air conditioning TOYOTA COROLLA HATCHBACK 2021 Owners Manual (in English)

1
1 Visit your Toyota dealer for information on customizing this feature.2 Programmable by customer. Refer to the Owner’s Manual for instructio\
ns and more information.
INDEX
Engine maintenance 8
Fuel tank door release & cap 7
Hood release 8
Indicator symbols 5
Instrument cluster 4
Instrument panel 2-3
Instrument panel light control 8
Keyless entry
1,26
Smart Key system 7
OVERVIEW
FEATURES & OPERATIONS FEATURES & OPERATIONS (continued)
TOYOTA SAFETY SENSE™ 2.0 (TSS 2.0)
SAFETY & EMERGENCY FEATURES
Air conditioning/heating
21
Audio 18
Auto lock/unlock
1,212
Blind Spot Monitor (BSM) and
Rear Cross Traffic Alert (RCTA) 23
Bottle holders 14
Continuously variable transmission 9
Cup holders 15
Door locks 14
Driving mode select 22
Electric parking brake 10
Lights
1 & turn signals 13
Manual transmission 9
Multi-Information Display (MID) 11
Power outlet-12V DC 19
Qi Wireless charger 19
Rear seats-Folding 16
Rear view monitor system 23
Seat adjustments-Front 16
Seat heaters 20
Seats-Head restraints 16
Steering lock release 15
Steering wheel switches &
telephone controls (Bluetooth
®) 17
Tilt & telescopic steering wheel 15 Vehicle Stability Control (VSC)/
TRAC OFF switch
22
USB charge port 18
USB media port 20
Windows-Power 14
Windshield wipers & washers 12
Floor mat installation 47
Rear door child safety locks 41
Safety Connect
®43
Seat belts 41
Seat belts-Shoulder belt anchor 41
Spare tire & tools 44
Star Safety System
™46-47
Tire Pressure Monitoring
(warning) System (TPMS) 42
Tire repair kit & tools 45
Automatic High Beams (AHB) 39
Dynamic Radar Cruise Control (DRCC)
or Full-Speed Range DRCC
36-38
Lane Departure Alert with
Steering Assist (LDA w/SA) 28-31
Lane Tracing Assist (LTA) 32-35
Pre-Collision System with Pedestrian
Detection (PCS w/PD) 25-27
Quick overview-
Toyota Safety Sense
™ 2.0 (TSS 2.0) 24
Road Sign Assist (RSA) 40
Sensors 25
BLUETOOTH® DEVICE
PAIRING SECTION 48-50
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES

3
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Emergency flasher switch
Seat heater switch1
Parking brake switch Brake hold switchVSC OFF switch
VSC OFF switch “SPORT” mode
switch
1
“iMT” (Intelligent
Manual Transmission)
switch
1
Qi Wireless charger switch1Seat heater switch1
With a continuously
variable transmission
With a manual
transmission
1 If equipped.2 For details, refer to the “Navigation and Multimedia System Owner’s M\
anual” or visit www.toyota.com/
audio-multimedia for additional resources.
Audio system1,2/
Navigation system1,2
Air conditioning/heating
controls

21
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Air conditioning/heating
WITHOUT DUAL AIR CONDITIONING SYSTEM
WITH DUAL AIR CONDITIONING SYSTEM
Temperature control
Temperature control
(driver side) Temperature control
(passenger side)
Fan speed
increases/decreases Fan speed
Windshield
airflow/defogger
Windshield
airflow/defogger Air Conditioning
ON/OFF
Air Conditioning
ON/OFF
Climate control OFF
Climate control OFF Eco air
conditioning mode
Eco air
conditioning mode
Automatic climate control ON
Adjusting the temperature setting
will cause the airflow vents,
air intake and fan to adjust
automatically to set temperature.
Automatic climate control ON
Adjusting the temperature setting
will cause the airflow vents,
air intake and fan to adjust
automatically to set temperature.
Airflow vent mode
Airflow vent mode
Outside rearview
mirror/Rear defogger
Outside rearview
mirror/Rear defogger Recirculate cabin air
(outside air when OFF)
Recirculate cabin air
(outside air when OFF)Outside air
Outside air
“SYNC” button
Indicator ON: Synchronized
temperature settings for
driver’s and front passenger’s
seat.
Indicator OFF: Separate
temperature settings for
driver’s and front passenger’s
seat.
