TOYOTA COROLLA HATCHBACK 2020 Accessories, Audio & Navigation (in English)

913-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
1 Select “Go” on the confirm
destination screen.
 For details about this screen:
P. 9 2
2 Select “OK” on the route
overview screen.
 For details about this screen:
P. 9 2
●The route for returning may not be
the same as that for going.
●The route guidance to the destina-
tion may not be the shortest route
or a route without traffic conges- tion.
●Route guidance may not be avail-
able if there is no road data for the
specified location.
●When setting the destination on a
map with a scale more than 0.5
mile (800 m), the map scale
changes to 0.5 mile (800 m) auto-
matically. If this occurs, set the
destination again.
●If a destination that is not located
on a road is set, the vehicle will be
guided to the point on a road near-
est to the destination. The road
nearest to the selected point is set
as the destination.
Starting route guid-
ance
When the destination is set,
the entire route map from
the current position to the
destination is displayed.
Starting route guidance
WARNING
●Be sure to obey traffic regula-
tions and keep road conditions
in mind while driving. If a traffic
sign on the road has been
changed, the route guidance
may not indicate such changed
information.

923-2. Destination search
COROLLA_HB_Navi_(U)
Select to search for the route.
(P. 9 1 )
• If a destination has already been
set, “Go Directl y” and “Add to
Route” will be displayed.
“Go Directly”: Select to delete the
existing destination(s) and set a
new one.
“Add to Route”: Select to add a
destination to the current route.
Select to register as a mem-
ory point.
Select to call the registered
number.
Select to update information
about the selected entry.*
*: This function is displayed only when there is information from
the Cloud. ( P. 8 4 )
Current position
Destination point
Select to display a list of the
turns required to reach the
destination. ( P. 9 3 )
Select to change the route.
( P.94)
Select the desired route from
3 possible routes. ( P.93)
Type of route and its distance
Distance of the entire route
Select to start guidance.
Select and hold to start demo
mode. ( P.92)
Displayed when the route
displayed is from the Cloud.
( P.95)
Before starting the route guid-
ance, the demonstration of the
route guidance can be viewed.
1 Select and hold “OK” on the
route overview screen until a
beep sounds.
 Press the “HOME” or “MAP”
button to end demo mode.
Confirm destination
screen
A
B
C
D
5RXWHRYHUYLHZVF\
UHHQ
6WDUWLQJGHPRPRGH
A
B
C
D
E
F
G
H
I

933-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
1 Select “3 Routes”.
2 Select the desired route.
Displayed when the route
displayed is available from
the Cloud. ( )
Select to display the quick-
est route.
Select to display the route
that is the shortest distance
to the set destination.
Select to display the alterna-
tive route.
Select to display the informa-
tion about the 3 routes.
( P. 9 3 ) 1
Select “Info”.
2 Check that the 3 routes infor-
mation screen is displayed.
Time necessary for the entire
trip
Distance of the entire trip
Distance of the toll road
Distance of the freeway
Distance of the ferry trip
A list of turn information from the
current position to the destina-
tion can be displayed.
1 Select “Turn List”.
2 Check that the turn list is dis-
played.
Current position
3 routes selection
A
B
C
D
E
'LVSOD\LQJURXWHVLQIRUPD
WLRQ
'LVSOD\LQJWXUQOLVW
A
B
C
D
E
A

943-2. Destination search
COROLLA_HB_Navi_(U)
Distance to the next turn
Turn direction at the intersec-
tion
Select to display the map of
the selected point.
●Not all road names on the route
may appear on the list. If a road
changes its name without requir-
ing a turn (such as on a street that
runs through 2 or more cities), the
name change will not appear on
the list. The street names will be
displayed in order from the start-
ing point, along wit h the distance
to the next turn or the destination.
Destinations can be added,
reordered or deleted, and condi-
tions for the route to the destina-
tion can be changed.
1 Select “Edit Route”.
2 Select the desired item.
Select to add destinations.
( P. 9 4 )
Select to delete destinations.
( P. 9 4 )
Select to reorder destina-
tions. ( P.102)
Select to set route prefer-
ences. ( P.102) 1
Select “Add”.
2 Search for an additional des-
tination in the same way as a
destination search. ( P.83)
 Up to 5 destinations can be
set.
3 Select “Add” at the position in
the route which you want to
add the destination.
1 Select “Delete”.
2 Select “Yes” when the confir-
mation screen appears.
 If more than 1 destination has
been set, select the destina-
tion(s) to be deleted. (The
navigation system will recal-
culate route(s) to the remain-
ing set destination(s).)
Editing route
B
C
D
A
B
C
D
$GGLQJGHVWLQDWLRQV
'HOHWLQJGHVWLQDWLRQV

953-2. Destination search
COROLLA_HB_Navi_(U)
3
Navigation system
*: This function is not made avail- able in some countries or areas.
When starting route guidance or
rerouting, a route can be pro-
vided automatically by the
Cloud. This function is available
when dynamic route setting is
enabled. ( P. 1 1 0 )
A route from the Cloud*

963-3. Route guidance
COROLLA_HB_Navi_(U)
3-3.Route guidance
Distance to the next turn and
an arrow indicating the turn-
ing direction
Guidance route
Current position
Select to mute the voice
guidance.
Route information (P.96)
Select to delete destinations.
( P. 2 2 )
Displays the lane recommen-
dation. ( P.97)
●If the vehicle goes off the guid-
ance route, the ro ute will be recal-
culated.
●For some areas, the roads have
not been complete ly digitized in
our database. For this reason, the
route guidance may select a road
that should not be traveled on.
●When arriving at the set destina-
tion, the destinat ion name will be
displayed on the upper part of the
screen.
●When the automatic zoom func-
tion is enabled, the map will auto-
matically change to a detailed
map as the vehicl e approaches a
guidance point. ( P. 1 1 0 )
●Vehicle with head-up display:
When the head-up display is set
to on, turn-by-turn guidance
arrows will be displayed on the
windshield.
When the vehicle is on the guid-
ance route, the route informa-
tion bar displays the distance
with the estimated travel/arrival
time to the destination.
When the set destination is 1
1 Check that the distance and
time to destination is dis-
played.
When the set destinations are
more than 1
1 Select the route information
bar.
Route guidance
screen
During the route guidance,
various types of guidance
screens can be displayed
depending on conditions.
Screen for route guidance
A
B
C
D
E
F
G
'LVWDQFHDQGWLPHWRGHVWL
QDWLRQ

973-3. Route guidance
COROLLA_HB_Navi_(U)
3
Navigation system
2 Check that the list of the dis-
tance and time is displayed.
 By selecting one of the num-
ber buttons, the desired route
information is displayed.
●When the vehicle is on the guid-
ance route, the distance mea-
sured along the route is displayed.
Travel time and arrival time are
calculated based on the average
speed of the specified speed limits
and current traffic information.
●When the vehicle gets off the
guidance route, the arrow facing
the destination is displayed
instead of the estimated
travel/arrival time.
●The route information bar fills from
left to right as the vehicle pro-
gresses along the route.
When approaching a turning
point, the lane recommendation
will automatically be displayed
on the map. During freeway driving, the free-
way information screen can be
displayed.
Distance from the current
position to the freeway
exit/rest area
Name of the freeway exit/rest
area
POIs that are close to a free-
way exit
Select to display farther free-
way exits/rest areas.
●This function is available when
“Automatic Freeway Exit List” is
set to on. ( P. 1 1 0 )
Lane recommendation
During freeway driving
A
B
C
D

983-3. Route guidance
COROLLA_HB_Navi_(U)
When the vehicle approaches
an exit or junction, the freeway
guidance screen will be dis-
played.Next exit or junction name
Select to hide the freeway
guidance screen.
• To return to the freeway guidance screen, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 0 )
When the vehicle approaches a
tollgate, the tollgate view will be
displayed.
Select to hide the tollgate
guidance screen.
• To return to the tollgate guidance screen, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 0 )
When approaching free-
way exit or junction
A
B
C
:KHQDSSURDFKLQJWROO
JDWH
A
B

993-3. Route guidance
COROLLA_HB_Navi_(U)
3
Navigation system
When the vehicle approaches a
junction, the junction view with
signage will be displayed. Select to hide the real free-
way junction view.
• To return to the real freeway junc-tion view, press the “MAP” button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 0 )
When the vehicle approaches
an intersection, the intersection
guidance screen will be dis-
played.
Next street name
Select to hide the intersection
guidance screen.
• To return to the intersection guid-ance screen, press the “MAP”
button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P. 1 1 0 )
When approaching junc-
tion
A
B
:KHQDSSURDFK\
LQJLQWHU
VHFWLRQ
A
B
C

1003-3. Route guidance
COROLLA_HB_Navi_(U)
1Select “Turn List” on the map
mode screen. ( P.77)
2 Check that the turn list
screen is displayed.
Turn direction
Next street or destination
name
Distance between turns On this screen, information
about the next turn on the guid-
ance route can be displayed.
1
Select “Turn-by-Turn Arrow”
on the map mode screen.
( P.77)
2 Check that the turn-by-turn
arrow screen is displayed.
Exit number or street name
Turn direction
Distance to the next turn
Turn list screen
A
B
C
7XUQE\WXUQD\
UURZVFUHHQ
A
B
C
