STARTING AND DRIVING
Starting and driving
Preparing to start the hybrid system301
. . . . . . . . . . . . . . . . . . . . . . . . . .
How to start the hybrid system 301
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving and parking using smart key system 304
. . . . . . . . . . . . . . . . . . .
Tips for driving in various conditions 307
. . . . . . . . . . . . . . . . . . . . . . . . . .
Winter driving tips 309
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . .
Dinghy towing 310
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
Trailer towing 310
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . .
How to save fuel and make your vehicle last longer 311
. . . . . . . . . . . . .
SECTION 3

’07Camry hybrid_U (L/O 0610)
301
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
1. Check the area around the vehicle be-fore getting in.
2. Adjust seat position, seatback angle, seat cushion angle, seat height, head
restraint height and steering wheel
angle.
3. Adjust the inside and outside rear view mirrors.
4. Lock all side doors and back door.
5. Fasten seat belts.
When you get in the vehicle, check
whether the “READY” light is on or
not.
CAUTION
Your vehicle does not produce any
noise or vibration when the vehicle is
ready to be driven with the “READY”
indicator light on. Move your foot
carefully from the brake pedal to the
acceleration pedal when driving.
1. Apply the parking brake firmly.
2. Turn off unnecessary lights and acces- sories.
3. Put the selector lever in “P”.
4. Depress the brake pedal and hold it to the floor until driving off.
As the hybrid system can be started only
with the transmission in the “P” position,
put the selector lever in “P” whenever
starting the system.
PUSH BUTTON START FUNCTION
The hybrid system can be started by
pressing the “POWER” switch.
Before starting the hybrid system, be sure
to follow the instructions in “(a) Before
starting”.
Starting procedure
With your foot off the accelerator pedal,
press the “POWER” switch briefly and
firmly. The “READY” light starts flashing
and then it stays on with sounding a
beep. If the ambient temperature is low,
such as during winter driving conditions,
it may take longer than the usual amount
of time until the “READY” light stays on.
Preparing to start the hybrid
system How to start the hybrid
system—
(a) Before starting (b) Starting the hybrid system

’07Camry hybrid_U (L/O 0610)
302
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
The engine may not start even with the
“READY” light on.
If there is a problem somewhere in the
hybrid system, the message “CHECK
HYBRID SYSTEM” will appear on the
multi−information display. Have your
vehicle checked by your Toyota dealer as
soon as possible.
If the hybrid system will not start...
In the following cases, the hybrid system
will not start.
If a buzzer sounds from the vehicle,
and the message “KEY IS NOT
DETECTED” appears on the multi −infor-
mation display and the master warning
light comes on when pressing the
“POWER” switch, this indicates that the
key is not in the vehicle.
If the key is placed in the trunk, the
hybrid system cannot be started.
There are instances in which the hybrid
system will not start, even if the key
is in the vehicle (e.g. on the floor, in
the cup holder or glove box).
When the push button start function
does not operate properly, the following
may be causes:
The key battery may be discharged if
the electronic key does not work.
You can start the hybrid system by
touching the Toyota logo side of the
electronic key to the “POWER” switch.
For details, see “Smart key system” on
page 32 in Section 1 −2.
Replace the key battery as soon as
possible. (See “—Replacing battery” on
page 30 in Section 1 −2.)
The hybrid system was repeatedly
turned on and off over a short period.
Wait 10 seconds and then start the
hybrid system.

’07Camry hybrid_U (L/O 0610)
303
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
If the green indicator light on the
“POWER” switch flashes, and the mes-
sage “S/T IS NOT UNLOCKED” ap-
pears on the multi−information display
and the master warning light comes on,
the steering wheel is locked.
To free the steering lock, turn the
steering wheel slightly while pressing
the “POWER” switch.
If the amber indicator light on the
“POWER” switch flashes, and the mes-
sage “CHECK S/T LOCK” appears on
the multi −information display and the
master warning light comes on, there is
a problem in the steering lock function.
Contact your Toyota dealer, and have
your vehicle and all keys inspected.
If the amber indicator light on the
“POWER” switch flashes, and no mes-
sage appears on the multi −information
display, there is a problem in the push
button start function.
Contact your Toyota dealer, and have
your vehicle and all keys inspected.
In addition to the above, there are
instances in which the smart key sys-
tem does not operate properly because
of the circumstances of use. For de-
tails, see “Smart key system” on page
32 in Section 1 −2.
In cases other than those described
above, it is possible that a problem has
occurred in an area other than the start
system. See “If your vehicle will not start”
on page 313 in Section 4. If the 12 volt battery is disconnected or
run down...
The “READY” light will not come on and
the hybrid system will not start after you
reconnect, replace or recharge the battery.
In this case, perform the following proce-
dure to restart the hybrid system:
1. Turn the hybrid system off.
2. Open and close the driver ’s door.
3. Press the “POWER” switch briefly and firmly.
If the hybrid system still will not start,
contact your Toyota dealer.CAUTION
Never start the hybrid system from
outside the vehicle, or an accident
may occur. Be sure to sit in the driv-
er seat, then start the system.

’07Camry hybrid_U (L/O 0610)
304
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
NOTICE
If any message appears on the mul-
tiinformation display or service re-
minder indicator light comes on
(see page 140 and page 150 in Sec-
tion 16 for details) or the 12 volt
battery is disconnected, the hybrid
system may not be started. In that
case, push the “POWER” switch
again. If the “READY” light does
not come on, contact your Toyota
dealer.
 When you start the hybrid system
at a lower outside temperature, it
may take longer before the blinking
“READY” light changes to constant
on.
TIPS FOR USING SMART KEY SYSTEM
When using the smart key system, it is
possible to start or stop the hybrid system
as long as the key is on your person.
For this reason, it is possible that a pas-
senger may remove the key from the ve-
hicle without the driver being aware of the
fact. In such a case, it is not possible to
restart the hybrid system after having
turned it off. In addition, it is possible that
one may get out of the vehicle without
being aware that the “POWER” switch has
not been turned off completely.
When driving or getting in or out of the
vehicle, drivers should make sure that
they are carrying the key.
CAUTION
Do not touch the “POWER” switch
while driving.
If you have to make an emergency stop,
press and hold the “POWER” switch for
more than 3 seconds.
Master warning light and multiinforma-
tion display
SYSTEM FUNCTION REMINDERS
Follow the instructions described below if
any of the following warnings occur:
(A) A warning buzzer sounds once from
the instrument cluster when the
“POWER” switch is pushed.
This indicates that the driver has gotten
into the vehicle without the key. The mes-
sage “KEY IS NOT DETECTED” will also
appear on the multi −information display
and the master warning light will come on.
Operate the “POWER” switch only after
taking care that the key is in the vehicle.
Driving and parking using
smart key system

’07Camry hybrid_U (L/O 0610)
305
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
If the warning light is still lit when the key
is in the vehicle, the key battery is dis-
charged. Check that the indicator light on
the key comes on by pushing the lock
button on the key. When the indicator light
does not come on, change the key battery
so that smart key system works properly.
(B) A warning buzzer sounds once fromthe instrument cluster, accompanied
by three warning sounds from the
vehicle when the driver gets out of
the vehicle and closes the door.
This indicates that the driver is attempting
to leave the vehicle carrying the key with
“POWER” switch turned off although the
transmission selector lever has been set
in the “P” position. The message “KEY IS
NOT DETECTED” will also appear on the
multi −information display and the master
warning light will come on.
Get out of the vehicle only after turning
off the hybrid system by pressing the
“POWER” switch and checking that the
indicator light on the “POWER” switch has
gone off. If the driver returns to the ve-
hicle without carrying the key and begins
driving, a warning buzzer will sound once
more. (C) A warning buzzer sounds from the
vehicle for two seconds after locking
the door with the door handle
switch.
This indicates that the driver is attempting
to lock the doors while carrying the key,
neglecting to follow the instructions for
case (B) above.
Lock the doors only after turning off the
hybrid system by pressing the “POWER”
switch and checking that the indicator light
on the “POWER” switch has gone off.
A warning buzzer that sounds even though
the engine has been turned off indicates
that driver is attempting to lock the ve-
hicle with the keys still in the vehicle.
Leave the vehicle only after making sure
that you are carrying the key. (D) A warning buzzer sounds continu-
ously from the instrument cluster
when opening the driver ’s door.
This indicates that the transmission selec-
tor lever is in a position other than “P”
and that the “POWER” switch is not
turned off. The message “SHIFT TO P
RANGE” will also appear on the multi −in-
formation display.
Get out of the vehicle only after setting
the transmission selector lever in the “P”
position, turning off the hybrid system by
pressing the “POWER” switch and
checking that the indicator light on the
“POWER” switch has gone off.

’07Camry hybrid_U (L/O 0610)
306
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
(E) A warning buzzer sounds continu-ously from the instrument cluster
and from the vehicle when closing
the door after getting out of the ve-
hicle.
This indicates that the driver is attempting
to leave the vehicle carrying the key, ne-
glecting to follow the instructions for case
(D) above. The messages, “SHIFT TO P
RANGE” and “KEY IS NOT DETECTED”,
will also appear alternately on the multi −
information display and the master warn-
ing light will come on.
Get out of the vehicle only after setting
the transmission selector lever in the “P”
position, turning off the hybrid system by
pressing the “POWER” switch and
checking that the indicator light on the
“POWER” switch has gone off. (F) A warning buzzer sounds once from
the instrument cluster and three
times from the vehicle when a pas-
senger is getting out of the vehicle.
This indicates that the passenger is
attempting to leave the vehicle carrying
the key, without turning the hybrid system
off. The message “KEY IS NOT
DETECTED” will also appear on the
multi −information display and the master
warning light will come on.
When passengers get out of the vehicle,
care should be taken to leave the key
with the driver. If the driver begins driving
after a passenger gets out of the vehicle
carrying the key, a warning buzzer will
sound once more.
(G) A warning buzzer sounds from the vehicle for two seconds when lock-
ing the vehicle from the outside with
the door handle switch.
This indicates that the driver is attempting
to lock the door with the key still in the
vehicle.
Leave the vehicle only after making sure
that you are carrying the key. (H) A warning buzzer sounds once from
the instrument cluster when the
“POWER” switch is turned off.
This indicates that the key battery is low.
(This warning buzzer sounds only when
the hybrid system has been on or the
“POWER” switch has been set at ON for
20 minutes or more.) The message “LOW
KEY BATTERY” will also appear on the
multi −information display.
Change the key battery ahead of time in
order to ensure that the smart key system
works properly.
(I) A warning buzzer sounds repeatedly from the instrument cluster when
opening the driver ’s door with the
“POWER” switch turned off.
This indicates that the steering wheel is
not locked. Turn the engine off and then
open the door in order to lock the steering
wheel.

’07Camry hybrid_U (L/O 0610)
307
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
(J) The “POWER” switch flashes greenonce every second.
This indicates that the steering lock is
stuck. The message “S/T IS NOT
UNLOCKED” will also appear on the
multi −information display.
To free it, rotate the steering wheel slight-
ly while pressing the “POWER” switch.
(K) The “POWER” switch flashes amber once every 2 seconds.
When the message “CHECK S/T LOCK”
appears on the multi −information display—
This indicates a problem with the steering
lock function. Have your vehicle checked
at your Toyota dealer.
When no message appears on the multi −
information display—
This indicates a problem with the push
button start function. Have your vehicle
checked at your Toyota dealer. THEFT PREVENTION FUNCTION
When the hybrid system is turned off,
the engine immobilizer system is auto-
matically set. (See “Engine immobilizer
system” on page 24 in Section 1
−2.)
When the driver ’s door is opened after
turning off the hybrid system, the steer-
ing wheel will lock.
When the 12 volt battery is discharged,
the steering lock function may not op-
erate properly.
Always slow down in gusty crosswinds.
This will allow you much better control.
Drive slowly onto curbs and, if pos-
sible, at a right angle. Avoid driving
onto high, sharp− edged objects and
other road hazards. Failure to do so
can lead to severe tire damage such
as a tire burst.
Drive slowly when passing over bumps
or travelling on a bumpy road. Other-
wise, the impact could cause severe
damage to the tires and/or wheels.
When parking on a hill, turn the front
wheels until they touch the curb so
that the vehicle will not roll. Apply the
parking brake, and place the transmis-
sion in “P”. If necessary, block the
wheels.
Tips for driving in various
conditions

’07Camry hybrid_U (L/O 0610)
308
2007 CAMRY HV from Oct. ’06 Prod. (OM33749U)
Washing your vehicle or driving through
deep water may get the brakes wet. To
see whether they are wet, check that
there is no traffic near you, and then
press the pedal lightly. If you do not
feel a normal braking force, the brakes
are probably wet. To dry them, drive
the vehicle cautiously while lightly
pressing the brake pedal with the park-
ing brake applied. If they still do not
work safely, pull to the side of the road
and call a Toyota dealer for assistance.
CAUTION
Before driving off, make sure that
the parking brake is fully released
and the parking brake reminder
light is off.
Do not leave your vehicle unat-
tended while the hybrid system is
operating.
Do not rest your foot on the brake
pedal while driving. It can cause
dangerous overheating, needless
wear, and poor fuel economy.
To drive down a long or steep hill,
reduce your speed and use engine
brake. Remember, if you ride the
brakes excessively, they may over-
heat and not work properly.
Be careful when accelerating, en-
gine braking or braking on a slip-
pery surface. Sudden acceleration
or engine braking could cause the
vehicle to skid or spin.
Do not drive in excess of the speed
limit. Even if the legal speed limit
permits it, do not drive over 140
km/h (85 mph) unless your vehicle
has highspeed capability tires.
Driving over 140 km/h (85 mph) may
result in tire failure, loss of control
and possible injury. Be sure to con-
sult a tire dealer to determine
whether the tires on your vehicle
are highspeed capability tires or
not before driving at such speeds.
Do not continue normal driving
when the brakes are wet. If they are
wet, your vehicle will require a
longer stopping distance, and it
may pull to one side when the
brakes are applied. Also, the park-
ing brake will not hold the vehicle
securely.
