TOYOTA HIGHLANDER HYBRID 2018 (in English) User Guide

9
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
NOTE: Regularly scheduled maintenance, including oil changes, will help
extend the life of your vehicle and maintain performance. Please refer to the
“Warranty & Maintenance Guide.”
Engine oil level dipstick
Engine coolant reservoir
Windshield washer fluid tank Engine oil filler cap
Engine maintenance

10
(1)
Put the selector lever in “P.”
(2) Depress the brake pedal, and “
” will be displayed on the Multi-Information
Display.
(3) Press the “POWER” switch briefly and firmly.
(4) The “READY” light will blink. After a few seconds, when the light \
remains steady
and a beep sounds, you may begin driving.
The Hybrid Synergy Drive System utilizes a computer-controlled gasoline \
engine
and electric motor to provide the most efficient combination of power fo\
r the
vehicle. To conserve energy, when the brakes are applied the braking for\
ce
generates electricity which is then sent to the traction battery. In add\
ition, the
engine shuts off when the vehicle is stopped. The benefits are better fu\
el economy,
reduced vehicle emissions and improved performance.
NOTE: Fuel consumption and energy information of the Hybrid System are shown on the Multi-Information Display and/or navigation system
screen (if equipped).
1. Ensure tire pressures are maintained at levels specified in the Owner’s Manual.
2. Link trips to reduce engine cold starts whenever possible.
3. Avoid driving at speeds that are higher than necessary, especially on\
the highway.
4. When possible, avoid sudden stops to maximize regenerative braking en\
ergy.
5. Minimize use of the Air Conditioning.
FEATURES & OPERATIONS Hybrid Synergy Drive System
TIPS FOR IMPROVED FUEL ECONOMY
STARTING THE HYBRID SYSTEM

11
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Use Eco drive mode to help achieve low fuel consumption during trips tha\
t involve
frequent accelerating.
Use EV drive mode when driving short distances to reduce noise late at n\
ight in resi-
dential areas or to cut emissions when parking in a small garage or und\
erground car
park. *
The engine switch must be “ON” and the brake pedal depressed to sh\
ift from
Park.
Shift the shift lever to “S” position from “D” position.
+: Upshift (push and release)
-: Downshift (pull and release)
Downshifting increases power going uphill, or provides engine braking do\
wnhill. For
best fuel economy during normal driving conditions, always drive with th\
e shift lever
in the “D” position.
Park*
Reverse
Neutral
Drive
P
R
N
D
“S” mode
+
-
Hybrid transmission
EV drive mode
ECO drive mode
“S” (SEQUENTIAL) MODE

12
LockUnlock
Unlock
Lock
Set: Depress
Release: Depress again
Automatic door locks can be programmed to operate in different modes, or\
turned
OFF.
Shift position linked door locking/unlocking function
-Doors lock when shifting from Park.
-Doors unlock when shifting into Park.
Speed linked door locking function
-Doors lock when the vehicle speed goes above approximately 12 mph.
Driver’s door linked door unlocking function
-Doors unlock when the “ENGINE START STOP” switch is set to OFF and\
driver’s door is opened.
Refer to the Owner’s Manual for more details.
Clock
Press “H” for Hours and “M” for minutes to
set or change the time.
HoursMinutes
FEATURES & OPERATIONS Auto lock/unlock
Door locks
Parking brake

13
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Push
Turn
MicrophoneSteering wheel telephone controls
Volume control
End call
Bluetooth® technology allows dialing or receipt of calls without taking hands from\

the steering wheel or using a cable to connect the compatible telephone \
and
the system. Refer to “Bluetooth
® Device Pairing Section,” in this guide, for more
information about phone connections and compatibility.
* Position of buttons may vary on some vehicles, for more details please\
refer to the
Owner’s Manual.
** Push and hold to access Mobile Assistant. Once you connect a compatible,\

registered mobile phone, you can access Siri® Eyes Free using Mobile Assistant
access switch.
Refer to the Owner’s Manual and the Navigation System Owner’s Manu\
al for more
details.

NOTE: Concentrating

on the road should always be your first priority while
driving. Do not use the hands-free phone system if it will distract you.
Voice command switch
Start call/
Mobile Assistant access**
Type A
Type B
Steering lock release
Steering wheel switches
& telephone controls (Bluetooth®)*

14
SHADE OPERATIONTILTING OPERATION
SLIDING OPERATIONTILTING OPERATION
Moonroof (if equipped)
Panoramic moonroof (if equipped)
FEATURES & OPERATIONS
Tilt
Close
Recommended open position to
minimize wind noise.
Push once to open partway;
again to open completely.
If the moonroof is open, pressing the switch
closes it up to the tilt-up position.
If the shade is closed past the half-open position
when the switch is pressed, it will open up to the
half-open position.
To stop operation partway, quickly slide and
release the switch again.
Close
Open
The moonroof stops slightly before the fully open position to reduce win\
d noise
and the shade opens fully. Slide the switch again to fully open or close\
the
moonroof.
SLIDING OPERATION

15
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Power Liftgate (back door) (if equipped)
PushPush and hold
Instrument panel
Open and close
Open: Push and hold
Close: Push and hold again
NOTE: If battery is disconnected, the power back door needs to be reinitialized.
Refer to
the Owner’s Manual for more details.
Open only
1. When the liftgate reaches the desired height, push the rear liftgate \
close-button (on the door jam of the liftgate) once. Press and hold the button unti\
l the buzzer
sounds.
2. To reset the height, with the liftgate open and not moving, press and\
hold the rear liftgate close-button until it buzzes, and continue to hold until i\
t buzzes
again -then let go. Push the same button to close the liftgate. When you\
next
open the liftgate it will open to the maximum height.
3. The height can also be set through the “Setup” screen on the au\
dio display. Setup > Vehicle Customization > Other Vehicle Settings > Power Back Door\

Opening Adjust. Through this screen, there are 5 height options to choos\
e
from.
NOTE: If the liftgate has stopped operating, check inside the glove box, on
the left side, to ensure the PWR DOOR OFF button has not been pushed.
For detailed instructions, see Owner’s Manual.
PROGRAMMABLE POWER LIFTGATE
Remote
control
(with
Smartkey)

16
MANUAL SEAT
POWER SEAT AND DRIVING POSITION MEMORY (IF EQUIPPED)
Hold wheel, push lever down, set angle and length, and return lever.
Angle
Lock release lever
NOTE: Do not attempt to adjust while the vehicle is in motion.
Length
Seatback angle
Memory
position 1
Memory
position 2
Set memory
position
Seatback angle
Seat position
(forward/backward)
Seat cushion
(front) angle
(driver’s side only)
Seat height
(driver’s side only)
Seat cushion length
(if equipped,
driver’s side only) Lumbar
support
(driver’s side only)
Tilt & telescopic steering wheel
Seat adjustments-Front
FEATURES & OPERATIONS
Seat position
(forward/backward)
Height crank
(driver’s side only)

17
OVERVIEW
FEATURES & OPERATIONS
TOYOTA SAFETY SENSE
SAFETY & EMERGENCY FEATURES
Second row type 1 Second row type 2Third row seat
Refer to the Owner’s Manual for more details.
Pull
(1) Pull(2) Raise
Seat position
(forward/backward) Seat position
(forward/backward)
Seatback angle Seatback angle
adjustment straps
Seatback angle
Height Lock release button Lock release button Lock release button
FrontSecond rowThird row
Height Height
Seat adjustments-Rear
Seats-Head restraints
Seats-Stowing & returning 3rd row seats

18
Single wipeInterval wipe
Off
Push to Wash and wipe
1 Intermittent windshield wiper
frequency adjustment
Rotate to increase/decrease wipe
frequency.
2 Rain-sensing windshield wipers
Rotate to increase/decrease sensor
sensitivity. (if equipped)Temporary
operation
Rain sensing
(AUTO)Low
HighAdjust sensitivity2
Pull to wash
and wipe
Interval wipe
Mist
Slow
Fast
Adjust frequency
1
Pull to wash
and wipe
Up
Down
Automatic operation front row or all-position (if equipped)
Push the switch
completely down or pull it completely up and release to fully open or cl\
ose. To stop
the window partway, operate the switch in the opposite direction.
Window lock switch Deactivates all passenger windows. Driver’s window remains
operable.
DRIVER SIDE WINDOW LOCK SWITCH
FEATURES & OPERATIONS
Windshield wipers & washers
FRONT-INTERMITTENT
FRONT-AUTO (RAIN-SENSING) (IF EQUIPPED)
REAR
Windows-Power
