seat adjustment TOYOTA GT86 2018 Owners Manual (in English)

53
1
Before driving
1-3. Adjustable components (seats, mirrors, steering wheel)
Front seats
Seat position adjustment
lever
Seatback angle adjustment
lever
Vertical height adjustment
lever (driver’s side only)
Seatback fold strap

55
1-3. Adjustable components (s
eats, mirrors, steering wheel)
1
Before driving
WARNING
■Seat adjustment
●To reduce the risk of sliding under the lap belt during a colli sion, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may cont act the
shoulder belt, increasing the risk of death or serious injury i n the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.
● After adjusting the seat, make sure that the seat is locked in position.
● Take care not to hit passengers with the seat.
When sliding the seat rearward, make sure not to squash the leg s of the
rear passengers.
● When returning the seatback upright, perform seatback angle adj ustment
while holding down the seatback.
● Do not pull on or use the seat belt guide to adjust or fold the front seat.
● Do not put your hands under the seat or near the moving parts t o avoid
injury. Fingers or hands may become jammed in the seat mechanis m.
■ When driving the vehicle
Never operate the seatback angle adjustment lever or seatback f old strap.
Doing so could cause an accident resulting in death or serious injury.
■ Getting in and out of the rear seats
● When getting in or out of the rear seats, make sure not to get your hands,
legs, etc. squashed in the movable or connecting parts.
● When getting in or out of the rear seats, make sure not to trip on the seat
rails.
● After getting in or out of the rear seats, always make sure the front seat is
locked in position.
■ When operating the front seat from the rear seat
Make sure that no passenger is seated in the front seat.

67
1
1-3. Adjustable components (seats, mirrors, steering wheel)
Before driving
Steering wheel
WARNING
■Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and an accident,
resulting in death or serious injury.
■ After adjusting the steering wheel
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causi ng an
accident, and resulting in death or serious injury.
The steering wheel can be adjust ed to a comfortable position.
Hold the steering wheel and
push the lever down.
Adjust to the ideal position by
moving the steering wheel
horizontally and vertically.
After adjustment, pull the lever
up to secure the steering
wheel.
STEP 1
STEP 2

88 1-7. Safety information
WARNING
■While driving
●Do not adjust the position of the driver's seat.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce
the effectiveness of the seat belt and head restraint, increasing the risk of
death or serious injury to the driver or passenger.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the s eat
tracks and stop the seat from locking in place. This may lead to an acci-
dent resulting in serious injury or death. The adjustment mecha nism may
also be damaged.
■ Adjusting the seat position
●Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.
● Do not put your hands under the seat or near the moving parts t o avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

524 Alphabetical index
Floor mat................................... 303
FluidBrake ..................................... 337
Washer .................................. 343
Fog lights
Switch.................................... 228
Front fog lights Switch.................................... 228
Front passenger occupant classification system ............ 128
Front passenger's seat belt
reminder light......................... 399
Front seats Adjustment ..............................53
Front side marker light Replacing light bulbs ............. 375
Wattage ................................. 469
Front turn signal lights Switch.................................... 188
Fuel
Capacity ................................ 461
Fuel gauge ............................ 191
Fuel pump shut off system .... 394
Gas station information ......... 532
Information ............................ 470
Refueling .................................75
Fuel door.....................................75
Fuel filler door ............................75
Fuel pump shut off system ..... 394
Fuses......................................... 367
Gauges ...................................... 191
Glove box.................................. 292 Hazard lights
Switch ................................... 384
Head restraints Adjusting ................................ 58
Headlights
Automatic headlight leveling ............................... 226
Switch ................................... 222
Heaters Seat heaters.......................... 301
Side mirror ............................ 284
Hill-start assist control ............ 252
Hood.......................................... 327
Horn .......................................... 190
I/M test ...................................... 323
Identification Engine ................................... 459
Vehicle .................................. 459
Ignition switch.................. 166, 175
Ignition switch light Ignition switch light ................ 289
Illuminated entry system......... 289
Immobilizer system ................... 79
Indicator lights ......................... 194
Inside rear view mirror .............. 68
Interior light Interior light ........................... 290
Switch ................................... 290
Wattage................................. 469
Jack Positioning a floor jack .......... 329
Vehicle-equipped
jack ..................................... 424
Jack handle .............................. 424
Jam protection function
Power windows ....................... 73F
G
H
I
J

526 Alphabetical index
Outside temperature display ............................ 200, 219
Overheating, Engine ................449
Paddle shift switches .............. 181
Parking brake ........................... 189
Parking lights Switch.................................... 222
Power outlets ........................... 299
Power windows ..........................72
Radiator .................................... 337
Rear seats ...................................56
Rear side marker lights Switch.................................... 222
Rear turn signal lights Switch.................................... 188
Rear view mirror
Inside rear view mirror.............68
Outside rear view mirrors ........69
Rear view monitor system ...... 237
Rear window defogger ............ 284
Replacing Fuses .................................... 367
Key battery ............................ 363
Light bulbs ............................. 375
Tires ...................................... 424
Reporting safety defects for U.S. owners ...................... 492
REV indicator ........................... 156
Seat belts
Adjusting the seat belt .............60
Automatic Locking Retractor (ALR).....................62
Child restraint system installation ........................... 141
Cleaning and maintaining
the seat belts ...................... 313 Emergency Locking
Retractor (ELR) .................... 62
How to wear your seat belt ..... 60
How your child should wear the seat belt ................. 62
Pregnant women, proper seat belt use .............. 64
Reminder light ....................... 399
Seat belt guide ........................ 61
Seat belt pretensioners ........... 61
Seat heaters ............................. 301
Seating capacity ...................... 260
Seats Adjustment .............................. 53
Adjustment precautions .......... 55
Child seats/child restraint system installation .............. 141
Cleaning ................................ 312
Head restraint ......................... 58
Properly sitting in the seat....... 87
Seat heaters.......................... 301
Service reminder indicators .............................. 194
Shift lever Automatic transmission ......... 178
If the shift lever cannot be shifted from P ................ 438
Manual transmission ............. 185
Shift lock system ..................... 438
Side airbags ............................... 89
Side maker lights Replacing light bulbs ............. 375
Switch ................................... 222
Wattage................................. 469
Side mirror
Adjusting and folding............... 69
Smart key system Antenna location ..................... 27
Entry function .......................... 25
Starting the engine ................ 166
P
R
S
