language TOYOTA HIGHLANDER HYBRID 2021 Accessories, Audio & Navigation (in English)

3 TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
4-2. Radio operation AM radio/FM radio/
SiriusXM
® Satellite
Radio(SXM) ..................... 141
4-3. Media operation USB memory ...................... 152
iPod/iPhone (Apple CarPlay)................ 154
Android Auto ...................... 157
Bluetooth
® audio ................ 158
4-4. Audio/visual remote controls Steering switches ............... 162
4-5. Setup Audio settings .................... 164
4-6. Tips for operating the audio/visual system
Operating information......... 167
4-7. Rear seat entertainment sys- tem
Rear seat entertainment system features ............................ 177
Some basics ...................... 178
4-8. Rear seat entertainment sys- tem operation
Playing a Blu-ray Disc™ (BD) and DVD discs ................. 186
Playing an audio CD and MP3/WMA/AAC discs ...... 197
Playing an SD card ............ 198
Using the DLNA mode........ 206
Using the Miracast
® mode . 211
Using the HDMI mode ........ 213
4-9. Tips for operating rear seat entertainment system
Operating information......... 2145-1. Voice command system oper-
ation
Voice command system ..... 246
Natural language understanding ......................................... 249
Command list ..................... 250
5-2. Mobile Assistant operation Mobile Assistant ................. 255
6-1. Information display Receiving weather information......................................... 258
Data services settings ........ 260
7-1. Rear view monitor system Rear view monitor system.. 264
Rear view monitor system pre- cautions ........................... 266
Things you should know .... 272
7-2. Toyota parking assist monitor Toyota parking assist monitor......................................... 274
Estimated course line display mode ................................ 277
Parking assist guide line display mode ................................ 279
Distance guide line display mode ................................ 280
Toyota parking assist monitor precautions ...................... 280
Things you should know .... 287
7-3. Panoramic view monitor Panoramic view monitor..... 289
5Voice command system
6Information
7Peripheral monitoring
system

191-1. Basic function
1
Quick guide
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
Leave the Bluetooth® phone in a
place where the condition of the
Bluetooth
® connection is good.
Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.
Audio/Audio Plus
Select to change the selected
language, operation sound
settings, etc. ( P.67)
Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P.45)
Select to set audio settings.
( P.164)
Select to set the phone
sound, contacts, message
settings, etc. ( P.351)
Select to set the voice set-
IndicatorsConditions
(Blue)
Indicates that the con-
dition of the Blue-
tooth
® connection is
good.
(Gray)
While in this condition,
sound quality during
phone calls may dete-
riorate.
Indicates that the cel-
lular phone is not con-
nected via Bluetooth
®.
“Setup” screen
“Setup” screen
A
B
C
D
E

201-1. Basic function
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
tings. (P.72)
Select to set vehicle informa-
tion. ( P. 7 3 )
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P.54)
Select to set Toyota apps set-
tings.
*2 (  P.384)
*1: Vehicles with DCM
*2: This function is not available in
some countries or areas.
Premium Audio/12.3-inch dis-
play model
Select to change the selected
language, operation sound
settings, etc. ( P. 6 7 ) Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P.45)
Select to set audio settings.
( P.164)
Select to set the phone
sound, contacts, message
settings, etc. ( P.351)
Select to set the voice set-
tings. ( P.72)
Select to set vehicle informa-
tion such as maintenance
information. ( P.73)
Select to set memory points
(home, favorites entries,
areas to avoid), or naviga-
tion details. ( P. 1 1 4 )
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P. 5 4 )
Select to set Toyota apps set-
tings.
*2 (  P.384)
Select to set traffic informa-
tion settings.
*2 (  P.123)
Select to set data services
settings.
*2 (  P.260)
*1: Vehicles with DCM
*2: This function is not available in
some countries or areas.
F
G
H
A
B
C
D
E
F
G
H
I
J
K

672-4. Other settings
2
Basic function
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
2-4.Other settings
1Press the “MENU” button.
8-inch display model
12.3-inch display model
2 Select “Setup”.
 If the general settings screen
is not displayed, select “Gen-
eral”. 3
Select the desired items to
be set.
 “Clock”
Select to change the time zone and
select “On” or “Off” or “Auto”
*1 for
daylight saving time, automatic
adjustment of the clock, etc.
(  P. 6 9 )
 “Language”
Select to change the language. The
language setting of Apple CarPlay/
Android Auto can only be changed
on the connected device.
“Customize Home Screen”
Select to change the display infor-
mation/area on the home screen
and the home screen layout.
( P. 3 3 )
 “Projection Settings”*2
Select to set automatic Apple Car-
Play/Android Auto connection
establishment on/off. ( P.70)
 “Beep”
Select to turn the beep sound
on/off.
“Theme Setting”
Select to change the screen theme
setting.
General settings
Settings are available for
clock, operation sounds,
etc.
Displaying the general
settings screen
General settings screen

702-4. Other settings
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
*: This function is not available in some countries or areas.
1 Display the general settings
screen. ( P.67)
2 Select “Projection Settings”.
3 Select the desired items to
be set.
Select to turn Apple CarPlay
connection establishment
on/off when a compatible
iPhone is connected to the
system via USB. ( P.59)
Depending on the system,
this setting cannot be
changed when a device is
connected to the system via
USB. Disconnect the device
before attempting to change
the setting.
Select to turn Android Auto
connection establishment
on/off when a compatible
device is connected to the
system via USB. ( P.60)
Depending on the system,
this setting cannot be
changed when a device is
connected to the system via
USB. Disconnect the device before attempting to change
the setting.
The driver settings feature will
allow the system to link some
preferences (such as audio pre-
sets, screen theme, language,
etc.) to a paired Bluetooth
®
phone.
1 Display the general settings
screen. ( P. 6 7 )
2 Select “Driver Setting”.
3 Select “Enable This Feature”.
Projection settings
*
A
B
'ULYHUVHWWLQJV

1864-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
4-8.Rear seat entertainment system operation
Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the menu screen
Displaying the option screen
Changing the audio language
Selecting a chapter
Turning on the BD/DVD
mode
Playing a Blu-ray
Disc™ (BD) and DVD
discs
This system can play
Blu-ray Disc™ (BD) videos
with digital sound. In addi-
tion to commercial BD and
DVD titles, AVCHD, BDAV
videos and Video CD can be
played on this system, so
digital TV recorded by home
digital video recorders and
BD/DVD home videos
recorded by home digital
video cameras can also be
played on this system.
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
WA R N I N G
●BD/DVD video precaution
• Conversational speech on some
BDs/DVDs is recorded at a low
volume to emphasize the
impact of sound effects. If you
adjust the volume assuming
that the conversations represent
the maximum volume level that
the BD/DVD will play, you may
be startled by louder sound
effects or startled when you
change to a different audio
source. Loud sounds may have
a significant impact on the
human body or pose a driving
hazard. Keep this in mind when
you adjust the volume.
Remote controller
A
B
C
D
E
F
G
H
I
J
K

1894-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
mined scene
Changing the audio language
Changing the subtitle lan-
guage
Changing the angle
Displaying the color key but-
tons
Displaying the 10 key pad
Displaying the secondary
video (Picture-in-picture)
Changing the secondary
audio
Displaying the menu screen
Changing the playback mode
Changing the audio channel
Searching by track
Returning to the previous
page screen (with the disc
menu displayed)
Proceeding to the next page
screen (with the disc menu
displayed)
BD video
Some BD video discs have a
pop-up navigation menu that
can be called up and be oper-
ated on the screen without inter-
rupting playback.
1 Select “Pop-up Menu”.
2 Select the menu item, and
press the “ENT” button to
enter.
BD video, DVD video,
AVCHD, BDAV
1 Select “Title”, “Chapter” or
“Search”.
2 Input the title number or
chapter number, and select
“OK”.
BD video, DVD video, BDAV
The angle can be changed for
discs that are multi-angle com-
patible when the angle mark
appears on the screen.
1 Select “Angle”.
2 Each time “Angle” is
selected, the angle changes.
Displaying the pop-up menu
L
M
N
O
P
Q
R
S
T
U
V
W
X
6HDUFKLQJIRUDWL\
WOHRUFKDS
WHU
&KDQJLQJWKHDQJOH

1904-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
BD video, DVD video, AVCHD
The subtitle language can be
changed for discs with multiple
subtitle languages.
1 Select “Subtitle”.
2 Each time “Subtitle” is
selected, another language
available on the disc is
selected.
“Hide”: Subtitle can be hidden.
BD video
“Style”: Subtitle style can be
changed.
BD video, DVD video,
AVCHD, BDAV
The audio language can be
changed for discs with multiple
audio languages.
1 Select “Audio”.
2 Each time “Audio” is
selected, another language
available on the disc is
selected.
BDAV, Video CD
The audio channel can be
changed for discs with multiple
audio channels.
1 Each time “Main/Sub” is
selected, the mode changes
in the following order:
“Main”: Main audio channel
Changing the subtitle lan-
guage
Changing the audio lan-
guage
Changing the audio channel

1944-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
Changing the initial audio
language
Changing the initial subtitle
language
Changing the initial lan-
guage of the disc menu
Setting the angle mark
Setting the DVD parental
control level
Setting the BD parental con-
trol age
Setting a quick playback
Setting a sound dynamic
range
Restores default settings
BD history data such as
bookmarks and resume point
can be deleted.
 Select or to show the
next or previous page.
■Changing the initial audio
language
1 Select “Audio Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.218)
■Changing the initial subtitle
language
1 Select “Subtitle Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.218)
■Changing the initial lan-
guage of the disc menu
1 Select “Menu Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.218)
■Setting the angle mark
If the BD/DVD disc has angle
options, you can turn the angle
mark on/off.
A
B
C
D
E
F
G
H
I
J

2034-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
MovieTurning off the option screen
Displaying the detail informa-
tion
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Changing the playback mode
Changing the audio channel
Displaying the top menu
screen
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage 1
Select “Detailed Information”.
2 Detail informations of the
video are displayed.
SD video
SD AVCHD
Movie
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Displaying the detail infor-
mations of the video
