display TOYOTA HIGHLANDER 2020 Accessories, Audio & Navigation (in English)

1994-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
You can display still pictures one
by one at a constant interval.
1 Select “Slideshow” to start
slideshow.
 When pressing the or
button during slideshow, the
previous or next still picture
will be shown, and the slide-
show will continue from that
picture.
 Press the “ENT” or “OPTION”
button to stop slideshow.
1 Select or to rotate a
still picture.
 The rotate information will be
maintained until the system is
turned off or the SD card is
removed.
1 Select to zoom out the
still pictures.
 Select again to cancel
zoom out.
 This function is only available
for smallsized still pictures. 1
Select “Detailed Information”.
2 Detail informations of the still
picture are displayed.
1 Select “Setup”.
2 The slideshow settings can
be changed. After the set-
tings are changed, select
“OK”.
Selects slideshow interval
time (seconds)
5  10  15  30  60
Selects slideshow effect
“Fade”  “Slide” “Wipe1”
 “Wipe2”  “Dissolve”
 “Zoom” “Off”
Selects on/off repeat slide-
show
Starting slideshow
Rotating the still pictures
Zoom out the still pictures
Displaying the detail infor-
mations of the still picture
Slideshow setup
A
B
C

2014-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Movie Turning off the option screen
Displaying the detail informa-
tion
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Changing the playback mode
Changing the audio channel
Displaying the top menu
screen
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage 1
Select “Detailed Information”.
2 Detail informations of the
video are displayed.
SD video
SD AVCHD
Movie
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Displaying the detail infor-
mations of the video

2044-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
●Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●The Wi-Fi® networks serve bestef-
fort traffic.
Selecting a control icon
Inputting the selected control
icon
Using the DLNA mode
Plays or displays music,
pictures and video that are
stored on a DLNA server.
This device supports a
DLNA renderer function.
This device can play and
display content from
devices equipped with a
DLNA server function.
Make sure to install DMC-
compatible software on the
DLNA server.
Press the “INPUT” button
repeatedly until the DLNA
mode is selected.
WA R N I N G
●Use Wi-Fi® devices only when
safe and legal to do so.
●Your audio unit is fitted with
Wi-Fi® antennas. People with
implantable cardiac pacemak-
ers, cardiac resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should maintain a reasonable
distance between themselves
and the Wi-Fi
® antennas. The
radio waves may affect the
operation of such devices.
●Before using Wi-Fi® devices,
users of any electrical medical
device other than implantable
cardiac pacemakers, cardiac
resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should consult the manufacturer
of the device for information
about its operation under the
influence of radio waves. Radio
waves could have unexpected
effects on the operation of such
medical devices.
NOTICE
●Do not leave your smartphone
in the vehicle. In particular, high
temperatures inside the vehicle
may damage the smartphone.
Remote controller
A
B

2054-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Turning on the DLNA mode
Volume up/down
Fast-forward/rewind
Play/pause
Displaying the option screen
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press and hold /
or / .
1 Display the DLNA operation
screen.
2 Check that “Wi-Fi
*” is on.
3 Connect a device to the rear
seat entertainment system
via Wi-Fi
®. 4
Operate the device to stream
video/music/photos.
*:Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●DLNA streaming will stop in the
following situations:
• Select “Refresh” button to change
the Wi-Fi
® setting information.
(  P.205)
• The DLNA connection is turned off on the device.
•The Wi-Fi
® function is turned off.
(  P.208)
• The rear seat entertainment sys- tem source is changed to different
source. ( P.179)
After a device has been con-
nected to the vehicle Wi-Fi®
access point once, the access
point information will remain on
the device, enabling it automati-
cally connect the next time the
device is brought within access
point range, unless the access
point name or password is
changed.
To change the access point
name and password, select
“Refresh”. If changed while a
device is connected to the
access point, the connection will
be canceled.
Playing/pausing a
video/music
Fast forwarding or
rewinding a track/file
Connecting the system
C
D
E
F
G
&KDQJLQJWKHDFFHVVSRLQW
QDPHDQGSDVVZRUG

2064-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Select “Refresh”.
2 Select “Yes”.
●When the Wi-Fi® information is
refreshed, connected devices are
disconnected, so make sure to do
the wireless connection settings
again.
●The access point name and pass-
word are only changed when
“Refresh” is selected (they are not
changed when the engine switch
is turned off and
back on).
The Wi-Fi® function is turned
on/off.
Select to display Wi-Fi
® sys-
tem information
1 Connect your smartphone to
a Wi-Fi
® network and send a
picture from a DLNA-compat-
ible application.
2 Picture is displayed on the
screen.
 Press the “INPUT” button to
DLNA operation
Playing still pictures
A
B

2074-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
return to the DLNA menu
screen. To display the picture
again, select “DLNA”.
1 Connect your smartphone to
a Wi-Fi
® network and send a
video from a DLNA-compati-
ble application.
2 Video will start playing.
 Press the “INPUT” button to
return to the DLNA menu
screen. To display the video
again, select “DLNA”. 1
Press the “OPTION” button
while watching a video, the
following screen appears.
Turning off the option screen
Rewind
Play/pause
Fast-forward
Playing video
Option screen
A
B
C
D

2094-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
●Miracast® is a registered trade-
mark of Wi-Fi Alliance®.
●Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●The Wi-Fi® networks serve bestef-
fort traffic.
●If a connected devi ce is taken out
of the Wi-Fi® connection area, the
connection will be severed.
●Depending on the environment in
which the access point is used,
the communication speed may be
low or communication may not be
possible.
●When a device is connected to the
rear seat entertainment system
via Wi-Fi
®, the device may not be
able to be connected to the inter-
net via mobile network (3G or 4G).
Using the Miracast®
mode
The screen of a Miracast®
compatible device (with
Android OS version 4.4 or
later) can be displayed on
the rear seat entertainment
system display.
This function is not avail-
able if the smartphone is
not certified by Wi-Fi
Alliance
® as Miracast®
device.
Refer to the instruction
manual and other documen-
tation included with the
external device to determine
whether it supports Mira-
cast
®.
Press the “INPUT” button
repeatedly until the Mira-
cast
® mode is selected.
WA R N I N G
●Use Wi-Fi® devices only when
safe and legal to do so.
●Your audio unit is fitted with
Wi-Fi® antennas. People with
implantable cardiac pacemak-
ers, cardiac resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should maintain a reasonable
distance between themselves
and the Wi-Fi
® antennas. The
radio waves may affect the
operation of such devices.
●Before using Wi-Fi® devices,
users of any electrical medical
device other than implantable
cardiac pacemakers, cardiac
resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should consult the manufacturer
of the device for information
about its operation under the
influence of radio waves. Radio
waves could have unexpected
effects on the operation of such
medical devices.
NOTICE
●Do not leave your smartphone
in the vehicle. In particular, high
temperatures inside the vehicle
may damage the smartphone.

2104-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Display the Miracast® opera-
tion screen.
2 Check that the following
screen is displayed.
3 Using your Miracast
®-com-
patible device, perform a
Miracast
® connection opera-
tion to connect to the rear
seat entertainment system
display.
4 The screen of the Mira-
cast
®-compatible device is
displayed on the rear seat
display.
 Press the “INPUT” button to
return to the “Rear-Mira-
cast™” screen. To display the
video again, select “Mira-
cast™”.
●Depending on the device, Mira-
cast® may be displayed as
“Screen Mirroring”, “Media Out-
put”, etc.
●Miracast® streaming will stop in
the following situations:
• The Miracast
® function of the con-
nected device is turned off.
• Select “Disconnect” on the “Rear-Miracast™” screen. • The rear seat entertainment sys-
tem source is changed to a differ-
ent source. ( P.179)
Select to disconnect the
Miracast
® device.
●With Miracast®, the screen of the
Miracast®-compatible device is
sent unmodified. Therefore, if
video playback is stopped on the
device that is sending data via
Miracast
®, the video on the rear
seat display also stops.
●When Bluetooth® (Bluetooth®
audio, hands-free function or Toy-
ota Entune) is being used in the
front seats, Miracast
® cannot be
used on the rear seat display.
Connecting to the system
Miracast® operation
A

2204-9. Tips for operating rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
Media that can be used for MP3,
WMA and AAC playback:
CD-ROM/R/RW
 DVD-ROM/R/RW
Playback in some instances
may not be possible, depending
on the status of the disc. Play-
back may not be possible or the
audio may jump if the disc is
scratched or marked with finger-
prints. The following disc formats can
be used.
MP3, WMA and AAC files writ-
ten in any format other than
those listed above may not play
correctly, and their file names
and folder names may not be
displayed correctly.
Items related to standards and
limitations are as follows.

Maximum directory hierar-
chy: 8 levels
 Maximum length of folder
names/file names: The num-
ber of the maximum indication
letters by design specifica-
tions of the indication
machine side (support propor-
tional font, and there are dis-
tinction of the half size and full
size)
 Maximum number of folders:
255 (including the root)
 Maximum number of files per
disc: 512
Compati-
ble stan-
dardsMPEG2/AAC-LC,
MPEG4/AAC-LC
(ADIF is not sup-
ported)
Compati-
ble sam-
pling
frequencies
ADTS (MPEG2 AAC):
16, 22.05, 24, 32,
44.1, 48 (kHz)
MP4 (MPEG4 AAC):
16, 22.05, 24, 32,
44.1, 48 (kHz)
Compati-
ble bit rates
ADTS (MPEG2 AAC):
8 - 384 (kbps)
MP4 (MPEG4 AAC): 8
- 384 (kbps)
Compati-
ble chan-
nel mode
ADTS (MPEG2 AAC):
1/0, 2/0, 3/0, 2/1, 2/2,
3/1, 3/2.1
MP4 (MPEG4 AAC):
1/0, 2/0, 3/0, 2/1, 2/2,
3/1, 3/2.1
Compatible media
Compatible disc formats
Disc for-
matsDVD-ROM, CDROM
Mode 1, CDROM XA
Mode 2 Form 1
File formats
ISO9660 Level 1, 2, 3,
4 (Romeo, Joliet,
RockRidge), UDF
(1.02, 1.50, 2.00,
2.01)

2264-9. Tips for operating rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
When Bluetooth® (Blue-
tooth® audio, hands-free
function or Toyota Entune) is
being used in the front seats,
DLNA cannot be used on the
rear seat display.
 The mobile device functions
that can be operated differ
depending on the communi- cation environment and the
type of connected mobile
device. Depending on the
device that is used, it may not
be possible to connect to the
internet while using the DLNA
function. Refer to the instruc-
tion manual and other docu-
mentation included with the
mobile device for details.
 Blu-ray Disc™, Blu-ray™,
BD-Live™, BDXL™, and the
logos are trademarks of the
Blu-ray Disc Association.
 “AVCHD” and the “AVCHD”
logo are trademarks of Pana-
sonic Corporation and Sony
Corporation.
NOTICE
• Do not use SD cards in any
place where static electricity or
electric noise adversely affects
SD cards. This may cause data
corruption or data loss.
• Always place the SD card in its storage case when not in use.
DLNA
Compatible format
Music file
format
MP3/WMA/AAC/
FLAC /WAV/ALAC/
Ogg Vorbis ( P.219,
222)
Video file
format
MPEG-4 Video,
H.264/AVC Video
(.mp4/.m4v/.3gp/.m2ts
), MPEG-2 Video
(.mpg), Windows
Media Video (.wmv),
AVI container (.avi)
Photo file
format
JPEG (Gray scale
JPEG and Motion
JPEG are not sup-
ported.)
Pixel size
(photo)Between 1 × 1 and
8192 × 8192 pixels
Copyrights and trade-
marks
