navigation system TOYOTA COROLLA HYBRID 2020 Accessories, Audio & Navigation (in English)

963-3. Route guidance
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
Select to detour on the entire
route.
Select to make the navigation
system search for the route
based on traffic congestion
information received from
traffic information.
* ( P. 7 6 )
*: This function is not made avail-
able in some countries or areas.
●This picture shows an example of
how the navigation system would
guide around a delay caused by a
traffic jam.
This position indi cates the loca-
tion of a traffic jam caused by
road repairs, an accident, etc.
This route indicates the detour
suggested by the navigation
system.
●When the vehicle i s on a freeway,
the detour distance selections are
5, 15 and 25 miles (or 5, 15 and
25 km if units are in km).
●The navigation system may not be
able to calculate a detour route
depending on the selected dis-
tance and surrounding road condi-
tions.
When a freeway and a surface
road run in parallel, the naviga-
tion system may show the guid- ance route going on the freeway
while driving on the surface
road, or vice versa.
If this happens, you can
instantly choose the adjacent
road for the route guidance.
1
Select on the map
screen. ( P. 6 8 )
2 Select “Adjacent Road”.
●When there is no adjacent road,
this screen butt on will not be dis-
played.
Adjacent road
D
E
A
B

973-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
3-4.Setup
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select the desired item to be
set. Select to set home. (
P. 9 7 )
Select to set the favorites list.
( P.98)
Select to set areas to avoid.
( P.100)
Select to set detailed naviga-
tion settings. ( P.102)
●When “Useful Navi. Information
Settings” is displayed on the
screen: P. 1 1 0
If home has been registered,
that information can be recalled
by selecting on the destina-
tion screen. ( P. 7 9 )
1 Display the navigation set-
tings screen. ( P.97)
2 Select “Home”.
Navigation settings
Home, favorites list entries,
areas to avoid can be set as
memory points. The regis-
tered points can be used as
the destinations. ( P.79)
Registered areas to avoid,
will be avoided when the
navigation system searches
for a route.
Displaying navigation set-
tings screen
Navigation settings
screen
Setting up home
A
B
C
D

993-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
1 Select “New”.
2 Select the desired item to
search for the location.
( P. 7 9 )
3 Select “OK” when the editing
favorites list screen appears.
( P. 9 9 )
●Up to 100 favorites list entries can
be registered.
The icon, name, location and/or
phone number of a registered
favorites list entry can be edited.
1Select “Edit”.
2 Select the desired favorites
list entry.
 Each time a star icon is
selected, its color will change.
Colored star icons indicate
that the favorite is registered
to the corresponding preset
destination button. Up to 2
entries can be registered as
quick favorite destinations.
( P. 8 5 ) 3
Select the desired item to be
edited.
Select to edit the favorites list
entry name. ( P.99)
Select to set display of the
favorites list entry name
on/off.
Select to edit location infor-
mation. ( P. 9 9 )
Select to edit the phone num-
ber. ( P.100)
Select to change the icon to
be displayed on the map
screen. ( P.100)
4 Select “OK”.
1 Select “Name”.
2 Enter a name and select
“OK”.
1 Select “Location”.
2 Scroll the map to the desired
point ( P.72) and select
“OK”.
Registering favorites list
entries
Editing favorites list
entries
Changing the name
Changing the location
A
B
C
D
E

1013-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
1 Select “New”.
2 Select the desired item to
search for the location.
( P. 7 9 )
3 Select either or to
change the size of the area to
be avoided and select “OK”.
4 Select “OK” when the area to
avoid screen appears.
●If a destination is entered in the
area to avoid or th e route calcula-
tion cannot be made without run-
ning through the a rea to avoid, a
route passing through the area to
be avoided may be shown.
●Up to 10 locations can be regis-
tered as points/areas to avoid.
The name, location and/or area
size of a registered area can be
edited.
1 Select “Edit”.
2 Select the desired area. 3
Select the desired item to be
edited.
Select to edit the name of the
area to avoid. ( P.101)
Select to set display of the
area to avoid name on/off.
Select to edit area location.
( P.101)
Select to edit area size.
( P.101)
Select to set the area to
avoid function on/off.
4 Select “OK”.
1 Select “Name”.
2 Enter a name and select
“OK”.
1 Select “Location”.
2 Scroll the map to the desired
point ( P.72) and select
“OK”.
1 Select “Size”.
Registering areas to avoid
Editing areas to avoid
Changing the name
Changing the location
Changing the area size
A
B
C
D
E

1033-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
 “Low Fuel Warning Pop-up”
Select to set display of low fuel
warning on/off. ( P.103)
 “Unverified Roads Guidance
Warning”
Select to set unverified roads guid-
ance warning on/off.
“Guidance on Unverified
Roads”
Select to set IPD road (roads that
are not completely digitized in our
database) guidance on/off.
“Guidance with Street Names”
Select to set the voice guidance for
the next street name on/off.
“Favorite POI Categories”
Select to set favorite POI catego-
ries that are used for POI selection
to display on the map screen.
(  P.104)
 “Calibration”
Select to adjust the current position
mark manually or to adjust miscal-
culation of the di stance caused by
tire replacement. ( P.104)
 “Adaptive Route”
Select to enable/d isable adaptive
routes. When enabled, the naviga-
tion system will provide frequently
used routes.
 “Reset Adaptive Route”
Select to erase adaptive route data.
“Automatic Destination List
Info”
Select to set automatic destination
list information on/off. When set to
on, the estimated time of arrival to
the registered ho me and preset
destinations from the current posi-
tion will be displayed.
 “Intersection Zoom Map”
Select to set display of a guidance
screen on/off.
“Automatic Zoom”
Select to set automatic zoom func-
tion on/off. When it is enabled, as
the vehicle approaches a guidance
point, the map will change to a
detailed map automatically.
 “State Border Guidance”
Select to set cross-border guidance
on/off.
“Map Color Customization”
Select to set the map display color.
“Map Animation”
Select to set map animation on/off.
“Dynamic Route”*
Select to enable/disable routes
sourced from the Toyota Entune
center. ( P.89)
 “Restore the default settings”
Select to reset all setup items.
*: This function is not made avail-
able in some countries or areas.
When the fuel level is low, a
warning message will pop up on
the screen.
Detailed navigation set-
tings screen
Low fuel warning

1053-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
When driving, the current posi-
tion mark will be automatically
corrected by GPS signals. If
GPS reception is poor due to
location, the current position
mark can be adjusted manually.
1 Select “Position/Direction”.
2 Scroll the map to the desired
point ( P.71) and select
“OK”.
3 Select an arrow to adjust the
direction of the current posi-
tion mark and select “OK”.
The tire change calibration func-
tion will be used when replacing
the tires. This function will adjust
miscalculation caused by the
circumference difference
between the old and new tires.
1 Select “Tire Change”.
 The message appears and
the quick distance calibration
starts automatically.
●If this procedure is not performed
when the tires are replaced, the
current position mark may be
incorrectly displayed.
*: This function is not made avail-
able in some countries or areas.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Traffic”.
4 Select the desired items to
be set.
Position/Direction calibra-
tion
Tire change calibration
Traffic settings*
Traffic information such as
traffic congestion or traffic
incident warnings can be
made available.
Displaying the traffic set-
tings screen
Screen for traffic settings

1073-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
7 Select the desired item to
search for the location.
( P. 7 9 )
8 Select “OK”.
9 Confirm the route overview
displayed.
Select the desired route from
3 possible routes. ( P. 8 7 )
Select to modify the route.
The routes can be adjusted
by setting preferred roads.
( P.107)
10 Select “OK”.
●Up to 5 routes can be registered.
1Select “Edit”.
2 Select the desired traffic
route. 3
Select the desired item to be
edited.
Select to edit the name of the
personal traffic route.
( P.106)
Select to edit start location.
( P.106)
Select to edit end location.
( P.106)
Select to see and modify the
entire route. ( P.107)
4 Select “OK”.
5 Follow the steps in “Register-
ing personal traffic routes”
from step 9. (  P.106)
1 Select “Delete”.
2 Select the desired traffic
route to be deleted and
select “Delete”.
3 Select “Yes” when the confir-
mation screen appears.
“My Traffic Routes” can be
adjusted by setting up to 2 pre-
Editing personal traffic
routes
A
B
'HOHWLQJSHUVRQDOWUDIILF
URXWHV
6HWWLQJSUHIHUUHGUR\
DGV
A
B
C
D

1093-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
3 Select the desired item.
Select to select automati-
cally change routes when
congestion information of the
guidance route has been
received.
Select to select manually
whether or not to change
routes when congestion
information of the guidance
route has been received. In
this mode, a screen will
appear to ask if you wish to
reroute.
Select to not reroute when
congestion information for
the guidance route has been
received.
When the navigation system
calculates a new route, a confir-
mation screen will be displayed. 1
Select the desired item.
Select to start route guidance
using the new route.
Select to confirm the new
route and current route on
the map.
Select to continue the current
route guidance.
Changing the route manually
A
B
C
A
B
C

1103-4. Setup
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
*: This function may not be avail-able immediately after purchase
of the vehicle.
1 Press the “MENU” button.
2 Select “Setup”.
3 Select “Navigation”.
4 Select “Useful Navi. Informa-
tion Settings”.
5 Select the desired items to
be set.
Use of infor mation
accumulated by navi-
gation system
* (vehi-
cles with DCM)
When enabled, information
collected by the navigation
system will be analyzed to
give advice for safe driving.
Displaying the useful nav-
igation information set-
tings screen

1113-5. Tips for the navigation system
COROLLA_COROLLA
HV(TMMMS)_Navi_(U)
3
Navigation system
3-5.Tips for the navigation system
The Global Positioning System
(GPS) developed and operated
by the U.S. Department of
Defense provides an accurate
current position, normally using
4 or more satellites, and in some
case 3 satellites. The GPS sys-
tem has a certain level of inac-
curacy. While the navigation
system compensates for this
most of the time, occasional
positioning errors of up to 300 ft.
(100 m) can and should be
expected. Generally, position
errors will be corrected within a
few seconds.
When the vehicle is not receiv-
ing signals from satellites, the
unreceived GPS mark appears
on the map screen. When the
vehicle is receiving the signals,
the unreceived GPS mark does not appear on the map screen.
The GPS signal may be physi-
cally obstructed, leading to inac-
curate vehicle position on the
map screen. Tunnels, tall build-
ings, trucks, or even the place-
ment of objects on the
instrument panel may obstruct
the GPS signals.
The GPS satellites may not
send signals due to repairs or
improvements being made to
them.
Even when the navigation sys-
tem is receiving clear GPS sig-
nals, the vehicle position may
not be shown accurately or inap-
propriate route guidance may
occur in some cases.

Accurate current position may
not be shown in the following
cases:
• When driving on a small angled
Y-shaped road.
• When driving on a winding road.
• When driving on a slippery road such as in sand, gravel, snow,
etc.
GPS (Global Position-
ing System)
This navigation system cal-
culates the current position
using satellite signals, vari-
ous vehicle signals, map
data, etc. However, an accu-
rate position may not be
shown depending on satel-
lite conditions, road config-
uration, vehicle condition or
other circumstances.
Limitations of the naviga-
tion system
NOTICE
●The installation of window tint-
ing may obstruct the GPS sig-
nals. Most window tinting
contains some metallic content
that will interf ere with GPS sig-
nal reception of the antenna in
the instrument panel. We advise
against the use of window tint-
ing on vehicles equipped with
navigation systems.
