CELICA U
1
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1−1
Overview of instruments
and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the
instrument panel
ProCarManuals.com
Page 2 of 204
CELICA U
2
Instrument panel overview
1. Side vents
2. Side defroster outlets
3. Instrument cluster
4. Personal lights
5. Electric moon roof switches and interiorlights
6. Glovebox
7. Power door lock switches
8. Power window switches
9. Ashtray
10. Cup holder 11. Parking brake lever
12. Manual transmission gear shift lever or automatic transmission selector lever
13. Lower vent
14. Hood lock release lever
15. Power rear view mirror control switch (with power windows)
ProCarManuals.com
Page 3 of 204
CELICA U
3
1. Headlight and turn signal switch
2. Wiper and washer switches
3. Emergency flasher switch
4. Clock
5. Center vents
6. Car audio
7. Auxiliary box
8. Air conditioning controls
9. Rear window defogger switch
10. Coupe and liftback— Power rear view mirror control switch
(without power windows)
Convertible—
Convertible top control switch and
quarter window control switches
11. Cigarette lighter
12. Ignition switch
13. Cruise control switch
14. Tilt steering lock release lever
15. Instrument panel light control knob
ProCarManuals.com
Page 4 of 204
CELICA U
4
Instrument cluster overview
1. Service reminder indicators and indica-tor lights
2. Tachometer
3. Odometer 4. Engine coolant temperature gauge
5. Fuel gauge
6. Trip meter
7. Trip meter reset knob
8. Speedometer
ProCarManuals.com
Page 5 of 204
CELICA U
5
Indicator symbols on the instrument panel
(type A)
(type A)
Brake system warning light∗
1
Discharge warning light∗1
Low oil pressure warning light∗1
Malfunction indicator lamp∗1
Headlight high beam indicator light
Overdrive −off indicator light
SRS airbag warning light∗
1
Turn signal indicator lights
Anti-lock brake system warning light∗1
Seat belt reminder light∗1
Open door warning light∗1
∗ 1
: For details, see ”Service reminder indicators and warning
buzzers” in Chapter 1 −5.
∗
2: If this light flashes, see ”Cruise control” in Chapter 1 −6.
Cruise control indicator light∗
2
Low fuel level warning light∗1
(type B)
(type B)
ProCarManuals.com
Page 6 of 204
CELICA U
6
ProCarManuals.com
Page 7 of 204
CELICA U
7
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLS—
Chapter 1−2
Keys and Doors
Keys
Side doors
Power windows
Trunk lid/Back door
Hood
Fuel tank cap
Electric moon roof
Convertible top
Keys
Your vehicle is supplied with two kinds
of key.
1. Master key—This key works in every lock.
2. Subkey—This key is for side doors.
To protect things locked in the glovebox,
trunk or luggage compartment when you
have your vehicle parked, leave the sub-
key with the attendant.
Since the side doors, trunk lid and back
door can be locked without a key, you
should always carry a spare master key
in case you accidentally lock your keys
inside the vehicle.KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
You should also put a copy of the key
number with your important papers.
ProCarManuals.com
Page 8 of 204
CELICA U
8
Side doors
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Both side doors lock and unlock simulta-
neously with either side door. In the driv-
er’s door lock, turning the key once will
unlock the driver’s door and twice in suc-
cession will unlock both side doors simul-
taneously.LOCKING AND UNLOCKING WITH IN-
SIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
Closing the side door with the lock knob
in the lock position will also lock the side
door. Be careful not to lock your keys in
the vehicle.
Vehicles with a power door lock sys-
tem—The side door cannot be locked if
you leave the key in the ignition switch.Driver’s side
Passenger’s side
ProCarManuals.com
Page 9 of 204
CELICA U
9
LOCKING AND UNLOCKING WITH POW-
ER DOOR LOCK SWITCH
Push the switch.
To lock: Push the switch on the front side.
To unlock: Push the switch on the rear
side.
Both side doors lock or unlock simulta-
neously.
CAUTION
Before driving, be sure that the side
doors are closed and locked, espe-
cially when small children are in the
vehicle. Along with the proper use of
seat belts, locking the side doors
helps prevent the driver and passen-
gers from being thrown out from the
vehicle during an accident. It also
helps prevent the side doors from be-
ing opened unintentionally.
CAUTION
To avoid serious personal injury, you
must do the following.
Always make sure the head, hands
and other parts of the body of all
occupants are kept completely in-
side the vehicle before you close
the power windows. If someone’s
neck, head or hands gets caught in
a closing window, it could result in
a serious injury. When anyone
closes the power windows, be sure
that they operate the windows safe-
ly.
When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock button to
prevent them from making unex-
pected use of the switches.
Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the power window switches and
get trapped in a window. Unat-
tended children can become in-
volved in serious accidents.
—Side windows
The windows can be operated with the
switch on each side door.
The power windows work when the ignition
switch is in the ”ON” position. However,
if both side doors are closed, they work
for 60 seconds even after the ignition
switch is turned off. They stop working
when either side door is opened.
OPERATING THE DRIVER’S WINDOW
Use the switch on the driver’s door.
Normal operation: The window moves as
long as you hold the switch.
To open: Lightly pull down the switch.
To close: Push up the switch.
Power windows—
—Power window pr ecautions
ProCarManuals.com
Page 10 of 204
CELICA U
10
Automatic operation (to open only): Pull
the switch completely down and then re-
lease it. The window will fully open. To
stop the window partway, lightly push the
switch up and then release it. OPERATING THE PASSENGER’S WIN-
DOW
Use the switch on the passenger ’s
door. The driver ’s door also has a
switch that controls the passenger ’s
window.
The window moves as long as you hold
the switch.
To open: Pull down the switch.
To close: Push up the switch.
If you push in the window lock button on
the driver ’s door, the passenger ’s window
cannot be operated.
Convertible models—The window lock but-
ton also locks the quarter windows.For front passenger’s use
Window
lock button
For driver’s use
ProCarManuals.com
