Audio remote control
switches
*
Automatic High Beam switch ................................. 236
Brake hold switch ................. 229
Cruise control switch ......................... 290, 306
Door lock switches................ 151
Driving mode select switches ............................. 375
Emergency flasher switch..... 516
Engine switch ............... 209, 211
Fuel door opener switch ....... 246
Garage door opener switches ............................. 432
Heated steering wheel .......... 402
Ignition switch ............... 209, 211
Light switch ........................... 231
LTA (Lane Tracing Assist)
switch ................................. 278
Meter control switches .... 99, 113
Moon roof switches............... 183
“ODO/TRIP” switch ......... 99, 113
Outside rear view mirror switches ............................. 177
Paddle shift switches ............ 219
Panoramic moon roof
switches ............................. 187
Parking brake switch ............ 225
Phone switch
*
Power window switches........ 179
Rear window and outside
rear view mirror
defoggers
switch ................. 383, 389, 397
