TOYOTA CAMRY HYBRID 2016 XV50 / 9.G Owners Manual

3315-11. Using the voice command system
5
Audio system
CAMRY_HV_U (OM33C35U)
The Mobile Assistant feature will activate Apple’s Siri® Eyes Free
mode via the steering wheel switches. To operate the Mobile Assis-
tant, a compatible cellular phone must be registered and connected to
this system via Bluetooth
®. (  P. 290)
Press and hold the until
you hear the beeps.
The Mobile Assistant can be
used only when the following
screen is displayed.
To cancel the Mobile Assistant,
select “Cancel”, or press and hold
the on the steering wheel.
To restart the Mobile Assistant for
additional commands, press the on the steering wheel.
• Mobile Assistant can only be restarted after the system responds to a voice command.
• After some phone and music commands, the Mobile Assistant feature will automatically end to complete the requested action.
n
Adjusting the Mobile Assistant volume
The volume of the Mobile Assistant can be adjusted using the
“PWR/VOL” knob or steering wheel volume switches. The Mobile
Assistant and phone call volumes are synchronized.
Mobile Assistant
1
2

3325-11. Using the voice command system
CAMRY_HV_U (OM33C35U)
n Notes about Mobile Assistant
lThe available features and functions may vary based on the iOS version
installed on the connected device.
l Some Siri features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri will inform you that the function is not avai\
lable.
l If Siri is not enabled on the cellular phone connected via Bluetooth
®, an
error message will be displayed on the screen.
l While a phone call is active, the Mobile Assistant cannot be used.
l If using the navigation feature of the cellular phone, ensure the active audio
source is Bluetooth
® audio or iPod in order to hear turn by turn direction
prompts.

333
6Interior features
CAMRY_HV_U (OM33C35U)6-1. Using the air
conditioning system
and defogger
Automatic air conditioning system............................. 334
Seat heaters...................... 341
6-2. Using the interior lights Interior lights list ................ 342
• Interior lights ................. 343
• Personal lights .............. 343 6-3. Using the storage
features
List of storage features ..... 345
• Glove box...................... 346
• Console box .................. 346
• Coin holder ................... 347
• Bottle holders ................ 347
• Cup holders .................. 348
• Auxiliary boxes.............. 349
• Open tray ...................... 354
Trunk features ................... 355
6-4. Other interior features Other interior features ....... 356
• Sun visors ..................... 356
• Vanity mirrors................ 356
• Clock ............................. 357
• Ashtray.......................... 358
• Power outlets ................ 359
• Armrest ......................... 360
• Assist grips ................... 360
• Coat hooks.................... 361
Garage door opener.......... 362
Safety Connect ................. 367
Compass ........................... 372

334
CAMRY_HV_U (OM33C35U)
6-1. Using the air conditioning system and defogger
nAdjusting the temperature setting
To adjust the temperature setting, turn clockwise to increase
the temperature and countercloc kwise to decrease the tempera-
ture.
nFan speed setting
To adjust the fan speed, press “ ” on to increase the fan
speed and “ ” to decrease the fan speed.
Press to turn the fan off.
Automatic air conditioning system
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Air conditioning controls

3356-1. Using the air conditioning system and defogger
6
Interior features
CAMRY_HV_U (OM33C35U)n
Change the airflow mode
To change the airflow mode,
press .
The air outlets used are
switched each time the button is
pressed.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the
windshield defogger oper-
ates.
Press .
The dehumidification function begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set-
ting.
Adjust the temperature setting.
To stop the operation, press .
nAutomatic mode indicator
If the fan speed setting or air fl ow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.
nAdjusting the temperature for driver and passenger seats sep-
arately (“SYNC” mode)
To turn on the “SYNC” mode, perform any of the following proce-
dures:
l Press .
l Adjust the passenger’s side temperature setting.
The indicator comes on when the “SYNC” mode is on.
While in “SYNC” mode, the temperature of the rear air outlets is set at
the driver’s side temperature setting.
1
2
3
4
Using automatic mode
1
2
3

3366-1. Using the air conditioning system and defogger
CAMRY_HV_U (OM33C35U)n
Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recir-
culated air mode (indicator on) each time is pressed.
n
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the air flow and
temperature up.
To return to the previous mode, press again when the windshield
is defogged.
n
Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
Other functions

3376-1. Using the air conditioning system and defogger
6
Interior features
CAMRY_HV_U (OM33C35U)n
Location of air outlets
The air outlets and air volume
change according to the
selected airflow mode.
*: If equipped
n
Adjusting the position of and opening and closing the air out-
lets
Direct air flow to the left or right, up or down.
Turn the knob to open or close the vent.
Air outlets
*
FrontRear (if equipped)
1
2

3386-1. Using the air conditioning system and defogger
CAMRY_HV_U (OM33C35U)
nOperation of the air conditioning system in Eco drive mode
In Eco drive mode, the air conditioning system is controlled as follows to pri-
oritize fuel efficiency:
lEngine speed and compressor operation controlled to restrict heating/cool-
ing capacity
l Fan speed restricted when automatic mode is selected
To improve air conditioning performance, perform the following operations:
l Adjust the fan speed
l Turn off Eco drive mode
n Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow
immediately after is pressed.
n Fogging up of the windows
lThe windows will easily fog up when the humidity in the vehicle is high.
Turning on will dehumidify the air from the outlets and defog the wind-
shield effectively.
l If you turn off, the windows may fog up more easily.
l The windows may fog up if the recirculated air mode is used.
n Windshield fog detection function
When automatic mode is set, the humidity sensor (P. 340) detects fog on
the windshield and controls the air conditioning system to prevent fog.
n Outside/recirculated air mode
lWhen driving on dusty roads such as tunnels or in heavy traffic, set the out-
side/recirculated air mode button to recirculated air mode. This is effective in
preventing outside air from entering the vehicle interior. During cooling oper-
ation, setting the recirculated air mode will also cool the vehicle interior
effectively.
l Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.
n When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on
lIn order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.
l Recirculated air mode is selected as a default mode when the power switch
is turned to ON mode.
l It is possible to switch to outside air mode at any time by pressing .

3396-1. Using the air conditioning system and defogger
6
Interior features
CAMRY_HV_U (OM33C35U)n
When the outside temperature is low
The dehumidification function may not operate even when is pressed.
n Ventilation and air conditioning odors
lTo let fresh air in, set the air conditioning system to the outside air mode.
l During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.
l To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air
mode prior to turning the vehicle off.
• The start timing of the blower may be delayed for a short period of time
immediately after the air conditioning system is started in automatic
mode.
n Air conditioning filter
P. 423
n Customization
The air conditioning control of Eco drive mode can be changed to the same
setting as that used in normal drive mode.
(Customizable features P. 536)
WARNING
nTo prevent the windshield from fogging up
lDo not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
n To prevent burns
Do not touch the rear view mirror surfaces when the outside rear view mirror
defoggers are on.
lDo not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.

3406-1. Using the air conditioning system and defogger
CAMRY_HV_U (OM33C35U)
NOTICE
nHumidity sensor
n To prevent 12-volt battery discharge
Do not leave the air conditioning system on longer than necessary when the
hybrid system is off.
In order to detect fog on the windshield, a
sensor which monitors the temperature
of the windshield, the surround humidity,
etc. is installed. ( P. 338)
Follow these points to avoid damaging
the sensor:
l Do not disassemble the sensor
l Do not spray the glass cleaner on the
sensor or subject it to strong impacts
l Do not stick anything on the sensor
