headlight bulb TOYOTA COROLLA 2023 Owners Manual

4TABLE OF CONTENTS
Tire inflation pressure.........328
Wheels ............................... 330
Air conditioning filter ........... 331
Wireless remote control/elec- tronic key battery.............. 333
Checking and replacing fuses ......................................... 336
Headlight aim ..................... 339
Light bulbs .......................... 340
7-1. Essential information Emergency flashers ........... 348
If your vehicle has to be stopped in an emergency .............. 348
If the vehicle is submerged or water on the road is rising......................................... 350
7-2. Steps to take in an emergency If your vehicle needs to be towed......................................... 351
If you think something is wrong ......................................... 354
Fuel pump shut off system ......................................... 355
If a warning light turns on or a warning buzzer sounds .... 356
If a warning message is dis- played .............................. 366
If you have a flat tire ........... 370
If the engine will not start ... 379
If you lose your keys .......... 381
If the electronic key does not operate properly ............... 381
If the vehicle battery is dis- charged ............................ 383
If your vehicle overheats .... 387
If the vehicle becomes stuck ......................................... 3898-1. Specifications
Maintenance data (fuel, oil level, etc.) .................................. 392
Fuel information ................. 399
Tire information .................. 401
8-2. Customization Customizable features ....... 412
8-3. Initialization Items to initialize ................ 422
9-1. For owners Reporting safety defects for U.S. owners ............................. 424
Reporting safety defects for Canadian owners ............. 424
Seat belt instructions for Cana- dian owners (in French) ... 425
SRS airbag instructions for Canadian owners (in French)......................................... 426
What to do if... (Troubleshooting) ......................................... 436
Alphabetical Index.............. 439
7When trouble arises
8Vehicle specifications
9For owners
Index

14Pictorial index
Fuel filler door .................................................................... P.180
Refueling method ............................................... .................. P.181
Fuel type/fuel tan k capacity ................................... .............. P.393
Tires..................................................................................... P.311
Tire size/inflation pressure ................................... ................ P.397
Winter tires/tire chains ....................................... .................. P.253
Checking/rotation/tire pressure warning system
*2............... P.311
Coping with flat tires......................................... .................... P.370
Hood ........................................................... ......................... P.302
Opening ............................................................................... P.302
Engine oil ..................................................... ........................ P.394
Coping with overheating ...................................................... P.387
Headlights/daytime running lights .............................. ..... P.173
Turn signal lights/parking lights .............................. ......... P.173
Front side marker lights ....................................... ............. P.173
LED accent lights
*2............................................................ P.1 73
Stop lights/tail lights/rear side marker lights/turn signal lig hts
P. 1 7 3
License plate lights........................................... ................. P.173
Tail lights
*2............................................................... ........... P.173
Back-up lights
Shifting the shift position to R ............................... ....... P.160, 162
Side turn signal lights
*2..................................................... P.167
*1: Vehicles with a smart key system
*2: If equipped
Light bulbs of the exterior lights for driving
(Replacing method: P.340, Watts: P.398)

287
6
6
Maintenance and care
Maintenance and care
.6-1. Maintenance and careCleaning and protecting the vehicle exterior .......... 288
Cleaning and protecting the vehicle interior ........... 291
6-2. Maintenance Maintenance requirements.................................. 294
General maintenance.. 296
Emission inspection and maintenance (I/M) pro-
grams ........................ 298
6-3. Do-it-yourself mainte- nance
Do-it-yourself service pre- cautions ..................... 300
Hood ........................... 302
Positioning a floor jack .................................. 303
Engine compartment ... 304
Tires ............................ 311
Tire inflation pressure.. 328
Wheels ......... ...............330
Air conditioning filter .... 331
Wireless remote con- trol/electronic key battery.................................. 333
Checking and replacing fuses.......................... 336
Headlight aim .............. 339
Light bulbs................... 340

3396-3. Do-it-yourself maintenance
6
Maintenance and care
Adjustment bolt A
Adjustment bolt B
 Make sure the vehicle has a
full tank of gasoline and the
area around the headlight is
not deformed.
 Park the vehicle on level
ground.
 Make sure the tire inflation
pressure is at the specified
level.
 Have someone sit in the
driver’s seat.
 Bounce the vehicle several
times. 1
Using a Phillips-head screw-
driver, turn bolt A in either
direction.
Remember the turning direction
and the number of turns.
2Turn bolt B the same number
of turns and in the same
direction as step 1.
If the headlight cannot be adjusted
using this procedu re, take the vehi-
cle to your Toyota dealer to adjust
the headlight aim.
Headlight aim (vehi-
cles with front side
marker lights [bulb
type])
Vertical movement adjust-
ing bolts
Before checking the head-
light aim
Adjusting the headlight
aim

3406-3. Do-it-yourself maintenance
Check the wattage of the light
bulb to be replaced. ( P.398)
■Front
Front side marker lights (bulb
type)
Front turn signal/parking
lights (vehicles without side
turn signal lights)
■RearBack-up lights
Rear turn signal lights
Rear side marker lights (bulb
type)
■Bulbs that need to be
replaced by your Toyota
dealer
 Headlights/daytime running
lights
 Parking lights (vehicles with
side turn signal lights)
 Front turn signal lights (vehi-
cles with side turn signal
lights)
 Front side marker lights (LED
type)
 LED accent lights (if
equipped)
 Side turn signal lights (if
equipped)
 Tail lights
 Stop lights
 Rear side marker lights (LED
type)
 High mounted stoplight
 License plate lights
Light bulbs
You may replace the follow-
ing bulbs yourself. The diffi-
culty level of replacement
varies depending on the
bulb. If necessary bulb
replacement seems difficult
to perform, contact your
Toyota dealer.
For more information about
replacing other light bulbs,
contact your Toyota dealer.
Preparing for light bulb
replacement
Bulb locations

3416-3. Do-it-yourself maintenance
6
Maintenance and care
■LED light bulbs
The lights other th an the front turn
signal lights/parking lights (vehicles
without side turn sig nal lights), front
side marker lights (bulb type), rear
turn signal lights, rear side marker
lights (bulb type) and back-up lights
consist of a number of LEDs. If any
of the LEDs burn out, take your
vehicle to your Toyota dealer to
have the light replaced.
■Condensation build-up on the
inside of the lens
In certain situatio ns, such as when
driving in the rain or when washing
the vehicle, condensation may form
on the inner side of the headlight
lens and other li ghts. As each light
has a ventilation hole, moist air may
enter. If the ambient temperature is
low, condensation may form tempo-
rarily, but it will di ssipate as the
inside of the light i s warmed up. As
the condensation is due to a phe-
nomenon similar to windows fogging
in the rain, it doe s not indicate a
malfunction.
Contact your Toyota dealer for more
information in the following situa-
tions:
●Large drops of water have built up
on the inside of the lens.
●Water has built up inside the
headlight.
■When replacing light bulbs
 P. 3 3 8
■Front turn signal/parking
lights (vehicles without side
turn signal lights)
1 Turn the bulb base counter-
clockwise.
Type A
Type B
2 Remove the light bulb.
Type A
Replacing light bulbs

443Alphabetical Index
H
Head restraints ....................... 128
Headlight aim .......................... 339
HeadlightsAHB (Automatic High Beam) 175
Light switch .......................... 173
Headlights/daytime running lightsReplacing light bulbs ............ 341
Heated steering wheel ........... 269
Heaters Automatic air conditioning sys-tem ..................................... 263
Heated steering wheel ......... 269
Manual air conditioning system ........................................... 258
Outside rear view mirrors ... 260, 265
Seat heaters ......................... 269
High mounted stoplight Replacing light bulbs ............ 341
Hill-start assist control .......... 249
Hood Open .................................... 302
Hooks Coat hooks ........................... 285
Retaining hooks (floor mat) .... 24
Horn ......................................... 130
I
I/M test ..................................... 298
Identification Engine .................................. 393
Vehicle.................................. 392
Ignition switch (engine switch) ....................................... 154, 155Auto power off function ........ 159
Changing the engine switch modes ................................ 158
If your vehicle has to be stopped in an emergency................. 348 Illuminated entry system .......272
Indicators ..................................84
Initialization
Items to initialize ...................422
Maintenance .........................295
Power windows ....................134
Inside rear view m irror ...........131
Instrument panel light control88, 91
Interior lights...........................271 Front interior light .................271
Rear interior light ..................271
Wattage ................................398
J
JackPositioning a floor jack .........303
Vehicle-equipped jack ..........371
Jack handle .............................371
Jam protection function Moon roof .............................137
Power windows ....................134
K
Keyless entrySmart key system .................120
Wireless remote control........108
Keys Battery-saving function .........121
Electronic key .......................106
Engine switch ...............154, 155
If the electronic key does not operate properly .................381
If you lose your keys.............381
Key number plate .................106
Keyless entry ................ 111, 120
Mechanical key.....................106
Replacing the battery ...........333
Warning buzzer ....................120
Wireless remote control........108
Knee airbags .............................31

444Alphabetical Index
L
Lane Departure Alert (LDA) ... 206
Lane Tracing Assist (LTA)...... 201 Operation ............................. 201
Language (multi-information dis- play) ................................. 95, 100
LATCH anchors ........................ 64
LDA (Lane Departure Alert) ... 206 Operation ............................. 206
LED accent lights Light switch .......................... 173
Replacing light bulbs ............ 341
Lever Auxiliary catch lever ............. 302
Hood lock release lever........ 302
Internal trunk release lever... 119
Shift lever ..................... 160, 162
Turn signal lever ................... 167
Wiper lever ........................... 178
License plate lights Light switch .......................... 173
Replacing light bulbs ............ 341
Wattage ................................ 398
Light bulbs Replacing ............................. 340
Lights AHB (Automatic High Beam) 175
Front interior lights ............... 271
Headlight switch ................... 173
Interior lights......................... 271
Interior lights list ................... 271
Personal lights...................... 272
Rear interior lights ................ 271
Replacing light bulbs ............ 341
Trunk light............................. 119
Turn signal lever ................... 167
Vanity lights .......................... 284
Wattage ................................ 398
Lock steering column ............ 154
LTA (Lane Tracing Assist) ...... 201 Operation ............................. 201 LTA (Lane Tracing Assist) switch
...............................................204
M
Maintenance Do-it-yourself maintenance ..300
General maintenance ...........296
Maintenance data .................392
Maintenance requirements ...294
Malfunction indicator lamp ....357
Manual air conditioning system ...............................................258
Menu icons ..........................91, 97
Meter Clock ................................86, 89
Indicators ................................84
Instrument panel light control88, 91
Meter control switches......92, 97
Meter light control ...................90
Meters ..............................86, 89
Multi-information display...91, 97
Settings ..........................95, 100
Warning lights .......................356
Warning message.................366
Mirrors Inside rear view mirror ..........131
Outside rear view mirror defog-gers ............................260, 265
Outside rear view mirrors .....132
Vanity mirrors........................284
Moon roof Door lock linked moon roof oper-ation....................................137
Jam protection function ........137
Operation..............................137
Multi-information display Audio system-linked display .95, 100
Clock ................................88, 91
Cruise control .......................228
Driving informati on display92, 98

446Alphabetical Index
RCTA function......................... 238
Rear Cross Traffic Alert (RCTA)............................................... 237
Rear seats ............................... 126 Head restraints ..................... 128
Rear side marker lights Light switch .......................... 173
Replacing light bulbs .... 341, 342
Wattage ................................ 398
Rear turn signal lights Replacing light bulbs .... 342, 343
Turn signal lever ................... 167
Wattage ................................ 398
Rear view mirror Inside rear view mirror.......... 131
Outside rear view mirrors ..... 132
Rear window defogger ... 260, 265
Refueling Capacity ............................... 393
Fuel types............................. 393
Opening the fuel tank cap .... 180
Replacing Electronic key battery ........... 333
Fuses ................................... 336
Light bulbs ............................ 340
Tires ..................................... 370
Wireless remote control battery........................................... 333
Reporting safety defects for Canadian owners ................. 424
Reporting safety defects for U.S. owners................................... 424
Resetting the message indicat- ing maintenance is required 295
Road Sign Assist (RSA) ......... 217
RSA (Road Sign Assist) ......... 217
S
Safe Exit Assist ...................... 243
Safety Connect ......................... 72
Seat belt reminder light . 359, 360 Seat belts...................................27
Adjusting the seat belt ............29
Automatic Locking Retractor ..29
Child restraint sys tem installation
.............................................50
Cleaning and maintaining the seat belt ..............................291
Emergency Locking Retractor 29
How to wear your seat belt .....28
How your child should wear the seat belt ................................28
Pregnant women, proper seat belt use .................................27
Reminder light and buzzer .359, 360
Seat belt extender ..................28
Seat belt pretensioners ..........30
SRS warning light .................357
Seat heaters ............................269
Seating capacity .............152, 392
Seats Adjustment ...........................125
Adjustment precautions ........125
Child seats/child restraint system installation ............................48
Cleaning ...............................291
Head restraints .....................128
Properly sitting in the seat ......25
Seat heaters ....... ..................269
Secondary Collision Brake ....249
Sensor AHB (Automatic High Beam) 175
Automatic headlight system .174
BSM (Blind Spot M onitor) .....232
Radar sensor ................233, 244
RCTA ....................................238
Service reminder message ....295
Shift lever Continuously variable transmis-sion .............................160, 162
If th e s hif t le ver ca n no t b e s hif te d from P .........................161, 164
