4-2. Radio operation AM/FM/SiriusXM
® Satellite
Radio................................ 139
4-3. Media operation USB memory ...................... 150
iPod/iPhone (Apple CarPlay) ......................................... 152
Android Auto ...................... 155
Bluetooth
® audio ................ 156
4-4. Audio/visual remote controls Steering switches ............... 160
4-5. Setup Audio settings .................... 162
4-6. Tips for operating the audio/visual system
Operating information......... 165
4-7. Rear seat entertainment sys- tem
Rear seat entertainment system features ............................ 175
Some basics ...................... 176
4-8. Rear seat entertainment sys- tem operation
Playing a Blu-ray Disc™ (BD) and DVD discs ................. 184
Playing an audio CD and MP3/WMA/AAC discs ...... 194
Playing an SD card ............ 196
Using the DLNA mode........ 204
Using the Miracast
® mode . 209
Using the HDMI mode ........ 211
4-9. Tips for operating rear seat entertainment system
Operating information......... 212
5-1. Voice command system oper- ation
Voice command system ..... 244Natural language understanding
......................................... 247
Command list ..................... 248
5-2. Mobile Assistant operation Mobile Assistant ................. 253
6-1. Information display Receiving weather information......................................... 256
Data services settings ........ 258
7-1. Rear view monitor system Rear view monitor system.. 262
Rear view monitor system pre- cautions ........................... 264
Things you should know .... 269
7-2. Toyota parking assist monitor Toyota parking assist monitor......................................... 271
Estimated course line display mode ................................ 274
Parking assist guide line display mode ................................ 276
Distance guide line display mode ................................ 277
Toyota parking assist monitor precautions ...................... 277
Things you should know .... 283
7-3. Panoramic view monitor Panoramic view monitor..... 285
Checking around the vehicle ......................................... 292
Checking the front and around the vehicle........................ 294
Checking the sides of the vehicle ......................................... 297
5Voice command system
6Information
7Peripheral monitoring
system

442-2. Connectivity settings
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1.2)
• This is a profile to transfer con-tacts data.
 PBAP (Phone Book Access
Profile) Ver. 1.0 (Recom-
mended: Ver. 1.2)
• This is a profile to transfer phone-
book data.
 MAP (Message Access Pro-
file) Ver. 1.0 (Recommended:
Ver. 1.2)
• This is a profile to use phone
message functions.
 SPP (Serial Port Profile) Ver.
1.1 (Recommended: Ver. 1.2)
• This is a profile to use the Toyota
audio multimedia function.
 A2DP (Advanced Audio Dis-
tribution Profile) Ver. 1.0 (Rec-
ommended: Ver. 1.3)
• This is a profile to transmit stereo
audio or high quality sound to the
audio/visual system.
 AVRCP (Audio/Video Remote
Control Profile) Ver. 1.0 (Rec-
ommended: Ver. 1.6)
• This is a profile to allow remote
control the A/V equipment.
●This system is n ot guaranteed to
operate with all Bluetooth®
devices.
●If your cellular phone does not
support HFP, registering the Blue-
tooth
® phone or using OPP,
PBAP, MAP or SPP profiles indi-
vidually will not be possible.
●If the connect ed Bluetooth®
device version is older than rec-
ommended or incompatible, the Bluetooth
® device function may
not work properly.
●Refer to https://www.toyota.com/
audio-multimedia in the United
States,
https://www.toyota.ca/connected

in Canada, and
http://www.toyotapr.com/
audio-multimedia in Puerto Rico,
to find approved Bluetooth®
phones for this system.
●Certification
Bluetooth is a registered trademark
of Bluetooth SIG, Inc.

1604-4. Audio/visual remote controls
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4-4.Audio/visual remote controls
Some parts of the audio/visual
system can be adjusted using
the switches on the steering
wheel.Volume control switch
“MODE” switch
*1: If equipped
*2: If cached radio is enabled, press-ing and holding the “MODE”
switch pauses the broadcast.
(Press and hold again to play
back the cached radio program.)
*3: When an Apple CarPlay is estab-lished, this function will be
unavailable.
*4: When an Android Auto is estab-lished, this function will be
unavailable.
Seek switch
Steering switches
Steering switch operation
ModeOperation/function
All
Press: Volume
up/down
Press and hold (0.8
sec. or more): Volume
up/down continuously
ModeOperation/function
AM/FM/
SXM
*1
Press: Change audio
modes
Press and hold (0.8
sec. or more): Mute
*2
(Press and hold again
to resume the sound.)
A
B
86%

L3RG
L3KRQH


$QGURLG
$XWR


%OXHWRRWK
Š
DXGLR


$336


3UHVV&KDQJHDXGLR
PRGHV
3UHVVDQGKROG
VHFRUPRUH\f3DXVH
3UHVVDQGKROGDJDLQ
WRUHVXPHWKHSOD\
PRGH\f
0RGH2SHUDWLRQIXQFWLRQ
$0)0
3UHVV3UHVHWFKDQ
QHOXSGRZQ
3UHVVDQGKROG
VHFRUPRUH\f6HHN
XSGRZQ
3UHVVDQGKROG
VHFRUPRUH\f6HHN
XSGRZQFRQWLQXRXVO\
ZKLOHWKHVZLWFKLV
EHLQJSUHVVHG
0RGH2SHUDWLRQIXQFWLRQ
C

1614-4. Audio/visual remote controls
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
*1: If equipped
*2: When an Apple CarPlay is estab- lished, this function will be
unavailable.
*3: When an Android Auto is estab-lished, this function will be
unavailable.
●In the APPS mode, some opera-
tion may be done on the screen
depend on t he selected APPS.
SXM*1
Press: Preset chan-
nel up/down
Press and hold (0.8
sec. or more): Seek
for stations in the rele-
vant program
type/channel category
Press and hold (1.5
sec. or more): Fast
channel up/down
USB*2, 3,
iPod/
iPhone
*3,
Bluetooth
®
audio
*2, 3
Press: Track/file
up/down
Press and hold (0.8
sec. or more): Fast
forward/rewind
Android
Auto
*2Press: Track up/down
ModeOperation/function

1754-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
4-7.Rear seat entertainment system
*: If equipped
Rear seat entertainment system
Remote controller
HDMI input port
Front audio/visual system
●This system can use infrared wireless headphones. ( P.182)
Rear seat enter tainment system features*
The rear seat entertainment system is designed for the rear
passengers to enjoy audio/visual system.
The video played by the rear seat entertainment system is not
displayed on the front audio/visual system’s screen.
The system can be used when the engine switch switch> is in ACC or ON.
System components
A
B
C
D

1784-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Open the cover and connect
audio-video equipment to the
HDMI input port.
2 Press the “INPUT” button to
turn on the HDMI mode.
●The volume can be adjusted using
the vehicle’s audio controls. All
other operations must be made on
the audio-visual equipment itself.
For details about operation of
audio-visual equipment, refer to
the manufacturer’ s instructions.
The rear seat entertainment
system can be operated with the
remote controller. The system
cannot be operated by touching
the switches on the screen
directly.
Turning on/off the rear seat
entertainment system
Selecting a control icon
Inputting the selected control
icon
Turning on/off the speaker
output
Changing the screen size
Turning on the DLNA/Mira-
cast
®/HDMI mode
Adjusting the volume
Turning on the SD mode
Turning on the DISC mode
HDMI input port
NOTICE
●When the HDMI input port is not
i n u s e , k e e p t h e H D M I i n p u t p o r t
cover closed. Inserting any-
thing other than an appropriate
plug may cause electrical fail-
ure.
Remote controller
A
B
C
D
E
F
G
H
I

1814-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Darkens the screen
Brightens the screen
*: This function is not available depending on the screen.
1 Remove the insulating sheet.
●An insulating sheet is set to pre-
vent the batteries from being dis-
charged.
1Remove the cover. 2
Remove the depleted batter-
ies and install 2 new AA bat-
teries.
●If the remote contr oller batteries
are discharged, the following
symptoms may occur.
• The rear seat entertainment sys-
tem control will no t function prop-
erly.
• The operational range is reduced.
●When replacing the AA batteries
• Batteries can be purchased at
your Toyota dealer, electric appli-
ance shop, or camera stores.
• Replace only with the same or
equivalent type recommended by
a Toyota dealer.
• Dispose of used batteries accord-
ing to local laws.
Before using the remote
controller (for new vehicle
owners)
When the remote control-
ler batteries are fully
depleted
G
H
:$ 5 1 , 1 *
●To prevent acci dents and elec-
tric shock
• Do not disassemble or modify the remote controller.
●When the remote controller is
not used
• Stow the remote c ontroller. Inju-
ries may result i n the event of
an accident or sudden braking.

1824-7. Rear seat entertainment system
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
For the rear seat entertainment
system, aftermarket head-
phones can be used to listen to
audio.
Wireless headphones can be
used.
When using wireless head-
phones, use headphones that
comply with the following condi-
tions.
■Communication system
Infrared rays
●With some wireless headphones
generally available in the market,
it may be difficult to catch signals
properly.
Toyota recommends the use of
Toyota genuine wireless head-
phones. Please contact your Toy-
ota dealer for further details.
●When the sound volume needs to
be changed while a wireless
headphone is used, adjust the vol-
ume using the wireless head-
phone’s volume switch.
WA R N I N G
●Removed batteries and other
parts
• Keep away from children. These parts are small and if
swallowed by a child, they can
cause choking.
NOTICE
●To prevent damage to the
remote controller
• Keep the remote controller away from direct sunlight, heat
and high humidity.
• Do not drop or strike the remote controller against hard objects.
• Do not sit on or place heavy objects on the remote controller.
●For normal operation after
replacing the batteries, observe
the following precautions to pre-
vent accidents.
• Always work with dry hands. Moisture may cau se the battery
to rust.
• Do not touch or move any other components inside the remote
controller.
• Do not bend any of the battery terminals.
Using headphones
Using wireless head-
phones (sold separately)

1844-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4-8.Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the menu screen
Displaying the option screen
Changing the audio language
Selecting a chapter
Turning on the BD/DVD
mode
Playing a Blu-ray
Disc™ (BD) and DVD
discs
This system can play
Blu-ray Disc™ (BD) videos
with digital sound. In addi-
tion to commercial BD and
DVD titles, AVCHD, BDAV
videos and Video CD can be
played on this system, so
digital TV recorded by home
digital video recorders and
BD/DVD home videos
recorded by home digital
video cameras can also be
played on this system.
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
WA R N I N G
●BD/DVD video precaution
• Conversational speech on some
BDs/DVDs is recorded at a low
volume to emphasize the
impact of sound effects. If you
adjust the volume assuming
that the conversations represent
the maximum volume level that
the BD/DVD will play, you may
be startled by louder sound
effects or startled when you
change to a different audio
source. Loud sounds may have
a significant impact on the
human body or pose a driving
hazard. Keep this in mind when
you adjust the volume.
Remote controller
A
B
C
D
E
F
G
H
I
J
K

1944-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Each time “Quick Play” is
selected, “On” or “Off” can be
selected.
■Setting a sound dynamic
range
The difference between the low-
est and highest sound volumes
can be adjusted.
1 Select “Sound Dynamic
Range”.
2 Select the desired setting.
“MAX”: Maximum sound
dynamic range
“MID”: Medium sound dynamic
range
“MIN”: Minimum sound dynamic
range Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Selecting a track/file
Selecting a folder
Playing an audio CD
and MP3/WMA/AAC
discs
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
The player will start to play
the disc automatically.
Remote controller
A
B
C
D
E
F
G
