TOYOTA CAMRY HYBRID 2023 Owners Manual

911-5. Theft deterrent system
1
For safety and security
■System maintenance
The vehicle has a maintenance-free type alarm system.
■ Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft , make sure of
the following:
● Nobody is in the vehicle.
● The windows and moon roof are closed before the alarm is set.
● No valuables or other personal items are left in the vehicle.
■ Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
●For Canada: The doors are unlocked
using the mechanical key.
● Except for Canada: The trunk is opened
using the mechanical key.
● A person inside the vehicle opens a door
or the trunk or hood, or unlocks the vehi-
cle.
● The 12-volt battery is recharged or
replaced when the vehicle is locked.
(P. 533)

921-5. Theft deterrent system
■Alarm-operated door lock
In the following cases, depending on the situation, the door ma y automatically
lock to prevent improper entry into the vehicle:
● When a person remaining in the vehicle unlocks the door and the alarm is
activated.
● While the alarm is activated, a person remaining in the vehicle unlocks the
door.
● When recharging or replacing the 12-volt battery
NOTICE
■To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

93
Instrument cluster2
2. Instrument clusterWarning lights and indicators .......................... 94
Gauges and meters .......... 100
Multi-information display (4.2-inch display) ............ 104
Multi-information display (7-inch display) ............... 117
Head-up display ................ 136
Energy monitor/ consumption screen ........ 142

942. Instrument cluster
4.2-inch display
7-inch display
The units used on the meters and some indicators may differ depending on
the target region.
Warning lights and indicators
The warning lights and indicators on the instrument cluster, ce n-
ter panel and outside rear view mirrors inform the driver of the
status of the vehicle’s various systems.
For the purpose of explanation, t he following illustrations dis-
play all warning lights a nd indicators illuminated.

952. Instrument cluster
2
Instrument cluster
Warning lights inform the driver of malfunctions in any of the vehicle’s
systems.
Warning lights
*1
(U.S.A.)
Brake system warning
light ( P. 497)*2Inappropriate pedal
operation warning light
(P. 498)
*1
(Canada)
(Red)
Brake system warning
light ( P. 497)
(U.S.A.)
Parking brake indicator
(P. 498)
*1
(Yellow)
Brake system warning
light ( P. 497)
(Canada)
Parking brake indicator
(P. 498)
*1
(U.S.A.)
Malfunction indicator
lamp ( P. 498)*1, 3
Brake hold operated
indicator ( P. 499)
*1
(Canada)
Malfunction indicator
lamp ( P. 498)*1
(Red/yellow)
Electric power steering
system warning light
(P. 499)
*1SRS warning light
(P. 498)
(Yellow)
LTA indicator ( P. 499)
*1
(U.S.A.)
ABS warning light
(P. 498)
*1
(Flashes or
illuminates)
PCS warning light
( P. 499)
*1
(Canada)
ABS warning light
(P. 498)*1, 3
(If equipped)
PKSB OFF indicator
(P. 499)

962. Instrument cluster
*1: These lights turn on when the power switch is turned to ON mode to indi-
cate that a system check is being performed. They will turn off after the
hybrid system is on, or after a few seconds. There may be a malfunction in
a system if a light does not come on, or turn off. Have the veh icle
inspected by your Toyota dealer.
*2: This light illuminates on the multi-information display with a message.
*3: This light flashes to indicate a malfunction.
*4: This light illuminates on the center panel.
(If equipped)
Intuitive parking assist
OFF indicator (P. 500)
Driver’s and front
passenger’s seat belt
reminder light
(P. 500)
(If equipped)
RCD OFF indicator
(P. 500)*4Rear passengers’ seat
belt reminder lights
(P. 500)
*1
Slip indicator ( P. 500)*1Master warning light
(P. 501)
Low fuel level warning
light ( P. 500)*1Tire pressure warning
light (P. 501)

972. Instrument cluster
2
Instrument cluster
The indicators inform the driver of the operating state of the vehicle’s
various systems.
Indicators
Turn signal indicator
( P. 222) Dynamic radar cruise
control indicator
(
P. 287)
(U.S.A.)
Headlight indicator
(P. 230) Cruise control “SET”
indicator
(
P. 287)
(Canada)
Tail light indicator
(P. 230) *1, 2PCS warning light
(P. 252)
Headlight high beam
indicator ( P. 231)
*1, 2
(If equipped)
PKSB OFF indicator
(P. 341)
*1Automatic High Beam
indicator ( P. 234)
(White)
LTA indicator ( P. 276)
AGC (Auto Glide Con-
trol) indicator ( P. 356)
(Green)
LTA indicator
(P. 253, 276)
(U.S.A.)
Parking brake indicator
(P. 223)*3
(Yellow)
LTA indicator ( P. 276)
(Canada)
Parking brake indicator
(P. 223)*1, 3
Slip indicator ( P. 304)
*1Brake hold operated
indicator (P. 227)*1, 2VSC OFF indicator
(P. 305)
*1Brake hold standby
indicator ( P. 227)
(If equipped)
“BSM” indicator
(P. 310)
Cruise control indicator
( P. 287)
(If equipped)
“RCTA” indicator
(P. 326)

982. Instrument cluster
*1: These lights turn on when the power switch is turned to ON mode to indi-
cate that a system check is being performed. They will turn off after the
hybrid system is on, or after a few seconds. There may be a malfunction in
a system if a light does not come on, or turn off. Have the veh icle
inspected by your Toyota dealer.
*2: This light turns on when the system is off.
*3: This light flashes to indicate that the system is operating.
*4, 5
(If equipped)
BSM (Blind Spot Moni-
tor) outside rear view
mirror indicators
( P. 310) “READY” indicator
(
P. 206)
*1, 6“AIRBAG ON/OFF”
indicator ( P. 4 7 ) EV indicator (
P. 80)
*6Security indicator
(P. 89, 90) EV drive mode indicator
(
P. 213)
(If equipped)
Intuitive parking assist
OFF indicator ( P. 317)*7
Low outside tempera-
ture indicator (P. 100)
“SPORT” indicator
( P. 355)
(If equipped)
RCD OFF indicator
(P. 335)
“ECO MODE” indicator
( P. 355)

992. Instrument cluster
2
Instrument cluster
*4: These indicators will illuminate in the following situations to indicate thatthe system initial check is being performed:
• When the BSM function or RCTA function is enabled and the powe r
switch is turned to ON mode.
• When the power switch is ON mode and the BSM function is enabl ed.
• When the power switch is ON mode and the RCTA function is enabled. (At this time, a buzzer will also sound).
The indicators will turn off after a few seconds. If the indicators do not
illuminate or turn off, or if a buzzer does not sound when the RCTA func-
tion is enabled, the system may be malfunctioning. Have the vehicle
inspected by your Toyota dealer.
*5: This light illuminates on the outside rear view mirrors.
*6: This light illuminates on the center panel.
*7: When the outside temperature is approximately 37°F (3°C) or lo wer, this
indicator will flash for approximately 10 seconds, then stay on .
WARNING
■If a safety system warning light does not come on
Should a safety system light such as the ABS and SRS warning lights not
come on when you start the hybrid system, this could mean that these sys-
tems are not available to help protect you in an accident, which could result
in death or serious injury. Have the vehicle inspected by your Toyota dealer
immediately if this occurs.

1002. Instrument cluster
4.2-inch display
7-inch display
Gauges and meters
