TOYOTA CAMRY HYBRID 2016 XV50 / 9.G Owners Manual

1313-3. Adjusting the seats
3
Operation of each component
CAMRY_HV_U (OM33C35U)
WARNING
nWhen folding the rear seatback down
Observe the following precautions. Failure to do so may result in death or
serious injury.
lDo not fold the seatback down while driving.
l Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.
l Do not allow anyone to sit on a folded seatback or in the trunk while driv-
ing.
l Do not allow children to enter the trunk.
n When returning the seat to its original position
l Ensure that the seat belt does not get caught between or behind the seats.
l If the seat belt has been released from its guide, pass the seat belt through
its guide. ( P. 32)
n Seat adjustment
Be careful not to get hands or feet pinched between the rear console box
and the rear seat when folding down the rear seatback.
n After returning the seatback to the upright position
Observe the following precautions. Failure to do so may result in death or
serious injury.
lMake sure the seatback is securely locked by pressing it forward and rear-
ward on the top.
l Check that the seat belts are not twisted or caught in the seatback.
l Make sure that the seat belt is passing through its guide.

1323-3. Adjusting the seats
CAMRY_HV_U (OM33C35U)
Vertical adjustmentUp
Pull the head restraint up.
Down
Push the head restraint down while
pressing the lock release button.
nRemoving the head restraints (front seats)
n Installing the head restraints (front seats)
Head restraints
Head restraints are provided for all seats.
Front seats
Lock release button
1
2
Pull the head restraint up while pressing
the lock release button.
Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.
Lock
release
button
Lock release
button

1333-3. Adjusting the seats
3
Operation of each component
CAMRY_HV_U (OM33C35U)n
Adjusting the height of the head restraints (front seats)
Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.
WARNING
n Head restraint precautions (front seats)
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.
lUse the head restraints designed for each respective seat.
l Adjust the head restraints to the correct position at all times.
l After adjusting the head restraints, push down on them and make sure
they are locked in position.
l Do not drive with the head restraints removed.

134
CAMRY_HV_U (OM33C35U)
3-4. Adjusting the steering wheel and mirrors
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.
After adjustment, pull the lever up
to secure the steering wheel.
To sound the horn, press on or
close to the mark.
Steering wheel
Adjustment procedure
1
2
Horn

1353-4. Adjusting the steering wheel and mirrors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
WARNING
nCaution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.
n After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, and resulting in death or serious injury. Also, the horn may not
sound if the steering wheel is not securely locked.

1363-4. Adjusting the steering wheel and mirrors
CAMRY_HV_U (OM33C35U)
The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.
Manual anti-glare inside rear view mirror
Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.
Normal position
Anti-glare position
Inside rear view mirror
The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.
Adjusting the height of rear view mirror
Anti-glare function
1
2

1373-4. Adjusting the steering wheel and mirrors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
Auto anti-glare inside rear view mirror
Responding to the level of brightness of the headlights of vehicles
behind, the reflected light is automatically reduced.
Changing automatic anti-glare
function mode
On/Off
When the automatic anti-glare
function is in ON mode, the indica-
tor illuminates.
The function will set to ON mode
each time the power switch is
turned to ON mode.
Pressing the button turns the func-
tion to OFF mode. (The indicator
also turns off.)
n To prevent sensor error (vehicles with an auto anti-glare inside rear view
mirror)
Indicator
To ensure that the sensors operate prop-
erly, do not touch or cover them.
WARNING
Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.

1383-4. Adjusting the steering wheel and mirrors
CAMRY_HV_U (OM33C35U)
To select a mirror to adjust,
press the switch.Left
Right
To adjust the mirror, press the
switch. Up
Right
Down
Left
Push the mirror back in the direc-
tion of the vehicle’s rear.
n Mirror angle can be adjusted when
The power switch is in ACCESSORY or ON mode.
n When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. ( P. 336)
Outside rear view mirrors
Adjustment procedure
1
1
2
2
1
2
3
4
Folding the mirrors

1393-4. Adjusting the steering wheel and mirrors
3
Operation of each component
CAMRY_HV_U (OM33C35U)
WARNING
nImportant points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.
lDo not adjust the mirrors while driving.
l Do not drive with the mirrors folded.
l Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.
n When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.
n When the mirror de foggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

140
CAMRY_HV_U (OM33C35U)
3-5. Opening and closing the windows
The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:
Closing
One-touch closing (front side
windows only)
*
Opening
One-touch opening (front side
windows only)
*
*
: To stop the window partway, oper- ate the switch in the opposite direc-
tion.
Press the switch to lock the pas-
senger window switches.
Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.
n The power windows can be operated when
The power switch is in ON mode.
n Operating the power windows afte r turning the hybrid system off
The power windows can be operated for approximately 45 seconds even
after the power switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.
n Jam protection function (front door windows)
If an object becomes caught between the window and the window frame, win-
dow travel is stopped and the window is opened slightly.
Power windows
Opening and closing procedures
1
2
3
4
Window lock switch
