TOYOTA CELICA 1996 User Guide

6ProCarManuals.com

Part 1Keys7
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-2
Keys and Doors

Keys

Side doors

Power windows

Trunk lid/Back door

Hood

Fuel tank cap

Electric moon roof

Convertible top
Your vehicle is supplied with two
kinds of key.
1 Master keyÐThis key works in every
lock.
2 SubkeyÐThis key is for side doors.
To protect things locked in the glovebox,
trunk or luggage compartment when you
have your vehicle parked, leave the sub-
key with the attendant.
Since the side doors, trunk lid and back
door can be locked without a key, you
should always carry a spare master key in
case you accidentally lock your keys in-
side the vehicle.KEY NUMBER PLATE
Your key number is shown on the
plate. Keep the plate in a safe place
such as your wallet, not in the vehicle.
If you should lose your keys or if you need
additional keys, duplicates can be made
by a Toyota dealer using the key number.
You should also put a copy of the key
number with your important papers.
ProCarManuals.com

8
LOCKING AND UNLOCKING WITH
KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Both side doors lock and unlock simulta-
neously with either side door. In the driv-
er 's door lock, turning the key once will un-
lock the driver's door and twice in
succession will unlock both side doors si-
multaneously.LOCKING AND UNLOCKING WITH IN-
SIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
Closing the side door with the lock knob in
the lock position will also lock the side
door. Be careful not to lock your keys in
the vehicle.
Vehicles with power door lock systemÐ
The side door cannot be locked if you
leave the key in the ignition switch.Driver's side
Passenger 's side
Side doors
ProCarManuals.com

9
LOCKING AND UNLOCKING WITH
POWER DOOR LOCK SWITCH
Push the switch.
To lock: Push the switch on the front side.
To unlock: Push the switch on the rear
side
Both doors lock or unlock simultaneously.
Before driving, be sure that the side
doors are closed and locked, espe-
cially when small children are in the
vehicle. Along with the proper use of
seat belts, locking the side doors
helps prevent the driver and passen-
gers from being thrown out from the
vehicle during an accident. It also
helps prevent the side doors from
being opened unintentionally. CAUTION
!
To avoid serious personal injury, you
must do the following.


Always make sure the head, hands
and other parts of the body of all oc-
cupants are kept completely inside
the vehicle before you close the
power windows. If someone's n eck,
head or hands gets caught in a clos-
ing window, it could result in a seri-
ous injury. When anyone closes the
power windows, be sure that they
operate the windows safely.

When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock button
to prevent them from making unex-
pected use of the switches.

Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the power window switches and
get trapped in a window. Unattended
children can become involved in se-
rious accidents. CAUTION
!
The windows can be operated with the
switch on each side door.
The power windows work when the igni-
tion
switch is in the ONº position. Howev-
er, if both side doors are closed, they work
for 60 seconds even after the ignition
switch is turned off. They stop working
when either side door is opened.
OPERATING THE DRIVER'S WINDOW
Use the switch on the driver's door.
Normal operation: The window moves
as long as you hold the switch.
To open: Lightly pull down the switch.
To close: Push up the switch.
Power windowsÐ
ÐPower window precautions ÐSide windows
ProCarManuals.com

10
Automatic operation (to open only):
Pull the switch completely down and then
release it. The window will fully open. To
stop the window partway, lightly push the
switch up and then release it. OPERATING
THE PASSENGERS' WIN-
DOW
Use the switch on the passenger's
door. The driver's door also has a
switch that controls the passengers'
window.
The window moves as long as you hold
the switch.
To open: Pull down the switch.
To close: Push up the switch.
If you push in the window lock button on
the driver's door, the passenger's window
cannot be operated.
Convertible modelsÐThe window lock
button also locks the quarter windows.For front passenger's use
For driver's use
ProCarManuals.com

11
The windows can be operated with
switches on the center console.
The windows move as long as you hold
the switch.
To open: Push on the lower side of the
switch.
To close: Push on the upper side of the
switch.To open the trunk lid or back door from
the outside, insert the master key and
turn it clockwise.
See Luggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
To close the trunk lid or back door, lower
it and press down on it. After closing the
trunk lid or back door, try pulling it up to
make sure it is securely closed.
Keep the trunk lid or back door closed
while driving. This not only keeps the
luggage from being thrown out but
also prevents exhaust gases from en-
tering the vehicle.
CAUTION!
To open the trunk lid or back door
from the driver's seat, pull up on the
lock release lever.
ÐLock release lever
ÐQuarter windows
(convertible) Trunk lid (c
oupe and convertible)/
Back door (liftback)Ð
ProCarManuals.com

12
This system deactivates the lock re-
lease lever so that things locked in the
trunk or luggage compartment can be
protected.
1. (Except convertible) Push down the
security lock levers to lock the rear
seatbacks.
After locking the rear seatbacks, try fold-
ing them down to make sure they are se-
curely lockedÐotherwise, someone
could get into the trunk or luggage
compartment by folding down a rear seat.2. After closing the trunk lid or back
door, insert the master key and turn it
counterclockwise to deactivate the
lock release lever.
After closing the trunk lid or back door, try
pulling it up to make sure it is securely
locked.To open the hood, do the following.
1. Pull the hood lock release lever.
The hood will spring up slightly.
ÐLuggage security system Hood
ProCarManuals.com

13
2. In front of the vehicle, pull up on the
auxiliary catch lever and lift the hood.3. Hold the hood open by inserting the
support rod into the slot.
Before closing the hood, check to see that
you have not forgotten any tools, rags,
etc. and return the support rod to its clip-
this prevents rattles. Then lower the hood
and make sure it locks into place. If neces-
sary, press down gently on the front edge
to lock it.
After inserting the support rod into
the slot, make sure the rod supports
the hood securely.
CAUTION!
1. To open the fuel filler door, pull the
lever up.

Do not smoke, cause sparks or al-
low open flames when refuelling.
The fumes are flammable.

When opening the cap, do not re-
move the cap quickly. In hot
weather, fuel under pressure
could cause injury by spraying out
of the filler neck if the cap is sud-
denly removed. CAUTION
!
Fuel tank cap
ProCarManuals.com

14
2. To remove the fuel tank cap, turn
the cap slowly counterclockwise, then
pause slightly before removing it. Af-
ter removing the cap, hang it on the
cap hanger.
It is not unusual to hear a slight swoosh
when the cap is opened. When installing,
turn the cap clockwise till you hear a click.

Make sure the cap is tightened se-
curely to prevent fuel spillage in
case of an accident.

Use only a genuine Toyota fuel
tank cap for replacement. It has a
built-in check valve to reduce fuel
tank vacuum.
CAUTION!
Sliding operation
Tilting operation To operate the moon roof, use the
switches beside the interior light.
The moon roof works when the ignition
switch is in the ONº position. However,
if both side doors are closed, it works for
60 seconds even after the ignition switch
is turned off. It stops working when either
side door is opened.
Sun shade operationÐ
The sun shade can be opened or closed
by hand.
Sliding operationÐ
To open: Push the switch on the SLIDEº
side.
The sun shade will be opened together
with the roof.
To close: Push the switch on the opposite
side of the SLIDEº side.
As a precaution when closing, the roof
stops at the three-quarters closed posi-
tion before fully closing. Therefore, re-
lease the switch and then push it again to
close it completely.
Tilting operationÐ
To tilt up: Push the switch on the UPº
side.
To lower: Push the switch on the ºopposite
of the UPº side.
You may stop the moon roof at any desired
position. The roof will move while the switch
is being pushed and stop when released .
Electric moon roof
ProCarManuals.com

15
To avoid serious personal injury, you
must do the following.

When the vehicle is moving, always
keep the head, hands and other
parts of the body of all occupants
away from the roof opening. Other-
wise, you could be seriously in-
jured if the vehicle stops suddenly
or if the vehicle is involved in an ac-
cident.

Always make sure nobody places
his/her head, hands and other parts
of the body in the roof opening be-
fore you close the roof . If some-
one's neck, head or hands gets
caught in the closing roof, it could
result in a seri ous injury. When any-
one closes the roof, first make sure
it is safe to do so.

Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the moon roof switches and get
trapped in the roof opening. Unat-
tended children can become in-
volved in serious accidents.

Never sit on top of the vehicle
around the roof opening. CAUTION
!


When raising or lowering the con-
vertible top, keep hands clear from
the hinges of the top side rails and
any part of the top linkage.

The vehicle should never be driv-
en with the convertible top partial-
ly lowered. Make sure the top has
been either fully latched to the
windshield frame or fully lowered
before driving. CAUTION
!
NOTICE
Make sure there are no items or
packages between the rear seat-
back and the convertible top stor-age area when raising or loweringthe convertible top. Even small
items may interfere with convert-ible top operation and can causedamage.
Do not sit or place excessive
weight on the convertible top;when the top is up or down, dam-
age to the top may result.
Do not raise or lower the convert-ible top when the temperature is
below 5
C (41 F), or damage to the
top material or rear window may re- sult. If necessary to do so, warm
the vehicle in a heated garage priorto operating the convertible topmechanism.
Do not lower the convertible top if
the top is damp or wet. Possible in-terior water damage, water stains
or mildew of the top material mayresult.
When the convertible top is com-pletely lowered, keep the rear win-dow defogger turned off to avoiddamage to the convertible top.
Convertible topÐ
ÐConvertible top precautions
ProCarManuals.com
