TOYOTA COROLLA 2016 11.G Owners Manual

601What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12J84U)
lIs the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 105)
lThe function to prevent the electronic key from being left inside the trunk
will operate and you can open the trunk as usual. Take the key out from the
trunk. ( P. 112)
The rear door cannot be opened
The trunk lid is closed with the electronic key left inside
(vehicles with a smart key system)

602What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12J84U)
lVehicles with a manual transmission:
Do you turn the key with the clutch pedal depressed firmly?
( P. 165)
lExcept vehicles with a manual transmission:
Is the shift lever in P? ( P. 165)
lIs the steering wheel unlocked? ( P. 165)
lIs the battery discharged? (P. 538)
lExcept vehicles with a manual transmission:
Did you press the engine switch while firmly depressing the brake pedal?
( P. 168)
lVehicles with a manual transmission:
Did you press the engine switch while firmly depressing the clutch pedal?
( P. 168)
lExcept vehicles with a manual transmission:
Is the shift lever in P? ( P. 173)
lIs the electronic key anywhere detectable inside the vehicle?
( P. 116)
lIs the steering wheel unlocked? ( P. 173)
lIs the electronic key battery weak or depleted?
In this case, the engine can be started in a temporary way.
( P. 536)
lIs the battery discharged? ( P. 538)
If you think something is wrong
The engine does not start
(vehicles without a smart key system)
The engine does not start
(vehicles with a smart key system)

603What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12J84U)
lVehicles without a smart key system:
Is the engine switch in the “ON” position?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in the “ON” position. (P. 534)
lVehicles with a smart key system:
Is the engine switch in IGNITION ON mode?
If you cannot release the shift lever by depressing the brake pedal with the
engine switch in IGNITION ON mode. ( P. 534)
lVehicles without a smart key system:
It is locked to prevent theft of the vehicle if the key is pulled from the engine
switch. (P. 166)
lVehicles with a smart key system:
It is locked automatically to prevent theft of the vehicle. ( P. 173)
lIs the window lock switch pressed?
The power window except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 137)
The shift lever cannot be shifted from P even if you depress
the brake pedal (vehicles with an automatic transmission or
continuously variable transmission)
The steering wheel cannot be turned after the engine is
stopped
The windows do not open or close by operating the power
window switches

604What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12J84U)
lThe auto power off function will be operated if the vehicle is left in ACCES-
SORY or IGNITION ON mode (the engine is not running) for a period of
time. (P. 172)
lThe seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? ( P. 500)
lThe brake system warning light is on
Is the parking brake released? (P. 187)
Depending on the situation, other types of warning buzzer may also sound.
(  P. 498, 510)
lIs the electronic key left inside the vehicle?
Vehicles with a multi-information display: Check the message on the multi-
information display. ( P. 510)

lDid anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. ( P. 68)
Vehicles without a smart key system
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart key system
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
lWhen a warning light turns on, refer to P. 498.
lWhen a warning light turns on or a warning message or indicator is dis-
played, refer to P. 498, 510.
The engine switch is turned off automatically
(vehicles with a smart key system)
A warning buzzer sounds during driving
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart key system)
An alarm is activated and the horn sounds
(vehicles with an alarm)
A warning light turns on
(vehicles with a drive monitor display)
A warning light turns on or a warning message or indicator
is displayed (vehicles with a multi-information display)

605What to do if... (Troubleshooting)
COROLLA_TMMMS_TMMC_U (OM12J84U)
lStop the vehicle in a safe place and replace the flat tire with the spare tire.
( P. 520)
lTry the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. ( P. 547)
When a problem has occurred
If you have a flat tire
The vehicle becomes stuck

606
COROLLA_TMMMS_TMMC_U (OM12J84U)
Alphabetical index
Alphabetical index
A/C .................................... 386, 392Air conditioning filter ............. 467
ABS (Anti-lock Brake System)...... 215Function ................................ 215
Warning light ......................... 499
Air conditioning filter .............. 467
Air conditioning system ............................ 386, 392Air conditioning filter ............. 467
Airbags ....................................... 34
Airbag operating conditions .... 41
Airbag precautions for your child .............................. 36
Airbag warning light .............. 499
Correct driving posture ........... 26
Curtain shield airbag operating conditions ............................. 41
Curtain shield airbag precautions ........................... 39
General airbag precautions .... 36
Locations of airbags................ 34
Modification and disposal of airbags ............... 40
Side airbag operating conditions ............................. 41
Side airbag precautions .......... 36
Side and curtain shield airbags
operating conditions ............. 41
Side and curtain shield airbags
precautions ........................... 36
SRS airbags............................ 34
Alarm .......................................... 68
Anchor brackets ........................ 57 Antennas
(smart key system) ............... 115
Anti-lock Brake System (ABS) ...................................... 215Function ................................ 215
Warning light......................... 499
Assist grips .............................. 412
Audio input
*................... 234, 293
Audio system
*......................... 228
Antenna ................................ 238
Audio input............................ 234
AUX port/USB port ..................................... 234
Bluetooth
® audio .................. 262
CD player.............................. 239
iPod ...................................... 248
MP3/WMA disc ..................... 239
Optimal use .......................... 235
Portable music player ........... 234
Radio .................................... 237
Steering wheel audio switch ................................. 233
USB memory ........................ 255
Automatic light control system.................................... 190
Automatic transmission ......... 176 If the shift lever
cannot be shifted from P .... 534
AUX port
*......................... 234, 293
A

607Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12J84U)
Back-up lightsReplacing light bulb .............. 483
Wattage ................................ 559
Battery ...................................... 450 Battery checking ................... 450
If the vehicle has discharged
battery ................................ 538
Preparing and checking
before winter....................... 221
Warning light ......................... 498
Bluetooth
®*
Audio system ................. ....... 262
Hands-free system (for cellular phone) ............. 262
Multimedia system ........ 341, 343
Bottle holders .......................... 406
Brake Fluid ...................................... 557
Parking brake........................ 187
Warning light ......................... 498
Brake assist ............................. 215
Break-in tips ............................ 149
Brightness control Instrument panel light control............................. 78, 83 Care .................................. 420, 423
Aluminum wheels ................. 421
Exterior ................................. 420
Interior .................................. 423
Seat belts.............................. 424
Cargo capacity......................... 160
CD player
*....................... 239, 309
Chains ...................................... 222
Child restraint system............... 53
Booster seats, definition ......... 54
Booster seats, installation....... 61
Convertible seats, definition ............................... 54
Convertible seats,
installation ............................ 60
Infant seats, definition............. 54
Infant seats, installation .......... 59
Installing CRS with LATCH anchors ................................ 58
Installing CRS with seat
belts...................................... 59
Installing CRS with top tether strap ..................................... 62
BC
*: For vehicles with a navigation system or Entune Audio Plus, refer to
the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER'S MANUAL”.

608Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12J84U)
Child safety ................................ 52Airbag precautions .................. 36
Battery precautions ....... 451, 542
Child restraint system ............. 53
How your child should wear
the seat belt .......................... 30
Installing child restraints ......... 57
Moon roof precautions .......... 144
Power window lock switch .... 137
Power window precautions ... 140
Rear door child-protectors .... 105
Removed electronic key battery precautions ............. 471
Seat belt extender
precautions ........................... 33
Seat belt precautions .............. 32
Seat heater precautions........ 417
Trunk precautions ................. 113
Child-protectors....................... 105
Cleaning ........................... 420, 423 Aluminum wheels.................. 421
Exterior ................................. 420
Interior................................... 423
Seat belts .............................. 424
Clock ......................................... 409
Condenser ................................ 448
Compass .................................. 413
Console box ............................. 405
Continuously variable transmission .................. 178, 180
If the shift lever cannot be shifted from P ..................... 534
M mode ................................. 182
Cooling system ........................ 446 Engine overheating ............... 543
Cruise control .......................... 201
Cup holders.............................. 407
Curtain shield airbags ............... 34
Customizable features ............ 576 Daytime running light
system.................................... 192
Defogger Outside rear view mirrors ........................ 387, 395
Rear window ................. 387, 395
Dimensions .............................. 550
Dinghy towing.................. 162, 163
Display Drive monitor display .............. 77
Multi-information display ......... 82
Trip information................. 79, 84
Warning message ................ 510
Do-it-yourself maintenance .... 434
Door lock
Doors .................................... 101
Smart key system ................. 101
Wireless remote control ........ 101
Key ....................................... 102
Doors ........................................ 101
Automatic door locking and unlocking systems ....... 106
Door lock .............................. 104
Door windows ....................... 137
Open door warning buzzer ... 116
Open door warning light ....... 500
Outside rear view mirrors ..... 135
Rear door child-protector ...... 105
Drive monitor display................ 77
Driving ...................................... 146 Break-in tips.......................... 149
Correct posture ....................... 26
Procedures ........................... 146
Winter drive tips .................... 221D

609Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12J84U)
Eco drive mode ........................ 179
Eco Driving Indicator ................ 92
Electric Power Steering (EPS)....................................... 215Function ................................ 215
Warning light ......................... 499
Electronic key ............................ 96 Battery-saving function ......... 118
If the electronic key does not
operate properly ................. 535
Replacing the battery ............ 469
Emergency, in case of If a warning buzzer sounds ................................ 498
If a warning light turns on...... 498
If a warning message or indicator is displayed .......... 510
If the battery is discharged.... 538
If the electronic key does not operate properly ................. 535
If the engine will not start ...... 532
If the shift lever cannot be shifted from P ..................... 534
If you have a flat tire ............. 520
If you think something is wrong.................................. 496
If your vehicle becomes
stuck ................................... 547
If your vehicle has to be stopped in an emergency ... 489
If your vehicle needs to be towed .................................. 491
If your vehicle overheats ....... 543 Emergency flashers ................ 488
Engine ...................................... 552
ACCESSORY mode ............. 170
Compartment ........................ 441
Engine switch ............... 165, 168
Hood ..................................... 437
How to start the engine ........................ 165, 168
Identification number ............ 551
If the engine will not start ...... 532
Ignition switch (engine switch) ........... 165, 168
Overheating .......................... 543
Engine coolant......................... 446
Capacity................................ 554
Checking............................... 446
Preparing and checking before winter ...................... 221
Engine coolant temperature gauge ................................. 77, 82
Engine immobilizer system ...... 66
Engine oil ................................. 442 Capacity................................ 552
Checking............................... 442
Preparing and checking
before winter ...................... 221
Engine switch .................. 165, 168
Entune Audio ................... 228, 290
Entune Audio Plus
*
EPS
(Electric Power Steering) ..... 215Function ................................ 215
Warning light......................... 499
E
*: For vehicles with a navigation system or Entune Audio Plus, refer to
the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER'S MANUAL”.

610Alphabetical index
COROLLA_TMMMS_TMMC_U (OM12J84U)
Flat tireVehicles with a spare tire ...... 520
Floor mats .................................. 24
Fluid Automatic transmission......... 556
Brake .................................... 557
Continuously variable transmission ....................... 556
Washer ................................. 453
Fog lights ................................. 195 Replacing light bulbs............. 478
Switch ................................... 195
Wattage ................................ 559
Front interior light ................... 402
Front passenger occupant
classification system .............. 46
Front seats ............................... 124
Adjustment ............................ 124
Cleaning................................ 423
Correct driving posture ........... 26
Head restraints ..................... 128
Seat heaters ......................... 417
Front turn signal lights ........... 186
Replacing light bulbs............. 481
Turn signal lever ................... 186
Wattage ................................ 559 Fuel ........................................... 198
Capacity................................ 552
Fuel gauge........................ 77, 82
Fuel pump shut off system ... 497
Information............................ 560
Refueling .............................. 198
Type.............................. 198, 552
Warning light......................... 500
Fuel filler door ......................... 198 Refueling .............................. 198
Fuel pump shut off system..... 497
Fuses ........................................ 472
F
