TOYOTA COROLLA HATCHBACK 2020 Accessories, Audio & Navigation (in English)

1213-5. Tips for the navigation system
COROLLA_HB_Navi_(U)
3
Navigation system
version.
 After replacing a tire: P. 1 1 2
●This navigation system uses tire
turning data and is designed to
work with factory- specified tires
for the vehicle. Ins talling tires that
are larger or smaller than the orig-
inally equipped diameter may
cause inaccurate display of the
current position. The tire pressure
also affects the diameter of the
tires, so make sure that the tire
pressure of all 4 tires is correct.
1 Select on the map
screen. ( P. 7 2 )
2 Select “Map Data”.
3 Check that the map data
screen is displayed.
Map version
Select to display map cover-
age areas.
Select to display legal infor-
mation.
Select to update map.
●For map data updates, contact
your Toyota dealer.
Map database version
and covered area
Coverage areas and legal
information can be dis-
played and map data can be
updated.
Map information
A
B
C
D

1223-5. Tips for the navigation system
COROLLA_HB_Navi_(U)
*: This function is not made avail-able in some countries or areas.
If the map data has been pro-
vided from the Cloud for any of
the following areas and the map
data in the navigation system is
older than what has been pro-
vided, the displayed map will be
updated temporarily:
• Areas around the area dis-
played on the map screen
(example: areas around cur-
rent position)
• Areas around destinations
• Areas along the set route
●The updated data will temporarily
be saved in the navigation sys-
tem.
●If temporary updat e data exceeds
the available memory in the tem-
porary map cache, the oldest data
will be deleted.
●The temporary map data will dis-
appear when the expiration date
has passed.
Temporary updates of the
map*

123
COROLLA_HB_Navi_(U)
4
4
Audio/visual system
Audio/visual system
.4-1. Basic operationQuick reference........... 124
Some basics ............... 125
4-2. Radio operation
AM/FM/SiriusXM
® Satellite
Radio ......................... 130
Internet radio ............... 138
4-3. Media operation USB memory............... 139
iPod/iPhone (Apple Car- Play) .......................... 141
Android Auto ............... 144
Bluetooth
® audio ......... 145
4-4. Audio/visual remote con- trols
Steering switches ....... 149
4-5. Setup Audio settings ............. 151
4-6. Tips for operating the audio/visual system
Operating information . 153

1244-1. Basic operation
COROLLA_HB_Navi_(U)
4-1.Basic operation
The audio control screen can be reached by the following methods:
From the “AUDIO” button
1 Press the “AUDIO” button.
From the “MENU” button
1 Press the “MENU” button, then select “Audio”.
 Using the radio ( P.130)
 Playing a USB memory ( P.139)
 Playing an iPod/iPhone (Apple CarPlay
*) ( P.141)
 Using the Android Auto
* ( P.144)
 Playing a Bluetooth
® device ( P.145)
 Using the steering wheel audio switches ( P.149)
 Audio system settings ( P.151)
*: This function is not made availa ble in some countries or areas.
Quick reference
Functional overview

1254-1. Basic operation
COROLLA_HB_Navi_(U)
4
Audio/visual system
“POWER VOLUME” knob:
Press to turn the audio/visual
system on and off. The system
turns on in the last mode used.
Turn this knob to adjust the vol-
ume. 1
Press the “AUDIO” button.
2 Select “Source” or press
“AUDIO” button again.
3 Select the desired source.
●Dimmed screen buttons cannot be
operated.
●When there are tw o pages, select
or to change the page.
●When an Apple CarPlay/Android
Auto connection is established,
some system functions, such as
the following, will be replaced by
similar Apple CarPlay/Android
Auto function or will become
unavailable
*:
• iPod (Audio Playback)
• USB audio/USB video
• Bluetooth
® audio
• Toyota apps
*: This function is not made avail-
able in some countries or areas.
Some basics
This section describes
some of the basic features
of the audio/visual system.
Some information may not
pertain to your system.
Your audio/visual system
works when the engine
switch is in ACC or ON.
NOTICE
●To prevent the battery from
being discharged, do not leave
the audio/visual system on lon-
ger than necessary when the
engine is not running.
Turning the system on
and off
Selecting an audio source

1264-1. Basic operation
COROLLA_HB_Navi_(U)
1Display the audio source
selection screen. ( P.125)
2 Select “Reorder”.
3 Select the desired audio
source then or to reor-
der.
4 Select “OK”.
1 Connect a device.
 Turn on the power of the
device if it is not turned on.
●If a USB hub is plugged-in, two
devices can be connected at a
time.
●Even if a USB hub is used to con-
nect more than two USB devices,
only the first two connected
devices will be recognized.
●If a USB hub that has more than
two ports is connected to the USB
port, devices connected to the
USB hub may not charge or be
operable, as the supply of current
may be insufficient.
1 Display the audio control
screen. ( P.125)
2 Select “Sound”.
3 Select the desired item to be
set.
Type A
Select to set the tre-
ble/mid/bass. ( P.127)
Select to set the fader/bal-
ance. ( P.127)
Select to set the automatic
sound levelizer. ( P.127)
Type B
Select to set the tre-
ble/mid/bass. ( P.127)
Select to set the fader/bal-
ance. ( P.127)
Select to set the automatic
sound levelizer. ( P.127)
Reordering the audio
source
USB port
Sound settings
A
B
C
A
B
C

1274-1. Basic operation
COROLLA_HB_Navi_(U)
4
Audio/visual system
Select to set the surround
on/off.
This function can create a
feeling of presence items.
■Treble/Mid/Bass
How good an audio program
sounds is largely determined by
the mix of the treble, mid and
bass levels. In fact, different
kinds of music and vocal pro-
grams usually sound better with
different mixes of treble, mid
and bass.
1 Select “Treble/Mid/Bass”.
2 Select the desired screen
button.
Select “+” or “-” to adjust
high-pitched tones.
Select “+” or “-” to adjust
mid-pitched tones.
Select “+” or “-” to adjust
low-pitched tones.
■Fader/Balance
A good balance of the left and
right stereo channels and of the
front and rear sound levels is
also important.
Keep in mind that when listening
to a stereo recording or broad- cast, changing the right/left bal-
ance will increase the volume of
1 group of sounds while
decreasing the volume of
another.
1
Select “Fader/Balance”.
2 Select the desired screen
button.
Select to adjust the sound
balance between the front
and rear speakers.
Select to adjust the sound
balance between the left and
right speakers.
■Automatic sound levelizer
(ASL)
The system adjusts to the opti-
mum volume and tone quality
according to vehicle speed to
compensate for increased road
noise, wind noise, or other
noises while driving.
Type A
1 Select “Automatic Sound
Levelizer”.
2 Select “High”, “Mid”, “Low” or
“Off”.
D
A
B
C
A
B

1284-1. Basic operation
COROLLA_HB_Navi_(U)
Ty p e B
1 Select “Automatic Sound
Levelizer”.
2 Select to set the automatic
sound levelizer on/off.
■Screen format settings
The screen format can be
selected for USB video.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Audio”.
4 Select “Common”.
5 Select “Screen Format”.
6 Select the desired item to be
adjusted.
Select to display a 4:3
screen, with either side in
black.
Select to enlarge the image
horizontally and vertically to
full screen.
Select to enlarge the image
by the same ratio horizontally
and vertically.
■Color, tone, contrast and
brightness adjustment
The color, tone, contrast and
brightness of the screen can be
adjusted.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Audio”.
4 Select “Common”.
5 Select “Display”.
6 Select the desired item to be
adjusted.
 “Color”
“R”: Select to strengthen the red
color of the screen.
“G”: Select to strengthen the green
color of the screen.
“Tone”
“+”: Select to strengthen the tone of
the screen.
“-”: Select to weaken the tone of the
screen.
“Contrast”
“+”: Select to strengthen the con-
trast of the screen.
“-”: Select to weaken the contrast of
the screen.
“Brightness”
“+”: Select to brighten the screen.
“-”: Select to darken the screen.
●Depending on the audio source,
some functions m ay not be avail-
able.
Audio screen adjustment
A
B
C

1294-1. Basic operation
COROLLA_HB_Navi_(U)
4
Audio/visual system
1 Press the talk switch to oper-
ate the voice command sys-
tem.
 The voice command system
and its list of commands can
be operated. ( P.164)
Voice command system

1304-2. Radio operation
COROLLA_HB_Navi_(U)
4-2.Radio operation
*: If equipped
The radio operation screen can
be reached by the following
methods:
P. 1 2 5
Select to display the audio
source selection screen.
Select to display the preset
stations screen. ( P.131)
Select to display the cache
radio operation screen.
( P.131)
Select to display a list of
receivable stations. ( P.132)
Select to display the radio
options screen. ( P.133)
Select to display the sound
setting screen. ( P.126)
Select to tune to preset sta-
tions/channels. ( P.131)
Displays items on the chan- nels registered to smart
favorites (
P.132, 152)
Displays the artist info and
song title or album
Select to change the dis-
played information.
Displays messages when
available from RBDS.
Displays cover art, station
logo, etc.
Displays genre information
Select to display HD) multi-
cast channels available.
( P.134)
Press to seek for stations in
the relevant program
type/channel category.
Press and hold for continu-
ous seek.
Turn to step up/down fre-
quencies/channels.
Turn to move up/down the
station. Also, the knob can be
used to enter selections on
the list screens by pressing it.
●The radio automatically changes
AM/FM/SiriusXM®
Satellite Radio*
Overview
Control screen
A
B
C
D
E
F
G
H
&RQWUROSDQHO
I
J
K
L
A
B
