navigation system TOYOTA COROLLA HYBRID 2020 Accessories, Audio & Navigation (in English)

813-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
*: This function is not made avail- able in some countries or areas.
A Destination Assist operator
can search for a destination.
You can request a specific busi-
ness, address, or ask for help
locating your desired destina-
tion. ( P.227)
1 Display the destination
screen. ( P.79)
2 Select “Dest Assist”.
1 Display the destination
screen. ( P.79)
2 Select “Recent”.
3 Select the desired destina-
tion.
“Sort/Delete”: Select to sort (date,
name) or delete destination(s).
●Up to 100 previously set destina-
tions are displayed on the screen.
1Select “Sort/Delete”.
2 Select “Delete Recent Desti-
nations”.
3 Select the desired recent
destination(s) to be deleted.
4 Select “Yes” when the confir-
mation screen appears.
“Sort/Delete All”: Select to sort
(date, name) desti nations or delete
all.
1 Display the destination
screen. ( P. 7 9 )
2 Select “Emergency”.
3 Select the desired emer-
gency category.
4 Select the desired destina-
tion.
●The navigation system does not
guide in areas where route guid-
ance is unavailable. ( P. 111 )
To use this function, it is neces-
sary to have contact data which
had been transferred to the nav-
igation system from a registered
Bluetooth
® phone. ( P.186)
1 Display the destination
screen. ( P. 7 9 )
2 Select “Contacts”.
3 Select the desired contact.
4 Select “Addresses”.
5 Select the desired address.
6 Follow the steps in “Search-
ing by keyword” from step 4.
( P.80)
●This function may not be available
depending on the type of Blue-
tooth
® phone.
Searching by Destination
Assist Connect*
Searching by recent desti-
nations
Deleting recent destina-
tions
Searching by emergency
Searching by contact

833-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
for a destination by Points of
Interest.
1 Display the destination
screen. ( P.79)
2 Select “Point of Interest”.
3 Select the desired search
method.
Select to change the search
area. ( P.79)
Select to search by name.
( P. 8 3 )
Select to search by category.
( P. 8 3 )
Select to search by phone
number. ( P.84)
1 Select “Name”.
2 Enter a POI name and select
“Search”.
3 Select the desired POI.
“Sort/Category/Cit y”: Select to sort
(name, distance) the displayed
entries, change the POI category,
or enter a city name.
 When entering the name of a
specific POI, and there are 2
or more sites with the same
name, the list screen will be displayed. Select the desired
POI.
●To search for a facility name using
multiple search words, put a
space between each word.
1
Select “Sort/Category/City”.
2 Select “Enter a city name”.
3 Enter a city name and select
“Search”.
“Any City”: Select to cancel the city
setting.
4Select the desired city name.
5 Select the desired POI.
1 Select “Sort/Category/City”.
2 Select “Change POI cate-
gory”.
3 Select the desired category.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categories”: Select to dis-
play all POI categories.
4 Select the desired POI.
1 Select “Category”.
Searching by name
A
B
C
D
6HOHFWLQJDFLW\WRVHDUFK
6HOHFWLQJIURPWKHFDWHJR
ULHV
6HDUFKLQJE\FDWHJRU\

843-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
2Select the desired search
point.
Select to search for POIs
near your current position.
Select to search for POIs
along the set route.
Select to search for POIs
near a specific city center.
( P. 8 4 )
Select to search for POIs
near a destination.
When more than 1 destina-
tion has been set, a list will
be displayed on the screen.
Select the desired destina-
tion.
3 Select the desired POI cate-
gory.
 If there is more than 1 result
for the selected category, a
detailed list will be displayed.
“List All Categories”: Select to dis-
play all POI categories.
“Favorite POI Categories”: Select to
use the 6 POIs tha t have been pre-
viously set. ( P.104)
4 Select the desired POI.
●The names of POIs located within
approximately 200 miles (320 km)
from the selected search point can
be displayed. They are displayed up to 200 names.
1
Select “Near a City Center in
XX
*”.
2 Enter a city name and select
“Search”.
“Last 5 Cities”: Select the desired
city name from the list of the last 5
cities.
3Select the desired city name.
4 Select “OK” when the city
center map screen is dis-
played.
5 Follow the steps in “Search-
ing by category” from step 3.
( P.83)
*: XX represents the selected
search area name.
●If the navigation system has never
been used, selecting the city
name from “Last 5 Cities” will not
be available.
1 Select “Phone #”.
2 Enter a phone number and
select “OK”.
 If multiple locations with the
same phone number exist,
the list screen will be dis-
played.
●If there is no match for the entered
phone number, a list of identical
numbers with different area codes
A
B
C
D
When “Near a City Center in
XX
*” is selected
Searching by phone num-
ber

853-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
will be displayed.
To use this function, it is neces-
sary to register a home and/or a
favorite location. Up to 2 favor-
ites can be registered as preset
destinations. ( P.97, 98)
To set the home or a preset des-
tination as the destination,
select the corresponding button.
1 Turn the engine switch
to ACC or
ON.
2 Press the “MAP” button.
3 Select the desired item.
Select to set the registered
home as the destination.
Select to set a registered
favorite as the destination.
(Up to 2 favorites can be reg-
istered as preset destina-
tions.)
 The estimated time of arrival
to the registered home and
preset destinations from the
current position will be dis- played.
 If the home or a preset desti-
nation has not been regis-
tered, “Save Home” or “Save
Favorite” will be displayed,
respectively. To register a
home or preset destination,
select the corresponding but-
ton.
●When the destination is very close
to the current po sition, “Nearby”
will be displayed.
●The one-touch buttons for home
and favorites will disappear after
the vehicle has been driven for a
while.
●The color of the estimated arrival
time indicator may change
depending on the traffic informa-
tion received.
●This function is available when
“Automatic Destination List Info” is
set to on. ( P.102)
One-touch setting
home/favorite as a desti-
nation
A
B

873-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
existing destination(s) and set a
new one.
“Add to Route”: Select to add a
destination to the current route.
Select to register as a mem-
ory point.
Select to call the registered
number.
Select to update information
about the selected entry.*
*: This function is displayed only when there is information from
the Toyota Entune center.
( P. 8 0 )
Current position
Destination point
Select to display a list of the
turns required to reach the
destination. ( P.88)
Select the desired route from
3 possible routes. ( P. 8 7 )
Select to change the route.
( P. 8 8 )
Type of route and its distance
Distance of the entire route
Select to start guidance.
Select and hold to start demo mode. (
P.87)
Displayed when the route
displayed is from the Toyota
Entune center. ( P.89)
Before starting the route guid-
ance, the demonstration of the
route guidance can be viewed.
1 Select and hold “OK” on the
route overview screen until a
beep sounds.
 Press the “HOME” or “MAP”
button to end demo mode.
1 Select “3 Routes”.
2 Select the desired route.
Displayed when the route
displayed is available from
the Toyota Entune center.
()
Select to display the quick-
est route.
Select to display the route
that is the shortest distance
to the set destination.
Select to display the alterna-
Route overview screen
C
D
E
A
B
C
D
E
F
G
H
6WDUWLQJGHPRPRGH
URXWHVVHOHFWLRQ
I
A
B
C
D

893-2. Destination search
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
2 Select the desired item.
Select to add destinations.
( P. 8 9 )
Select to delete destinations.
( P. 8 9 )
Select to reorder destina-
tions. ( P.95)
Select to set route prefer-
ences. ( P.95)
When the vehicle is stopped
1 Select “Add”.
2 Search for an additional des-
tination in the same way as a
destination search. ( P. 7 9 )
 Up to 5 destinations can be
set.
3 Select “Add Destination
Here” at the position in the
route which you want to add
the destination.
While driving
1 Select “Add”.
2 Search for an additional des-
tination in the same way as a
destination search. ( P. 7 9 )
 Up to 5 destinations can be set.
3 Select “Beginning” or “End”.
1 Select “Delete”.
2 Select “Yes” when the confir-
mation screen appears.
 If more than 1 destination has
been set, select the destina-
tion(s) to be deleted. (The
navigation system will recal-
culate route(s) to the remain-
ing set destination(s).)
*: This function is not made avail-
able in some countries or areas.
When starting route guidance or
rerouting, a route can be pro-
vided automatically by the Toy-
ota Entune center. This function
is available when dynamic route
setting is enabled. ( P.102)
Adding destinations
A
B
C
D
'HOHWLQJGHVWLQDWLRQV
$URXWHIURPWK\
H7R\RWD
(QWXQHFHQWHU
9HKLFOHV
ZLWK'&0\f

913-3. Route guidance
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
2 Check that the list of the dis-
tance and time is displayed.
 By selecting one of the num-
ber buttons, the desired route
information is displayed.
“Arrival Time”: Select to display the
estimated arrival time.
“Time to Dest.”: Select to display
the estimated travel time.
●When the vehicle is on the guid-
ance route, the distance mea-
sured along the route is displayed.
Travel time and arrival time are
calculated based on the average
speed of the specified speed limits
and current traffic information.
●When the vehicle gets off the
guidance route, the arrow facing
the destination is displayed
instead of the estimated
travel/arrival time.
●The route information bar fills from
left to right as the vehicle pro-
gresses along the route.
During freeway driving, the free-
way information screen can be
displayed. Distance from the current
position to the freeway
exit/rest area
Name of the freeway exit/rest
area
POIs that are close to a free-
way exit
Select to display the selected
map of the exit vicinity.
Select to display the nearest
freeway exits/rest areas from
the current position.
: Select to scroll
to farther free-
way exits/rest areas.
: Select to scroll to closer free-
way exits/rest areas.
When the vehicle approaches
an exit or junction, the freeway
guidance screen will be dis-
played.
During freeway driving
When approaching free-
way exit or junction
A
B
C
D
E

933-3. Route guidance
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
an intersection, the intersection
guidance screen will be dis-
played. Next street name
Distance to the intersection
Select to hide the intersection
guidance screen.
• To return to the intersection guid-ance screen, press the “MAP”
button.
Remaining distance bar to
the guidance point
●This function is available when
“Intersection Zoom Map” is set to
on. ( P.102)
1Select “Turn List” on the map
mode screen. ( P.73)
2 Check that the turn list
screen is displayed.
Turn direction Distance between turns
Next street or destination
name
On this screen, information
about the next turn on the guid-
ance route can be displayed.
1 Select “Turn-by-Turn Arrow”
on the map mode screen.
( P.73)
2 Check that the turn-by-turn
arrow screen is displayed.
Exit number or street name
Turn direction
Distance to the next turn
Turn list screen
A
B
C
D
A
7XUQE\WXUQD\
UURZVFUHHQ
B
C
A
B
C

943-3. Route guidance
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
●If a voice guidance command can-
not be heard, press the “MAP”
button to hear it again.
●To adjust the voice guidance vol-
ume: P. 6 0
●To mute the voice guidance:
 P. 9 0
●Voice guidance may be made
early or late.
●If the navigation system cannot
determine the current position cor-
rectly, you may not hear voice
guidance or may not see the mag-
nified intersection on the screen.
1 Select on the map
screen. ( P. 6 8 )
2 Select the desired item to be
set.
Select to display the over-
view of the entire route.
( P.87)
Select to reorder destina-
tions. ( P.95)
Select to change route type.
( P.95)
Select to set route prefer-
ences. ( P. 9 5 )
Select to set detours.
( P.95)
Select to start from adjacent
road. ( P. 9 6 )
 To hide the route options
screen, touch any part of the
map screen.
3 Check that the route over-
view is displayed. ( P.87)
Typical voice guid-
ance prompts
As the vehicle approaches
an intersection, or point,
where maneuvering the
vehicle is necessary, the
navigation system’s voice
guidance will provide vari-
ous messages.
WA R N I N G
●Be sure to obey the traffic regu-
lations and keep the road condi-
t i o n i n m i n d e s p e c i a l l y w h e n y o u
are driving on IPD roads (roads
that are not completely digitized
in our database). The route
guidance may not have the
updated information such as the
direction of a one way street.
Editing route
Displaying the edit route
screen
A
B
C
D
E
F

953-3. Route guidance
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
When more than 1 destination
has been set, the arrival order of
the destinations can be
changed.
1 Select on the map
screen. ( P.68)
2 Select “Reorder”.
3 Select the desired destina-
tion and select “Move Up” or
“Move Down” to change the
arrival order. Then select
“OK”.
1 Select on the map
screen. ( P.68)
2 Select “Route Type”.
3 Select the desired route type.
 The entire route from the
starting point to the destina-
tion is displayed. ( P.87)
 During driving, the route guid-
ance starts after selecting the
desired route type.
The conditions to determine the
route can be selected from vari-
ous choices such as freeways,
toll roads, ferries, etc.
1 Select on the map
screen. ( P.68)
2 Select “Preference”. 3
Select the desired route pref-
erences and select “OK”.
●Even if the “Freeways” route pref-
erence is turned off, the route may
not be able to avoid freeways in
some cases.
●If the calculated route includes a
trip by ferry, the route guidance
shows a sea route. After traveling
by ferry, the curre nt position may
be incorrect. Upon reception of
GPS signals, it is automatically
corrected.
During the route guidance, the
route can be changed to detour
around a section of the route
where a delay is caused by road
repairs, an accident, etc.
1 Select on the map
screen. ( P. 6 8 )
2 Select “Detour”.
3 Select the desired detour dis-
tance.
Select to detour within 1 mile
of the current position.
Select to detour within 3
miles of the current position.
Select to detour within 5
miles of the current position.
Reordering destinations
Selecting route type
Setting route preferences
Detour setting
A
B
C
