Page 381 of 608
3816-1. Using the air conditioning system and defogger
6
Interior features
COROLLA_TMMMS_TMMC_U
WARNING
■To prevent the windshield from fogging up
● Do not use during cool air operation in extremely humid weathe r.
The difference between the temperature of the outside air and t hat of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.
■ To prevent burns
● Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.
● Do not touch the glass at lower part of the windshield or to the side of the
front pillars when the windshield wiper de-icer is on. (if equi pped)
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessa ry when the
engine is stopped.
● Do not place anything on the instrument
panel which may cover the air outlets.
Otherwise, air flow may be obstructed,
preventing the windshield defoggers
from defogging.
Page 382 of 608

3826-1. Using the air conditioning system and defogger
COROLLA_TMMMS_TMMC_U
Heated steering wheel/seat heaters
: If equipped
The heated steering wheel and seat heaters heat the side grips
of the steering wheel and seats, respectively.
WARNING
●Care should be taken to prevent injury if anyone in the followi ng categories
comes in contact with the steering wheel or seats when the heater is on:
• Babies, small children, the elderly, the sick and the physical ly chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sle eping
drugs, cold remedies, etc.)
● Observe the following precautions to prevent the minor burns or overheat-
ing
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use the seat heaters more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the sea t and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent battery discharge, do not use the functions when the engine is
stopped.
Page 383 of 608
3836-1. Using the air conditioning system and defogger
6
Interior features
COROLLA_TMMMS_TMMC_U
Turn the heated steering wheel on/off
The indicator light comes on when
the heated steering wheel is oper-
ating.
■The heated steering wheel can be used when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
Press the switch.
High temperature
Low temperature
The indicator light comes on when
the switch is on.
■ The seat heaters can be used when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
■ When not in use
Put the switch in the neutral position. The indicator will turn off.
Heated steering wheel
Seat heaters
1
2
Page 384 of 608
384
COROLLA_TMMMS_TMMC_U
6-2. Using the interior lights
Front interior light/personal lights (P. 385)
Rear interior light ( P. 386)
Engine switch light (vehicles with a smart key system)
Interior li ghts list
1
2
3
Page 385 of 608
3856-2. Using the interior lights
6
Interior features
COROLLA_TMMMS_TMMC_U■
Front interior light
Off
Door position
On
■Personal lights
When a light is on due to its door link switch, the light will not turn off
even if the lens or switch is pressed.
Front interior light/personal lights
Ty p e AType B
1
2
3
Ty p e AType B
On/off On Off
1
2
Page 386 of 608

3866-2. Using the interior lights
COROLLA_TMMMS_TMMC_U
On
Door position
Off
■Illuminated entry system
Vehicles without a smart key system
When the interior light switch is in the door position, the int erior light automat-
ically turns on/off according to the engine switch position, whether the doors
are locked/unlocked and whether the doors are open/closed.
Vehicles with a smart key system
When the interior light switch is in the door position, the int erior light and
engine switch light automatically turn on/off according to engine switch mode,
the presence of the electronic key, whether the doors are locke d/unlocked
and whether the doors are open/closed.
■ To prevent battery discharge
The following lights will go off automatically after 20 minutes :
● Front interior light/personal lights
● Rear interior light
● Trunk light
■ Customization
Setting (e.g. the time elapsed before lights turn off) can be c hanged.
(Customizable features: P. 564)
Rear interior light
1
2
3
Page 387 of 608
387
6
Interior features
COROLLA_TMMMS_TMMC_U
6-3. Using the storage features
List of storage features
Glove box ( P. 3 8 8 )
Bottle holders ( P. 3 8 9 ) Console box (
P. 388)
Cup holders ( P. 390)
WARNING
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spa ces, as this
may cause the following when cabin temperature becomes high:
● Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
■ When driving or when the storage compartments are not in use
Keep the lids closed.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items stored inside.
1
2
3
4
Page 388 of 608
3886-3. Using the storage features
COROLLA_TMMMS_TMMC_U
Pull up the lever to open the glove
box.
Console box
Lift the lid while pulling up the
knob on the right side.
Upper level box
Lift the lid while pulling up the
knob on the left side.
Glove box
Console box
Page 389 of 608
3896-3. Using the storage features
6
Interior features
COROLLA_TMMMS_TMMC_U■
Front
■Rear
■
When using the holder as a bottle holder
● When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
WARNING
■Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders .
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■ Items that should not be st owed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottl es in the bot-
tle holders, or glass or paper cups containing liquid. The cont ents may spill
and glass cups may break.
Page 390 of 608
3906-3. Using the storage features
COROLLA_TMMMS_TMMC_U■
Front
■Rear (if equipped)
Pull the armrest down.
Cup holders
