clock setting TOYOTA COROLLA HATCHBACK 2023 Owners Manual

752-1. Instrument cluster
2
Vehicle status information and indicators
■Locations of gauges and metersEngine coolant temperature gauge
Displays the engine c oolant temperature
Outside temperature
Displays the outside temperature within the range of -40°F (-40 °C) to 140°F
(60°C)
Speedometer/Tachometer
This setting can be changed on the setting screen. ( P.386)
Clock ( P. 7 7 )
Fuel gauge
Displays the quantity of fu el remaining in the tank
Odometer and trip meter display ( P.76)
Shift position indicator ( P.137)
Multi-information display
Presents the driver with a variety of vehicle data (P.83)
Displays warning messages if a malfunction occurs (P.330)
Speedometer
Gauges and meters (7-inch display)
Meter display

772-1. Instrument cluster
2
Vehicle status information and indicators
can be used to record and display
different distances independently.
To reset, display the desired trip
meter and press and hold the dis-
play change button.
The brightness of the instrument
panel lights can be adjusted.
1Brighter
2 Darker
■Instrument panel light bright-
ness adjustment
When the headlights or parking
lights are turned on, the meter and
instrument panel lights will be
dimmed. However, if the instrument
panel brightness dial is set to the
highest position, the lights will not
dim even if the headlights or parking
lights are turned on.
■The clocks can be adjusted
on the audio system
screen.
Refer to “MULTIMEDIA
OWNER’S MANUAL”.
■Display
Driving support system status
display area
Displays an image when the follow-
ing systems are operating and a
menu icon other than is
selected:
• LTA (Lane Tracing Assist)
• LDA (Lane Departure Alert)
• RSA (Road Sign Assist)
• Dynamic radar cruise control
• Cruise control
Content display area
By selecting menu icons on the
multi-information di splay, a variety
of driving-related information can
be displayed. The multi-information
display can also be used to change
display settings and other vehicle
settings.
Warning or advice pop-up displays
are also displayed in certain situa-
tions.
■Menu icons
The menu icons will be dis-
played by pressing the or
Changing the instrument
panel light brightness
Adjusting the clock
Multi-infor mation dis-
play (4.2-inch display)
Display and menu icons

2355-1. Using the air conditioning system and defogger
5
Interior features
Vehicles with DUAL mode air conditioning systemLeft-hand side temperature control switch
Right-hand side temperature control switch
“SYNC” switch
“A/C” switch
Outside air mode switch
Recirculated air mode switch
Airflow mode control switch
Fan speed increases switch
Fan speed decreases switch
Eco air conditioning mode switch
Rear window defogger and outside rear view mirror defoggers
switch
Windshield defogger switch
Off switch
Automatic mode switch
■Adjusting the temperature
setting
To adjust the temperature set-
ting, turn the temperature con-
trol switch clockwise (warm) or
counterclockwise (cool).
If “A/C” switch is not pressed, the
system will blow a mbient tempera-
ture air or heated air.
Vehicles with DUAL mode air con-
ditioning system: The air condition- ing system switches between
individual and synchronized modes
each time “SYNC” switch is
pressed.
The air conditioning system
switches between
individual and
synchronized modes each time
“SYNC” switch is pressed.
Synchronized modes (indicator on):
The left-hand side temperature
control switch can be used to adjust

2365-1. Using the air conditioning system and defogger
the temperature for the driver’s and
front passenger’s side. At this time,
operate the right-hand side tem-
perature control switch to enter
individual mode.
Individual modes (indicator off):
The temperature for the driver’s
and front passenger’s side can be
adjusted separately.
■Setting the fan speed
Vehicles without DUAL mode
air conditioning system
To adjust the fan speed, turn the
fan speed control switch clock-
wise (increase) or counterclock-
wise (decrease).
Pressing the off switch to turns off
the fan.
Vehicles with DUAL mode air
conditioning system
Operate the fan speed
increases switch to increase the
fan speed and the fan speed
decrease switch to decrease the
fan speed.
Pressing the off switch to turns off
the fan.
■Change the airflow mode
Press the airflow mode control
switch.
The airflow mode changes as fol-
lows each time the switch is
pressed.
1 Upper body
2 Upper body and feet
3 Feet
4 Feet and the windshield
defogger operates
■Switching between outside
air and recirculated air
modes
 To change to recirculated air
mode, press the recirculated
air mode switch.
The indicator illuminates on the
recirculated air mode switch.
To change to outside air
mode, press the outside air
mode switch.
The indicator illuminates on the out-
side air mode switch.
■Set cooling and dehumidifi-
cation function
Press the “A/C” switch.
When the function is on, the indica-
tor illuminates on the “A/C” switch.
■Defogging the windshield
Defoggers are used to defog the

416Alphabetical Index
Lane Tracing Assist (LTA)...... 177Operation ............................. 177
Language (multi-information dis- play) ................................... 81, 86
LATCH anchors ........................ 56
LDA (Lane Departure Alert) ... 182 Operation ............................. 182
Lever Auxiliary catch lever ............. 273
Hood lock release lever........ 273
Shift lever ............................. 137
Turn signal lever ................... 141
Wiper lever ........................... 154
License plate lights Light switch .......................... 148
Replacing light bulbs ............ 309
Wattage ................................ 372
Light Wattage ................................ 372
Light bulbs Replacing ............................. 309
Lights AHB (Automatic High Beam) 150
Front interior lights ............... 243
Headlight switch ................... 148
Interior lights......................... 243
Interior lights list ................... 243
Luggage compartment light.. 101
Personal lights...................... 244
Rear interior lights ................ 243
Replacing light bulbs ............ 309
Turn signal lever ................... 141
Vanity lights .......................... 257
Wattage ................................ 372
LTA (Lane Tracing Assist) ...... 177 Operation ............................. 177
LTA (Lane Tracing Assist) switch ............................................... 180
Luggage compartment features ............................................... 248
Luggage compartment light Wattage ................................ 372 Luggage cover ........................249
M
Maintenance
Do-it-yourself maintenance ..271
General maintenance ...........267
Maintenance data .................366
Maintenance requirements ...265
Malfunction indicator lamp ....321
Menu icons ..........................77, 83
Meter Clock ................................72, 75
Indicators ................................70
Instrument panel light control74, 77
Meter control switches......78, 83
Meter light control ...................76
Meters ..............................72, 75
Multi-information display...77, 83
Settings ............................81, 86
Warning lights .......................320
Warning message.................330
Mirrors Inside rear view mirror .......... 114
Outside rear view mirror defog-gers ....................................237
Outside rear view mirrors ..... 115
Vanity mirrors........................257
Multi-information display Audio system-linked display .81, 86
Clock ................................74, 77
Cruise control .......................202
Driving informati on display78, 84
Driving support system informa- tion display .....................80, 85
Dynamic radar cruise control 196
Eco Driving Indicator ........79, 84
Fuel economy ...................79, 84
Menu icons .......................77, 83
Meter control switches......78, 83
