sensor TOYOTA CAMRY HYBRID 2009 XV40 / 8.G User Guide

352 5-2. Steps to take in an emergency
*1: Open door warning buzzer:The open door warning buzzer sounds to alert the driver that one or more of
the doors is not fully closed (with the vehicle having reached a speed of 3
mph [5 km/h]).
*
2: Driver's and front passenger’s seat belt reminders: The driver’s and front passenger’s seat belts reminder sound to alert the
driver and front passenger that his or her seat belt is not fastened. The
buzzer sounds intermittently for 10 seconds after the vehicle has reached a
speed of at least 12 mph (20 km/h). Then, if the seat belt is still unfastened,
the buzzer will sound in a different tone for 20 more seconds.
Master warning light A buzzer sounds and the
warning light comes on
and flashes to indicate that
the master warning system
has detected a malfunc-
tion. →P. 3 5 7
■ Front passenger detection sensor and passenger seat belt reminder
● If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash, even if a passen-
ger is not sitting in the seat.
● If a cushion is placed on the seat, the sensor may not detect a passen-
ger, and the warning light may not operate properly.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch does not turn off the tire
pressure warning light.
■The tire pressure warning light ma y turn on due to natural causes
The tire pressure warning light may turn on due to natural causes such
as natural air leaks or tire inflat ion pressure changes caused by tem-
perature. In this case, adjusting the tire inflation pressure will turn off the
warning light (after a few minutes).
Warning lightWarning light/DetailsCorrection procedure

423
6-2. Customization
6
Vehicle specifications
Door lock
(
→P. 50)
Unlocking using a key
Driver's door
unlocked in one step, all doors
unlocked in two steps All doors
unlocked in one step.
Speed-detecting auto-
matic door lock function Off On
Opening driver's door
unlocks all doors Off On
Shifting gears to P
unlocks all doors. On Off
Shifting gears to posi-
tion other than P locks
all doors. On Off
Automatic
light control
system
(
→P. 149) Light sensor sensitivity Level 3 Level 1 to 5
Time elapsed before
headlights automati-
cally turn off after doors
are closed
30 seconds0 seconds
60 seconds
90 seconds
Lights
(
→P. 149) Daytime running light
system (U.S.A. only)
On Off
Illumination
(
→P. 244) Time elapsed before
lights turn off
15 seconds7.5 seconds
30 seconds
Operation when the
doors are unlocked On Off
Operation after the
hybrid system is off On Off
Seat belt
reminder
(
→P. 351) Vehicle speed linked
seat belt reminder
buzzer
On Off
ItemFunctionDefault settingCustomized
setting

438 Alphabetical index
SeatsAdjustment ..............................56
Adjustment precautions........... 57
Child seats/child restraint system installation .............. 109
Cleaning ................................ 276
Head restraint..........................59
Properly sitting in the seat .......86
Seat heaters .......................... 259
Service reminder indicators .............................. 142
Shift lever If the shift lever cannot be shifted from P................. 380
Transmission ......................... 135
Shift lock system ..................... 380
Side airbags................................88
Side marker lights Replacing lights bulbs ........... 336
Switch.................................... 149
Wattage ................................. 405
Side mirror Adjusting and folding ...............71
Smart key system Entry function ..........................36
Starting the hybrid system..... 131
Spare tire Inflation pressure................... 313
Spare tire............................... 368
Spark plug ................................ 401
Specifications........................... 396
Speedometer ............................ 139
Steering Column lock release.............. 133
Steering wheel
Adjustment ..............................68
Air conditioning system switches .............................. 179
Audio switches ...................... 211
Stop lights Wattage ................................. 405
Storage feature......................... 247
Storage precautions ................164 Stuck
If your vehicle becomes
stuck ................................... 393
Sun visors ................................ 253
Sunshade Roof ........................................ 76
Switch “ECO HEAT/COOL” switch ... 174
Engine switch ....................... 131
Ignition switch ....................... 131
Light switches ....................... 149
Power door lock switch ........... 50
Power switch ......................... 131
Power window switch .............. 73
Window lock switch ................. 73
Wiper and washer switch ...... 153
Tachometer .............................. 139
Tail lights Switch ................................... 149
Wattage................................. 405
Theft deterrent system
Immobilizer system ................. 83
Theft prevention labels ............. 85
Tire inflation pressure ............. 313
Tire information Glossary ................................ 415
Size ....................................... 412
Tire identification number...... 411
Uniform tire quality grading ... 413
Tires
Chains ................................... 166
Checking ............................... 304
If you have a flat tire.............. 368
Inflation pressure .................. 313
Inflation pressure sensor....... 305
Replacing .............................. 368
Rotating tires ......................... 304
Size ....................................... 404
Snow tires ............................. 166
Spare tire .............................. 368
Tools ......................................... 368
Total load capacity .................. 165
T
