TOYOTA CAMRY HYBRID 2016 XV50 / 9.G Owners Manual

3015-9. Bluetooth® phone
5
Audio system
CAMRY_HV_U (OM33C35U)
You can make a call using numbers registered in the contact.Display the phone screen. ( P. 297)
Select “Favorites” tab.
Select the desired number to make a call.
You can make a call using the call history, which has the 3 functions
below. : calls which you missed
: calls which you received
: calls which you made
Display the phone screen. ( P. 297)
Select “Call History” tab.
Select or the desired entry from the list.
When is selected
Check that the “Call” screen is displayed.
When the desired contact is selected
Select the desired number.
Check that the “Call” screen is displayed.
nCall history list
lIf you make a call to or receive a call from a number registered in the con-
tact, the name is displayed in the call history.
l If you make multiple calls to the same number, only the last call made is dis-
played in the call history.
n International calls
You may not be able to make international calls, depending on the mobile
phone in use.
Calling using favorites list
Dialing from call history
1
2
3
1
2
3
4
4
5

3025-9. Bluetooth® phone
CAMRY_HV_U (OM33C35U)
Press the switch on the steer-
ing wheel or select .
Press the switch on the steering wheel or select .
Turn the “PWR/VOL” knob. You can also adjust the volume using the
steering switches.
n International calls
Received international calls may not be displayed correctly depending on the
cellular phone in use.
Receiving a call
When a call is received, the following screen is displayed
together with a sound.
To answer the phone
To refuse a call
To adjust the incoming call volume

3035-9. Bluetooth® phone
5
Audio system
CAMRY_HV_U (OM33C35U)
Select “-” or “+”. You can also adjust the volume using the steering
switches or the volume knob.
Select “Mute”.
When using phone services such as an answering service or a bank,
you can store phone numbers and code numbers in the contact.
Select “0-9”.
Input the number.
nRelease Tones
“Release Tones” appear when a c ontinuous tone signal(s) contain-
ing a (w) is registered in the contact list.
Select “Release Tones”.
Speaking on the phone
The following screen is displayed when speaking on the phone.
To adjust the call volume
To prevent the other party from hearing your voice
Inputting tones
1
2
1

3045-9. Bluetooth® phone
CAMRY_HV_U (OM33C35U)
nRelease Tones
lA continuous tone signal is a character string that consists of numbers and
the characters p or w. (e.g.056133w0123p#1 )
l When the “p” pause tone is used, the tone data up until the next pause tone
will be automatically sent after 2 seconds have elapsed. When the “w”
pause tone is used, the tone data up until the next pause tone will be auto-
matically sent after a user operation is performed.
l Release tones can be used when automated operation of a phone based
service such as an answering machine or bank phone service is desired. A\
phone number with continuous tone signals can be registered in the contact
list.
l Tone data after a “w” pause tone can be operated on voice command during
a call.
Select “Handset Mode” to on from a hands-free call to a cellular
phone call.
Select “Handset Mode” to off from a cellular phone call to a hands-free
call.
Select “Transmit Volume”.
Select the desired level for the transmit volume.
Select “OK”.
Press the switch on the steering wheel or select .
To transfer a call
Transmit volume setting
To hang up
1
2
3

3055-9. Bluetooth® phone
5
Audio system
CAMRY_HV_U (OM33C35U)
When a call is interrupted by a third party while talking, an incoming
call message will be displayed.
To talk with the other party:• Press the switch on the steering wheel.
• Select .
To refuse the call: • Press the switch on the steering wheel.
• Select .
Every time you press the switch on the steering wheel or select during call waiting, you will be switched to the other party.
nTransferring calls
lIf you transfer from the cellular phone to hands-free, the hands-free screen
will be displayed, and you can operate the system using the screen.
l Transfer method and operation may vary according to the cellular phone
used.
l For operation of the cellular phone in use, see the phone's manual.
n Call waiting operation
Call waiting operation may differ depending on your phone company and cel-
lular phone.
Call waiting

3065-9. Bluetooth® phone
CAMRY_HV_U (OM33C35U)
Press the “ ” button.
Select .
When an e-mail/SMS/MMS is received, the incoming message screen
pops up with sound and is ready to be operated on the screen. Select to check the message.
Select to refuse the message.
Select to call the message
sender.
nReceiving a message
lDepending on the cellular phone used for receiving messages, or its regis-
tration status with the navigation system, some information may not be dis-
played.
l The pop up screen is separately available for incoming e-mail and SMS/
MMS messages under the following conditions:
E-mail:
• “Incoming E-mail Display” is set to “Full Screen”. ( P. 317)
• “E-mail Notification Popup” is set to on. ( P. 317)
SMS/MMS:
• “Incoming SMS/MMS Display” is set to “Full screen”. (P. 317)
• “SMS/MMS Notification Popup” is set to on. ( P. 317)
Bluetooth® phone message function
Received messages can be forwarded from the connected
Bluetooth® phone, enabling checking and replying using the
multimedia system.
Depending on the type of Bluetooth
® phone connected, received
messages may not be transf erred to the message inbox.
If the phone does not support the message function, this func-
tion cannot be used.
Displaying message inbox screen
Receiving a message
1
2
1
2
3

3075-9. Bluetooth® phone
5
Audio system
CAMRY_HV_U (OM33C35U)
Display the message inbox screen. (P. 306)
Select the desired message from the list.
Check that the message is dis-
played. E-mails: Select “Mark
Unread” or “Mark Read” to
mark mail unread or read on
the message inbox screen.
This function is available when
“Update Read Status on Phone”
is set to on. ( P. 317)
Select to make a call to the sender.
Select to have messages read out. To cancel this function, select
“Stop”.
Select to display the previous or next message.
Select to reply the message.
n Check the messages
lDepending on the type of Bluetooth® phone being connected, it may be nec-
essary to perform additional steps on the phone.
l Messages are displayed in the appropriate connected Bluetooth
® phone’s
registered mail address folder.
Select the tab of the desired folder to be displayed.
l Only received messages on the connected Bluetooth
® phone can be dis-
played.
l The text of the message is not displayed while driving.
l When “Automatic Message Readout” is set to on, messages will be auto-
matically read out. ( P. 317)
l Turn the “PWR/VOL” knob, or use the volume switch on the steering wheel
to adjust the message read out volume.
l The message read out function is available even while driving.
Checking the messages
1
2
3
1
2
3
4
5

3085-9. Bluetooth® phone
CAMRY_HV_U (OM33C35U)
Display the message inbox screen. (P. 306)
Select the desired message from the list.
Select “Quick Message”.
Select the desired message.
Select “Send”.
nEditing quick reply message Select “Quick Message”.
Select corresponding to the desired message to edit.
Select “OK” when editing is completed.
Calls can be made to an e-mail/SMS/MMS message sender's phone
number. Display the message inbox screen. ( P. 306)
Select the desired message.
Select .
Check that the “Call” screen is displayed.
nCalling from a number within a message
Calls can be made to a number identified in a message's text area.
Display the message inbox screen. ( P. 306)
Select the desired message.
Select the text area.
Select corresponding to the desired number.
Check that the “Call” screen is displayed.
nCalling from the incoming message screen  P. 305
Replying to a message
Calling the message sender
1
2
3
4
5
1
2
3
1
2
3
4
1
2
3
4
5

3095-9. Bluetooth® phone
5
Audio system
CAMRY_HV_U (OM33C35U)n
Steering wheel switches on the right hand side
Off hook switch• Make a call
• Receive a call
• Display “Phone” screen
On hook switch • End a call
• Refuse a call
nSteering wheel switches on the left hand side
Vo l u m e s w i t c h• Increase/Decrease the volume
• Press and hold: Continuously increase/
decrease the volume
Back switch • Return to the previous screen
Cursor switch • Select a list/tab
Enter switch • Select an item
Using the steering wheel switches
The steering wheel switches can be used to operate a connected
cellular phone.
Operating a telephone using the steering wheel switches
1
2
1
2
3
4

3105-9. Bluetooth® phone
CAMRY_HV_U (OM33C35U)
To display the screen shown below, press the “SETUP” button, and
select “Phone” on the “Setup” screen.Set the phone connection
( P. 290)
Setting the sound ( P. 310)
Contact/Call History Settings
(  P. 311)
Set the message settings
(  P. 317)
Set the phone display
(  P. 318)
Display the “Phone/Message Settings” screen. ( P. 310)
Select “Sound Settings” on the
“Phone/Message Settings”
screen. Set the desired ringtone.
Adjust the ringtone volume.
Adjust the message readout
volume.
Set the desired incoming
SMS/MMS tone.
Adjust the incoming SMS/
MMS tone volume.
Set the incoming e-mail tone.
Adjust the incoming e-mail tone volume.
Adjust the default volume of the other party's voice.
n To return to the default volume settings
Select “Default”, and then “Yes”.
Bluetooth® phone settings
You can adjust the hands-free system to your desired settings.
“Phone/Message Settings” screen
1
2
13
14
5
Sound setting
1
2
1
2
13
4
5
6
7
8
