TOYOTA CAMRY HYBRID 2016 XV50 / 9.G Owners Manual

1113-2. Opening, closing and locking the doors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
nOperation signals
Doors:
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
Driver’s window and moon roof:
A buzzer sounds to indicate that the driver’s window and moon roof are open-
ing.
n Security feature
If a door is not opened within approximately 60 seconds after the vehicle is
unlocked, the security feature automatically locks the vehicle again.
n When the door cannot be locked by the lock sensor on the side of the
door handle
n Door lock buzzer
If an attempt to lock the doors is made when a door is not fully closed, a
buzzer sounds for 5 seconds. Fully close the door to stop the buzzer, and
lock the doors again.
n Alarm (if equipped)
Locking the doors will set the alarm system. ( P. 80)
n If the smart key system or the wireless remote control does not operate
properly
Use the mechanical key to lock and unlock the doors. ( P. 487)
Replace the battery with a new one if it is depleted. ( P. 425)
If the door will not lock even when the
side sensor area is touched, try using
your palm to touch the lock sensor.

1123-2. Opening, closing and locking the doors
CAMRY_HV_U (OM33C35U)
uDoor lock switchesLocks all the doors
Unlocks all the doors
uInside lock buttonsLocks the door
Unlocks the door
The front doors can be opened
by pulling the inside handle
even if the lock buttons are in
the lock position.
Move the inside lock button to the lock position.
Close the door.
The door cannot be locked if the pow er switch is in ACCESSORY or
ON mode, or the electronic key is left inside the vehicle.
The key may not be detected correctly and the door may be locked.
Unlocking and locking the doors from the inside
1
2
1
2
Locking the front doors from the outside without a key
1
2

1133-2. Opening, closing and locking the doors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
The door cannot be opened from
inside the vehicle when the lock is
set.Unlock
Lock
These locks can be set to prevent
children from opening the rear
doors. Push down on each rear
door switch to lock both rear doors.
The following functions can be set or cancelled:
Rear door child-protector lock
1
2
Automatic door lockin g and unlocking systems
FunctionOperation
Shift position linked door
locking function Shifting the shift lever out of P locks all the
doors.
Shift position linked door
unlocking function Shifting the shift lever to P unlocks all the doors.
Speed linked door lock-
ing function All the doors are locked when the vehicle speed
is approximately 12 mph (20 km/h) or higher.
Driver's door linked door
unlocking function All the doors are unlocked when the driver's
door is opened within 10 seconds after turning
the power switch off.

1143-2. Opening, closing and locking the doors
CAMRY_HV_U (OM33C35U)n
Setting and canceling the functions
The automatic door locking and unlocking functions can be set or
canceled on the Entune
Audio system screen (P. 529) or by fol-
lowing the procedure below.
Close all the doors and turn the power switch to ON mode. (Per-
form step 2 within 10 seconds.)
Shift the shift lever to P or N,
and press and hold the
driver's door lock switch
(
or ) for
approximately 5 seconds and
then release.
The shift lever and switch posi-
tions corresponding to the
desired function to be set are
shown as follows.
Use the same procedure to cancel the function.
When the setting or canceling operation is complete, all doors are
locked and then unlocked.
1
2
FunctionShift lever positionDriver’s door lock switch position
Shift position linked door lock-
ing function
PShift position linked door
unlocking function
Speed linked door locking func-
tion
NDriver's door linked door
unlocking function

1153-2. Opening, closing and locking the doors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
nSwitching the door unlock function
It is possible to set which doors the entry function unlocks using the wireless
remote control.
Turn the power switch off.
When the indicator light on the key surface is not on, press and hold ,
or for approximately 5 seconds while pressing and holding
.
The setting changes each time an operation is performed, as shown below.
(When changing the setting continuously, release the buttons, wait for at least
5 seconds, and repeat step .)
Vehicles with an alarm: To prevent un intended triggering of the alarm, unlock
the doors using the wireless remote control and open and close a door once
after the settings have been changed. (If a door is not opened within 60 sec-
onds after is pressed, the doors will be locked again and the alarm will
automatically be set.)
In case that the alarm is triggered, immediately stop the alarm. ( P. 8 0 )
n Conditions affecting the operation of the smart key system or wireless
remote control
P. 124
n Customization
Settings (e.g. unlocking function using a key) can be changed.
(Customizable features: P. 529)
1
2
2
Multi-information
displayUnlocking functionBeep
Holding the driver’s door
handle unlocks only the
driver’s door.
Exterior: Beeps 3
times
Interior: Pings once
Holding the front passen-
ger’s door handle unlocks
all the doors.
Holding either front door
handle unlocks all the
doors.Exterior: Beeps
twice
Interior: Pings once

1163-2. Opening, closing and locking the doors
CAMRY_HV_U (OM33C35U)
WARNING
nTo prevent an accident
Observe the following precautions while driving the vehicle.
Failure to do so may result in a door opening and an occupant falling out,
resulting in death or serious injury.
lEnsure that all doors are properly closed.
l Do not pull the inside handle of the doors while driving.
Be especially careful for the front doors, as the doors may be opened
even if the inside lock buttons are in locked position.
l Set the rear door child-protector locks when children are seated in the rear
seats.

1173-2. Opening, closing and locking the doors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
Pull up the lever to release the
trunk lid.
uSmart key system
While carrying the electronic
key, press the button on the
trunk lid.
When all the doors are unlocked
with the power door lock sys-
tem, the trunk can be opened
without carrying the electronic
key.
uWireless remote control
Press and hold the switch.
Tr unk
The trunk can be opened using the trunk opener, entry function,
wireless remote control.
Opening the trunk from inside the vehicle
Opening the trunk from outside the vehicle

1183-2. Opening, closing and locking the doors
CAMRY_HV_U (OM33C35U)
nOperation signal
A buzzer sounds to indicate that the trunk has been opened.
n Trunk light
The trunk light turns on when the trunk is opened.
n Function to prevent the tr unk being locked with the electronic key inside
l When all doors are being locked, closing the trunk lid with the electronic key
left inside the trunk will sound an alarm.
In this case, the trunk lid can be opened by pressing the trunk release but-
ton on the trunk lid.
l Even when the spare electronic key is put in the trunk with all the doors
locked, the key confinement prevention function can be activated so the
trunk can be opened. In order to prevent theft, take all electronic keys with
you when leaving the vehicle.
l Even when the electronic key is put in the trunk with all the doors are locked,
the key may not be detected depending on the places and the surrounding
radio wave conditions. In this case, the key confinement prevention function
cannot be activated, causing the doors to lock when the trunk is closed.
Make sure to check where the key is before closing the trunk.
l The key confinement prevention function cannot be activated if any one of
the doors is unlocked. In this case, open the trunk using the trunk opener.
n Internal trunk release lever
The trunk lid can be opened by pushing
the glow-in-the-dark lever located on the
inside of the trunk lid to the side.
The lever will continue to glow for some
time after the trunk lid is closed.

1193-2. Opening, closing and locking the doors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
nBefore driving
lMake sure that the trunk lid is fully closed. If the trunk lid is not fully closed,
it may open unexpectedly while driving and hit near-by objects or luggage
in the trunk may be thrown out, causing an accident.
l Do not allow children to play in the trunk.
If a child is accidentally locked in the trunk, they could suffer from heat
exhaustion, suffocation or other injuries.
l Do not allow a child to open or close the trunk lid.
Doing so may cause the trunk lid to open unexpectedly, or cause the
child’s hands, head, or neck to be caught by the closing trunk lid.
n Important points while driving
Never let anyone sit in the trunk. In the event of sudden braking or a colli-
sion, they are susceptible to death or serious injury.

1203-2. Opening, closing and locking the doors
CAMRY_HV_U (OM33C35U)
WARNING
nUsing the trunk
Observe the following precautions.
Failure to do so may cause parts of the body to be caught, resulting in seri-
ous injury.
lRemove any heavy loads, such as snow and ice, from the trunk lid before
opening it. Failure to do so may cause the trunk lid to suddenly shut again
after it is opened.
l When opening or closing the trunk lid, thoroughly check to make sure the
surrounding area is safe.
l If anyone is in the vicinity, make sure they are safe and let them know that
the trunk is about to open or close.
l Use caution when opening or closing the trunk lid in windy weather as it
may move abruptly in strong wind.
l Do not attach any accessories other than genuine Toyota parts to the trunk
lid. Such additional weight on the trunk lid may cause the lid to suddenly
shut again after it is opened.
lThe trunk lid may suddenly shut if it is
not opened fully. It is more difficult to
open or close the trunk lid on an incline
than on a level surface, so beware of
the trunk lid unexpectedly opening or
closing by itself. Make sure that the
trunk lid is fully open and secure before
using the trunk.
l When closing the trunk lid, take extra
care to prevent your fingers etc. from
being caught.
l When closing the trunk lid, make sure to
press it lightly on its outer surface.
